Acura ILX (2018 year). Manual

Bluetooth® HandsFreeLink®

HFL Menus

340

Features

■

To make a call using the call history

Call history is stored by All, Dialed,
Received, and Missed.
1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

to select Call History, then

press .

4. Move

select

All, Dialed,

Received, and Missed.

5. Rotate

to select a number, then press

Dialing starts automatically.

■

To make a call using a speed dial entry

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

to select Speed Dial, then press

4. Rotate

to select a number, then press

Dialing starts automatically.

To make a call using the call history

The call history displays the last 20 dialed, received, or
missed calls.
(Appears only when a phone is connected to HFL.)

These icons next to the number indicate the
following:

: Dialed calls.
: Received calls.
: Missed calls.

To make a call using a speed dial entry

Move to select More Speed Dials to view another
paired phone’s speed dial list. You can make a call
from that list using the currently connected phone.

When a voice tag is stored, press the

button to

call the number using the voice tag.

2 Speed Dial P. 334

Any voice-tagged speed dial entry, phonebook name
or number can be dialed by voice from any screen.
Press the

button and follow the prompts.

18 ACURA ILX-31TX66500.book 340 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

341

Bluetooth® HandsFreeLink®

HFL Menus

Features

When there is an incoming call, an audible
notification sounds (if activated) and the
Incoming call screen appears.

Press the

button to answer the call.

Press the

button to decline or end the call.

■

Receiving a Call

Receiving a Call

Call Waiting

Press the

button to put the current call on hold to

answer the incoming call.

Press the

button again to return to the current

call.
Ignore the incoming call if you do not want to answer
it.
Press the

button if you want to hang up the

current call.

You can select the icons on the On Demand Multi-
Use Display

instead of the

and

buttons.

18 ACURA ILX-31TX66500.book 341 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth® HandsFreeLink®

HFL Menus

342

Features

The following options are available during a call.
Mute: Mute your voice.
Transfer: Transfer a call from HFL to your phone.
Touch Tones: Send numbers during a call. This is useful when you call a menu-
driven phone system.

The available options are shown on the Phone
screen.
Rotate

to select the option, then press

The mute icon appears when Mute is
selected. Select Mute again to turn it off.

■

Options During a Call

Options During a Call

Touch Tones: Available on some phones.

You can select the icons on the On Demand Multi-
Use Display

Mute Icon

18 ACURA ILX-31TX66500.book 342 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

343

Bluetooth® HandsFreeLink®

HFL Menus

Features

HFL can display newly received text and e-mail messages as well as 20 of the most
recently received messages on a linked cell phone. Each received message can be
read aloud and replied to using a fixed common phrase.

1. A pop-up appears and notifies you of a new

text or e-mail message.

2. Rotate

to select Read to listen to the

message, then press

The text or e-mail message is displayed.
The system automatically starts reading
out the message.

3. To discontinue the message read-out, press

■

Receiving a Text/E-mail Message

Receiving a Text/E-mail Message

The system does not display any received messages
while you are driving. You can only hear them read
aloud.

With some phones, you may be able to display up to
20 most recent text and e-mail messages.

State or local laws may limit your use of the HFL text/
e-mail message feature. Only use the text/e-mail
message feature when conditions allow you to do so
safely.

When you receive a text or e-mail message for the
first time since the phone is paired to HFL, you are
asked to turn the New Text/Email Alert setting to
On.

2 To turn on or off the text/e-mail message

notice P. 328

18 ACURA ILX-31TX66500.book 343 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth® HandsFreeLink®

HFL Menus

344

Features

If a paired phone has text message or mail accounts, you can select one of them to
be active and receive notifications.

1. Press the SETTINGS button.
2. Rotate

to select Phone Settings, then

press .

Repeat the procedure to select Select
Account.

3. Rotate

to select Text Messages or an

e-mail message account you want, then
press .

■

Selecting a Mail Account

Selecting a Mail Account

You can also select a mail account from the folder list
screen or the message list screen.
Move to select Select Account, then press

You can only receive notifications from one text
message or mail account at a time.

18 ACURA ILX-31TX66500.book 344 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

345

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

Displaying text messages

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

to select Text/Email, then press

Select account if necessary.

4. Rotate

to select a message, then press

The text message is displayed. The
system automatically starts reading the
message aloud.

■

Displaying Messages

Displaying Messages

The

icon appears next to an unread message.

If you delete a message on the phone, the message
will also be deleted from the system. If you send a
message from the system, the message goes to your
phone’s outbox.

To see the previous or next message, move

on the text message screen.

Message List

Text Message

18 ACURA ILX-31TX66500.book 345 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth® HandsFreeLink®

HFL Menus

346

Features

■

Displaying e-mail messages

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

to select Text/Email, then press

4. Rotate

to select a folder, then press

5. Rotate

to select a message, then press

The e-mail message is displayed. The
system automatically starts reading the
message aloud.

Displaying e-mail messages

Received text and e-mail messages may appear in the
message list screen at the same time. In this case, text
messages are titled No subject.

Folder List

Message List

E-mail Message

18 ACURA ILX-31TX66500.book 346 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

347

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

Read or stop reading a message

1. Go to the text or e-mail message screen.

The system automatically starts reading
the message aloud.

2 Displaying Messages P. 345

2. Press

to stop reading.

Press

again to start reading the message

from the beginning.

■

Reply to a message

1. Go to the text or e-mail message screen.

The system automatically starts reading
the message aloud.

2 Displaying Messages P. 345

2. Move and rotate

to select Reply,

then press

3. Rotate

to select the reply message, then

press .

The pop-up menu appears on the screen.

4. Select Send to send the message.

Message sent appears on the screen
when the reply message was successfully
sent.

Reply to a message

The available fixed reply messages are as follows:

•

Talk to you later, I’m driving.

•

I’m on my way.

•

I’m running late.

•

Yes

•

You cannot add, edit, or delete reply messages.

Only certain phones receive and send messages when
paired and connected. For a list of compatible
phones:

•

U.S.: Visit www.handsfreelink.com/Acura, or call 1-
888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

18 ACURA ILX-31TX66500.book 347 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

348

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

Making a call to a sender

1. Go to the text message screen.

The system automatically starts reading
the message aloud.

2 Displaying text messages P. 345

2. Move and rotate

to select Call, then

press .

18 ACURA ILX-31TX66500.book 348 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

350

Driving

Before Driving

Driving Preparation

Check the following items before you start driving.

• Make sure there are no obstructions on the windows, door mirrors, exterior

lights, or other parts of the vehicle.

Remove any frost, snow, or ice.

Remove any snow on the roof, as this can slip down and obstruct your field of
vision while driving. If frozen solid, remove ice once it has softened.

When removing ice from around the wheels, be sure not to damage the wheel
or wheel components.

• Make sure the hood is securely closed.

If the hood opens while driving, your front view will be blocked.

• Make sure the tires are in good condition.

Check air pressures, and check for damage and excessive wear.

2 Checking and Maintaining Tires P. 462

• Make sure there are no people or objects behind or around the vehicle.

There are blind spots from the inside.

■

Exterior Checks

Exterior Checks

NOTICE

When doors are frozen shut, use warm water around
the door edges to melt any ice. Do not try to force
them open, as this can damage the rubber trim
around the doors. When done, wipe dry to avoid
further freezing.

Do not pour warm water into the key cylinder.
You will be unable to insert the key if the water
freezes in the hole.

Heat from the engine and exhaust can ignite
flammable materials left under the hood, causing a
fire. If you've parked your vehicle for an extended
period, inspect and remove any debris that may have
collected, such as dried grass and leaves that have
fallen or have been carried in for use as a nest by a
small animal. Also check under the hood for leftover
flammable materials after you or someone else has
performed maintenance on your vehicle.

18 ACURA ILX-31TX66500.book 350 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

351

Before Driving

Driving Preparation

Driving

• Store or secure all items on board properly.

Carrying too much cargo, or improperly storing it, can affect your vehicle's
handling, stability, stopping distance, and tires, and make it unsafe.

2 Maximum Load Limit P. 353

• Do not pile items higher than the seat height.

They can block your view and may be thrown forward in the event of sudden
braking.

• Do not place anything in the front seat footwells. Make sure to secure the floor

mat.

An object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.

• If you have any animals on board, do not let them move around in the vehicle.

They may interfere with driving and a crash could occur.

• Securely close and lock all doors and the trunk.

2 Locking/Unlocking the Doors from the Inside P. 121

• Adjust your seating position properly.

Adjust the head restraint, too.

2 Adjusting the Seats P. 151
2 Adjusting the Front and Rear Outer Head Restraint Positions P. 154

• Adjust the mirrors and steering wheel properly for your driving.

Adjust them while sitting in the proper driving position.

2 Adjusting the Mirrors P. 149
2 Adjusting the Steering Wheel P. 146

■

Interior Checks

Interior Checks

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the trunk have the aiming readjusted
at a dealer or by a qualified technician.

18 ACURA ILX-31TX66500.book 351 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

352

Before Driving

Driving Preparation

Driving

• Be sure items placed on the floor behind the front seats cannot roll under the

seats.

They can interfere with the driver's ability to operate the pedals, the operation
of the seats, or the operation of the sensors under the seats.

• Everyone in the vehicle must fasten their seat belt.

2 Fastening a Seat Belt P. 33

• Make sure that the indicators in the instrument panel come on when you start the

vehicle, and go off soon after.

Always have a dealer check the vehicle if a problem is indicated.

2 Indicators P. 66

18 ACURA ILX-31TX66500.book 352 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

353

Before Driving

Maximum Load Limit

Continued

Driving

Maximum Load Limit

The maximum load for your vehicle is 850 lbs (385 kg). See the Tire
and Loading Information label attached to the driver's doorjamb.

This figure includes the total weight of all occupants, cargo, and
accessories, and the tongue load if you are towing a trailer.

Steps for Determining Correct Load Limit -
(1) Locate the statement “The combined weight of occupants and

cargo should never exceed XXX kg or XXX lbs.” on your
vehicle's placard.

(2) Determine the combined weight of the driver and passengers

that will be riding in your vehicle.

(3) Subtract the combined weight of the driver and passengers

from XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and

luggage load capacity. For example, if the “XXX” amount
equals 1,400 lbs. and there will be five 150 lb. passengers in
your vehicle, the amount of available cargo and luggage load
capacity is 650 lbs.
(1,400 - 750 (5 x 150) = 650 lbs.)

Maximum Load Limit

Gross Vehicle Weight Rating (GVWR):
The maximum allowable weight of the vehicle, all
occupants, all accessories, and all cargo.

2 Specifications P. 524

Gross Axle Weight Rating (GAWR):
The maximum allowable weight of the vehicle axle.

2 Specifications P. 524

WARNING

Overloading or improper loading
can affect handling and stability
and cause a crash in which you
can be hurt or killed.

Follow all load limits and other
loading guidelines in this manual.

Label Example

18 ACURA ILX-31TX66500.book 353 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

354

Before Driving

Maximum Load Limit

Driving

(5) Determine the combined weight of luggage and cargo being

loaded on the vehicle. That weight may not safely exceed the
available cargo and luggage load capacity calculated in step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will

be transferred to your vehicle. Consult this manual to
determine how this reduces the available cargo and luggage
load capacity of your vehicle.

In addition, the total weight of the vehicle, all occupants,
accessories, cargo, and trailer tongue load must not exceed the
Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight
Rating (GAWR). Both are on a label on the driver’s doorjamb.

Load Limits Example

Example1

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 2 = 300 lbs

(68 kg x 2 = 136 kg)

Cargo Weight

550 lbs

(249 kg)

Example2

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 5 = 750 lbs

(68 kg x 5 = 340 kg)

Cargo Weight

100 lbs
(45 kg)

18 ACURA ILX-31TX66500.book 354 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Acura ILX (2018 year). Manual - part 22
