Acura ILX (2018 year). Manual

100

Gauges and Multi-Information Display

Multi-Information Display

strum

nt Pa

nel

■

Customization flow

Press the

button to select Vehicle Settings and press the SEL/RESET button.

Vehicle Settings

“Trip A” Reset Timing

Language Selection

Adjust Outside Temp. Display

Memory Position Link

Door Unlock Mode

Keyless Access Light Flash

Driver Assist System Setup

Meter Setup

Driving Position Setup

Keyless Access Setup

“Trip B” Reset Timing

Turn by Turn Display

Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep

Lane Keeping Assist Suspend Beep

Blind Spot Info

Keyless Access Beep

ACC Display Speed Unit

Road Departure Mitigation Setting

SEL/RESET

Remote Start System On/Off

* Not available on all models

18 ACURA ILX-31TX66500.book 100 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

101

Gauges and Multi-Information Display

Multi-Information Display

Continued

strum

nt Pa

nel

Exit

Door Setup

Maintenance Info.

Default All

Lighting Setup

Key And Remote Unlock Mode

Auto Door Lock

Auto Door Unlock

Keyless Lock Answer Back

Security Relock Timer

Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

Maintenance Reset

SEL/RESET

18 ACURA ILX-31TX66500.book 101 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

102

Gauges and Multi-Information Display

Multi-Information Display

strum

nt Pa

nel

■

List of customizable options

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driver Assist
System
Setup

Forward Collision
Warning Distance

Changes at which distance CMBS

alerts.

Long/Normal

/Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of the ACC range.

On/Off

ACC Display Speed Unit

Changes the speed unit for ACC on the multi-
information display.

mph

/km/h (U.S.)

mph/km/h

(Canada)

Road Departure
Mitigation Setting

Changes the setting for the road departure mitigation
system.

Normal

/Wide/Warning

Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is suspended.

On/Off

Blind Spot Info

Changes the setting for the blind spot information.

Audible And Visual
Alert

/Visual Alert/Off

* Not available on all models

18 ACURA ILX-31TX66500.book 102 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

103

Gauges and Multi-Information Display

Multi-Information Display

Continued

strum

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Meter Setup

Language Selection

Changes the displayed language.

English

/Français/

Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few degrees.

-5°F ~ ±0°F

~ +5°F

(U.S.)
-3°C ~ ±0°C

~ +3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and elapsed
time A.

When Refueled/IGN Off/
Manually Reset

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and elapsed
time B.

When Refueled/IGN Off/
Manually Reset

Turn by Turn Display

Selects whether the turn-by-turn display comes on
during the route guidance.

/Off

* Not available on all models

18 ACURA ILX-31TX66500.book 103 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

104

Gauges and Multi-Information Display

Multi-Information Display

strum

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driving
Position
Setup

Memory Position Link

Turns the driving position memory system on and
off.

/Off

Keyless
Access
Setup

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

/All Doors

Keyless Access Light
Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

/Off

Keyless Access Beep

Causes the beeper to sound when you unlock/lock
the doors.

/Off

Remote Start System On/
Off

Turns the remote engine start feature on and off.

/Off

* Not available on all models

18 ACURA ILX-31TX66500.book 104 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

105

Gauges and Multi-Information Display

Multi-Information Display

Continued

strum

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay on
after you close the doors.

60sec/30sec

/15sec

Headlight Auto Off
Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60sec/30sec/15sec

/0sec

Auto Light Sensitivity

Changes the timing for the headlights to come on.

Max/High/Mid

/Low/Min

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

/Shift

From P/Off

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When Driver’s
Door Opens

/All Doors

When Shifted To Park/All
Doors When Ignition
Switched Off/Off

Key And Remote Unlock
Mode

Sets up either the driver’s door or all doors to unlock
on the first operation of the remote or built-in key.

Driver Door

/ All Doors

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

/Off

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.

90sec/60sec/30sec

18 ACURA ILX-31TX66500.book 105 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

106

Gauges and Multi-Information Display

Multi-Information Display

strum

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Maintenance
Info.

Maintenance Reset

Resets/Cancels the engine oil life display when you
have performed the maintenance service.

Cancel/Reset

Default All

—

Cancels/Resets all the customized settings as
default.

Cancel/Set

18 ACURA ILX-31TX66500.book 106 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

107

Gauges and Multi-Information Display

Multi-Information Display

Continued

strum

nt Pa

nel

■

Example of customization settings

The steps for changing the “Trip A” Reset Timing setting to When Refueled are
shown below. The default setting for “Trip A” Reset Timing is Manually Reset.

1. Press and release the

button to

select Vehicle Settings, then press the
SEL/RESET button.

2. Press and release the

button until

Meter Setup appears on the display.

3. Press the SEL/RESET button.

Language Selection appears first on
the display.

*1 : Models with full color display
*2 : Models without full color display

18 ACURA ILX-31TX66500.book 107 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

108

Gauges and Multi-Information Display

Multi-Information Display

strum

nt Pa

nel

4. Press and release the

button until

“Trip A” Reset Timing appears on the
display, then press the SEL/RESET button.

The display switches to the
customization setup screen, where you
can select When Refueled, IGN Off,
Manually Reset, or Exit.

5. Press and release the

button select

When Refueled, then press the SEL/
RESET button.

The When Refueled Setup screen
appears, then the display returns to the
customization menu screen.

6. Press and release the

button until

Exit appears on the display, press the SEL/
RESET button.

7. Repeat Step 6 until you return to the

normal screen.

*1 : Models with full color display
*2 : Models without full color display

18 ACURA ILX-31TX66500.book 108 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

110

Co
ntrols

Clock

You can adjust the time in the clock display, with the power mode in ON.

Adjusting the Clock

1. Press the SETUP button.
2. Rotate

to select Adjust Clock on the

screen.

3. Press .

Adjust Clock appears.

4. Rotate

to select the item you want to

adjust (12/24 hour mode, hour, minute).

Then press

5. Rotate

to make the adjustment.

6. Press

to enter your selection. The display

returns to Adjust Clock. Repeat steps 4 to
6 to adjust other items.

7. To enter the selection, rotate

and select

Set, then press

Clock

The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.

Models with navigation system

Models without navigation system

Adjusting the Clock

These indications are used to show how to operate
the selector knob.
Rotate

to select.

Press

to enter.

Models with one display

SETUP Button

18 ACURA ILX-31TX66500.book 110 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

111

Clock

Adjusting the Clock

Co
ntrols

1. Press the SETTINGS button.
2. Rotate

to select System Settings, then

press .

Repeat the procedure to select Clock,
then Clock Adjustment.

3. Rotate

to change hour, then press

4. Rotate

to change minute, then press

Adjusting the Clock

The clock is automatically updated when your
smartphone is connected to the audio system with
Sync Clock w/ Smartphone setting.

2 Customized Features

P. 263

Models with two displays

* Not available on all models

18 ACURA ILX-31TX66500.book 111 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

112

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the keyless access remote to start and
stop the engine, to lock and unlock the doors
and to open the trunk.

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 129

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the keyless access system may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the two-way
keyless access remote.

2 Remote Engine Start with Vehicle

Feedback

P. 358

Models with two-way keyless access remote

Models without two-way keyless
access remote

Models with two-way keyless access
remote

* Not available on all models

18 ACURA ILX-31TX66500.book 112 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

113

Locking and Unlocking the Doors

Key Types and Functions

Continued

Co
ntrols

The built-in key can be used to lock/unlock the
doors when the keyless access remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
keyless access remote until it clicks.

■

Built-in Key

Built-in Key

Release Knob

Models without two-way keyless
access remote

Models with two-way keyless access
remote

Release Knob

Built-in Key

18 ACURA ILX-31TX66500.book 113 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking and Unlocking the Doors

Low Keyless Access Remote Signal Strength

114

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

Low Keyless Access Remote Signal Strength

The vehicle transmits radio waves to locate the keyless access remote when locking/
unlocking the doors, opening the trunk, or to start the engine.

In the following cases, locking/unlocking the doors, opening the trunk, or starting
the engine may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the keyless access remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the keyless access remote.

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

Low Keyless Access Remote Signal Strength

Communication between the keyless access remote
and the vehicle consumes the keyless access remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the keyless access
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

18 ACURA ILX-31TX66500.book 114 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

115

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the keyless access remote,
you can lock/unlock the doors and open the
trunk.
You can lock/unlock the doors and trunk
within a radius of about 32 inches (80 cm) of
the outside door handle or trunk release
button.

■

Locking the doors and the trunk

Press the door lock button on the front door.

Some exterior lights flash; the beeper
sounds; all the doors lock; and the
security system sets.

■

Using the Keyless Access System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors.
No doors opened: The light fades out after 30
seconds.
Doors relocked: The light goes off immediately.

2 Interior Lights P. 159

Door Lock Button

Using the Keyless Access System

If you do not open a door within 30 seconds of
unlocking the vehicle with the keyless access system,
the doors will automatically relock.

You can lock or unlock doors using the keyless access
system only when the power mode is in VEHICLE OFF.

18 ACURA ILX-31TX66500.book 115 ページ２０１７年８月２５日　金曜日　午前１１時３１分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Acura ILX (2018 year). Manual - part 7
