Acura RLX Hybrid (2017 year). Manual - part 15





232

uu

Audio System Basic Operation

u

Voice Control Operation

Features

Voice Control Operation

Your vehicle has a voice control system that allows hands-free operation of most of
the navigation system functions.
The voice control system uses the

 (Talk) and

 (hang-up/back) buttons on the

steering wheel and a microphone near the map lights on the ceiling.

To achieve optimum voice recognition when using the voice control system:
• Make sure the correct screen is displayed for the voice command that you are

using.

• Close the windows and moonroof.
• Adjust the dashboard and side vents so air does not blow onto the microphone

on the ceiling.

• Speak clearly in a clear, natural speaking voice without pausing between words.
• Reduce any background noise if possible. The system may misinterpret your

command if more than one person is speaking at the same time.

• Refer to the Voice Help feature.

Refer to the Navigation System Manual

Voice Recognition

1

Voice Control Operation

When you press the

 button, a helpful prompt asks

what you would like to do. Press and release the



button again to bypass this prompt and give a
command.

1

Voice Recognition

The voice control system can only be used from the
driver’s seat because the microphone unit removes
noises from the front passenger’s side.

17 ACURA RLX E-AWD-31TY36300.book  232 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

233

uu

Audio System Basic Operation

u

Voice Control Operation

Continued

Features

When the

 (Talk) button is pressed,

available voice commands appear on the
screen.
For a complete list of commands, say “Voice
Help”
 after the beep or select Voice Help.

You can see the list of commands in Voice
Info
 on the Info menu screen. Select Info,
then select

.

Voice Portal Screen

Phone Call

This can be only used when the phone is
connected. When the system recognizes the
Phone call command, the screen will
change the dedicated screen for the voice
recognition of the phone.
• Call <Your Contact Name>
• Call <Phone Number>

Music Search

This can be only used when the iPod or HDD
device is connected.

Voice Help

You can see a list of the available
commands on the screen.
• Navigation Commands
• Useful Commands
• Phone Commands
• Audio Commands
• On Screen Commands
• Music Search Commands
• General Commands
• Climate Control Commands
• All Commands
• Voice Settings
• Getting Started

Navigation

The screen changes the navigation screen.

Refer to the Navigation System Manual

17 ACURA RLX E-AWD-31TY36300.book  233 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

234

uu

Audio System Basic Operation

u

Voice Control Operation

Features

Audio

When the system recognizes the Audio
command, the screen will change the
dedicated screen for the voice recognition
of the audio.
• Audio On

*1

• Audio off

*1

• FM
• AM
• SXM
• Disc
• HDD
• USB
• iPod
• Bluetooth® Audio
• Pandora

*

• Aha
• AUX

Audio Commands P. 235

*1: These commands toggle the function
on and off, so the command may not match
your intended action.

Climate Control

The screen changes the climate control
screen.

Climate Control Commands P. 236

The system accepts these commands on the
voice portal top screen.
• Call <Your Contact Name>
• Call <Phone Number>
• What time is it?
• What is today's date?

Useful Commands

The system accepts these commands on the
dedicated screen for the voice recognition
of the phone.
• Call <Your Contact Name>
• Call <Phone Number>

Phone Commands

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  234 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

235

uu

Audio System Basic Operation

u

Voice Control Operation

Continued

Features

The system accepts these commands on the
dedicated screen for the voice recognition
of the audio.

Radio FM Commands

• Radio tune to <87.7-107.9> FM
• Radio FM preset <1-12>

Radio AM Commands

• Radio tune to <530-1710> AM
• Radio AM preset <1-6>

Radio SXM Commands

• SXM channel <1-999>
• Radio SXM preset <1-12>

Disc Commands

• Disc play
• Disc play track <1-30>

HDD Commands

• HDD play
• HDD play track <1-30>
• Music Search
• What album is this?
• What am I listening to?

Audio Commands

iPod Commands

• iPod play
• iPod play track <1-30>
• Music Search
• What album is this?
• What am I listening to?

USB Commands

• USB play
• USB play track <1-30>

Bluetooth® Audio Commands

• Bluetooth® Audio play

NOTE:
Bluetooth® Audio commands may not work
on some phones or Bluetooth® Audio
devices.

Pandora Commands

*

• Pandora play

Aha Commands

• Aha radio play

AUX Commands

• AUX play

The system accepts the the voice command
operation of the voice recognition screen.

On Screen Commands

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  235 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

236

uu

Audio System Basic Operation

u

Voice Control Operation

Features

The system accepts these commands on the
Music Search
 screen.

Using Song By Voice

Song By Voice

TM

 is a feature that allows you

to select music from your iPod or HDD
device using Voice Commands. To activate
this mode, you must press the

 (Talk)

button and say: “Music Search”.

Song By Voice Commands

• Music Search
• What am I listening to?
• Who am I listening to?
• Who is this?
• What's playing?
• Who's playing?
• What album is this?

Music Search Commands

Play Commands

• Play artist <Name>
• Play album <Name>
• Play song <Name>
• Play composer <Name>
• Play genre <Name>
• Play playlist <Name>

List Commands

• List artist <Name>
• List album <Name>
• List composer <Name>
• List genre <Name>
• List playlist <Name>

• What time is it?
• What is today's date?

General Commands

The system accepts these commands on the
Climate control
 screen.
• Climate Control Automatic
• Climate Control On

*1

• Climate Control Off

*1

• Air conditioner On

*1

• Air conditioner Off

*1

• Defrost On

*1

• Defrost Off

*1

• Vent
• Dash and Floor
• Floor Vents
• Floor and Defrost
• Fan Speed Up
• Fan Speed Down
• Fan Speed <1-7>
• Temperature Up
• Temperature Down
• Temperature Max Heat
• Temperature Max Cool
• Temperature <57-87> Degrees (U.S.)
• Temperature <18-32> Degrees (Canada)

*1: These commands toggle the function
on and off, so the command may not match
your intended action.

Climate Control Commands

17 ACURA RLX E-AWD-31TY36300.book  236 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

237

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

Audio/Information Screen

On Demand Multi-Use Display

TM

Tune Up/Down Icons
Select

or

to

tune the radio frequency.

MENU Button
Press to display the menu items.

 (Power) Button

Press to turn the audio system
on and off.

Audio Source
Select to change a band or change
an audio source.

Tune
Select to switch to tune mode.

Preset Icons
Select to store a station.
To listen to a stored channel, select
1-6 (AM) or 1-12 (FM).

Skip/Seek Icons
Select

 or

 to search up

and down the selected band for
a station with a strong signal.

More
Select to display the menu items.

BACK Button
Press to go back to the previous display.

VOL (Volume) Knob
(Pushed out)
Turn to adjust the volume.

Interface Dial/ENTER Button
Press and turn to select preset radio
stations.
Move up, down, right and left to
select secondary menu.

TAG
Select to tag the song if it is played on
an HD Radio

TM

 station. The iPod/iPhone

should be connected to the audio
system to store the tagged song
information on your device.

Models with HD Radio

TM

 feature

iPod/iPhone

Scan
Select to sample each of the
strongest stations on the selected
band for 10 seconds.

17 ACURA RLX E-AWD-31TY36300.book  237 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Audio System Basic Operation

u

Playing AM/FM Radio

238

Features

To store a station:

1. Tune to the selected station.
2. Move

 or

 to select the Preset tab.

3. Rotate

 to select the preset number you want to store the station.

4. Press and hold

 for a few seconds.

You can also store that station by the following procedure.
1. Tune to the selected station.
2. Press the MENU button.
3. Rotate

to

select

Save Preset, then press

.

4. Rotate

 to select the preset number you want to store that station, then press

.

1. Tune to the selected station.
2. Change the display to the preset screen.
3. Select and hold the preset number you want to store that station.

You can also store that station by the following procedure.
1. Tune to the selected station.
2. Select More.
3. Select Save Preset.
4. Select the preset number you want to store that station.

Preset Memory

1

Playing AM/FM Radio

You can control the AM/FM radio using voice
commands.

Voice Control Operation P. 232

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Press the SOURCE button on the steering wheel.

Audio Remote Controls P. 215

You can also switch the mode by pressing the MENU
button and selecting Change Source on the Audio
menu
 screen.

You can store 6 AM stations and 12 FM stations into
the preset memory.

HD Radio Technology manufactured under license
from iBiquity Digital Corporation. U.S. and Foreign
Patents. HD Radio

TM

 and the HD, HD Radio, and

"Arc" logos are proprietary trademarks of iBiquity
Digital Corp.

Models with HD Radio

TM

 feature

Interface Dial

On Demand Multi-Use Display

TM

17 ACURA RLX E-AWD-31TY36300.book  238 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

239

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Features

Provides text data information related to your selected RDS-capable FM station.

To find an RDS station from Station List

1. Move

or

to

select

the

Station List

tab.

2. Rotate

 to select the station, then press

.

Manual update

Updates your available station list at any time.
1. Press the MENU button while listening to an FM station.
2. Rotate

 to select Refresh Station List, then press

.

Radio Data System (RDS)

1

Playing AM/FM Radio

iTunes Tagging
“iTunes” in “iTunes Tagging” is a trademark of
Apple Inc.
When an HD Radio

TM

 station is selected, the HD

indicator appears on the audio/information screen
and On Demand Multi-Use Display

TM

.

If you want to have the information on the song
played from the HD Radio

TM

 station, select TAG in On

Demand Multi-Use Display

TM

 or select Tag Song in

the menu with the interface dial.
If the iPod/iPhone is connected, the tag is transferred
to the connected device immediately, otherwise the
tag will be transferred when the device is connected
and Tag Song in the menu is selected with Interface
dial.

Models with HD Radio

TM

17 ACURA RLX E-AWD-31TY36300.book  239 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

240

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Features

Radio text

Display the radio text information of the selected RDS station.
1. Press the MENU button.
2. Rotate

to

select

Radio Text, then press

.

Scan

Samples each of the strongest stations on the selected band for 10 seconds.

1. Press the MENU button.
2. Rotate

to

select

Scan, then press

.

To turn off scan, press

 to select Cancel Scan, or press the BACK button.

Playing AM/FM Radio P. 237

To turn off scan, select Stop Scan.

Tag song to device

You can store the TAG information in the connected iPod/iPhone.
If the iPod/iPhone is not connected to the audio system, the information is stored in
the audio unit temporarily, then once the device is connected to the system, data is
transferred to the iPod/iPhone.
To store the TAG information to the iPod/iPhone, or the audio system:
1. Press the MENU button.
2. Rotate

to

select

Tag Song, then press

.

3. Select the song for which you want to save the information.

Interface Dial

On Demand Multi-Use Display

TM

Models with HD Radio

TM

17 ACURA RLX E-AWD-31TY36300.book  240 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

241

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Features

Tagged song list

Displays the TAG information saved to the audio system.
1. Press the MENU button.
2. Rotate

 to select Tagged Song List, then press

.

HD subchannel

Displays the subchannel list when an HD Radio

TM

 station is selected.

1. Press the MENU button.
2. Rotate

 to select HD Subchannel, then press

.

3. Rotate

 to select a channel from a list, then press

.

Select the

 or

 when the subchannel number is displayed.

You can also select the channel by the following procedure.
1. Select More.
2. Select HD Subchannel.
3. Select the channel number.

Interface Dial

On Demand Multi-Use Display

TM

17 ACURA RLX E-AWD-31TY36300.book  241 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

242

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

Features

Playing SiriusXM® Radio

Audio/Information Screen

On Demand Multi-Use Display

TM

Category Up/Down Icons
Select

 or

 to display and select

an SiriusXM® Radio category.

MENU Button
Press to display the menu items.

 (Power) Button

Press to turn the audio system
on and off.

Audio Source
Select to change an audio source.

Tune
Select to switch to tune mode.

Preset Icons
Select to store a station.
To listen to a stored channel, select
1-12.

More
Select to display the menu items.

BACK Button
Press to go back to the previous display.

VOL (Volume) Knob
(Pushed out)
Turn to adjust the volume.

Interface Dial/ENTER Button
Press and turn to select preset radio
stations.
Move up, down, right and left to
select secondary menu.

Scan
Select to sample each of the
strongest stations on the selected
band for 10 seconds.

Skip/Seek Icons
Select

 or

 to the previous

or next channel.
In channel mode, select and hold
to change the channel rapidly.

17 ACURA RLX E-AWD-31TY36300.book  242 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

243

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

Features

1. Select the SiriusXM® mode.

Audio Remote Controls P. 215
On Demand Multi-Use Display

TM

 P. 217

2. Press the MENU button.
3. Rotate

 to select Channel List, then press

.

4. Rotate

 to select a channel from a list, then press

.

2. Select a channel using the

 icons on the tune mode screen or

the preset numbers (1-12) on the preset mode screen.

To change the tune mode:

1. Press the MENU button.
2. Rotate

 to select XM Tune Mode, then press

.

3. Rotate

 to select Channel Mode or Category Mode, then press

.

1. Select More.
2. Select XM Tune Mode.
3. Select Channel Mode or Category Mode.

To Play the SiriusXM® Radio

1

Playing SiriusXM® Radio

You can control the SiriusXM® radio using voice
commands.

Voice Control Operation P. 232

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM® Radio does
not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

SiriusXM® Radio stations load in ascending order,
which can take about a minute. Once they have
loaded you will be able to scroll up or down to make
your selections.

Interface Dial

On Demand Multi-Use Display

TM

Interface Dial

On Demand Multi-Use Display

TM

17 ACURA RLX E-AWD-31TY36300.book  243 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

244

Features

To store a station:

1. Tune to the selected station.
2. Move

 or

 to select the Preset tab.

3. Rotate

 to select the preset number you want to store the station.

4. Press and hold

 for a few seconds.

You can also store that station by the following procedure.
1. Tune to the selected station.
2. Press the MENU button.
3. Rotate

to

select

Save Preset, then press

.

4. Rotate

 to select the preset number you want to store that station, then press

.

1. Tune to the selected station.
2. Change the display to the preset screen.
3. Select and hold the preset number you want to store that station.

You can also store that station by the following procedure.
1. Tune to the selected station.
2. Select More.
3. Select Save Preset.
4. Select the preset number you want to store that station.

Preset Memory

1

Playing SiriusXM® Radio

You can store 12 SiriusXM® stations into the preset
memory.

Interface Dial

On Demand Multi-Use Display

TM

17 ACURA RLX E-AWD-31TY36300.book  244 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

245

uu

Audio System Basic Operation

u

Playing a CD

Continued

Features

Playing a CD

Your audio system supports audio CDs, CD-Rs and CD-RWs in either MP3, WMA, or
AAC

*1

 format. With the CD loaded, select the CD mode.

*1:Only AAC format files recorded with iTunes are playable on this unit.

Audio/Information Screen

MENU Button
Press to display the menu items.

CD Slot
Insert a CD about halfway into the CD
slot.

 (CD Eject) Button

Press to eject a CD.

Folder Up/Down Icons
Select

 to skip to the next folder, and

 to skip to the beginning of the

previous folder in MP3, WMA, or AAC.

Audio Source
Select to change an audio source.

Skip/Seek Icons
Select

 or

 to change tracks

(files in MP3, WMA, or AAC).
Select and hold to move rapidly within
a track/file.

More
Select to display the menu items.

BACK Button
Press to go back to the previous display.

Interface Dial/ENTER Button
Press and turn to select an item,
then press to set your selection.
Move up, down, right and left to
select secondary menu.

On Demand Multi-Use Display

TM

 (Power) Button

Press to turn the audio system
on and off.

VOL (Volume) Knob (Pushed out)
Turn to adjust the volume.

Scan
Select to use a scan feature.

Random
Select to use a random feature.

Repeat
Select to use a repeat feature.

17 ACURA RLX E-AWD-31TY36300.book  245 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Audio System Basic Operation

u

Playing a CD

246

Features

1. Press the MENU button.
2. Rotate

 to select Music Search, then

press .

3. Rotate

, move

 or

, then press

 to

select a file from the Music Search list.

You can also select a file by the following
procedure.
1. Rotate

 or press

 to display the song

list.

2. Rotate

, move

 or

, then press

 to

select a file from the list.

How to Select a File from the Music Search List
(MP3/WMA/AAC)

1

Playing a CD

NOTICE

Do not use CDs with adhesive labels. The label can
cause the CD to jam in the unit.

WMA and AAC files protected by digital rights
management (DRM) cannot be played.
The audio system displays Unplayable File, then
skips to the next file.

Text data appears on the display under the following
circumstances:

When you select a new folder, file, or track.

When you change the audio mode to CD.

When you insert a CD.

If you eject the CD but do not remove it from the slot,
the system reloads the CD automatically after several
seconds.

You can control a CD audio using voice commands.

Voice Control Operation P. 232

Folder Selection

File Selection

17 ACURA RLX E-AWD-31TY36300.book  246 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

247

uu

Audio System Basic Operation

u

Playing a CD

Features

You can select scan, repeat, and random modes when playing a track or file.

1. Press the MENU button.
2. Rotate

 to select Scan or Random/

Repeat, then press

.

3. Rotate

 to select a mode, then press

.

1. Select ScanRandom or Repeat.

Playing a CD P. 245

2. Select a mode.

To turn off a play mode

1. Press the MENU button.
2. Rotate

 to select the mode you want to turn off, then press

.

1. Select ScanRandom or Repeat.

Playing a CD P. 245

2. Select the mode you want to turn off.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Scan
Scan Folders
 (MP3/WMA/AAC): Provides a 10-
second sampling of the first file in each of the main
folders.
Scan Tracks: Provides a 10-second sampling of all
tracks on the CD (all files in the current folder in MP3,
WMA, or AAC).

Random/Repeat
Repeat Folder
 (MP3/WMA/AAC): Repeats all files in
the current folder.
Repeat Track: Repeats the current track/file.
Random in Folder (MP3/WMA/AAC): Plays all files
in the current folder in random order.
Random All Tracks: Plays all tracks/files in random
order.

Random/Repeat is selected.

Interface Dial

On Demand Multi-Use Display

TM

Interface Dial

On Demand Multi-Use Display

TM

17 ACURA RLX E-AWD-31TY36300.book  247 ページ  2016年6月17日 金曜日 午前8時29分

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     13      14      15      16     ..
