Acura RDX (2019 year). Manual - part 1

4

Quick

 Referenc

e Guide

Quick Reference Guide

Visual Index

❙

Steering Wheel Adjustments

(P 203)

❙

ENGINE START/STOP Button

(P 182)

❙

Rear Defogger

(P 200)

❙

Heated Mirror Button

(P 200)

❙

Climate Control System

(P 230)

❙

Audio System

(P 238)

❙

Hazard Warning Button

❙

Audio/Information Screen

(P 249)

❙

Navigation System

*



() See the Navigation System Manual

❙

Front Seat Heater Buttons

(P 228)

❙

Front Seat Ventilation Buttons

*



(P 228)

❙

Auto Idle Stop OFF Button

(P 429)

❙

 (Vehicle Stability Assist® (VSA®) System OFF) Button

(P 435)

❙

Parking Sensor System Button

*



(P 498)

❙

Collision Mitigation Braking System

TM

 (CMBS

TM

) OFF Button

(P 449)

❙

Road Departure Mitigation (RDM) Button

(P 481)

❙

Heated Windshield Button

*



(P 200)

❙

Headlight Washer Button

*



(P 197)

❙

Head-Up Display Buttons

*



(P 138, 199)

❙

Automatic Brake Hold Button

(P 491)

❙

Electric Parking Brake Switch

(P 486)

❙

Multi-Information Display

(P 127)

❙

System Indicators

(P 74 )

❙

Gauges

(P 126)

19 ACURA RDX-31TJB6000.book  4 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

5

Quick

 Referenc

e Guide

❙

Headlights/Turn Signals

(P 185, 186)

❙

Fog Lights

*



(P 190)

❙

Brightness Control

(P 198)

❙

Paddle Shifter (Shift down)

(P 425)

❙

Paddle Shifter (Shift up)

(P 425)

❙

Wipers/Washers

(P 194)

❙

Lane Keeping Assist System (LKAS)
Button

(P 473)

❙

Horn (Press an area around

.)

❙

CAMERA Button

*



(P 508)

❙

Interval Button

(P 465)

❙

Adaptive Cruise Control (ACC) with Low
Speed Follow (LSF) Buttons

(P 456)

❙

Right Selector Wheel

(P 129)

❙

Heated Steering Wheel Button

*



(P 227)

❙

Left Selector Wheel

(P 243)

❙

Audio Remote Controls

(P 243)

❙

Voice Control Buttons

*



(P 271)

❙

Bluetooth® HandsFreeLink® System Voice
Control Buttons

(P 358)

* Not available on all models

19 ACURA RDX-31TJB6000.book  5 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Visual Index

6

Quick

 Referenc

e Guide

❙

Rearview Mirror

(P 204)

❙

Shift Button
Electronic Gear Selector

(P 418)

❙

Driver’s Front Airbag

(P 45)

❙

Glove Box

(P 221)

❙

Passenger’s Front Airbag

(P 45)

❙

HomeLink® Buttons

(P 356)

❙

Interior Fuse Box Type A

(P 618)

❙

Dynamic Mode Switch

(P 426)

❙

Front Passenger’s Knee Airbag

(P 49)

❙

True Touchpad

(P 246)

❙

USB Port

(P 239)

❙

Driver’s Knee Airbag

(P 49)

❙

USB Ports

*



(P 240)

❙

Power Window Switches

(P 176)

❙

Memory Buttons

(P 202)

❙

SET Button

(P 202)

❙

Power Door Lock Master Switch

(P 161)

❙

Door Mirror Controls

(P 205)

❙

Hood Release Handle

(P 533)

❙

Power Tailgate Button

(P 167)

❙

Interior Fuse Box Type C

(P 620)

❙

Rear Seat Heater Buttons

*



(P 229)

❙

Interior Fuse Box Type B

(P 619)

19 ACURA RDX-31TJB6000.book  6 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

7

Quick

 Referenc

e Guide

❙

Cargo Area Light

❙

Seat Belt (Installing a Child Seat)

(P 65)

❙

Side Curtain Airbags

(P 54)

❙

Map Lights

(P 220)

❙

Seat Belts

(P 35)

❙

Panoramic Roof Switch

(P 181)

❙

Map Lights

(P 220)

❙

Sunglasses Holder

(P 227)

❙

USB Port

(P 240)

❙

Auxiliary Input Jack

(P 241)

❙

Front Seat

(P 207)

❙

Side Airbags

(P 52)

❙

Coat Hook

(P 225)

❙

LATCH to Secure a Child Seat

(P 63)

❙

Accessory Power Socket

(P 225)

❙

Rear Seat

(P 216)

❙

Sun Visors

❙

Vanity Mirrors

❙

Seat Belt to Secure a Child Seat

(P 67)

❙

Grab Handle

* Not available on all models

19 ACURA RDX-31TJB6000.book  7 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Visual Index

8

Quick

 Referenc

e Guide

❙

How to Refuel

(P 516)

❙

High-Mount Brake Light

(P 548)

❙

Opening/Closing the Tailgate

(P163)

❙

Rear Wiper

(P 196, 552)

❙

Taillights, Brake and Rear Side Marker Lights

(P 186, 547)

❙

Rear Turn Signal Lights

(P 185, 546)

❙

Multi-View Rear Camera

*



(P 505)

❙

Rear License Plate Light

(P 186, 548)

❙

Tailgate Outer Handle

(P 168, 172)

❙

Rearview Camera Washer

*



(P 194)

❙

Taillights/Brake and Back-Up Lights

(P 186, 548)

❙

Windshield Wipers

(P 194, 549)

❙

Power Door Mirrors

(P 205)

❙

Maintenance Under the Hood

(P 532)

❙

Fog Lights

*



(P 190, 545)

❙

Tires

(P 554, 579, 587)

❙

Door Lock/Unlock Control

(P 150)

❙

Front Turn Signal Lights

(P 185, 545)

❙

Front Side Marker Lights

(P186, 545)

❙

Parking/Daytime Running Lights

(P 186, 545)

❙

Side Turn Signal Lights

(P 185, 545)

❙

Headlights

(P 186, 545)

19 ACURA RDX-31TJB6000.book  8 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

9

Quick

 Referenc

e Guide

Auto Idle Stop Function

To improve fuel economy, the engine stops and then restarts as detailed below. When Auto Idle Stop is on, the Auto Idle Stop indicator
(green) comes on.

(P428)

At

Automatic transmission

Engine status

Deceleration

Stop

Start-up

Stop the vehicle and depress the brake pedal.

On

Keep the brake pedal
depressed.

U.S.

Canada

With the automatic brake hold system activated,
you can release the brake pedal when the



indicator comes on.

Off

Release the brake pedal.

With the automatic brake hold system activated,
depress the accelerator pedal.

Restarting

* Not available on all models

19 ACURA RDX-31TJB6000.book  9 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

10

Quick

 Referenc

e Guide

Safe Driving

(P 29)

Airbags

(P 42)

● Your vehicle is fitted with airbags to help protect you and

your passengers during a moderate-to-severe collision.

Child Safety

(P 58)

● All children 12 and younger should be seated in the rear seat.

● Smaller children should be properly restrained in a forward-facing child seat.

● Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard

(P 71)

● Your vehicle emits dangerous exhaust gases that contain carbon

monoxide. Do not run the engine in confined spaces where carbon
monoxide gas can accumulate.

Before Driving Checklist

(P 34)

● Before driving, check that the front seats, head restraints,

steering wheel, and mirrors have been properly adjusted.

Seat Belts

(P 35)

● Fasten your seat belt and sit upright well

back in the seat.

● Check that your passengers are wearing

their seat belts correctly.

Fasten your lap belt as
low as possible.

19 ACURA RDX-31TJB6000.book  10 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

11

Quick

 Referenc

e Guide

Instrument Panel

(P 73)

Indicators

(P 74)

/Multi-Information Display

(P 127)

/Gauges

(P 126)

/

Head-Up Display

*



(P 138)

Speedometer

Fuel Gauge

Multi-Information Display

Temperature Gauge

Tachometer

Head-Up Display

*

Immobilizer System Indicator/
Security System Alarm Indicator

Gear Position Indicator/
Transmission System Indicator

Turbo Meter

M (sequential mode) Indicator/
Gear Selection Indicator

G-meter

* Not available on all models

19 ACURA RDX-31TJB6000.book  11 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

12

Quick

 Referenc

e Guide

Controls

(P 143)

Clock

(P 144)

The clock is automatically updated through
the audio system.

You can adjust the time using the true
touchpad A.

a

Press the

 (home) button.

b

Select Settings.

c

Select System.

d

Select Date & Time.

e

Select Set Date & Time.

f

Select Automatic Date & Time.

g

Select Off.

h

Select Set Date or Set Time.

i

Select

(

+/

(

- to adjust the dates, hours

and minutes.

j

Press the

 (back) button to set the

date or time.

ENGINE START/STOP
Button

(P 182)

Press the button to change the vehicle’s
power mode.

Turn Signals

(P 185)

Lights

(P 186)

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing

19 ACURA RDX-31TJB6000.book  12 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

13

Quick

 Referenc

e Guide

Wipers and Washers

(P 194)

Wiper/Washer Control Lever

Adjustment Ring

(

- : Low Sensitivity

*1

: Lower speed, fewer sweeps

*2

(

+ : High Sensitivity

*1

: Higher speed, more sweeps

*2

MIST
OFF
AUTO

*1

: Wiper speed varies automatically

INT

*2

: Low speed with intermittent

LO: Low speed wipe
HI: High speed wipe

Pull toward
you to spray
washer fluid.

*1 : Models with automatic intermittent wipers
*2 : Models without automatic intermittent

wipers

AUTO should always be turned OFF before
the following situations in order to prevent
severe damage to the wiper system:
● Cleaning the windshield

● Driving through a car wash

● No rain present

Steering Wheel

(P 203)

● To adjust, push the adjustment lever

down, adjust to the desired position, then
lock the lever back in place.

Models with automatic intermittent wipers

Unlocking the Front
Doors from the Inside

(P 159)
● Pull either front door inner handle to

unlock and open it at the same time.

● Unlocking and opening the driver’s door

from the inner handle unlocks all the
other doors.

19 ACURA RDX-31TJB6000.book  13 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

14

Quick

 Referenc

e Guide

Tailgate

(P 163)

● Press the tailgate outer handle to unlock

and open the tailgate when you carry the
keyless access remote.

● Press the power tailgate button on the

driver’s door or the remote transmitter to
open and close the power tailgate.

Use a forward and back kicking motion
under the center of the rear bumper to
open or close the power tailgate while
carrying the keyless access remote.

Models with Hands Free Access

1 sec.

Power Door Mirrors

(P 205)
● With the power mode in ON, move the

selector switch to L or R.

● Push the appropriate edge of the

adjustment switch to adjust the mirror.

● Press the folding button

*

 to fold in and

out the door mirrors.

Selector Switch

Adjustment Switch

Folding Button

*

19 ACURA RDX-31TJB6000.book  14 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

15

Quick

 Referenc

e Guide

Power Windows

(P 176)

● With the power mode in ON, open and

close the power windows.

● If the power window lock button is in the

off position, each passenger’s window
can be opened and closed with its own
switch.

● If the power window lock button is in the

on position (indicator is on), each
passenger’s window switch is disabled.

Power Window Lock Button

Window Switch

Indicator

* Not available on all models

19 ACURA RDX-31TJB6000.book  15 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

16

Quick

 Referenc

e Guide

Climate Control System

(P 230)

● Press the AUTO button to activate the climate control system.

● Press the

 button to turn the system on or off.

● Press the

 button to defrost the windshield.

Driver’s Side Temperature
Control Buttons

 (Windshield Defroster) Button

A/C (Air Conditioning) Button

Air flows from floor and
windshield defroster vents.

Air flows from floor vents.

Air flows from floor and
dashboard vents, and back
of the center console.

Air flows from dashboard
vents and back of the
center console.

SYNC (Synchronization) Button

 (Recirculation) Button

AUTO Button

Passenger’s Side Temperature
Control Buttons

MODE Control Button

 (ON/OFF) Button

Fan Control Button

19 ACURA RDX-31TJB6000.book  16 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

17

Quick

 Referenc

e Guide

Features

(P 237)

Audio Remote Controls

(P 243)

● VOL

(

+/VOL

(

- (Volume) Switch

Press up or down to adjust the volume.

●

 (Power) Button

Press to turn the audio system on and off.

● Left Selector Wheel

When selecting the audio mode
Press the APPS button, then roll up or
down to select an item on the multi-
information display or the head-up
display

*

, and then press the left selector

wheel.

Left Selector Wheel

APPS Button

VOL

(

+/VOL

(

- (Volume) Switch

 (Power) Button

Roll up or down: To cycle through the
following items, roll up or down and then
press the left selector wheel:

You can add or remove the items and
change their order on multi-information
display or the head-up display

*

.

Navigation

*

Phone

FM Radio

USB Audio

SiriusXM

Select Driving View

*

Customize Apps

● When listening to the radio

Move to a side to change the favorite
radio station or channel.

● When listening to an iPod, USB flash

drive, Bluetooth® Audio, or Smartphone
Connection
Move to a side to skip to the beginning of
the next song or return to the beginning
of the current or previous song.

* Not available on all models

19 ACURA RDX-31TJB6000.book  17 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

18

Quick

 Referenc

e Guide

Audio System

(P 245)

 (Home) Button

 (Cards List) Button

 (Back) Button

Audio/Information Screen

For navigation system operation

() See the Navigation System Manual

True Touchpad A

 (Seek/Skip) Button

 (Seek/Skip) Button

 VOL/AUDIO

(Volume/Power) Knob

True Touchpad B

19 ACURA RDX-31TJB6000.book  18 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

19

Quick

 Referenc

e Guide

Driving

(P 397)

Automatic Transmission

(P418)

● Select

(

P and depress the brake pedal when starting the engine.

Park
Press the

(

P button.

Used when parking or before
turn off or start the engine.
Transmission is locked.

Reverse
Pull back the

(

R button.

Used when reversing.

Neutral
Press the

(

N button.

Transmission is not locked.

Drive/S Position
Each time you press the

 button, the mode

switches between Drive and S Position mode.

●

Normal driving (gears change between 1st
and 10th automatically)

●

Temporarily driving in the sequential mode

●

Automatically changing gears between 1st
and 8th (8th gear is used only at high speed)

●

Driving in the sequential mode

D/S

Drive

S Position

Gear Position Indicator
The gear position indicator and the
shift button indicator indicate the
current gear selection.

Gear Position Indicator

Shift Button
Indicator

Gear selection

19 ACURA RDX-31TJB6000.book  19 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
