360

uu

Before Driving

u

Driving Preparation

Driving

• Be sure items placed on the floor behind the front seats cannot roll under the

seats.

u

They can interfere with the driver’s ability to operate the pedals, the operation
of the seats, or the operation of the sensors under the seats.

• Everyone in the vehicle must fasten their seat belt.

2 Fastening a Seat Belt P. 39

• Make sure that the indicators in the instrument panel come on when you start the

vehicle, and go off soon after.

u

Always have a dealer check the vehicle if a problem is indicated.

2 Indicators P. 74

17 ACURA RLX E-AWD-31TY36300.book  360 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

361

uu

Before Driving

u

Maximum Load Limit

Continued

Driving

Maximum Load Limit

The maximum load for your vehicle is 850 lbs (385 kg). See the
Tire and Loading Information label attached to the driver’s doorjamb.

This figure includes the total weight of all occupants, cargo, and
accessories, and the tongue load if you are towing a trailer.

Steps for Determining Correct Load Limit -
(1) Locate the statement “The combined weight of occupants and

cargo should never exceed XXX kg or XXX lbs.” on your
vehicle’s placard.

(2) Determine the combined weight of the driver and passengers

that will be riding in your vehicle.

(3) Subtract the combined weight of the driver and passengers

from XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and

luggage load capacity. For example, if the “XXX” amount
equals 1,400 lbs. and there will be five 150 lb. passengers in
your vehicle, the amount of available cargo and luggage load
capacity is 650 lbs. (1,400 - 750 (5 x 150) = 650 lbs.)

1

Maximum Load Limit

Gross Vehicle Weight Rating (GVWR):
The maximum allowable weight of the vehicle, all
occupants, all accessories and all cargo.

2 Specifications P. 554

Gross Axle Weight Rating (GAWR):
The maximum allowable weight of the vehicle axle.

2 Specifications P. 554

3

WARNING

Overloading or improper loading
can affect handling and stability
and cause a crash in which you
can be hurt or killed.

Follow all load limits and other
loading guidelines in this manual.

Label Example

17 ACURA RLX E-AWD-31TY36300.book  361 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

362

uu

Before Driving

u

Maximum Load Limit

Driving

(5) Determine the combined weight of luggage and cargo being

loaded on the vehicle. That weight may not safely exceed the
available cargo and luggage load capacity calculated in step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will

be transferred to your vehicle. Consult this manual to
determine how this reduces the available cargo and luggage
load capacity of your vehicle.

In addition, the total weight of the vehicle, all occupants,
accessories, cargo, and trailer tongue load must not exceed the
Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight
Rating (GAWR). Both are on a label on the driver’s doorjamb.

Load Limits Example

Example1

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 2 = 300 lbs

(68 kg x 2 = 136 kg)

Cargo Weight

550 lbs

(249 kg)

Example2

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 5 = 750 lbs

(68 kg x 5 = 340 kg)

Cargo Weight

100 lbs
(45 kg)

17 ACURA RLX E-AWD-31TY36300.book  362 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

363

Driving

Towing a Trailer

Your vehicle is not designed to tow a trailer. Attempting to do so can void your
warranties.

Towing Your Vehicle

Your vehicle is not designed to be towed behind a motor home. If your vehicle needs
to be towed in an emergency, refer to the emergency towing information.

2 Emergency Towing P. 548

17 ACURA RLX E-AWD-31TY36300.book  363 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

364

Driving

When Driving

Turning on the Power

1. Make sure the parking brake is applied.

u

The electric parking brake indicator
comes on for 15 seconds when you pull
up the electric parking brake switch.

2. Depress the brake pedal.

u

Make sure the transmission is in

(

P.

1

When Driving

When you set the power mode to ON, you may feel
as if the brake pedal is sinking down. This is normal.

1

Turning on the Power

Keep your foot firmly on the brake pedal when
starting the power system.

The engine is harder to start in cold weather and in
thinner air found at altitudes above 8,000 feet (2,400
meters).

When turning on the power system in cold weather,
turn off all electrical accessories such as the lights,
climate control system, and rear defogger in order to
reduce 12-volt battery drain.

If you live in a region where winter is extremely cold,
an engine block heater and transmission clutch
actuator heater will improve starting and reduce the
warming time required before driving. Consult a
dealer for details.

If the exhaust system sounds abnormal or you can
smell exhaust gas inside the vehicle, have your vehicle
checked by a dealer. There may be a problem with
the engine or exhaust system.

Electric Parking
Brake Switch

Brake Pedal

17 ACURA RLX E-AWD-31TY36300.book  364 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

Continued

365

uu

When Driving

u

Turning on the Power

Driving

3. Press the POWER button without

depressing the accelerator pedal.

u

The Ready To Drive message appears
on the multi-information display.

u

When the ambient temperature is
extremely low, the vehicle does not move
until certain conditions are met.
A warning message appears instead of
Ready To Drive.

2 Multi-Information Display Warning

and Information Messages P. 99

u

If the High Voltage battery is fully
charged, the gasoline engine may not
start.

u

If the High Voltage battery charge level is
low, the gasoline engine starts.

You can turn the power system off when the vehicle is completely stopped.
1. Select

(

P.

2. Press the POWER button.

1

Turning on the Power

The immobilizer system protects your vehicle from
theft.
If an improperly coded device is used, the power
system does not activate.

2 Immobilizer System P. 149

Bring the keyless access remote close to the POWER
button if the battery in the keyless access remote is
weak.

2 If the Keyless Access Remote Battery is

Weak P. 530

The power system may not activate if the keyless
access remote is subjected to strong radio waves.

Do not hold the POWER button to start the power
system.
If the power system does not start, wait at least 30
seconds before trying again.

■

Stopping the Power System

17 ACURA RLX E-AWD-31TY36300.book  365 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

uu

When Driving

u

Turning on the Power

366

Driving

You can remotely turn the power system on using the two-way keyless access
remote from extended distances.

■

To turn the power system on

The power system is on for up to 10 minutes without you starting the vehicle.
To extend the time for another 10 minutes during the first 10 minutes, press the

 button, then press and hold the

 button.

u

The amber LED blinks, then the green LED comes back on if a 10-minute
extension request was transmitted successfully.

After pressing the (lock) button, wait for the green LED to blink. This indicates that
the all the doors and the trunk are locked.

■

Remote Engine Start with Vehicle Feedback

*

1

Remote Engine Start with Vehicle Feedback

*

If there are buildings and obstacles between your
vehicle and the remote, the range will be reduced.
This distance may vary by external electrical
interference.
The power system may not be turned on by the
remote engine start if:

•

You have disabled a remote engine start setting
using the multi-information display.

•

The power mode is not in VEHICLE OFF (LOCK).

•

The gear is in a position other than

(

P.

•

The hood is open, or any door or the trunk is
unlocked.

•

You have already used the remote twice to turn the
power system on.

•

Another registered keyless access remote is in the
vehicle.

•

There is any antenna failure.

•

Door is unlocked with the built-in key.

3

WARNING

Engine exhaust contains toxic carbon
monoxide.

Breathing carbon monoxide can kill you
or cause unconsciousness.

Never use the remote engine starter
when the vehicle is parked in a garage
or other area with limited ventilation.

With the doors locked, Press the

 button,

then press and hold the

 button.

Amber LED: Blinks when any button is pressed.

Continues to blink
during a vehicle
self check until the
power system is
turned on.

Go within the range,
and try again.

Green LED: Comes on while
the power system is on.

Red LED: Blinks when the
remote is out of the keyless
access system range.

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  366 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

Continued

367

uu

When Driving

u

Turning on the Power

Driving

■

To turn the power system off

Press and hold the

 button

for one second.

Go within the range,
and try again.

Amber LED: Blinks when any
button is pressed.

Red LED:

●

Comes on for one second to let you know
that the power system is turned off.

●

Blinks when the remote is out of the keyless
access system range. The power system will not
be turned off.

1

Remote Engine Start with Vehicle Feedback

*

•

The engine oil pressure is low.

•

The engine coolant temperature is extremely high.

•

The telematics unit malfunctions.

•

The security system alarm is not set.

Before turning the power system on, make sure to
check the door lock status using the remote. When
you press the

 button, wait for the green LED to

blink. If the red LED turns on, the doors and trunk did
not lock, and the power system is not turned on.

While the power system is on, the vehicle will
automatically precondition inside the vehicle.
When it is warm outside:

•

The air conditioning is activated in recirculation
mode.

When it is cold outside:

•

The defroster is activated at a moderately warm
temperature.

•

The rear defogger and door mirror heaters are
activated.

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  367 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

uu

When Driving

u

Turning on the Power

368

Driving

1. While depressing the brake pedal, press the POWER button.

2. Change the gear position to

(

D. Select

(

R when reversing.

3. With the parking brake applied, release the brake pedal and gently depress the

accelerator pedal.

u

Make sure the electric parking brake indicator goes off.

4. Gradually release the brake pedal and gently depress the accelerator pedal to pull

away.

■

Hill Start Assist System

Hill start assist keeps the brake engaged briefly to help prevent the vehicle from
rolling on inclines as you move your foot from the brake pedal to the accelerator.

Change to

(

D when facing uphill, or

(

R when facing downhill, then release the

brake pedal.

■

Starting to Drive

1

Starting to Drive

You can also release the parking brake by pressing
the electric parking brake switch while depressing the
brake pedal.
When facing downhill, you can start your vehicle
more smoothly by manually releasing it with the
electric parking brake switch than by releasing it with
the accelerator pedal.

The power sytem is turned off when the gear position
is changed from

(

P before the POWER button is

pressed. Follow the step 1 when starting to drive.

When the engine was started using the two-way
keyless access remote

*

When the engine was started using the two-way keyless access remote

*

When the engine was started in any case

1

Hill Start Assist System

Hill start assist may not prevent the vehicle from
rolling downhill on a very steep or slippery slope, and
does not operate on small inclines.

Hill start assist is not a replacement for the parking
brake.

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  368 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

369

uu

When Driving

u

Precautions While Driving

Continued

Driving

Precautions While Driving

Avoid driving in deep water and on flooded roads. This can damage the power
system or driveline, or cause electrical component failure.

■

In Rain

1

Precautions While Driving

NOTICE

Do not select a shift button while pressing the
accelerator pedal. You could damage the
transmission.

NOTICE

The following can damage the under spoiler:

•

Parking the vehicle by a parking block

•

Parallel parking along the road shoulder

•

Driving toward the bottom of a hill

•

Driving up or down to a different surface level
(such as a road shoulder)

•

Driving on a rutted or bumpy road

•

Driving on a road with potholes.

NOTICE

If you repeatedly turn the steering wheel at an
extremely low speed, or hold the steering wheel on
the full left or right position for a while, the electric
power steering (EPS) system heats up. The system
goes into a protective mode, and limits its
performance. The steering wheel becomes harder
and harder to operate. Once the system cools down,
the EPS system is restored.
Repeated operation under these conditions can
eventually damage the system.

If the power mode is set to ACCESSORY while
driving, the power system will shut down and all
steering and brake power assist functions will stop,
making it difficult to control the vehicle.

17 ACURA RLX E-AWD-31TY36300.book  369 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

uu

When Driving

u

Dual Clutch Transmission

370

Driving

If there is a strong impact with something under the vehicle, stop in a safe location.
Check the underside of the vehicle for damage or any fluid leaks.

Dual Clutch Transmission

As with a conventional gasoline-powered vehicle with an automatic transmission,
this vehicle will creep.
Keep the brake pedal firmly depressed when stopped.

Quickly depressing the accelerator pedal while driving uphill may cause the
transmission to drop to a lower gear, unexpectedly increasing vehicle speed. Depress
the accelerator pedal carefully, especially on slippery roads and curves.

■

Other Precautions

■

Creeping

■

Kickdown

1

Precautions While Driving

Do not press the

(

N button, as you will lose

regenerative braking (and acceleration) performance.

During the first 600 miles (1,000 km) of operation,
avoid sudden acceleration or full throttle operation so
as to not damage the engine or powertrain.

Avoid hard braking for the first 200 miles (300 km).
You should also follow this when the brake pads are
replaced.

17 ACURA RLX E-AWD-31TY36300.book  370 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

371

uu

When Driving

u

Shifting

Continued

Driving

Shifting

Change the gear position in accordance with your driving needs.

■

Shift button positions

1

Shifting

While the High Voltage battery level is full, or the
High Voltage battery temperature is low,
regenerative braking may become less effective.

To prevent malfunction and unintended
engagement:

•

Do not spill any liquids on or around shift buttons.

•

Do not place or drop any objects on or around shift
buttons.

•

Do not let passengers or children operate the shift
buttons.

You may occasionally find that it takes longer than
usual for the vehicle to start moving when you select

(

R, release the brake pedal, and/or depress the

accelerator pedal. This may occur when the High
Voltage battery level is extremely low, and does not
indicate a vehicle malfunction.

3

WARNING

The vehicle can roll away if left unattended
without confirming that Park is engaged.

Always keep your foot on the brake pedal
until you have confirmed that

(

P

 is shown

on the gear position indicator.

Park
Used when parking or starting the power
system

Reverse
Used when reversing

Neutral
Used when idling

Drive
Used for:

●

Normal driving (gears change between 1st
and 7th automatically)

●

Temporarily driving in the sequential
mode

●

Driving in the sequential mode (when
driving in SPORT mode)

17 ACURA RLX E-AWD-31TY36300.book  371 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

uu

When Driving

u

Shifting

372

Driving

■

(

P (park) button

The gear position changes to

(

P when you

press the

(

P button while the vehicle is

parked with the power mode in ON.
The indicators on the sides of the

(

P button

come on.

1

Shifting

The beeper sounds when you depress the accelerator
pedal with the gear position in

(

N.

Change the gear position to

(

D or

(

R with the brake

pedal depressed.

When shifting gears in extremely low temperatures
(-22°F/-30°C), there may be a short delay before the
shift is indicated in the display. Always confirm you
are in the correct gear before driving.

(

P Button

17 ACURA RLX E-AWD-31TY36300.book  372 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

Continued

373

uu

When Driving

u

Shifting

Driving

■

Shift Operation

1

Shift Operation

NOTICE

When you change

(

D to

(

R and vice versa, come to

a complete stop and keep the brake pedal depressed.
Operating the shift button before the vehicle has
come to a complete standstill can damage the
transmission.

Use the gear position indicator and the shift button
indicator to check the gear position before selecting
a shift button.

If the indicator of the currently selected gear position,
or all the gear position indicators are blinking
simultaneously, there is a problem with the
transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer’s red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

When the engine speed is increased while the
transmission is in

(

N,

(

P or

(

R, the fuel supply may

be cut off even without the engine speed entering
the tachometer’s red zone.

The beeper sounds once when you change to

(

R.

Gear Position Indicator

Tachometer’s red zone

Press the

(

P button.

Press back the

(

R button.

Press the

(

N button.

Press the

(

D button.

Shift Button
Indicator

M (sequential mode)
Indicator

Sequential Mode Gear
Selection Indicator

17 ACURA RLX E-AWD-31TY36300.book  373 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

uu

When Driving

u

Shifting

374

Driving

■

When opening the driver’s door

If you open the driver’s door under the following conditions, the gear position
automatically changes to

(

P.

• The vehicle is in stationary with the power mode in ON, or moving at 1 mph (2

km/h) or slower.

• The transmission is in other than

(

P.

• You have unfastened the driver side seat belt.

u

If you manually change the gear position from

(

P with the brake pedal

depressed, the gear position will automatically return to

(

P once you release

the brake pedal.

■

When turning off the power mode

If you turn the power system off while the vehicle is stationary, and the transmission
is in other than

(

P, the gear position automatically changes to

(

P.

■

If you want to keep the transmission in

(

N position (car wash mode)

With the engine running:
1. Press and hold the brake pedal.
2. Within five seconds select

(

N.

3. Then press the POWER button.

u

This puts the vehicle in car wash mode which must be used when your vehicle
is pulled through a conveyor type automatic car wash where you or an
attendant do not remain in the vehicle.

u

The gear position remains in

(

N with the power mode in ACCESSORY for 15

minutes, then, it automatically changes to

(

P and the power mode changes to

OFF.

Manually changing to

(

P cancels ACCESSORY mode. The

(

P indicator comes on

and the power mode changes to OFF.

1

When opening the driver’s door

While the system is designed to automatically change
the gear position to

(

P under the described

conditions, in the interest of safety you should always
select

(

P before opening the driver's door.

Make sure to park the vehicle in a safe place.

2 When Stopped P. 434

If you want to drive the vehicle after the gear position
has automatically changed to

(

P under the described

conditions, close the door, fasten the seat belt,
depress the brake pedal, then change the gear
position.

If you leave the vehicle, turn off the power system
and lock the doors.

17 ACURA RLX E-AWD-31TY36300.book  374 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

375

uu

When Driving

u

Shifting

Continued

Driving

■

Restriction on selecting a gear position

You cannot select a gear position under certain circumstances that may lead to unexpected accidents.

When the
transmission is in:

1. Under the circumstances
of that:

2. You cannot select:

3. The gear position
remains in/changes to:

How to change the
gear position

(

P

The brake pedal is not
depressed.

Other gear position

(

P

Release the accelerator
pedal and depress the
brake pedal.

The accelerator pedal is
depressed.

(

N

The vehicle is moving at low
speed without the brake pedal
depressed.

(

N

The vehicle is moving at low
speed with the accelerator
pedal depressed.

(

N

 or (

D

The vehicle is moving forward.

(

R

Park your vehicle in a
safe place.

(

R

 or (

N

The vehicle is moving backward.

(

D

(

R

, (

N

, or (

D

The vehicle is moving.

(

P

(

P

 or (

N

The READY indicator is not on.

A gear position other than

(

P

or

(

N

(

P

 or (

N

Make sure that the
READY indicator
comes on.

17 ACURA RLX E-AWD-31TY36300.book  375 ページ  ２０１６年６月１７日　金曜日　午前８時２９分
