586

Info

rm

ation

Specifications

■

Vehicle Specifications

■

Air Conditioning

Model

Acura RLX

No. of Passengers:
Front

2

Rear

3

Total

5

Weights:
Gross Vehicle Weight
Rating

U.S.: 5,379 lbs (2,440 kg)
Canada: 2,440 kg

Gross Axle Weight
Rating (Front)

U.S.: 2,822 lbs (1,280 kg)
Canada: 1,280 kg

Gross Axle Weight
Rating (Rear)

U.S.: 2,590 lbs (1,175 kg)
Canada: 1,175 kg

Refrigerant Type

HFC-134a (R-134a)

Charge Quantity

15.3 - 17.1 oz (435 - 485 g)

Lubricant Type

ND-OIL 11

Quantity

7.9 - 8.8 cu-in (130.0 - 145.0 cm

3

)

■

Engine Specifications

■

Fuel

■

Washer Fluid

Displacement

212 cu-in (3,471 cm

3

)

Spark Plugs

NGK

DILZKR7B11G

Type

Unleaded premium gasoline, Pump octane
number of 91 or higher

Fuel Tank Capacity

15.1 US gal (57 L)

Tank Capacity

U.S.: 2.6 US qt (2.5 L)
Canada: 5.3 US qt (5.0 L)

■

Light Bulbs

*1: Not available on all models

Headlights (Low Beam)

LED

Headlights (High Beam)

LED

Fog Lights

*1

LED

Front Turn Signal Lights

LED

Parking/Daytime Running Lights

LED

Front Side Marker Lights

LED

Side Turn Signal Lights
(on Door Mirrors)

LED

Brake/Taillights/Rear Side Marker
Lights

LED

Taillights

LED

Back-Up Lights

LED

Rear Turn Signal Lights

LED

High-Mount Brake Light

LED

Rear License Plate Lights

LED

Door Outer Handle Ambient Lights LED
Interior Lights

Front and Rear Map Lights

LED

Front and Rear Ambient Lights LED
Vanity Mirror Lights

2.1 W

Front Door Pocket Lights

LED

Center Pocket Light

LED

Beverage Holder Light

LED

Door Courtesy Lights

3.4 W

Console Compartment Light

LED

Glove Box Light

LED

Front and Rear

*1

 Foot Lights

LED

Door Inner Handle Lights

LED

Trunk Light

5 W

18 ACURA RLX E-AWD-31TY36400.book  586 ページ  ２０１７年７月２０日　木曜日　午後６時８分

587

uu

Specifications

u

Info

rm

ation

■

Brake Fluid

■

Dual Clutch Transmission Fluid

■

Twin Motor Unit Fluid

Specified

Acura Heavy Duty Brake Fluid DOT 3

Specified

Acura Automatic Transmission Fluid
ATF DW-1

Capacity

Change

3.7 US qt (3.5 L)

Specified

Acura Automatic Transmission Fluid
ATF DW-1

Capacity

Change

2.56 US qt (2.42 L)

■

Engine Oil

■

Engine Coolant

■

Inverter Coolant

Recommended

·Genuine Acura Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil

Capacity

Change

4.2 US qt (4.0 L)

Change
including
filter

4.5 US qt (4.3 L)

Specified

Acura Long Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

2.1 US gal (7.9 L)
(change including the remaining
0.225 US gal (0.85 L) in the reserve tank)

Specified

Acura Long Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

0.32 US gal (1.23 L)
(change including the remaining
0.03 US gal (0.11 L) in the reserve tank)

■

Tire

*1: Vehicles with optional spare tire kit

Regular

Size

245/40R19 98W

Pressure
psi (kPa [kgf/cm

2

])

36 (250 [2.5])

Compact
Spare

*1

Size

T155/70D17 110M

Pressure
psi (kPa [kgf/cm

2

])

60 (420 [4.2])

Wheel Size

Regular

19 x 8J

Compact Spare

*1

17 x 4T

18 ACURA RLX E-AWD-31TY36400.book  587 ページ  ２０１７年７月２０日　木曜日　午後６時８分

588

Info

rm

ation

Identification Numbers

Vehicle Identification Number (VIN), Engine Number,
Motor Number, and Transmission Number

Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle.
The locations of your vehicle’s VIN, engine number, motor number, and
transmission number are shown as follows.

1

Vehicle Identification Number (VIN), Engine Number, Motor
Number, and Transmission Number

The interior vehicle identification number (VIN) is
located under the cover.

Cover

Vehicle Identification Number

Engine Number

Dual Clutch
Transmission
Number

Certification Label/
Vehicle Identification Number

Vehicle Identification Number

Motor Number

Motor Number

Motor Number

18 ACURA RLX E-AWD-31TY36400.book  588 ページ  ２０１７年７月２０日　木曜日　午後６時８分

589

Info

rm

ation

Devices that Emit Radio Waves

The following products and systems on your vehicle emit radio waves when in operation.

Each of the above complies with the appropriate requirements or the required standards of FCC

(Federal Communications Commission) and Industry Canada Standard, described below:

As required by the FCC:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

This device complies with industry Canada licence-exempt RSS standard(s). Operation is subject to

the following two conditions: (1) this device may not cause interference, and (2) this device must

accept any interference, including interference that may cause undesired operation of the device.

AcuraLink
Audio System
Blind Spot Information System
Bluetooth® Audio
Bluetooth® HandsFreeLink®
Collision Mitigation Braking System

TM

HomeLink® Universal Transceiver
Immobilizer System
Keyless Access System
Tire Pressure Monitoring System (TPMS)
Remote Engine Start with Vehicle Feedback

18 ACURA RLX E-AWD-31TY36400.book  589 ページ  ２０１７年７月２０日　木曜日　午後６時８分

590

Info

rm

ation

Reporting Safety Defects

In the U.S.
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to
notifying American Honda Motor Co., Inc.

If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists
in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer, or American Honda Motor Co., Inc.

To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-
9153); go to http://www.safercar.gov; or write to: Administrator, NHTSA, 1200 New Jersey Avenue, SE.,
Washington, DC 20590. You can also obtain other information about motor vehicle safety from http://
www.safercar.gov.

In Canada
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform Honda Canada Inc. and you may also inform Transport Canada.

If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may lead to a recall and remedy campaign. However, Transport Canada
cannot become involved in individual problems between you, your dealer, or Honda Canada Inc.

To contact Transport Canada’s Defect Investigations and Recalls Division, you may call 1-800-333-0510. For
more information on reporting safety defects or about motor vehicle safety, go to http://www.tc.gc.ca/
roadsafety.

18 ACURA RLX E-AWD-31TY36400.book  590 ページ  ２０１７年７月２０日　木曜日　午後６時８分

591

Continued

Info

rm

ation

Emissions Testing

Testing of Readiness Codes

Your vehicle has readiness codes as part of the onboard self diagnostic system.
Some States use these codes for testing to verify whether your vehicle’s emissions
components are working properly.
The codes may not be read properly if testing is performed just after the 12-volt
battery has gone dead or been disconnected.

To check if they are set, set the power mode to ON, without turning the power
system on. The malfunction indicator lamp will come on for several seconds. If it
then goes off, the readiness codes are set. If it blinks five times, the readiness codes
are not set.

If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:

1. Fill the gas tank to approximately 3/4 full.
2. Park the vehicle and leave the power system off for 6 hours or more.
3. Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4. Turn the power system on.

1

Testing of Readiness Codes

The readiness codes are erased when the 12-volt
battery is disconnected, and set again only after
several days of driving under a variety of conditions.

If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.

If the testing facility determines the readiness codes
are still not set, see a dealer.

18 ACURA RLX E-AWD-31TY36400.book  591 ページ  ２０１７年７月２０日　木曜日　午後６時８分

592

uu

Emissions Testing

u

Testing of Readiness Codes

Info

rm

ation

5. Select a nearby, lightly traveled major highway where you can maintain a speed

of 50 mph (80 km/h) over for at least 20 minutes. Drive on the highway in

(

D

with SPORT mode. Do not use cruise control.

6. Drive in city or suburban traffic for at least 10 minutes. When traffic conditions

allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.

7. Park the vehicle and leave the power system off for 40 minutes.

18 ACURA RLX E-AWD-31TY36400.book  592 ページ  ２０１７年７月２０日　木曜日　午後６時８分

593

Continued

Info

rm

ation

Warranty Coverages

■

U.S.Owners

Your new vehicle is covered by these warranties:

New Vehicle Limited Warranty – covers your new vehicle, except for the
emissions control systems and accessories, against defects in materials and
workmanship.

Emissions Control Systems Defects Warranty and Emissions Performance
Warranty – these two warranties cover your vehicle’s emissions control systems.
Time, mileage, and coverage are conditional. Please read your warranty booklet for
exact information.

Seat Belt Limited Warranty – a seat belt that fails to function properly is covered
by a limited warranty. Please read your warranty booklet for details.

Rust Perforation Limited Warranty – all exterior body panels are covered against
rusting from the inside out for the specified time period, regardless of mileage.

Accessory Limited Warranty – Acura accessories are covered under this warranty.
Time and mileage limits depend on the type of accessory and other factors. Please
read your warranty booklet for details.

Replacement Parts Limited Warranty – covers all Acura replacement parts
against defects in materials and workmanship.

18 ACURA RLX E-AWD-31TY36400.book  593 ページ  ２０１７年７月２０日　木曜日　午後６時８分

594

uu

Warranty Coverages

u

Info

rm

ation

Replacement 12-Volt Battery Limited Warranty – provides prorated coverage
for a replacement battery purchased from your dealer.

Replacement Muffler Lifetime Limited Warranty – provides coverage for as
long as the purchaser of the muffler owns the vehicle.

Restrictions and exclusions apply to all these warranties. Please read the Acura
warranty information booklet that came with your vehicle for precise information on
warranty coverages. Your vehicle’s original tires are covered by their manufacturer.
Tire warranty information is in a separate booklet.

■

Canadian Owners

Please refer to the warranty manual that came with your vehicle.

■

EPA Contact Information

An owner may obtain further information concerning emission warranties or report
violations of the terms of the emission warranties by contacting:

U.S. Environmental Protection Agency
Office of Transportation and Air Quality
Compliance Division, Light-Duty Vehicle Group
Attn: Warranty Complaints
2000 Traverwood Drive
Ann Arbor, MI 48105
Email: complianceinfo@epa.gov

18 ACURA RLX E-AWD-31TY36400.book  594 ページ  ２０１７年７月２０日　木曜日　午後６時８分

595

Info

rm

ation

Authorized Manuals

■

Service Express

For electronic copies of service publications, you can purchase a subscription to
Service Express. Visit www.techinfo.honda.com for pricing and options.

■

For U.S. Owners

Manuals can be purchased from Helm Incorporated. You can order a manual by
phone at 1 (800) 782-4356 (credit card orders only), or online at www.helminc.com.

■

For Canadian Owners

Please contact a dealer to order any manuals that you may require.

18 ACURA RLX E-AWD-31TY36400.book  595 ページ  ２０１７年７月２０日　木曜日　午後６時８分

596

Info

rm

ation

Client Service Information

Acura dealership personnel are trained professionals who should be able to deal
with any problems you may encounter with your vehicle. If, however, you are faced
with a problem that they cannot resolve to your satisfaction, contact Acura Client
Relations/Services.

U.S. Owners
American Honda Motor Co., Inc.
Acura Client Relations
Mail Stop 100-5E-8F
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: 1 (800) 382-2238

Canadian Owners
Honda Canada Inc.
Acura Client Services
180 Honda Boulevard Markham, ON
L6C 0H9
Tel: 1-866-78-ACURA
Fax: 1-877-939-0909
E-mail: acura_cr@ch.honda.com

In Puerto Rico and the U.S. Virgin Islands
Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: 1 (787) 620-7546

1

Client Service Information

When you call or write, please give us the following
information:

•

Vehicle Identification Number

2 Vehicle Identification Number (VIN),

Engine Number, Motor Number, and
Transmission Number P. 588

•

Date of purchase

•

Odometer reading of your vehicle

•

Your name, address, and telephone number

•

A detailed description of the problem

•

Name of the dealer who sold the vehicle to you

18 ACURA RLX E-AWD-31TY36400.book  596 ページ  ２０１７年７月２０日　木曜日　午後６時８分

597

uu

Client Service Information

u

Continued

Info

rm

ation

Music recognition technology and related
data are provided by Gracenote®.
Gracenote is the industry standard in music
recognition technology and related content
delivery.
For more information, visit
www.gracenote.com.
When music is recorded to the HDD from a
CD, information such as the recording artist
and track name are retrieved from the
Gracenote Database and displayed (when
available).
Gracenote may not contain information for
all albums.
Gracenote is an internet-based music
recognition service that allows artist, album,
and track information from CDs to display
on the HDD.
Gracenote users are allowed 4 free updates
a year. More information about Gracenote,
its features, and downloads are available at

■

Gracenote Music Recognition
Service (CDDB)

www.acura.com (in U.S.) or www.acura.ca
(in Canada).
CD and music-related data from Gracenote,
Inc., copyright © 2000 to present
Gracenote. Gracenote Software, copyright
© 2000 to present Gracenote.
One or more patents owned by Gracenote
apply to this product and service. See the
Gracenote website for a non-exhaustive list
of applicable Gracenote patents.
Gracenote, CDDB, MusicID, MediaVOCS,
the Gracenote logo and logotype, and the
“Powered by Gracenote” logo are either
registered trademarks or trademarks of
Gracenote in the United States and/or other
countries.

This application or device contains software
from Gracenote, Inc. of Emeryville,
California (“Gracenote”). The software
from Gracenote (the “Gracenote
Software”) enables this application to
perform disc and/or file identification and
obtain music- related information, including
name, artist, track, and title information
(“Gracenote Data”) from online servers or

■

Gracenote® END USER LICENSE
AGREEMENT

embedded databases (collectively,
“Gracenote Servers”) and to perform other
functions. You may use Gracenote Data
only by means of the intended End-User
functions or this application or device.

You agree that you will use Gracenote Data,
the Gracenote Software, and Gracenote
Servers for your own personal non-
commercial use only.

You agree not to assign, copy, transfer, or
transmit the Gracenote Software or any
Gracenote Data to any third party.

YOU AGREE NOT TO USE OR EXPLOIT
GRACENOTE DATA, THE GRACENOTE
SOFTWARE, OR GRACENOTE SERVERS,
EXCEPT AS EXPRESSLY PERMITTED HEREIN.

You agree that your non-exclusive license to
use the Gracenote Data, the Gracenote
Software, and Gracenote Servers will
terminate if you violate these restrictions. If
your license terminates, you agree to cease
any and all use of the Gracenote Data, the
Gracenote Software, and Gracenote
Servers.

18 ACURA RLX E-AWD-31TY36400.book  597 ページ  ２０１７年７月２０日　木曜日　午後６時８分

598

uu

Client Service Information

u

Info

rm

ation

Gracenote reserves all rights in Gracenote
Data, the Gracenote Software, and the
Gracenote Servers, including all ownership
rights. Under no circumstances will
Gracenote become liable for any payment
to you for any information that you provide.
You agree that Gracenote, Inc. may enforce
its rights under this Agreement against you
directly in its own name.

The Gracenote service uses a unique
identifier to track queries for statistical
purposes. The purpose of a randomly
assigned numeric identifier is to allow the
Gracenote service to count queries without
knowing anything about who you are. For
more information, see the web page for the
Gracenote Privacy Policy for the Gracenote
service.

The Gracenote Software and each item of
Gracenote Data are licensed to you “AS IS.”

Gracenote makes no representations or
warranties, express or implied, regarding
the accuracy of any Gracenote Data from in
the Gracenote Servers. Gracenote reserves
the right to delete data from the Gracenote
Servers or to change data categories for any

cause that Gracenote deems sufficient. No
warranty is made that the Gracenote
Software or Gracenote Servers are error-
free or that functioning of Gracenote
Software or Gracenote Servers will be
uninterrupted.

Gracenote is not obligated to provide you
with new enhanced or additional data types
or categories that Gracenote may provide in
the future and is free to discontinue its
services at any time.

GRACENOTE DISCLAIMS ALL WARRANTIES
EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, TITLE, AND
NONINFRINGEMENT. GRACENOTE DOES
NOT WARRANT THE RESULTS THAT WILL BE
OBTAINED BY YOUR USE OF THE
GRACENOTE SOFTWARE OR ANY
GRACENOTE SERVER. IN NO CASE WILL
GRACENOTE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL
DAMAGES OR FOR ANY LOST PROFITS OR
LOST REVENUES.
© Gracenote 2009

Requirements to access Pandora®
• Latest version of the Pandora app

installed on your Android, Blackberry, or
iPhone.

• Registered Pandora account (you can

create a free account at
www.pandora.com <http://
www.pandora.com/> or on your
smartphone)

• Connection to the internet via WiFi or

cellular data network.

■

Disclaimer of Pandora®

18 ACURA RLX E-AWD-31TY36400.book  598 ページ  ２０１７年７月２０日　木曜日　午後６時８分

599

uu

Client Service Information

u

Info

rm

ation

Limitations
• Access to Pandora requires an active

internet connection

• Ability to access Pandora through this

system is subject to change without
notice

• Certain functionality of Pandora service is

not available when accessing the service
through this system including, but not
limited to, creating new stations, deleting
stations, emailing current stations,
buying songs, viewing additional text
information, logging in to Pandora, and
adjusting Cell Network Audio Quality.
Pandora internet radio is a music service
not affiliated with HONDA. More
information is available at http://
www.pandora.com <http://
www.pandora.com/>. Pandora, the
Pandora logo, and the Pandora trade
dress are trademarks or registered
trademarks of Pandora Media, Inc., used
with permission.

• Mobile access requires a smartphone

with an active data plan. Standard data
rates may apply.

• Pandora is only available in the United

States.

18 ACURA RLX E-AWD-31TY36400.book  599 ページ  ２０１７年７月２０日　木曜日　午後６時８分

Index

600

In

dex

Index

Numbers

12-Volt Battery Charging System

Indicator .................................................... 81

A

AAC.................................................... 245, 269
ABS (Anti-lock Brake System)................... 458
Accessories and Modifications ................. 538
Accessory Power Sockets .......................... 190
Acoustic Vehicle Alerting System ............ 397
AcuraLink .................................................. 365
AcuraWatch

TM

..................................... 26, 398

Adaptive Cruise Control (ACC) with Low

Speed Follow (LSF) ............................ 90, 404

Additives

Coolant ........................................... 510, 512
Engine Oil................................................ 505
Washer.................................................... 514

Adjusting

Armrest ................................................... 181
Front Seats .............................. 175, 178, 180
Head Restraints........................................ 178
Mirrors .................................................... 172
Steering Wheel ........................................ 171
Temperature............................................ 116

Agile Handling Assist................................ 443
Aha

TM

 Menu .............................................. 268

Aha

TM

 Radio .............................................. 278

Air Conditioning System (Climate Control

System) ....................................................  200

Changing the Mode ................................  203
Defrosting the Windshield and

Windows...............................................  207

Dust and Pollen Filter...............................  532
Rear Temperature Control Dial ................  208
Sensors ...................................................  209
Using Automatic Climate Control ............  200

Air Pressure.......................................  522, 587
Airbags........................................................  45

Advanced Airbags .....................................  51
Airbag Care...............................................  59
Driver’s Knee Airbag..................................  52
Event Data Recorder....................................  0
Front Airbags (SRS)....................................  48
Indicator..............................................  57, 84
Passenger Airbag Off Indicator ..................  58
Sensors .....................................................  45
Side Airbags ..............................................  54
Side Curtain Airbags..................................  56

AM/FM Radio............................................  237
Anti-lock Brake System (ABS) ..................  458

Indicator....................................................  84

Armrest .....................................................  181
Audio Remote Controls ...........................  215
Audio System............................................  212

Adjusting the Sound................................  230
Auxiliary Input Jack..................................  213

Error Messages .......................................  274
General Information................................  279
HDD .......................................................  248
Internet Radio .........................................  266
iPod ........................................................  258
MP3/WMA/AAC .............................  245, 269
Reactivating ............................................  214
Recommended CDs ................................  280
Recommended Devices ...........................  282
Remote Controls .....................................  215
Security Code .........................................  214
Shortcuts ................................................  218
Theft Protection ......................................  214
USB Flash Drives......................................  282
USB Port .................................................  213

Audio/Information Screen .......................  225
Authorized Manuals ................................  595
Auto Door Locking/Unlocking ................  142

Customize ..............................................  312

Auto Engine Stop/Start..............................  13
Auto High-Beam ......................................  160
Automatic Brake Hold .............................  456

Indicator ...........................................  78, 456

Automatic Brake Hold System

Indicator ...........................................  78, 456

Automatic Lighting..................................  157
Auxiliary Input Jack .................................  213
Average Fuel Economy ............................  116
Average Speed .........................................  117

18 ACURA RLX E-AWD-31TY36400.book  600 ページ  ２０１７年７月２０日　木曜日　午後６時８分

601

In

dex

B

Battery

12-Volt ...................................................  530
12-Volt Battery Charging System

Indicator .........................................  81, 569

Charging (12-Volt Battery) ......................  530
High Voltage...........................................  451
Jump Starting .........................................  564
Maintenance (Checking the 12-Volt

Battery) .................................................  530

Maintenance (Replacing).........................  531

Battery Types..............................................  12
Belts (Seat)..................................................  38
Beverage Holders.....................................  189
Blind Spot Information (BSI) System.......  445
Bluetooth® Audio.....................................  272
Bluetooth® HandsFreeLink® ....................  326
Booster Seats (For Children)......................  71
Brake System ............................................  452

Anti-lock Brake System (ABS) ..................  458
Automatic Brake Hold.............................  456
Brake Assist System.................................  459
Fluid .......................................................  513
Foot Brake ..............................................  455
Parking Brake..........................................  452

Brake System (Amber)

Indicator ...................................................  79

Brake System (Red)

Indicator ...........................................  76, 570

Brightness Control (Head-Up Display) ....  167
Brightness Control (Instrument Panel) ...  166

Bulb Replacement .................................... 515

Back-Up Lights ........................................ 517
Brake/Taillights and Rear Side Marker

Lights .................................................... 516

Door Outer Handle Ambient Lights .......... 517
Fog Lights................................................ 515
Front Side Marker Lights .......................... 516
Front Turn Signal/Parking Lights............... 515
Headlights ............................................... 515
High-Mount Brake Light .......................... 517
Rear License Plate Lights .......................... 517
Rear Turn Signal Lights ............................ 516
Side Turn Signal/Emergency Indicator

Lights .................................................... 516

Taillights .................................................. 516

Bulb Specifications ................................... 586

C

CAMERA Button ....................................... 481
Carbon Monoxide Gas................................ 72
Cargo Area ................................................ 193
Cargo Hooks ............................................. 192
Carrying Cargo.................................. 375, 377
CD Player ................................................... 245
Center Pocket ........................................... 188
Certification Label .................................... 588
Changing Bulbs......................................... 515
Charging System Indicator ....................... 569
Child Safety ................................................. 60

Childproof Door Locks ............................. 141

Child Seat....................................................  60

Booster Seats ............................................  71
Child Seat for Infants.................................  62
Child Seat for Small Children.....................  63
Installing a Child Seat with a Lap/Shoulder Seat

Belt .........................................................  67

Larger Children .........................................  70
Rear-facing Child Seat ...............................  62
Selecting a Child Seat................................  64
Using a Tether...........................................  69

Childproof Door Locks .............................  141
Cleaning the Exterior ...............................  535
Cleaning the Interior................................  533
Client Service Information .......................  596
Climate Control System............................  200

Changing the Mode ................................  203
Defrosting the Windshield and

Windows...............................................  207

Dust and Pollen Filter...............................  532
Rear Temperature Control Dial ................  208
Sensors ...................................................  209
Using Automatic Climate Control ............  200

Clock..........................................................  128
CMBS

TM

 (Collision Mitigation Braking

System

TM

).................................................  460

Coat Hooks ...............................................  191
Collision Mitigation Braking System

TM



(CMBS

TM

) .................................................  460

Compact Spare Tire (Optional)........  555, 587
Console Compartment .............................  187
Controls.....................................................  127

18 ACURA RLX E-AWD-31TY36400.book  601 ページ  ２０１７年７月２０日　木曜日　午後６時８分
