485

uu

AcuraWatch

TM

u

Radar Sensor

Driving

Radar Sensor

The radar sensor is behind the emblem.

1

Radar Sensor

Avoid strong impacts to the radar sensor cover.

For the CMBS

TM

 to work properly:

•

Always keep the radar sensor cover clean.

•

Never use chemical solvents or polishing powder
for cleaning the sensor cover. Clean it with water
or a mild detergent.

•

Do not put a sticker on the radar sensor cover or
replace the radar sensor cover.

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by using the CMBS

TM



off button and take your vehicle to a dealer.

2 CMBS

TM

 On and Off P. 449

If the vehicle is involved in any of the following
situations, the radar sensor may not work properly.
Have your vehicle checked by a dealer:

•

Your vehicle is involved in a frontal collision

•

Your vehicle drives through deep water or is
submerged in deep water

•

Your vehicle strongly strikes a bump, curb, chock,
or embankment that could jar the radar sensor

Radar
Sensor

The radar sensor is
behind the emblem.

19 ACURA RDX-31TJB6000.book  485 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

486

Driving

Braking

Brake System

Use the parking brake to keep the vehicle stationary when parked. When the
parking brake is applied, you can manually or automatically release it.

■

To apply

The electric parking brake can be applied any
time the vehicle has battery, no matter which
position the power mode is in.

Press the electric parking brake switch gently
and securely.

u

The indicator in the switch comes on.

u

The Parking Brake and Brake System
indicator (red) comes on.

■

Parking Brake

1

Brake System

When you depress the brake pedal, you may hear a
whirring sound coming from the engine
compartment while the brake system activates. This is
normal.

1

Parking Brake

You may hear the electric parking brake system
motor operating from the rear wheel area when you
apply or release the parking brake. This is normal.

The brake pedal may slightly move due to the electric
parking brake system operation when you apply or
release the parking brake. This is normal.

You cannot apply or release the parking brake if the
battery goes dead.

2 Jump Starting P. 604

If you press and hold the electric parking brake
switch while driving, the brakes on all four
wheels are applied by the VSA® system until the
vehicle comes to a stop. The electric parking
brake then applies, and the switch should be
released.

Electric Parking
Brake Switch

19 ACURA RDX-31TJB6000.book  486 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

487

uu

Braking

u

Brake System

Driving

■

Automatic parking brake feature operation

If the automatic parking brake feature has been activated:
• The parking brake is applied automatically when you set the power mode to

VEHICLE OFF.

• To confirm that the parking brake is applied, check if the Parking Brake and Brake

System indicator (red) is on.

2 Activating and deactivating the automatic parking brake feature P. 489

■

To release

The power mode must be in ON in order to
release the electric parking brake.
1. Depress the brake pedal.
2. Pull the electric parking brake switch up

gently and securely.

u

The indicator in the switch goes off.

u

The Parking Brake and Brake System
indicator (red) goes off.

Manually releasing the parking brake using
the switch helps your vehicle start slowly and
smoothly when facing down hill on steep hills.

1

Parking Brake

In the following situations, the parking brake
automatically operates.

•

When the vehicle stops more than 10 minutes
while ACC with LSF is activated.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped automatically by ACC with
LSF.

•

When the engine is turned off, except by Auto Idle
Stop system, while ACC with LSF is activated.

•

When the vehicle stops with the automatic brake
hold system activated for more than 10 minutes.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped and brake hold is applied.

•

When the engine is turned off, except by Auto Idle
Stop system, while brake hold system is applied.

•

When there is a problem with the automatic brake
hold system while Brake Hold is applied.

Electric Parking
Brake Switch

19 ACURA RDX-31TJB6000.book  487 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Braking

u

Brake System

488

Driving

■

To release automatically

Depressing the accelerator pedal releases the parking brake.
Use the accelerator pedal to release the brake when you are starting the vehicle
facing uphill, or in a traffic jam.

Gently depress the accelerator pedal.
When on a hill, it may require more
accelerator input to release.

u

The Parking Brake and Brake System
indicator (red) goes off.

You can release the parking brake automatically when:
• You are wearing the driver’s seat belt.
• The engine is running.
• The transmission is not in

(

P or

(

N.

1

Parking Brake

If the parking brake cannot be released
automatically, release it manually.

When the vehicle is traveling uphill, the accelerator
pedal may need to be pressed farther to
automatically release the electric parking brake.

The parking brake cannot be released automatically
while the following indicators are on:

•

Malfunction indicator lamp

•

Transmission system indicator

The parking brake may not be released automatically
while the following indicators are on:

•

Electric parking brake system indicator

•

VSA® system indicator

•

ABS indicator

•

Supplemental restraint system indicator

Accelerator Pedal

19 ACURA RDX-31TJB6000.book  488 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

489

uu

Braking

u

Brake System

Driving

■

Activating and deactivating the automatic parking brake feature

With the power mode is in ON, carry out the following steps to either activate or
deactivate the automatic parking brake feature.
1. Put the transmission into

(

P.

2. Without depressing the brake pedal, press and release the parking brake switch.

u

Check that the Parking Brake and Brake System indicator (red) has come on.

3. Press and hold the parking brake switch. When you hear a beeping sound, release

the switch and within 3 seconds pull up and hold the switch again.

4. When you hear a sound indicating that the procedure is completed, release the

switch.

u

Two beeps indicates that the feature has been activated.

u

One beep indicates that the feature has been deactivated.

u

When you have completed activating the feature, the parking brake will
remain applied after you turn off the engine.

u

To confirm that the parking brake is applied, check if the Parking Brake and
Brake System indicator (red) is on.

If you need to temporarily deactivate the feature for when putting your vehicle
through a conveyor type car wash, you can follow the procedure explained below.
1. Depress the brake pedal and bring the vehicle to a stop.
2. Set the power mode to VEHICLE OFF and then within 2 seconds pull up the

parking brake switch.

u

Activation and deactivation settings for the feature will not be affected.

u

Before temporarily deactivating the feature, make sure to first turn off both
ACC with LSF and the automatic brake hold system.

u

To confirm that the parking brake is applied, check if the Parking Brake and
Brake System indicator (red) is on.

1

Parking Brake

In cold climates, the parking brake may freeze in
place if applied.

When parking the vehicle, chock the wheels and
make sure the automatic parking brake feature is
deactivated.

Also, when putting your vehicle through a conveyor-
type car wash or when having your vehicle towed,
deactivate the automatic parking brake feature and
leave the parking brake released.

19 ACURA RDX-31TJB6000.book  489 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Braking

u

Brake System

490

Driving

Your vehicle is equipped with disc brakes at all four wheels. The brake assist system
increases the stopping force when you depress the brake pedal hard in an
emergency situation. The anti-lock brake system (ABS) helps you retain steering
control when braking very hard.

2 Brake Assist System P. 494
2 Anti-lock Brake System (ABS) P. 493

■

Foot Brake

1

Foot Brake

Check the brakes after driving through deep water,
or if there is a buildup of road surface water. If
necessary, dry the brakes by lightly depressing the
pedal several times.

If you hear a continuous metallic friction sound when
applying the brakes, this is caused by the brake wear
indicator rubbing on the brake rotor and indicates
that the brake pads need to be replaced. Have the
vehicle checked by a dealer. If you hear only an
occasional squeak or squeal when you initially apply
the brake pedal, this may be normal and caused by
high frequency vibration of the brake pads against
the rotating brake disc.

Constantly using the brake pedal while going down a
long hill builds up heat, which reduces the brake
effectiveness. Apply engine braking by taking your
foot off the accelerator pedal and downshifting to a
lower gear.

Do not rest your foot on the brake pedal while
driving, as it will lightly apply the brakes and cause
them to lose effectiveness over time and reduce pad
life. It will also confuse drivers behind you.

Whenever the brakes are activated by CMBS

TM

 or

another system that automatically controls braking,
the brake pedal is depressed and released in
accordance with braking function.

19 ACURA RDX-31TJB6000.book  490 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

491

uu

Braking

u

Brake System

Driving

Keeps the brake applied after releasing the brake pedal until the accelerator pedal is
pressed. You can use this system while the vehicle is temporarily stopped, like at
traffic lights and in heavy traffic.

■

Automatic Brake Hold

1

Automatic Brake Hold

3

WARNING

Activating the automatic brake hold system
on steep hills or slippery roads may still
allow the vehicle to move if you remove
your foot from the brake pedal.

If a vehicle unexpectedly moves, it may
cause a crash resulting in serious injury or
death.

Never activate the automatic brake hold
system or rely on it to keep a vehicle from
moving when stopped on a steep hill or
slippery roads.

3

WARNING

Using the automatic brake hold system to
park the vehicle may result in the vehicle
unexpectedly moving.

If a vehicle moves unexpectedly, it may
cause a crash, resulting in serious injury or
death.

Never leave the vehicle when braking is
temporarily kept by automatic brake hold
and always park the vehicle by putting the
transmission in

(

P

 and applying the parking

brake.

■

Turning on the system

Fasten your seat belt
properly, then start the
engine. Press the
automatic brake hold
button.

●

The automatic brake
hold system indicator
comes on. The system
is turned on.

■

Activating the system

Depress the brake pedal
to come to a complete
stop. The transmission
must be in

(

D,

(

S or

(

N.

●

The automatic brake
hold indicator comes
on. Braking is kept for
up to 10 minutes.

●

Release the brake
pedal after the
automatic brake hold
indicator comes on.

■

Canceling the system

Depress the accelerator
pedal while the
transmission is in

(

D or

(

S. The system is

canceled and the vehicle
starts to move.

●

The automatic brake
hold indicator goes
off. The system
continues to be on.

Accelerator Pedal

Brake Pedal

Automatic Brake
Hold Button

Goes
Off

Comes
On

On

On

Comes
On

Comes
On

U.S.

Canada

19 ACURA RDX-31TJB6000.book  491 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Braking

u

Brake System

492

Driving

■

The system automatically cancels when:

• You depress the brake pedal and change to

(

P or

(

R.

• You engage the parking brake.

■

The system automatically cancels and the parking brake is applied when:

• Braking is kept for more than 10 minutes.
• The driver’s seat belt is unfastened.
• The engine is turned off.
• Brake Hold System Problem. Apply Brake When Stopped. See Your

Dealer. appears on the multi-information display.

• There is a problem with automatic brake hold system.

■

Turning off the automatic brake hold system

While the system is on, press the automatic
brake hold button again.

u

The automatic brake hold system
indicator goes off.

If you want to turn off automatic brake hold
while the system is in operation, press the
automatic brake hold button with the brake
pedal depressed.

1

Automatic Brake Hold

While the system is activated, you can turn off the
engine or park the vehicle through the same
procedure as you normally do.

2 When Stopped P. 495

Whether the system is on, or the system is activated,
the automatic brake hold turns off once the engine is
off.

1

Turning off the automatic brake hold system

Make sure to turn off the automatic brake hold
system before using an automated car wash.

You may hear an operating noise if the vehicle moves
while the automatic brake hold system is in
operation.

Automatic Brake
Hold Button

Goes
Off

19 ACURA RDX-31TJB6000.book  492 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

493

uu

Braking

u

Anti-lock Brake System (ABS)

Driving

Anti-lock Brake System (ABS)

Helps prevent the wheels from locking up, and helps you retain steering control by
pumping the brakes rapidly, much faster than you.

The electronic brake distribution (EBD) system, which is part of the ABS, also
balances the front-to-rear braking distribution according to vehicle loading.

You should never pump the brake pedal. Let the ABS work for you by always
keeping firm, steady pressure on the brake pedal. This is sometimes referred to as
“stomp and steer.”

■

ABS operation

The brake pedal may pulsate slightly when the ABS is working. Depress the brake
pedal and keep holding the pedal firmly down. On dry pavement, you will need to
press on the brake pedal very hard before the ABS activates. However, you may feel
the ABS activate immediately if you are trying to stop on snow or ice.

ABS may activate when you depress the brake pedal when driving on:
• Wet or snow covered roads.
• Roads paved with stone.
• Roads with uneven surfaces, such as potholes, cracks, manholes, etc.

When the vehicle speed goes under 6 mph (10 km/h), the ABS stops.

■

ABS

1

Anti-lock Brake System (ABS)

NOTICE

The ABS may not function correctly if you use a tire of
the wrong size or type.

If the ABS indicator comes on while driving, there
may be a problem with the system.
While normal braking will not be affected, there is a
possibility that the ABS will not be operating. Have
your vehicle checked by a dealer immediately.

The ABS is not designed for the purpose of reducing
the time or distance it takes for a vehicle to stop: It is
designed to limit brake lockup which can lead to
skidding and loss of steering control.

In the following cases, your vehicle may need more
distance to stop than a vehicle without the ABS:

•

You are driving on rough or uneven road surfaces,
such as gravel or snow.

•

The tires are equipped with tire chains.

The following may be observed with the ABS system:

•

Motor sounds coming from the engine
compartment when the brakes are applied, or
when system checks are being performed after the
engine has been started and while the vehicle
accelerates.

•

Brake pedal and/or the vehicle body vibration when
ABS activates.
These vibrations and sounds are normal to ABS
systems and are no cause for concern.

19 ACURA RDX-31TJB6000.book  493 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

494

uu

Braking

u

Brake Assist System

Driving

Brake Assist System

Designed to assist the driver by generating greater braking force when you depress
the brake pedal hard during emergency braking.

■

Brake assist system operation

Press the brake pedal firmly for more powerful braking.

When brake assist operates, the pedal may wiggle slightly and an operating noise
may be heard. This is normal. Keep holding the brake pedal firmly down.

19 ACURA RDX-31TJB6000.book  494 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

495

Continued

Driving

Parking Your Vehicle

When Stopped

1. Depress the brake pedal firmly.
2. With the brake pedal depressed, press the electric parking brake switch slowly,

but fully.

3. Change the shift position to

(

P.

4. Turn off the engine.

The Parking Brake and Brake System indicator (red) goes off in about 30 seconds.

1

Parking Your Vehicle

Do not park your vehicle near flammable objects,
such as dry grass, oil, or timber.
Heat from the exhaust can cause a fire.

1

When Stopped

NOTICE

The following can damage the transmission:

•

Depressing the accelerator and brake pedals
simultaneously.

•

Holding the vehicle in place when facing uphill by
depressing the accelerator pedal.

•

Changing into

(

P before the vehicle stops

completely.

3

WARNING

The vehicle can roll away if left unattended
without confirming that Park is engaged.

A vehicle that rolls away could cause a crash
resulting in serious injury or death.

Always keep your foot on the brake pedal
until you have confirmed that

(

P

 is shown

on the gear position Indicator.

19 ACURA RDX-31TJB6000.book  495 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Parking Your Vehicle

u

When Stopped

496

Driving

Always confirm the electric parking brake is set, particularly if you are parked on an
incline.

1

When Stopped

In extremely cold temperatures, the parking brake
may freeze up if applied. If such temperatures are
expected, do not apply the parking brake but, if
parking on a slope, either turn the front wheels so
they will contact the curb if the vehicle rolls down the
slope or block the wheels to keep the vehicle from
moving. If you do not take either precaution, the
vehicle may roll unexpectedly, leading to a crash.

19 ACURA RDX-31TJB6000.book  496 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

497

uu

Parking Your Vehicle

u

Parking Sensor System

*

Continued

Driving

Parking Sensor System

*

The corner and center sensors monitor obstacles near your vehicle, and the beeper
and audio/information screen let you know the approximate distance between your
vehicle and the obstacle.

■

The sensor location and range

1

Parking Sensor System

*

Even when the system is on, always confirm if there is
no obstacle near your vehicle before parking.

The system may not work properly when:

•

The sensors are covered with snow, ice, mud or
dirt.

•

The vehicle is on uneven surface, such as grass,
bumps, or a hill.

•

The vehicle has been out in hot or cold weather.

•

The system is affected by devices that emit
ultrasonic waves.

•

Driving in bad weather.

The system may not sense:

•

Thin or low objects.

•

Sonic-absorptive materials, such as snow, cotton,
or sponge.

•

Objects directly under the bumper.

Do not put any accessories on or around the sensors.

Forward
Front: 24 in (60 cm) or less
Rear: 28 in (70 cm) or less

Front Corner Sensors

Rear Corner Sensors

Rear Center Sensors

Forward
Front: 30 in (75 cm) or less
Rear: 43 in (110 cm) or less

Front Center Sensors

Backward
Front: 26 in (65 cm) or less
Rear: 30 in (75 cm) or less

Backward
Front: 32 in (80 cm) or less
Rear: 45 in (115 cm) or less

* Not available on all models

19 ACURA RDX-31TJB6000.book  497 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

498

uu

Parking Your Vehicle

u

Parking Sensor System

*

Driving

■

Parking sensor system on and off

With the power mode in ON, press the
parking sensor system button to turn on or off
the system. The indicator in the button comes
on when the system is on.

The front center and front corner sensors start
to detect an obstacle when the transmission is
in any position other than

(

Por

(

R, and the

vehicle speed is less than 5 mph (8 km/h).

The front corner, rear center and rear corner
sensors start to detect an obstacle when the
transmission is in

(

R, and the vehicle speed is

less than 5 mph (8 km/h).

19 ACURA RDX-31TJB6000.book  498 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

499

uu

Parking Your Vehicle

u

Parking Sensor System

*

Continued

Driving

■

When the distance between your vehicle and obstacles becomes shorter

*1: At this stage, only the center sensors detect obstacles.

Direction

Length of the

intermittent

beep

Distance between the Bumper and Obstacle

Indicator

Audio/information

screen

Corner Sensors

Center Sensors

Forward

Moderate

—

Front: About 30-24 in (75-60 cm)

Rear: About 43-28 in (110-70 cm)

Blinks in
Yellow

*1

Short

Front: About 24-18 in (60-45 cm)

Rear: About 28-18 in (70-45 cm)

Front: About 24-18 in (60-45 cm)

Rear: About 28-18 in (70-45 cm)

Blinks in

Amber

Very short

About 18-14 in (45-35 cm)

About 18-14 in (45-35 cm)

Continuous

About 14 in (35 cm) or less

About 14 in (35 cm) or less

Blinks in

Red

Backward

Moderate

—

Front: About 32-26 in (80-65 cm)

Rear: About 45-30 in (115-75 cm)

Blinks in
Yellow

*1

Short

Front: About 26-20 in (65-50 cm)

Rear: About 30-20 in (75-50 cm)

Front: About 26-20 in (65-50 cm)

Rear: About 30-20 in (75-50 cm)

Blinks in

Amber

Very short

About 20-16 in (50-40 cm)

About 20-16 in (50-40 cm)

Continuous

About 16 in (40 cm) or less

About 16 in (40 cm) or less

Blinks in

Red

Indicators light where
the sensor detects an
obstacle

19 ACURA RDX-31TJB6000.book  499 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Parking Your Vehicle

u

Parking Sensor System

*

500

Driving

1. Make sure that the parking sensor system is not activated. Set the power mode to

VEHICLE OFF (LOCK).

2. Press and hold the parking sensor system button, and set the power mode to ON.
3. Keep pressing the button for 10 seconds. Release the button when the indicator

in the button flashes.

4. Press the button again. The indicator in the button goes off.

u

The beeper sounds twice. The rear sensors are now turned off.

To turn the rear sensors on again, follow the above procedure. The beeper sounds
three times when the rear sensors come back on.

■

Turning off All Rear Sensors

1

Turning off All Rear Sensors

When you shift to

(

R, the indicator in the parking

sensor system button blinks as a reminder that the
rear sensors have been turned off.

19 ACURA RDX-31TJB6000.book  500 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
