486

uu

When Driving

u

Integrated Dynamics System

Driving

Integrated Dynamics System

Modifies the dynamic character of the vehicle. There are three modes to select from:
Comfort, Normal, and Sport.
Press the Dynamic Mode button to select a mode. The mode you have selected
appears on the MID.
You can customize the mode default setting using the MID.

2 Customized Features P. 126

Normal
Balanced driving
performance for most
driving situations.

Sport
Enhances vehicle response
feel through decreased
steering assist, heightened
throttle response, increased
SH-AWD

*

 torque bias, and

modified active sound
control.

Comfort
Maximizes driver comfort
through increased steering
assist.

Dynamic Mode
Button

* Not available on all models

18 ACURA MDX-31TZ56400.book  486 ページ  ２０１７年８月２３日　水曜日　午後４時１分

487

uu

When Driving

u

Front Sensor Camera

Continued

Driving

Front Sensor Camera

The camera, used in systems such as LKAS, RDM, ACC with LSF, CMBS

TM

, and auto

high-beam, is designed to detect an object that triggers any of the systems to
operate its functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

1

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, hood, or front grill that could obstruct
the camera’s field of vision and cause the system to
operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Acura replacement windshield. Making even
minor repairs within the camera’s field of vision or
installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor
Camera

18 ACURA MDX-31TZ56400.book  487 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

When Driving

u

Front Sensor Camera

488

Driving

1

Front Sensor Camera

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

18 ACURA MDX-31TZ56400.book  488 ページ  ２０１７年８月２３日　水曜日　午後４時１分

489

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Continued

Driving

Adaptive Cruise Control (ACC) with Low Speed
Follow (LSF)

Helps maintain a constant vehicle speed and a set following-interval behind a vehicle
detected ahead of yours and, if the detected vehicle comes to a stop, can decelerate
and stop your vehicle, without you having to keep your foot on the brake or the
accelerator.
When ACC with LSF slows your vehicle by applying the brakes, your vehicle’s brake
lights will illuminate.

1

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Important Reminder
As with any system, there are limits to ACC with LSF.
Use the brake pedal whenever necessary, and always
keep a safe interval between your vehicle and other
vehicles.

Be careful not to severely impact the radar sensor
cover.

3

WARNING

Improper use of ACC with LSF can lead to a
crash.

Use ACC with LSF only when driving on
expressways or freeways and in good
weather conditions.

3

WARNING

ACC with LSF has limited braking capability
and may not stop your vehicle in time to
avoid a collision with a vehicle that quickly
stops in front of you.

Always be prepared to apply the brake
pedal if the conditions require.

When to use

■

Vehicle speed for ACC with LSF: A vehicle is detected ahead within ACC with
LSF range – ACC with LSF operates at speeds up to 90 mph (145 km/h).
No vehicle is detected within ACC with LSF range – ACC with LSF operates at
the speed of about 25 mph (40 km/h) or above.

■

Gear position for ACC with LSF: In

(

D or

(

S.

The radar sensor is in
the front grille.

The camera is
located behind the
rearview mirror.

18 ACURA MDX-31TZ56400.book  489 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

490

Driving

■

How to activate the system

1

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

When the MAIN button is pressed, both ACC with
LSF and the Lane Keeping Assist System (LKAS) are
either turned on or off.

ACC with LSF may not work properly under certain
conditions.

2 ACC with LSF Conditions and Limitations

P. 495

When not using ACC with LSF: Turn off adaptive
cruise by pressing the MAIN button. This also will
turn off the Lane Keeping Assist System (LKAS).

Do not use ACC with LSF under the following
conditions.

•

On roads with heavy traffic or while driving in
continuous stop and go traffic.

•

On roads with sharp turns.

•

On roads with steep downhill sections, as the set
vehicle speed can be exceeded by coasting. In such
cases, ACC with LSF will not apply the brakes to
maintain the set speed.

•

On roads with toll collection facilities or other
objects between lanes of traffic, or in parking
areas, or facilities with drive through access.

■

Press the MAIN button on
the steering wheel.

ACC (green) is on in the
instrument panel.
ACC with LSF is ready to
use.

18 ACURA MDX-31TZ56400.book  490 ページ  ２０１７年８月２３日　水曜日　午後４時１分

491

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Continued

Driving

When driving at about 25 mph (40 km/h) or above: Take your foot off the
pedal and press down the RES/+/SET/– switch when you reach the desired speed.
The moment you release the switch, the set speed is fixed, and ACC with LSF begins.
When driving at slower than about 25 mph (40 km/h): If the vehicle is moving
and the brake pedal is not depressed, pressing the switch fixes the set speed to about
25 mph (40 km/h) regardless of current vehicle speed. While stationary and a vehicle
is ahead of you, the vehicle speed can be set, even with the brake pedal depressed.

When ACC with LSF starts operating, the
vehicle icon, interval bars and set speed
appear on the MID.

■

To Set the Vehicle Speed

On when ACC with LSF
begins

Press down and release

RES/+/SET/− Switch

Set Vehicle Speed

Set Vehicle Interval

18 ACURA MDX-31TZ56400.book  491 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

492

Driving

■

There is a vehicle ahead

ACC with LSF monitors if a vehicle ahead of you enters the ACC with LSF range. If a
vehicle is detected doing so, the ACC with LSF system maintains or decelerates your
vehicle’s set speed in order to keep the vehicle’s set following-interval from the
vehicle ahead.

2 To Set or Change Following-interval P. 498

When a vehicle whose speed is slower than
your set speed is detected in front of you, your
vehicle starts to slow down.

■

When in Operation

1

When in Operation

If the vehicle detected ahead of you slows down
abruptly, or if another vehicle is detected cutting in
front of you, the beeper sounds and a message
appears on the MID, and the head-up warning lights

*



come on.
Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

Even if the interval between your vehicle and the
vehicle detected ahead is short, ACC with LSF may
start accelerating your vehicle under the following
circumstances:

•

The vehicle ahead of you is going at almost the
same speed as, or faster than, your vehicle.

•

A vehicle that cuts in front of you is going faster
than your vehicle, gradually increasing the interval
between the vehicles.

Beep

Head-up Warning
Lights

*

ACC with LSF Range: 394 ft. (120 m)

A vehicle icon appears
on the MID.

* Not available on all models

18 ACURA MDX-31TZ56400.book  492 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

493

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

■

There is no vehicle ahead

Your vehicle maintains the set speed without
having to keep your foot on the brake or
accelerator pedal.
If there previously was a vehicle detected
ahead that kept your vehicle from traveling at
the set speed, ACC with LSF accelerates your
vehicle to the set speed, and then maintains it.

While stationary and no vehicle is detected,
ACC with LSF automatically cancels and a
beeper sounds.

■

When you depress the accelerator pedal

You can temporarily increase the vehicle speed. In this case, there is no audible or
visual alert even if a vehicle is in the ACC with LSF range.
ACC with LSF stays on unless you cancel it. Once you release the accelerator pedal,
the system resumes the set speed.
There are times when the vehicle speed will decrease when the accelerator pedal is
lightly applied.

A vehicle icon with dotted-line
contour appears on the MID.

1

When in Operation

You can also set the system to beep when a vehicle
detected in front of you comes in and goes out of the
ACC with LSF detecting range. Change the ACC
Forward Vehicle Detect Beep setting.

2 Customized Features P. 126, 358

Limitations
You may need to use the brake to maintain a safe
interval when using ACC with LSF. Additionally, ACC
with LSF may not work properly under certain
conditions.

2 ACC with LSF Conditions and Limitations

P. 495

18 ACURA MDX-31TZ56400.book  493 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

494

Driving

■

A vehicle detected ahead is within ACC with LSF range and slows to a stop

Your vehicle also stops, automatically. The
Stopped message appears on the MID.
When the vehicle ahead of you starts again,
the vehicle icon on the MID blinks. If you press
the RES/+/SET/– switch up or down, or
depress the accelerator pedal, ACC with LSF
operates again within the prior set speed.

1

A vehicle detected ahead is within ACC with LSF range and slows
to a stop

3

WARNING

Exiting a vehicle that has been stopped
while the ACC with LSF system is operating
can result in the vehicle moving without
operator control.

A vehicle that moves without operator
control can cause a crash, resulting in
serious injury or death.

Never exit a vehicle when the vehicle is
stopped by ACC with LSF.

18 ACURA MDX-31TZ56400.book  494 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

495

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

The system may automatically shut off and the ACC indicator will come on under
certain conditions. Some examples of these conditions are listed below. Other
conditions may reduce some of the ACC functions.

2 Front Sensor Camera P. 487

■

Environmental conditions

Driving in bad weather (rain, fog, snow, etc.).

■

Roadway conditions

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks, reflected
lights, road spray, high contrast).

■

Vehicle conditions

• The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.
• An abnormal tire or wheel condition (Wrong sized, varied size or construction,

improperly inflated, compact spare tire

*

, etc.).

• The camera temperature gets too high.
• The parking brake is applied.
• When the front grille is dirty.
• The vehicle is tilted due to a heavy load or suspension modifications.
• When tire chains are installed.

■

ACC with LSF Conditions and Limitations

1

ACC with LSF Conditions and Limitations

The radar sensor for ACC with LSF is shared with the
Collision Mitigation Braking System

TM

 (CMBS

TM

).

2 Collision Mitigation Braking System

TM



(CMBS

TM

) P. 536

You can read about handling information for the
camera equipped with this system.

2 Front Sensor Camera P. 487

Always keep the radar sensor cover clean.

Never use chemical solvents or polishing powder for
cleaning the sensor cover. Clean it with water or a
mild detergent.

Do not put a sticker on the radar sensor cover or
replace the radar sensor cover.

* Not available on all models

18 ACURA MDX-31TZ56400.book  495 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

496

Driving

■

Detection limitations

• A vehicle or pedestrian suddenly crosses in front of you.
• The interval between your vehicle and the vehicle or pedestrian ahead of you is

too short.

• A vehicle cuts in front of you at a slow speed, and it brakes suddenly.
• When you accelerate rapidly and approach the vehicle or pedestrian ahead of you

at high speed.

• The vehicle ahead of you is a motorcycle, bicycle, mobility scooter, or other small

vehicle.

• When there are animals in front of your vehicle.
• When you drive on a curved or winding or undulating road that makes it difficult

for the sensor to properly detect a vehicle or a pedestrian in front of you.

• The speed difference between your vehicle and a vehicle in front of you is

significantly large.

• An oncoming vehicle suddenly comes in front of you.
• Your vehicle abruptly crosses over in front of an oncoming vehicle.
• When driving through a narrow iron bridge.
• When the vehicle ahead of you brakes suddenly.
• When the vehicle ahead of you has a unique shape.
• When your vehicle or the vehicle ahead of you is driving on one edge of the lane.

1

ACC with LSF Conditions and Limitations

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by pressing the MAIN
button and take your vehicle to a dealer.

Have your vehicle checked by a dealer if you find any
unusual behavior of the system (e.g., the warning
message appears too frequently).

If the front of the vehicle is impacted in any of the
following situations, the radar sensor may not work
properly. Have your vehicle checked by a dealer:

•

The vehicle mounted onto a bump, curb, chock,
embankment, etc.

•

You drive the vehicle where the water is deep.

•

Your vehicle has a frontal collision.

18 ACURA MDX-31TZ56400.book  496 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

497

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

Increase or decrease the vehicle speed using the RES/+/SET/– switch on the steering
wheel.

• Each time you press the switch up or down, the vehicle speed is increased or

decreased by about 1 mph or 1 km/h accordingly.

• If you keep the switch pressed up or down, the vehicle speed increases or

decreases by about 5 mph or 5 km/h accordingly.

■

To Adjust the Vehicle Speed

1

To Adjust the Vehicle Speed

If a vehicle detected ahead is going at a speed slower
than your increased set speed, ACC with LSF may not
accelerate your vehicle. This is to maintain the set
interval between your vehicle and the vehicle ahead.

You can switch the displayed set speed
measurements on the MID between mph and km/h.

2 Customized Features P. 126

To increase speed

To decrease speed

18 ACURA MDX-31TZ56400.book  497 ページ  ２０１７年８月２３日　水曜日　午後４時１分

498

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

Press the   (interval) button to change the
ACC with LSF following-interval.
Each time you press the button, the following-
interval (the interval behind a vehicle detected
ahead of you) setting cycles through short,
middle, long, and extra long following-
intervals.

Determine the most appropriate following-
interval setting based on your specific driving
conditions. Be sure to adhere to any
following-interval requirements set by local
regulation.

■

To Set or Change Following-interval

Interval Button

18 ACURA MDX-31TZ56400.book  498 ページ  ２０１７年８月２３日　水曜日　午後４時１分

499

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Continued

Driving

The higher your vehicle’s following-speed is, the longer the short, middle, long or
extra long following-interval becomes. See the following examples for your
reference.

When your vehicle stops automatically because a vehicle detected ahead of you has
stopped, the interval between the two vehicles will vary based on the ACC with LSF
interval setting.

Following-interval

When the Set Speed is:

50 mph (80 km/h)

65 mph (104 km/h)

Short

83 feet

25 meters

1.1 sec

100 feet

31 meters

1.1 sec

Middle

110 feet

33 meters

1.5 sec

137 feet

42 meters

1.5 sec

Long

154 feet

47 meters

2.1 sec

200 feet

61 meters

2.1 sec

Extra
Long

204 feet

62 meters

2.8 sec

265 feet

81 meters

2.8 sec

18 ACURA MDX-31TZ56400.book  499 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

500

Driving

To cancel ACC with LSF, do any of the
following:
• Press the CANCEL button.
• Press the MAIN button.

u

ACC with LSF indicator goes off.

• Depress the brake pedal.

u

When the LSF function has stopped the
vehicle, you cannot cancel ACC with LSF
by depressing the brake pedal.

■

To Cancel

1

To Cancel

Resuming the prior set speed: After you have
canceled ACC with LSF, you can resume the prior set
speed while it is still displayed. Press the RES/+/
SET/– switch up.

The set speed cannot be set or resumed when ACC
with LSF has been turned off using the MAIN button.
Press the MAIN button to activate the system, then
set the desired speed.

CANCEL
Button

MAIN
Button

18 ACURA MDX-31TZ56400.book  500 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

501

uu

When Driving

u

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

■

Automatic cancellation

The beeper sounds and a message appears on the MID when ACC with LSF is
automatically canceled. Any of these conditions may cause the ACC with LSF to
automatically cancel:
• Bad weather (rain, fog, snow, etc.)
• When the radar sensor in the front grille gets dirty.
• The vehicle ahead of you cannot be detected.
• An abnormal tire condition is detected, or the tires are skidding.
• Driving on a mountainous road, or driving off road for extended periods.
• Abrupt steering wheel movement.
• When the ABS, VSA® or CMBS

TM

 is activated.

• When the ABS or VSA® system indicator comes on.
• When the vehicle is stopped on a very steep slope.
• When you manually apply the parking brake.
• When the detected vehicle within the ACC with LSF range is too close to your

vehicle.

• When a detected vehicle goes out of the ACC with LSF range while your vehicle

is stationary.

• The camera behind the rearview mirror, or the area around the camera, including

the windshield, gets dirty.

The ACC with LSF automatic cancellation can be also triggered by the following
causes. In these cases, the electric parking brake will be automatically applied.
• The driver’s seat belt is unfastened when the vehicle is stationary.
• The vehicle stops for more than 10 minutes.
• The engine is turned off.
• When trailer stability assist is activated.

2 Trailer Stability Assist P. 460

1

Automatic cancellation

Even though ACC with LSF has been automatically
canceled, you can still resume the prior set speed.
Wait until the condition that caused ACC with LSF to
cancel improves, then press the RES/+/SET/– switch
up.

18 ACURA MDX-31TZ56400.book  501 ページ  ２０１７年８月２３日　水曜日　午後４時１分
