280

uu

General Information on the Audio System

u

Recommended CDs

Features

Recommended CDs

• Use only high-quality CD-R or CD-RW discs labeled for audio use.
• Use only CD-R or CD-RW discs on which the recordings are closed.
• Play only standard round-shaped CDs.

• Some software files may not allow for audio play or text data display.
• Some versions of MP3, WMA or AAC formats may be unsupported.

1

Recommended CDs

A Dual-disc cannot play on this audio unit. If recorded
under certain conditions, a CD-R or CD-RW may not
play either.

For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, and DTS Digital
Surround and DTS Neural Surround are trademarks of
DTS, Inc. © DTS, Inc. All Rights Reserved.

■

CDs with MP3, WMA or AAC files

The CD packages or jackets should have one of these marks.

Also includes:

17 ACURA RLX E-AWD-31TY36300.book  280 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

281

uu

General Information on the Audio System

u

Recommended CDs

Features

■

Protecting CDs

Follow these precautions when handling or storing CDs:
• Store a CD in its case when it is not being played.
• When wiping a CD, use a soft clean cloth from the center to the outside edge.
• Handle a CD by its edge. Never touch either surface.
• Never insert foreign objects into the CD player.
• Keep CDs out of direct sunlight and extreme heat.
• Do not place stabilizer rings or labels on the CD.
• Avoid fingerprints, liquids, and felt-tip pens on the CD.

1

Protecting CDs

NOTICE

Do not insert a damaged CD. It may be stuck inside
and damage the audio unit.

Examples:

●

Damaged CDs

Bubbled/
Wrinkled

With Label/
Sticker

Using
Printer Label
Kit

Sealed

With Plastic Ring

●

Poor quality
CDs

Chipped/
Cracked

Warped

Burrs

●

Small CDs

3-inch
(8-cm)
CD

●

Bubbled, wrinkled, labeled, and
excessively thick CDs

17 ACURA RLX E-AWD-31TY36300.book  281 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

282

uu

General Information on the Audio System

u

Compatible iPod, iPhone, and USB Flash Drives

Features

Compatible iPod, iPhone, and USB Flash Drives

• Use a recommended USB flash drive of 256 MB or higher.
• Some digital audio players may not be compatible.
• Some USB flash drives (e.g., a device with security lockout) may not work.
• Some software files may not allow for audio play or text data display.
• Some versions of MP3, WMA, or AAC formats may be unsupported.

■

iPod and iPhone Model Compatibility

Model

iPod (5th generation)

iPod classic 80GB/160GB (launch in 2007)

iPod classic 120GB (launch in 2008)
iPod classic 160GB (launch in 2009)

iPod nano (1st to 7th generation) released between 2005 and 2012

iPod touch (1st to 5th generation) released between 2007 and 2012

iPhone 3G/iPhone 3GS/iPhone 4/iPhone 4s/iPhone 5/iPhone 5c/iPhone 5s/iPhone 6/

iPhone 6 Plus/iPhone 6s/iPhone 6s Plus

■

USB Flash Drives

1

iPod and iPhone Model Compatibility

This system may not work with all software versions
of these devices.

1

USB Flash Drives

Files on the USB flash drive are played in their stored
order. This order may be different from the order
displayed on your PC or device.

17 ACURA RLX E-AWD-31TY36300.book  282 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

283

Continued

Features

Customized Features

Use the audio/information screen to customize certain features.

■

How to customize

Select your desired setting item by pressing the SETTINGS button, then rotating



while the power mode is ON and the vehicle is at a complete stop. Press

.

1

Customized Features

When you customize setting, make sure that the
vehicle is at a complete stop and shift to

(

P.

To customize other features, rotate

, move

,  ,

 or  , and press

.

2 List of customizable options P. 292

SETTINGS Button

Audio/Information Screen

17 ACURA RLX E-AWD-31TY36300.book  283 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

284

uu

Customized Features

u

Features

■

Customization flow

Song By Voice

Song By Voice Phonetic Modification

Phonebook Phonetic Modification

Press the SETTINGS button.







Guidance Volume

Voice Prompt



Message Auto Reading

Guidance Volume

Interface Dial Feedback

Verbal Reminder

Brightness

Contrast

Black Level











Bluetooth Status

Bluetooth Device List

Edit Pairing Code



Default

Sound/

Beep

Display

System

Settings

Bluetooth

Voice Reco

Sync Display Brightness



Sound Volume



Opening

17 ACURA RLX E-AWD-31TY36300.book  284 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

285

uu

Customized Features

u

Continued

Features

System Device Information

Factory Data Reset



Background Color

Header Clock Display

Clock Reset

Auto Time Zone

Auto Daylight

Clock

Clock Adjustment

Clock Format

Clock







Units

Language

Voice Command Tips

Others





Wallpaper

Clock/Wallpaper

Type

17 ACURA RLX E-AWD-31TY36300.book  285 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

286

uu

Customized Features

u

Features

“Trip A” Reset Timing

“Trip B” Reset Timing

Language Selection

Adjust Outside Temp. Display











Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep



Turn By Turn Display

Default

Memory Position Link



Door Unlock Mode

Keyless Access Light Flash







Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

Vehicle

Settings

Meter/

Head-up

Display

Setup

Driver

Assist

System

Setup

Keyless

Access

Setup

Lighting

Setup

Keyless Access Beep

Lane Keeping Assist Suspend Beep

Blind Spot Info

Steering Wheel Movement At Entry/Exit

Auto Seat Belt Tension



Driving

Position

Setup

Display Speed Unit

Reactive Force Pedal

Head-up Warning

Road Departure Mitigation Setting

Remote Start System On/Off

*



* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  286 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

287

uu

Customized Features

u

Continued

Features



Fixed Guideline

Dynamic Guideline





Default

Rear

Camera

Cross Traffic Monitor

*1: Models with multi-view rear camera



Maintenance Reset

Maintenance Info.



Wiper Action

Wiper

Setup



Key And Remote Unlock Mode

Keyless Lock Answer Back

Security Relock Timer

Auto Door Lock

Auto Door Unlock





Door

Setup

Auto Folding Door Mirror



Camera

Settings

*1

17 ACURA RLX E-AWD-31TY36300.book  287 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

288

uu

Customized Features

u

Features



Fixed Guideline

Dynamic Guideline





Default

Guidelines

Cross Traffic Monitor



Automatically show

camera after reverse

Default camera mode in

forward

Preferences

Default camera mode in

reverse

Show camera when

decelerating

Clear parking guideline

automatically

Display

*2: Models with surround view camera system (MVCS)





Camera

Settings

*2

MVCS

17 ACURA RLX E-AWD-31TY36300.book  288 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

289

uu

Customized Features

u

Continued

Features





Default

Source Select Popup

HD Radio Mode

*, *1

Cover Art

*1

Connect Bluetooth Audio Device

*1

Bluetooth Device List

*1

Recording from CD

*1

Recording Quality

*1

HDD Info

*1

Update Gracenote Album Info

*1

Delete all HDD Data

*1





*1: May change depending on your currently selected source.

CD/HDD

Bluetooth

Other



Audio

Settings

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  289 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

290

uu

Customized Features

u

Features



Add Bluetooth

Device

Disconnect

Default





Phone

Connect Phone



Edit Bluetooth

Device

Add Bluetooth

Device



Bluetooth Device

List

Edit Speed Dial

Auto Transfer

Auto Answer

Ring Tone

Automatic Phone Sync

Use Contact Photo



Default



Default

Enable Text/Email

Select Account

New Text/Email Alert



Text/Email



Phone

Settings



17 ACURA RLX E-AWD-31TY36300.book  290 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

291

uu

Customized Features

u

Continued

Features

Auto Daylight

Clock Reset

Info Screen Preference



Clock Format

Auto Time Zone







Clock/Wallpaper Type

Clock Adjustment

Clock

Default



Others

Info

Settings

Navi

Settings

See the Navigation System Manual.

AcuraLink Subscription Status





AcuraLink Msg Notice

Delete AcuraLink Message

AcuraLink



17 ACURA RLX E-AWD-31TY36300.book  291 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

292

uu

Customized Features

u

Features

■

List of customizable options

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Display

Sync Display Brightness

Selects whether the display brightness synchronizes
with the instrument panel brightness.

On

*1

/Off

Brightness

Changes the brightness of the audio/information
screen.

—

Contrast

Changes the contrast of the audio/information screen.

—

Black Level

Changes the black level of the audio/information
screen.

—

Sound/
Beep

Guidance Volume

Changes the volume of the audio speakers.

—

Interface Dial Feedback

Sets if and when the system reads aloud a

selection made using the Interface Dial.

On/Off/Auto

*1

Message Auto Reading

Selects whether the system automatically reads

out messages, and, if selected, whether only

when driving.

On/Off/Auto

*1

Verbal Reminder

Turns the verbal reminders on and off.

On

*1

/Off

Blue-
tooth

Bluetooth Status

Turns the Bluetooth® on and off.

On

*1

/Off

Bluetooth Device List

Pairs a new phone to HFL, edits and deletes a
paired phone, and creates a security PIN.

2 Phone Setup P. 316

—

Edit Pairing Code

Changes a pairing code.

2 To change the pairing code setting P. 318

Random/Fixed

*1

17 ACURA RLX E-AWD-31TY36300.book  292 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

293

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Voice
Reco

Guidance Volume

Changes the volume of the voice prompt.

—

Voice Prompt

Turns the voice prompt on and off.

On

*1

/Off

Song By Voice

Turns the Song By Voice

TM

 on and off.

2 Song By Voice

TM

 (SBV) P. 262

On

*1

/Off

Song By Voice Phonetic
Modification

Modifies a voice command for music stored in
the HDD or an iPod.

2 Phonetic Modification P. 264

—

Phonebook Phonetic
Modification

Modifies a voice command for the phonebook.

2 Phonebook Phonetic Modification P. 331

—

Opening

Sound Volume

Changes the volume of the system’s startup sound.

—

Clock

Clock/
Wallpaper
Type

Clock

Changes the clock display type.

Analog/Digital

*1

/

Small Digital/Off

Wallpaper

●

Changes the wallpaper type.

●

Imports an image file for a new wallpaper.

●

Deletes an image file for a wallpaper.

2 Wallpaper Setup P. 228

Blank/Galaxy

*1

/

Metallic

Clock Adjustment

Adjusts Clock.

2 Clock P. 132

—

Clock Format

Selects the digital clock display from 12H to 24H.

12H

*1

/24H

Auto Time Zone

Sets the navigation system to automatically adjust
the clock when driving through different time zones.

On

*1

/Off

17 ACURA RLX E-AWD-31TY36300.book  293 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

294

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Clock

Auto Daylight

Sets the navigation system to automatically adjust
the clock (“spring ahead” or “fall back” by one
hour) when a daylight saving time change occurs.

On

*1

/Off

Clock Reset

Resets the settings of all items in the Clock group.

—

Others

Units

Changes the distance unit on the navigation map
screen.

mile

*1

/km (U.S.)

mile/km

*1

 (Canada)

Language

Changes the display language.

English

*1

/French/

Spanish

Voice Command Tips

Alerts you when manual control of the system is
disabled to prevent distraction while driving. Only
voice commands are available.

On

*1

/Off

Background Color

Changes the background color of the audio/
information screen and the On Demand Multi-
Use Display

TM

.

Blue

*1

/Amber/Red/

Green

Header Clock Display

Selects whether the clock display comes on.

On/Off

*1

System Device Information

Displays the system/device information.

—

Factory Data Reset

Resets all the settings to their factory default.

2 Defaulting All the Settings P. 306

—

Default

Cancels /Resets all customized items in the
System Settings group as default.

Default/OK

17 ACURA RLX E-AWD-31TY36300.book  294 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

295

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Driver
Assist
System
Setup

Forward Collision Warning
Distance

Changes at which distance the CMBS

TM

 alerts.

Long/Normal

*1

/

Short/Off

Head-up Warning

Turns the head-up warning on and off.

On

*1

/Off

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out of
the ACC with LSF range.

On/Off

*1

Road Departure Mitigation
Setting

Changes the setting for the road departure
mitigation system.

Normal

*1

/Wide/

Warning Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is
suspended.

On/Off

*1

Blind Spot Info

Changes the setting for the blind spot
information.

Audible And Visual
Alert

*1

/Visual Alert/

Off

Reactive Force Pedal

Change the amount of the accelerator pedal
resistance force.

High Force/Low
Force

*1

17 ACURA RLX E-AWD-31TY36300.book  295 ページ  ２０１６年６月１７日　金曜日　午前８時２９分
