Acura MDX (2018 year). Manual - part 26

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

406

Features

■

To turn on or off the text/e-mail
message function

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

3. Rotate

 to select Enable Text/Email.

4. Press

 to select On or Off.

■

To turn on or off the text/e-mail
message notice

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

3. Rotate

 to select New Text/Email

Alert.

4. Press

 to select On or Off.

■

To Set Up a Text/e-mail Message Option

1

To Set Up a Text/e-mail Message Option

To use the text/e-mail message function, you need a
Bluetooth-compatible cell phone. For a list of
compatible phones, pairing procedures, and special
feature capabilities:

•

U.S.: Visit www.handsfreelink.com/Acura, or call 1-
888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

Some text/e-mail features may not be available
depending on a cellular phone.

1

To turn on or off the text/e-mail message notice

On: A pop-up notification comes on every time you
receive a new text message.
Off: The message you receive is stored in the system
without notification.

18 ACURA MDX-31TZ56400.book  406 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

407

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To set up the auto reading option

*

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

3. Rotate

 to select Message Auto

Reading.

4. Press

to

select

On or Off.

1

To set up the auto reading option

*

On: A text/e-mail message is always read aloud.
Off: A text/e-mail message is not read aloud.

* Not available on all models

18 ACURA MDX-31TZ56400.book  407 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

408

Features

You can protect each of the six cell phones with a security PIN.

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select
Bluetooth Device List.

3. Rotate

 to select a phone you want to

add a security PIN to, then press

.

4. Rotate

 to select Edit PIN, then press

.

5. Enter a new four-digit number.

u

Select

 to delete. Select

 of the

right side upper screen, the screen
returns to the previous screen.

6. Select OK to enter the security PIN.
7. Re-enter the four-digit number.

u

The screen returns to the screen in step
4.

■

To Create a Security PIN

1

To Create a Security PIN

If the phone is already security PIN protected, you
need to enter the current security PIN before clearing
the PIN or creating a new one.

Information Screen

On Demand Multi-Use Display

TM

X

X

18 ACURA MDX-31TZ56400.book  408 ページ  ２０１７年８月２３日　水曜日　午後４時１分

409

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

Edit the user name of a paired phone as
follows:
1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select
Bluetooth Device List.

3. Rotate

 to select a phone you want to

edit, then press

.

4. Rotate

 to select Edit Device Name,

then press

.

5. Enter a new name of the phone.

u

Use the keyboard on the On Demand
Multi-Use Display

TM

 to enter the name,

then select OK.

■

Editing User Name

*

* Not available on all models

18 ACURA MDX-31TZ56400.book  409 ページ  ２０１７年８月２３日　水曜日　午後４時１分

410

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

3. Rotate

 to select Auto Transfer.

4. Press

 to select On or Off.

You can set HFL to automatically answer an incoming call in four seconds.

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

3. Rotate

 to select Auto Answer.

4. Press

 to select On or Off.

■

Automatic Transferring

■

Auto Answer

18 ACURA MDX-31TZ56400.book  410 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

411

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

You can change the ring tone setting.

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select Ring
Tone.

3. Rotate

 to select Fixed, Mobile Phone

or Off, then press

.

You can display a caller’s picture on an incoming call screen.

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

3. Rotate

 to select Use Contact Photo.

4. Press

to

select

On or Off.

■

Ring Tone

1

Ring Tone

Fixed: The fixed ring tone sounds from the speaker.
Mobile Phone: The ring tone stored in the
connected cell phone sounds from the speaker.
Off: No ring tones sound from the speaker.

■

Use Contact Photo

18 ACURA MDX-31TZ56400.book  411 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

412

Features

■

When Automatic Phone Sync is set to
On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to HFL.

■

Changing the Automatic Phone Sync
setting

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select
Automatic Phone Sync.

3. Rotate

 to select On or Off, then press

.

■

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

When you select a person from the list in the cellular
phonebook, you can see up to three category icons.
The icons indicate what types of numbers are stored
for that name.

On some phones, it may not be possible to import the
category icons to HFL.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Preference

Home

Mobile

Work

Pager

Fax

Car

Other

Voice

18 ACURA MDX-31TZ56400.book  412 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

413

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

Up to 20 speed dial numbers can be stored per phone.

To store a speed dial number:
1. Press the PHONE button.
2. Rotate

to

select

Speed Dial, then press

.

u

Repeat the procedure to select New
Entry.

3. Rotate

 to select a place to choose a

number from, then press

.

From Import from Call History:

u

Select a number from the call history.

From Manual Input:

u

Input the number manually.

From Import from Phonebook:

u

Select a number from the linked cell
phone’s imported phonebook.

4. When the speed dial is successfully stored

from Import from Call History or Import
from Phonebook, you are asked to create
a voice tag for the number. Rotate

 to

select Yes or No, then press

.

5. Using the

 button, follow the prompts to

store a voice tag for the speed dial entry.

■

Speed Dial

1

Speed Dial

When a voice tag is stored, press the

 button to

call the number using the voice tag. Say “Call” and
the voice tag name.

18 ACURA MDX-31TZ56400.book  413 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

414

Features

■

To add a voice tag to a stored speed
dial number

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select Edit
Speed Dial.

3. Select an existing speed dial entry.

u

From the pop-up menu, rotate

 to

select Edit, then press

.

4. Rotate

 to select Voice Tag, then press

.

u

From the pop-up menu, rotate

 to

select Record, then press

.

5. Using the

 button, follow the prompts to

complete the voice tag.

5. Press .

u

Using the

 button, follow the prompts

to complete the voice tag.

6. You will receive a confirmation message on

the screen. Rotate

 to select OK, then

press .

1

Speed Dial

Avoid using duplicate voice tags.
Avoid using “home” as a voice tag.
It is easier for HFL to recognize a longer name. For
example, use “John Smith” instead of “John.”

Models without navigation system

Models with navigation system

18 ACURA MDX-31TZ56400.book  414 ページ  ２０１７年８月２３日　水曜日　午後４時１分

415

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To delete a voice tag

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select Edit
Speed Dial.

3. Select an existing speed dial entry.

u

From the pop-up menu, rotate

 to

select Edit, then press

.

4. Rotate

 to select Voice Tag, then press

.

u

From the pop-up menu, rotate

 to

select Clear, then press

.

5. A confirmation message appears on the

screen. Rotate

 to select Yes, then press

.

■

To delete a speed dial

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select Edit
Speed Dial.

3. Select an existing speed dial entry.

u

From the pop-up menu, rotate

 to

select Delete, then press

.

4. A confirmation message appears on the

screen. Rotate

 to select Yes, then press

.

18 ACURA MDX-31TZ56400.book  415 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

416

Features

Add phonetic modifications or a new voice tag to the phone’s contact name so that
it is easier for HFL to recognize voice commands.

■

To add a new voice tag

1. Press the SETTINGS button.
2. Rotate

 to select System Settings,

then press

.

3. Rotate

 to select Phonebook

Phonetic Modification, then press

.

4. Rotate

 to select the phone you want

to add phonetic modification to, then
press .

5. Rotate

 to select Options..., then press

.

6. Rotate

to

select

New Voice Tag, then

press .

■

Phonebook Phonetic Modification

*

1

Phonebook Phonetic Modification

*

You can store up to 20 phonetic modification items.

* Not available on all models

18 ACURA MDX-31TZ56400.book  416 ページ  ２０１７年８月２３日　水曜日　午後４時１分

417

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

7. Move

 or

 and rotate

 to select a

contact name, then press

.

u

The pop-up menu appears on the
screen.

8. Rotate

to

select

Modify, then press

.

9. Press .

u

Using the

 button, follow the

prompts to complete the voice tag.

10. You will receive a confirmation message

on the screen. Rotate

 to select OK,

then press

.

11. Rotate

to

select

Options..., then press

.

12. Rotate

to

select

OK, then press

.

18 ACURA MDX-31TZ56400.book  417 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

418

Features

■

To modify a voice tag

1. Press the SETTINGS button.
2. Rotate

 to select System Settings,

then press

.

3. Rotate

 to select Phonebook

Phonetic Modification, then press

.

4. Rotate

 to select the phone you want

to add phonetic modification to, then
press .

5. Rotate

 to select a contact name you

want to modify, then press

.

u

The pop-up menu appears on the
screen.

6. Rotate

 to select Modify, then press

.

7. Press .

u

Using the

 button, follow the

prompts to complete the voice tag.

8. You will receive a confirmation message

on the screen. Rotate

 to select OK,

then press

.

9. Rotate

 to select Options..., then press

.

10. Rotate

 to select OK, then press

.

1

Phonebook Phonetic Modification

*

You can only modify or delete contact names for the
currently connected phone.

* Not available on all models

18 ACURA MDX-31TZ56400.book  418 ページ  ２０１７年８月２３日　水曜日　午後４時１分

419

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To delete a modified voice tag

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Rotate

 to select Phonebook Phonetic

Modification, then press

.

4. Rotate

 to select the phone you want to

delete phonetic modification, then press

.

5. Rotate

 to select a contact name you

want to delete, then press

.

u

The pop-up menu appears on the screen.

6. Rotate

 to select Delete, then press

.

u

Items to be deleted are indicated with a
trash icon.

7. Rotate

 to select Options..., then press

.

8. Rotate

 to select OK, then press

.

Trash Icon

18 ACURA MDX-31TZ56400.book  419 ページ  ２０１７年８月２３日　水曜日　午後４時１分

420

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To delete all modified voice tags

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Rotate

 to select Phonebook Phonetic

Modification, then press

.

4. Rotate

 to select the phone you want to

delete phonetic modification, then press

.

5. Rotate

 to select Options..., then press

.

6. Rotate

 to select Delete All, then press

.

7. You will receive a confirmation message on

the screen. Rotate

 to select Yes, then

press .

18 ACURA MDX-31TZ56400.book  420 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

421

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, speed dial entries, or
redial.

■

Making a Call

1

Making a Call

Any voice-tagged speed dial entry, phonebook name,
or number can be dialed by voice from most screens.

Press the

 button and say “Call” and the voice tag

name, “Call by name” and the phonebook name, or
“Call” and the phone number.

The maximum range between your phone and
vehicles is 30 feet (10 meters).

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

While there is an active connection with Apple
CarPlay, phone calls cannot be made with
HandsFreeLink® and are only made from Apple
CarPlay.

18 ACURA MDX-31TZ56400.book  421 ページ  ２０１７年８月２３日　水曜日　午後４時１分
