Acura ILX (2018 year). Manual - part 12

180

uu

Audio System Basic Operation

u

Wallpaper Setup

Features

Wallpaper Setup

You can change, store and delete the wallpaper on the audio/information screen.

You can import up to three images, one at a time, for wallpaper from a USB flash
drive.

1. Connect the USB flash drive to the adapter

cable.

2 USB Adapter Cable

*

 P. 171

2. Press the SETUP button.
3. Rotate

 to select Display Setup, then

press .

4. Rotate

to

select

Wallpaper, then press

.

5. Rotate

 to select Import, then press

.

6. Rotate

 to select a desired picture, then

press .

u

The preview of the imported data is
displayed.

7. Press

 to save the data.

u

The confirmation message will appear.
Then the display will return to the import
wallpaper list.

8. Rotate

 to select the place to save the

data, then press

.

u

The confirmation message will appear.

■

Import Wallpaper

1

Wallpaper Setup

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

Each image file can be up to 2 MB.

•

The maximum image size is 1,680 x 936 pixels. If
the image size is less than 420 x 234 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

•

Up to 255 files can be selected.

If the USB flash drive does not have any pictures, No
compatible images were found. See Owner's
Manual. will appear.

* Not available on all models

18 ACURA ILX-31TX66500.book  180 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

181

uu

Audio System Basic Operation

u

Wallpaper Setup

Features

1. Rotate

 to select Select on the wallpaper setup menu, then press

.

u

The screen will change to the wallpaper list.

2. Rotate

 to select desired wallpaper and press

.

u

When the scroll is stopped, the thumbnail is displayed.

1. Rotate

 to select Delete on the wallpaper setup menu, then press

.

u

The screen will change to the delete wallpaper list.

2. Rotate

 to select wallpaper that you want to delete and press

.

u

The confirmation message will appear.

3. Rotate

 to select Yes, then press

 to delete completely.

■

Select Wallpaper

■

Delete wallpaper

18 ACURA ILX-31TX66500.book  181 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

182

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

Press the SETUP button, and rotate

 to

select Sound Settings, then press

. Rotate

 to scroll through the following choices:

1

Adjusting the Sound

The SVC has four modes: Off, Low, Mid, and High.
SVC adjusts the volume level based on the vehicle
speed. As you go faster, audio volume increases. As
you slow down, audio volume decreases.

Selector Knob

SETUP Button

Treble is selectable.

Speed-sensitive Volume
Compensation

Bass

Treble

Fader

Balance

BAS

TRE

FAD

BAL

SVC

18 ACURA ILX-31TX66500.book  182 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

183

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

SCAN Button
Press to sample each of the strongest stations
on the selected band for 10 seconds. To turn
off scan, press the button again.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

A.SEL (Auto Select) Button
Press to scan both bands and store the
strongest station in each preset. To turn
off auto select, press the button again. This
restores the presets you originally set.

SETUP Button
Press to display menu items.

Selector Knob
Turn to tune the radio frequency.

FM Button
Press to select a band.

AM Button

BACK Button
Press to go back to the previous display.

SKIP Bar
Press to search up and down the selected
band for a station with a strong signal.

Preset Buttons (1-6)
To store a station:
1. Tune to the desired station.
2. Pick a preset button and hold it until

you hear a beep.

To listen to a stored station, select a band,
then press the preset button.

FOLDER Bar
Press either side to display and select an
RDS category.

18 ACURA ILX-31TX66500.book  183 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Audio System Basic Operation

u

Playing AM/FM Radio

184

Features

Provides text data information related to your selected RDS-capable FM station.

■

RDS Information

1. Press the SETUP button and rotate

 to

select RDS Information.

2. Each time you press

, the RDS

Information switches between on and off.

■

To find an RDS station from your selected program category

1. Press the FOLDER bar to display and select

an RDS category.

2. Use SKIP or SCAN to select an RDS station.

■

Radio Data System (RDS)

RDS Category

1

Playing AM/FM Radio

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Press the MODE button on the steering wheel.

2 Audio Remote Controls P. 174

You can store 6 AM stations and 12 FM stations into
the preset button memory. FM1 and FM2 let you
store 6 stations each.

Auto Select function scans and stores up to 6 AM
stations and 12 FM stations with a strong signal into
the preset button memory.

If you do not like the stations auto select has stored,
you can manually store your preferred frequencies.

18 ACURA ILX-31TX66500.book  184 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

185

uu

Audio System Basic Operation

u

Playing a CD

Continued

Features

Playing a CD

Your audio system supports audio CDs, CD-Rs and CD-RWs in either MP3, WMA or
AAC format. With the CD loaded, press the CD button.

SCAN Button
You will get a 10-second sampling of each song.

●

Press to sample all tracks on the CD (all files in
the current folder in MP3, WMA or AAC).

●

Press and hold to sample the first file in each of
the main folders (MP3, WMA or AAC).

●

To turn off scan, press the button.

CD Slot
Insert a CD about halfway into the CD slot.

SKIP Bar
Press

 or

 to change tracks (files in

MP3, WMA or AAC).
Press and hold to move rapidly within a
track/file

Selector Knob
Turn to change tracks/files. Turn to select
an item, then press to set your selection.

CD Button
Press to play a CD.

 (CD Eject) Button

Press to eject a CD.

BACK Button
Press to go back to the previous display.

FOLDER Bar
Press

(

+ to skip to the next folder, and

(

-

to skip to the beginning of the previous
folder in MP3, WMA or AAC.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

SETUP Button
Press to display menu items.

18 ACURA ILX-31TX66500.book  185 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Audio System Basic Operation

u

Playing a CD

186

Features

1. Press

 to switch the display to a folder list.

2. Rotate

 to select a folder.

3. Press

 to change the display to a list of

files in that folder.

4. Rotate

 to select a file, then press

.

■

How to Select a File from a Folder with the Selector Knob
(MP3/WMA/AAC)

1

Playing a CD

NOTICE

Do not use CDs with adhesive labels. The label can
cause the CD to jam in the unit.

WMA files protected by digital rights management
(DRM) cannot be played.
The audio system displays Unplayable File, then
skips to the next file.

Text data appears on the display under the following
circumstances:

•

When you select a new folder, file, or track.

•

When you change the audio mode to CD.

•

When you insert a CD.

If you eject the CD but do not remove it from the slot,
the system reloads the CD automatically after several
seconds.

Folder Selection

Track Selection

18 ACURA ILX-31TX66500.book  186 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

187

uu

Audio System Basic Operation

u

Playing a CD

Features

You can select repeat and random modes when playing a track or file.

1. Press the SETUP button.

2. Rotate

 to select Play Mode, then press

.

3. Rotate

 to select a mode, then press

.

■

To turn off a play mode

1. Press the SETUP button.
2. Rotate

 to select Play Mode, then press

.

3. Rotate

 to select Normal Play, then press

.

■

How to Select a Play Mode

1

How to Select a Play Mode

Press the BACK button to go back to the previous
display, and press the SETUP button to cancel this
setting mode.

Play Mode Menu Items
Normal Play
Repeat One Track: Repeats the current track/file(s).
Repeat One Folder (MP3/WMA/AAC): Repeats all
files in the current folder.
Random in Folder (MP3/WMA/AAC): Plays all files
in the current folder in random order.
Random All: Plays all tracks/files in random order.

Play Mode
Items

18 ACURA ILX-31TX66500.book  187 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

188

uu

Audio System Basic Operation

u

Playing an iPod

Features

Playing an iPod

Connect the iPod using your USB connector to the USB adapter cable, then press the
AUX button.

2 USB Adapter Cable

*

 P. 171

AUX Button
Press to select iPod (if connected).

Album Art

USB Indicator
Appears when an iPod is connected.

Selector Knob
Turn to change songs. Turn to select an item,
then press to set your selection.

BACK Button
Press to go back to the previous display.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

SKIP Bar
Press

 or

 to change songs.

Press and hold to move rapidly within a
song.

SETUP Button
Press to display menu items.

* Not available on all models

18 ACURA ILX-31TX66500.book  188 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

189

uu

Audio System Basic Operation

u

Playing an iPod

Features

1. Press

 to display the iPod menu.

2. Rotate

 to select a menu.

3. Press

 to display the items on that menu.

4. Rotate

 to select an item, then press

.

■

How to Select a File from the iPod Menu

1

Playing an iPod

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle's audio system.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 241

iPod Menu

18 ACURA ILX-31TX66500.book  189 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Audio System Basic Operation

u

190

Features

You can select repeat and shuffle modes when playing a file.

1. Press the SETUP button.

2. Rotate

 to select Play Mode, then press

.

3. Rotate

 to select a mode, then press

.

■

To turn off a play mode

1. Press the SETUP button.
2. Rotate

 to select Play Mode, then press

.

3. Rotate

 to select Normal Play, then press

.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Normal Play
Repeat Off: Turns off the repeat mode.
Repeat One Track: Repeats the current track.
Shuffle Off: Turns off the shuffle mode.
Shuffle: Plays all available files in a selected list
(playlists, artists, albums, songs, genres, or
composers) in random order.
Shuffle Albums: Plays all available albums in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.

Play Mode
Items

18 ACURA ILX-31TX66500.book  190 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

191

uu

Audio System Basic Operation

u

Playing Internet Radio

Continued

Features

Playing Internet Radio

Activate Pandora®, and connect the iPhone using your USB connector to the USB
adapter cable, then press the AUX button.

2 USB Adapter Cable

*

 P. 171

U.S. models

iPhone use only

AUX Button
Press to select iPhone (if connected when
the Pandora® application is activated).

Rating Icon

Selector Knob
Press to enter PANDORA MENU.
Press and turn to select an item, then press to set
your selection.

BACK Button
Press to go back to the previous display.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

SKIP Bar
Press

 to skip a song.

SETUP Button
Press to display menu items.

FOLDER Bar
Press

(

+ to the next station. Press

(

- to the

previous station.

Album Art

* Not available on all models

18 ACURA ILX-31TX66500.book  191 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Audio System Basic Operation

u

Playing Internet Radio

192

Features

You can operate some of the Pandora menu items from your vehicle’s audio system.
The available items are:
• Station List (QuickMix is also available)
• Like
• Dislike
• Resume/Pause
• SKIP
• Bookmark This Song
• Bookmark This Artist

■

Operating a menu item

1. Press

 to display the PANDORA MENU.

2. Rotate

 to select a menu.

3. Press

 to display the items on that menu.

■

Pandora® Menu

1

Playing Internet Radio

Pandora® is a personalized Internet radio service that
selects music based on an artist, song, or genre a user
enters, and streams what is likely to be of interest.

To use this service in your vehicle, the Pandora® app
must first be installed on your iPhone. Visit
www.pandora.com. for more information.

If you cannot operate Pandora® through the audio
system, it may be streaming through Bluetooth®
Audio. Make sure Pandora® mode on your audio
system is selected.

1

Pandora® Menu

Available operating functions vary on software
versions. Some functions may not be available on the
vehicle's audio system.

If there is a problem, you may see an error message
on the audio/information screen.

2 Pandora® P. 243

There are restrictions on the number of songs you
can skip or dislike in a given hour.

18 ACURA ILX-31TX66500.book  192 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

193

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Continued

Features

Playing a USB Flash Drive

Your audio system reads and plays sound files on a USB flash drive in either MP3,
WMA or AAC

*1

 format.

Connect your USB flash drive to the USB adapter cable, then press the AUX button.

2 USB Adapter Cable

*

 P. 171

*1:Only AAC format files recorded with iTunes are playable on this unit.

BACK Button
Press to go back to the previous display.

SKIP Bar
Press

 or

 to change files.

Press and hold to move rapidly within a
file.

SETUP Button
Press to display menu items.

Selector Knob
Press and turn to select a file, then press
to set your selection.

AUX Button
Press to select USB flash drive
(if connected).

VOL/

 (Volume/Power) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

FOLDER Bar
Press

(

+ to skip to the next folder, and

(

-

to skip to the beginning of the previous
folder.

SCAN Button
You will get a 10-second sampling of each file.

●

Press to sample all files in the current folder.

●

Press and hold to sample the first file in each
of the main folders.

●

To turn off scan, press the button.

USB Indicator
Appears when a USB flash drive is
connected.

* Not available on all models

18 ACURA ILX-31TX66500.book  193 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

194

Features

1. Press

 to switch the display to a folder list.

2. Rotate

 to select a folder.

3. Press

 to change the display to a list of

files in that folder.

4. Rotate

 to select a file, then press

.

■

How to Select a File from a Folder with the Selector Knob

1

Playing a USB Flash Drive

Use the recommended USB flash drives.

2 General Information on the Audio System

P. 246

Files in WMA format protected by digital rights
management (DRM) are not played.
The audio system displays Unplayable File, and then
skips to the next file.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 241

Folder Selection

Track Selection

18 ACURA ILX-31TX66500.book  194 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

195

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Features

You can select repeat and random modes when playing a file.

1. Press the SETUP button.

2. Rotate

 to select Play Mode, then press

.

3. Rotate

 to select a mode, then press

.

■

To turn off a play mode

1. Press the SETUP button.
2. Rotate

 to select Play Mode, then press

.

3. Rotate

 to select Normal Play, then press

.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Normal Play
Repeat One Track: Repeats the current file.
Repeat One Folder: Repeats all files in the current
folder.
Random in Folder: Plays all files in the current folder
in random order.
Random All: Plays all files in random order.

Play Mode
Items

18 ACURA ILX-31TX66500.book  195 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分
