Acura ILX (2018 year). Manual - part 19

292

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

*1: Appears only when a phone is connected to HFL.

Speed Dial

*1

Phonebook

Call History

Phone Number

Change Speed Dial

Delete Speed Dial

Store Voice Tag

Change Voice Tag

Delete Voice Tag

Add New

Existing entry list

Select a phone number from the
phonebook to store as a speed dial
number.

Select a phone number from the call
history to store as a speed dial number.

Enter a phone number to store as a
speed dial number.

Change a previously stored speed dial
number.

Delete a previously stored speed dial
number.

Create a voice tag for a speed dial
number.

Change a voice tag for a speed dial
number.

Delete a voice tag for a speed dial
number.

18 ACURA ILX-31TX66500.book  292 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

293

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

*1: Appears only when a phone is connected to HFL.

Passcode

*1

Auto Transfer

Caller ID Info

Name Priority

Number Priority

Message Notice

System Clear

Set calls to automatically transfer from your phone to HFL when you
enter the vehicle.

Prioritize the caller’s name as the
caller ID.

Prioritize the caller’s phone number as
the caller ID.

Create a security PIN for a paired phone.

Turn incoming text message notifications on or off.

Clear the system of all paired phones, phonebook entries, and security
codes.

18 ACURA ILX-31TX66500.book  293 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

294

Features

■

To pair a cell phone (when there is no
phone paired to the system)

1. Press the PHONE button or the

 button.

2. Rotate

 to select Yes, then press

.

3. Make sure your phone is in search or

discoverable mode, then press

.

u

HFL automatically searches for a
Bluetooth device.

4. When your phone appears on the list, select

it by pressing

.

u

If your phone doesn’t appear, select
Phone Not Found? and search for
Bluetooth devices using your phone.
From your phone, select
HandsFreeLink.

5. HFL gives you a four-digit pairing code to

input on your phone.
When your phone prompts you, input the
four-digit pairing code.

6. You will receive a notification on the screen

if pairing is successful.

■

Phone Setup

1

Phone Setup

Your Bluetooth-compatible phone must be paired to
HFL before you can make and receive hands-free
calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone's battery may drain faster when it is
paired to HFL.

•

If your phone is not ready for pairing or not found
by the system within three minutes, the system will
time out and returns to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.
: The phone is compatible with Bluetooth® Audio.

18 ACURA ILX-31TX66500.book  294 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

295

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To pair a cell phone (when a phone has
already been paired to the system)

1. Press the PHONE button or the

 button.

u

If a prompt appears asking to connect to
a phone, select No and proceed with
step 2.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Connection, then press

.

4. Rotate

 to select Add a New Phone,

then press

.

u

The screen changes to Select Location.

5. Rotate

 to select Empty, then press

.

18 ACURA ILX-31TX66500.book  295 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

296

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

6. Make sure your phone is in search or

discoverable mode, then press

.

u

HFL automatically searches for a
Bluetooth device.

7. When your phone appears on the list, select

it by pressing

.

u

If your phone doesn’t appear, select
Phone Not Found? and search for
Bluetooth devices using your phone.
From your phone, select
HandsFreeLink.

8. HFL gives you a four-digit pairing code to

input on your phone.
When your phone prompts you, input the
four-digit pairing code.

9. You will receive a notification on the screen

if pairing is successful.

18 ACURA ILX-31TX66500.book  296 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

297

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To change the pairing code setting

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Connection, then press

.

4. Rotate

 to select Pairing Code, then

press .

5. Rotate

to

select

Fixed or Random, then

press .

1

To change the pairing code setting

The default pairing code is 0000 until you change the
setting.
To create your own, select Fixed, and delete the
current code, then enter a new one.

For a randomly generated pairing code each time you
pair a phone, select Random.

18 ACURA ILX-31TX66500.book  297 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

298

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To delete a paired phone

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select
Connection, then Delete a Phone.

3. Rotate

 to select a phone you want to

delete, then press

.

4. You will receive a confirmation message on

the screen. Rotate

 to select Yes, then

press .

u

You will receive a notification on the
screen if it is successful.

18 ACURA ILX-31TX66500.book  298 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

299

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Message Notice, then

press .

4. Rotate

 to select a mode you want, then

press .

■

To Set Up a Text Message Notice Option

1

To Set Up a Text Message Notice Option

On: A pop-up notification comes on every time you
receive a new text message.
Off: The message you receive is stored in the system
without notification.

18 ACURA ILX-31TX66500.book  299 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

300

Features

You can protect each of the six cell phones with a security PIN.

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select
Passcode.

3. Select a phone you want to add a security

PIN to.

u

Rotate

 to select a phone you want to

add a security PIN to, then press

.

4. You will receive a confirmation message on

the screen.

u

Rotate

 to select Yes, then press

.

5. Enter a new four-digit number.

u

Rotate

 to select, then press

. Press

 to delete. Press

 to enter the

security PIN.

6. Re-enter the four-digit number.

u

The screen returns to the screen in step
2.

■

To Create a Security PIN

1

To Create a Security PIN

In the phone is already security PIN protected, you
need to enter the current security PIN before clearing
the PIN or creating a new one.

18 ACURA ILX-31TX66500.book  300 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

301

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select Auto
Transfer.

3. Rotate

 to select On, then press

.

4. You will receive a notification on the screen

if the change is successful.

You can select a caller’s information to be displayed when you have an incoming
call.

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select Caller ID
Info.

3. Rotate

 to select a mode you want, then

press .

4. You will receive a notification on the screen

if the change is successful.

■

Automatic Transferring

■

Caller’s ID Information

1

Caller’s ID Information

Name Priority mode: A caller’s name is displayed if it
is stored in the phonebook.
Number Priority mode: A caller’s phone number is
displayed.

18 ACURA ILX-31TX66500.book  301 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

302

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

Security codes, paired phones, all stored voice tags, all speed dial entries, and all
imported phonebook data are erased.

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select System
Clear.

3. Rotate

 to select Yes, then press

.

4. You will receive a notification message on

the screen. Rotate

 to select Yes, then

press .

5. You will receive a confirmation message on

the screen. Press

 to finish.

■

To Clear the System

18 ACURA ILX-31TX66500.book  302 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

303

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

When your phone is paired, the contents of its phonebook and call history are
automatically imported to HFL.

■

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

When you select a person from the list in the cellular
phonebook, you can see up to three category icons.
The icons indicate what types of numbers are stored
for that name.

On some phones, it may not be possible to import the
category icons to HFL.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Pref

Home

Mobile

Work

Pager

Car

Fax

Message

Other

Voice

18 ACURA ILX-31TX66500.book  303 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

304

Features

Up to 15 speed dial numbers can be stored per phone.

To store a speed dial number:
1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select Speed
Dial, then Add New.

3. Rotate

 to select a place to choose a

number from, then press

.

By Phonebook:

u

Select a number from the linked cell
phone’s imported phonebook.

By Call History:

u

Select a number from the call history.

By Phone Number:

u

Input the number manually.

4. When the speed dial is successfully stored,

you are asked to create a voice tag for the
number. Rotate

 to select Yes or No,

then press

.

5. Using the

 button, follow the prompts to

say the name for the speed dial entry.

■

Speed Dial

1

Speed Dial

You can use the audio preset buttons during a call to
store a speed dial number:
1. Press and hold the desired audio preset button

during a call.

2. The contact information for the active call will be

stored for the corresponding speed dial.

When a voice tag is stored, press the

 button to

call the number using the voice tag.

18 ACURA ILX-31TX66500.book  304 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

305

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To add a voice tag to a stored speed
dial number

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select Speed
Dial.

3. Select an existing speed dial entry.
4. Rotate

 to select Store Voice Tag, then

press .

5. Using the

 button, follow the prompts to

complete the voice tag.

■

To delete a voice tag

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select Speed
Dial.

3. Select an existing speed dial entry.
4. Rotate

 to select Delete Voice Tag,

then press

.

u

You will receive a confirmation message
on the screen. Rotate

 to select Yes,

then press

.

1

Speed Dial

Avoid using duplicate voice tag.
Avoid using “home” as a voice tag.
It is easier for HFL to recognize a longer name. For
example, use “John Smith” instead of “John.”

18 ACURA ILX-31TX66500.book  305 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

306

Features

■

To delete a speed dial number

1. Press the PHONE button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

u

Repeat the procedure to select Speed
Dial.

3. Select an existing speed dial entry.
4. Rotate

 to select Delete Speed Dial,

then press

.

u

You will receive a confirmation message
on the screen. Rotate

 to select Yes,

then press

.

You can make calls by inputting any phone number, or by using the imported
phonebook, call history, speed dial entries, or redial.

■

Making a Call

1

Making a Call

Voice-tagged speed dial entries can be dialed by
voice from any screen.

Press the

 button and follow the prompts.

The maximum range between your phone and
vehicles is 30 feet (10 meters).

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

18 ACURA ILX-31TX66500.book  306 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

307

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To make a call using the imported
phonebook

When your phone is paired, the contents of its
phonebook are automatically imported to
HFL.
1. Press the PHONE button or the

 button.

2. Rotate

 to select Phonebook, then press

.

3. The phonebook is stored alphabetically.

Rotate

 to select the initial, then press

.

4. Rotate

 to select a name, then press

.

5. Rotate

 to select a number, then press

.

u

Dialing starts automatically.

■

To make a call using a phone number

1. Press the PHONE button or the

 button.

2. Rotate

 to select Dial, then press

.

3. Rotate

 to select a number, then press

.

4. Rotate

 to select

, then press

.

u

Dialing starts automatically.

1

To make a call using the imported phonebook

This function is disabled while the vehicle is moving.
However, you can call a stored speed dial number
with a voice tag using voice commands.

2 Limitations for Manual Operation P. 288
2 Speed Dial P. 304

1

To make a call using a phone number

This function is disabled while the vehicle is moving.
However, you can call a stored speed dial number
with a voice tag using voice commands.

2 Limitations for Manual Operation P. 288
2 Speed Dial P. 304

18 ACURA ILX-31TX66500.book  307 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分
