Acura TLX (2019 year). Manual - part 24

uu

When Driving

u

Shifting

374

Driving

■

If you want to keep the transmission in

(

N position [car wash mode]

With the engine running:
1. Press and hold the brake pedal.
2. Select

(

N, then release the button to display

(

N (Neutral) hold mode on the

multi-information display.

3. Press and hold

(

N again for two seconds.

u

This puts the vehicle in car wash mode which must be used when your vehicle
is pulled through a conveyor type automatic car wash where you or an
attendant do not remain in the vehicle.

If the ENGINE START/STOP button is pressed
after car wash mode has been activated, the
power mode will change to ACCESSORY and
a message will be displayed on the multi-
information display.

u

The gear position remains in

(

N with the

power mode in ACCESSORY for 15
minutes, then, it automatically changes
to

(

P and the power mode changes to

OFF.

u

Manually changing to

(

P cancels

ACCESSORY mode. The

(

P indicator

comes on and the power mode changes
to OFF. You must always shift to

(

P

when car wash mode is no longer
needed.

1

If you want to keep the transmission in

(

N position [car wash

mode]

To keep the vehicle in

(

N position, you can also

follow this procedure:
While the power mode is on, select

(

N, and then

within five seconds, press the ENGINE START/STOP
button.

The transmission may not stay in

(

N position while

the following indicators are on or when the message
below appears:

•

Malfunction indicator lamp

•

Transmission system indicator

•

Charging system indicator

•

The Charging System Problem message on the
multi-information display.

19 ACURA TLX-31TZ36400.book  374 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

375

uu

When Driving

u

Shifting

Continued

Driving

■

Restriction on selecting a gear position

You cannot select a gear position under certain circumstances that may lead to a crash.

When the
transmission is in:

1. Under the circumstances
of that:

2. You cannot select:

3. The gear position
remains in/changes to:

How to change the
gear position

(

P

The brake pedal is not
depressed.

Other gear position

(

P

Release the accelerator
pedal and depress the
brake pedal.

The accelerator pedal is
depressed.

(

N

The vehicle is moving at low
speed without the brake pedal
depressed.

(

N

The vehicle is moving at low
speed with the accelerator
pedal depressed.

(

N

 or (

D

The vehicle is moving forward.

(

R

Stop your vehicle in a
safe place, depress the
brake pedal, and select
the appropriate gear
position.

(

R

 or (

N

The vehicle is moving backward.

(

D

(

R

, (

N

, or (

D

The vehicle is moving.

(

P

19 ACURA TLX-31TZ36400.book  375 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

376

uu

When Driving

u

Shifting

Driving

Use the paddle shifters to change between 1st and 9th gears without releasing your
hands from the steering wheel. The transmission will switch to the sequential mode.

■

When the transmission is in

(

D:

The vehicle will go into the sequential mode momentarily, and the sequential mode
gear selection indicator will come on.
When the vehicle goes into the sequential mode by

(

- paddle shifter and the lower

gear is available, the transmission properly selects single or double gear change.
Once you start traveling at a constant speed, the sequential mode will automatically
switch off, and the sequential mode gear selection indicator will go off.

Hold the

(

+ paddle shifter for two seconds or push the

(

D button to return to

normal drive.

■

When the transmission is in

(

D with Sport+ mode:

The vehicle will go into the sequential mode, and the M (sequential mode) indicator
and sequential mode gear selection indicator will come on.
If the vehicle speed increases and the engine speed reaches near the tachometer’s
red zone, the transmission automatically shifts up to the next gear.
You can cancel this mode by pressing Dynamic Mode button to select other than
Sport+ mode or push the

(

D button to return to normal drive Sport+ mode. When

the sequential mode is canceled, the sequential mode indicator and sequential
mode gear selection indicator will turn off.

■

Sequential Mode

19 ACURA TLX-31TZ36400.book  376 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

377

uu

When Driving

u

Shifting

Driving

■

Sequential Mode Operation

1

Sequential Mode Operation

Each paddle shift operation makes a single gear
change.
To change gears continuously, release the paddle
shifter before pulling it again for the next gear.

If the sequential mode gear selection indicator blinks
when you try to shift up or down, this means your
vehicle speed is not in its allowable gear range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

Downshifting when pulling
the

 paddle shifter.

(Changes to a lower gear)

Upshifting when pulling
the

 paddle shifter.

(Changes to a higher gear)

Paddle Shifter
(Shift down)

Paddle Shifter
(Shift up)

19 ACURA TLX-31TZ36400.book  377 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

378

uu

When Driving

u

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift lever positions

Models with shift lever

1

Shift lever positions

You cannot change the power mode from ON to
VEHICLE OFF (LOCK) unless the shift lever is in

(

P.

The vehicle may move very slightly even in

(

N while

the engine is cold.
Depress the brake pedal firmly and, when necessary,
apply the parking brake.

When shifting gears in extremely low temperatures
(-22°F/-30°C), there may be a short delay before the
shift is indicated in the display. Always confirm you
are in the correct gear before driving.

Park
Used when parking or starting the engine

Reverse
Used when reversing

Neutral
Transmission is not locked

Drive
Used for:

●

Normal driving (gears change between 1st
and 8th automatically)

●

Temporarily driving in the sequential shift
mode

●

Driving in the sequential shift mode (when
driving in Sport+ mode)

Release Button

19 ACURA TLX-31TZ36400.book  378 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

Continued

379

uu

When Driving

u

Shifting

Driving

■

Shift Lever Operation

1

Shift Lever Operation

NOTICE

When you change the shift lever from

(

D to

(

R and

vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the shift lever position indicator to check the
lever position before pulling away.

Whichever position the shift lever is in when driving,
a blinking transmission system indicator indicates a
transmission problem.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer’s red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

When the engine speed is increased while the shift
lever is in

(

N,

(

P or

(

R, the fuel supply may be cut

off even without the engine speed entering the
tachometer’s red zone.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

Shift Lever Position Indicator
(transmission system indicator)

Depress the brake pedal
and press the shift lever
release button to shift.

Shift without pressing the
shift lever release button.

Press the shift lever
release button and
shift.

Tachometer’s red zone

M (sequential mode) Indicator

Sequential Mode Gear
Selection Indicator

19 ACURA TLX-31TZ36400.book  379 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

380

uu

When Driving

u

Shifting

Driving

Use the paddle shifters to change between 1st and 8th gears without releasing your
hands from the steering wheel. The transmission will switch to the sequential shift
mode.

■

When the shift lever is in

(

D:

The vehicle will go into the sequential shift mode momentarily, and the sequential
mode gear selection indicator will come on.
Once you start traveling at a constant speed, the sequential shift mode will
automatically switch off, and the sequential mode gear selection indicator will go
off.

Hold the

(

+ paddle shifter for two seconds to return to normal drive.

■

When the shift lever is in

(

D with Sport+ mode:

The vehicle goes into sequential shift mode and the M (sequential shift) indicator
comes on. At speeds of 2 mph (4 km/h) or less, the vehicle automatically shifts down
into 1st gear.
If you are in 1st through 6th gears and do not operate the paddle shifters as engine
speed increases approaches the tachometer red zone, the transmission
automatically shifts up to the next gear.
You can cancel Sport+ mode by either:
• Pressing the Dynamic Mode button.
• Or holding the

(

+ paddle shifter for two seconds.

When the mode is canceled the sequential mode and sequential mode gear
indicators will turn off.

■

Sequential Shift Mode

19 ACURA TLX-31TZ36400.book  380 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

381

uu

When Driving

u

Shifting

Driving

■

Second gear lock mode

If you pull the

(

+ paddle shifter while stopped or driving at 6 mph (10 km/h) or less,

the gear position will be locked in 2nd gear. This makes it easier to pull away on
slippery surfaces such as snow covered roads.

To cancel the 2nd gear lock mode, pull the

(

- paddle shifter.

■

Sequential Shift Mode Operation

1

Sequential Shift Mode Operation

Each paddle shift operation makes a single gear
change.
To change gears continuously, release the paddle
shifter before pulling it again for the next gear.

If the sequential mode gear selection indicator blinks
when you try to shift up or down, this means your
vehicle speed is not in its allowable gear range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

Downshifting when pulling
the

 paddle shifter.

(Changes to a lower gear)

Upshifting when pulling
the

 paddle shifter.

(Changes to a higher gear)

Paddle Shifter
(Shift down)

Paddle Shifter
(Shift up)

19 ACURA TLX-31TZ36400.book  381 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

382

uu

When Driving

u

Auto Idle Stop

*

Driving

Auto Idle Stop

*

To help maximize fuel economy, the engine automatically stops when the vehicle
comes to a stop, depending on environmental and vehicle operating conditions. The
indicator (green) comes on.

The engine then restarts once the vehicle is
about to move again, or depending on
environmental and vehicle conditions, and the
indicator (green) goes off.

2 The Engine Automatically Restarts When:

P. 386

A message associated with Auto Idle Stop
appears on the multi-information display.

2 Indicators P. 89
2 Customized Features P. 124, 301

If the driver’s door is opened while the
indicator (green) comes on, a buzzer sounds
to notify you that the Auto Idle Stop function
is in operation.

1

Auto Idle Stop

*

The 12-volt battery installed in this vehicle is
specifically designed for a model with Auto Idle Stop.
Using a 12-volt battery other than this specified type
may shorten the battery life, and prevent Auto Idle
Stop from activating. If you need to replace the
battery, make sure to select the specified type. Ask a
dealer for more details.

The duration of the Auto Idle Stop operation:

•

Increase in the ECON mode, compared to when
the ECON mode is off, with climate control in use.

Auto Idle Stop
Indicator (Green)

* Not available on all models

19 ACURA TLX-31TZ36400.book  382 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

Continued

383

uu

When Driving

u

Auto Idle Stop

*

Driving

To turn the Auto Idle Stop system off, press
this button. The Auto Idle Stop system stops.

u

Auto Idle Stop system will stop and the
Indicator (amber) will come on.

The Auto Idle Stop system is turned on every
time you start the engine, even if you turned it
off the last time you drove the vehicle.

■

Auto Idle Stop System ON/OFF

1

Auto Idle Stop System ON/OFF

Pressing the Auto Idle Stop OFF button restarts the
engine during the Auto Idle Stop activated.

Auto Idle Stop System
Indicator (Amber)

19 ACURA TLX-31TZ36400.book  383 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

When Driving

u

Auto Idle Stop

*

384

Driving

The vehicle stops with the gear position in

(

D and the brake pedal depressed.

■

Auto Idle Stop does not activate when:

• The Auto Idle Stop OFF button is pressed.
• The driver’s seat belt is not fastened.
• The engine coolant temperature is low or high.
• The transmission fluid temperature is low or high.
• The vehicle comes to a stop again before the vehicle speed reaches 3 mph (5

km/h) after the engine starts.

• Stopped on a steep incline.
• The transmission is in a position other than

(

D or Sport+.

• The engine is started with the hood open.

u

Turn off the engine. Close the hood before you restart the engine to activate
Auto Idle Stop.

• The battery charge is low.
• The internal temperature of the battery is 14°F (−10°C) or less.
• The climate control system is in use, and the outside temperature is below −4°F

(−20°C) or over 104°F (40°C).

• The climate control system is in use, and the temperature is set to Hi or Lo.
•

 is ON (indicator on).

■

Auto Idle Stop Activates When:

1

Auto Idle Stop Activates When:

When ACC with LSF is in operation, the vehicle stops
without depressing the brake pedal and Auto Idle
Stop may activate.

Do not open the hood while the Auto Idle Stop
function is activated. If the hood is opened, the
engine will not restart automatically.

In this case, restart the engine with the ENGINE
START/STOP button.

2 Starting the Engine P. 362

Pressing the ENGINE START/STOP button changes
the power mode to ACCESSORY even while Auto Idle
Stop is in operation. Once in ACCESSORY, the engine
no longer restarts automatically. Follow the standard
procedure to start the engine.

2 Starting the Engine P. 362

19 ACURA TLX-31TZ36400.book  384 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

385

uu

When Driving

u

Auto Idle Stop

*

Continued

Driving

■

Auto Idle Stop may not activate when:

• The vehicle is stopped by braking suddenly.
• The steering wheel is operated.
• The fan speed is high.
• Altitude is high.
• The vehicle is repeatedly accelerated and decelerated at a low speed.
• The climate control system is in use, and there is a significant difference between

the set temperature and the actual interior temperature.

• Humidity in the interior is high.

19 ACURA TLX-31TZ36400.book  385 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

When Driving

u

Auto Idle Stop

*

386

Driving

• The brake pedal is released (without the automatic brake hold system activated).
• The accelerator pedal is depressed (with the automatic brake hold system

activated).

2 Automatic Brake Hold P. 432

■

The engine restarts even if the brake pedal is depressed

*1

 when:

• The Auto Idle Stop OFF button is pressed.
• A steering wheel is operated.
• The transmission is in a position other than

(

D or Sport+.

• The pressure on the brake pedal is reduced and the vehicle starts moving while

stopped on an incline.

• The pressure on the brake pedal is repeatedly applied and released slightly during

a stop.

• The battery charge becomes low.
• The accelerator pedal is depressed.
• The driver’s seat belt is unlatched.
•

 is ON (indicator on).

• The climate control system is in use, and the difference between the set

temperature and actual interior temperature becomes significant.

• The climate control system is being used to dehumidify the interior.
• The vehicle ahead of you starts again when your vehicle stops automatically with

ACC with LSF.

Briefly keeps the brake applied after releasing the brake pedal to restart the engine.
This can keep your vehicle from unexpectedly moving while on an incline.

■

The Engine Automatically Restarts When:

■

Starting Assist Brake Function

1

The Engine Automatically Restarts When:

If you are using an electronic device during Auto Idle
Stop, the device may temporarily be turned off when
the engine restarts.

1

The engine restarts even if the brake pedal is depressed

*1

 when:

*1: With the automatic brake hold system activated,
you can release the brake pedal during Auto Idle Stop
is in operation.
However, if the automatic brake hold system has
been turned off, or if there is a problem with the
system, the engine will restart automatically when
you release the brake pedal.

2 Automatic Brake Hold P. 432

19 ACURA TLX-31TZ36400.book  386 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

387

uu

When Driving

u

Integrated Dynamics System

Driving

Integrated Dynamics System

Modifies the dynamic character of the vehicle. There are four modes to select from: Econ, Normal, Sport, and Sport+.
Press the Dynamic Mode button to select a mode. The mode you have selected appears on the multi-information display.
You can customize the mode default setting using the multi-information display.

2 Customized Features P. 120, 292

When you restart the engine with Sport+ mode, the mode is changed to Sport automatically.

Dynamic Mode Button

Econ (Econ mode)
Maximizes fuel economy.

Normal (Normal mode)
Provides the best balance of fuel economy and sportiness for
everyday driving.

Sport (Sport mode)
Enhances vehicle response and feel with decreased steering
assist. Also increases throttle response and SH-AWD

*

 control.

Sport+ (Sport+ mode)
Adds to Sport mode to allow for increase performance when
using the steering wheel paddle shifters.

* Not available on all models

19 ACURA TLX-31TZ36400.book  387 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

388

uu

When Driving

u

Front Sensor Camera

Driving

Front Sensor Camera

The camera, used in systems such as LKAS, RDM, ACC with LSF, CMBS

TM

, and auto

high-beam, is designed to detect an object that triggers any of the systems to
operate its functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

1

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, hood, or front grill that could obstruct
the camera’s field of vision and cause the system to
operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Acura replacement windshield. Making even
minor repairs within the camera’s field of vision or
installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor
Camera

19 ACURA TLX-31TZ36400.book  388 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

389

uu

When Driving

u

Front Sensor Camera

Driving

1

Front Sensor Camera

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

19 ACURA TLX-31TZ36400.book  389 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分
