Acura NSX (2017 year). Manual - part 29

455

uu

Specifications

u

Info

rm

ation

■

Brake Fluid

■

Dual Clutch Transmission Fluid

■

Twin Motor Unit Fluid

Specified

Acura Heavy Duty Brake Fluid DOT 4

Specified

Acura Automatic Transmission Fluid
ATF DW-1

Capacity

Change

2.75 US qt (2.6 ℓ)

Specified

Acura Gear Oil GO-Type 2.0

Capacity

Change

4.86 US qt (4.6 ℓ)

Specified

Acura Automatic Transmission Fluid
ATF DW-1

Capacity

Change

2.56 US qt (2.42 ℓ)

Clutch

Transmission

■

Engine Oil

■

Engine Coolant

■

Inverter Coolant

Recommended

Ultimate Full Synthetic Motor Oil, Type3,
0W-40

Capacity

Change

7.7 US qt (7.3 ℓ)

Change
including
filter

8.3 US qt (7.9 ℓ)

Specified

Acura Long Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

4.1 US gal (15.5 ℓ)
(change including the remaining
0.34 US gal (1.29 ℓ) in the reserve tank and
heater)

Specified

Acura Long Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

0.50 US gal (1.90 ℓ)
(change including the remaining
0.12 US gal (0.46 ℓ) in the reserve tank)

■

Tire

Regular

Size

Front
245/35ZR19 (93Y)
Rear
305/30ZR20 (103Y)

Pressure
psi (kPa [kgf/cm

2

])

Front
32 (220 [2.2])
Rear
32 (220 [2.2])

Wheel Size

Regular

Front
19 X 8 1/2J
Rear
20 X 11J

17 NSX-31T6N6000.book  455 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

456

Info

rm

ation

Identification Numbers

Vehicle Identification Number (VIN), Engine Number,
Motor Number, and Transmission Number

Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle.
The locations of your vehicle’s VIN, engine number, motor number and transmission
number are shown as follows.

1

Vehicle Identification Number (VIN), Engine Number, Motor
Number, and Transmission Number

The interior vehicle identification number (VIN) is
located under the cover.

Cover

Vehicle Identification Number

Engine Number

Dual Clutch
Transmission
Number

Certification Label/Vehicle
Identification Number

Motor Number

Motor Number

Motor Number

Dual Clutch Transmission
Number

17 NSX-31T6N6000.book  456 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

457

Info

rm

ation

Devices that Emit Radio Waves

The following products and systems on your vehicle emit radio waves when in
operation.

Each of the above complies with the appropriate requirements or the required

standards of FCC (Federal Communications Commission) and Industry Canada

Standard, described below:

As required by the FCC:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

This device complies with industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference

that may cause undesired operation of the device.

AcuraLink

*

Audio System
Bluetooth® Audio
Bluetooth® HandsFreeLink®
HomeLink® Universal Transceiver
Immobilizer System
Keyless Access System
Tire Pressure Monitoring System (TPMS)

* Not available on all models

17 NSX-31T6N6000.book  457 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

458

Info

rm

ation

Reporting Safety Defects

In the U.S.
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to
notifying American Honda Motor Co., Inc.

If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists
in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer, or American Honda Motor Co., Inc.

To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-
9153); go to http://www.safercar.gov; or write to: Administrator, NHTSA, 1200 New Jersey Avenue, SE.,
Washington, DC 20590. You can also obtain other information about motor vehicle safety from http://
www.safercar.gov.

In Canada
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform Honda Canada Inc. and you may also inform Transport Canada.

If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may lead to a recall and remedy campaign. However, Transport Canada
cannot become involved in individual problems between you, your dealer, or Honda Canada Inc.

To contact Transport Canada’s Defect Investigations and Recalls Division, you may call 1-800-333-0510. For
more information on reporting safety defects or about motor vehicle safety, go to http://www.tc.gc.ca/
roadsafety.

17 NSX-31T6N6000.book  458 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

459

Continued

Info

rm

ation

Emissions Testing

Testing of Readiness Codes

Your vehicle has readiness codes as part of the onboard self diagnostic system.
Some States use these codes for testing to verify whether your vehicle’s emissions
components are working properly.
The codes may not be read properly if testing is performed just after the 12-volt
battery has gone dead or been disconnected.

To check if they are set, set the power mode to ON, without turning the power
system on. The malfunction indicator lamp will come on for several seconds. If it
then goes off, the readiness codes are set. If it blinks five times, the readiness codes
are not set.

If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:

1. Fill the gas tank to approximately 3/4 full.
2. Park the vehicle and leave the power system off for six hours or more.
3. Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4. Start the engine without touching the accelerator pedal, and let it idle for 20

seconds.

5. Keep the vehicle in

(

P. Increase the engine speed to 2,000 rpm, and hold it there

for about three minutes.

6. Let the engine idle with your foot off the accelerator for 20 seconds.

1

Testing of Readiness Codes

The readiness codes are erased when the 12-volt
battery is disconnected, and set again only after
several days of driving under a variety of conditions.

If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.

If the testing facility determines the readiness codes
are still not set, see an authorized Acura NSX dealer.

17 NSX-31T6N6000.book  459 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

460

uu

Emissions Testing

u

Testing of Readiness Codes

Info

rm

ation

7. Select a nearby, lightly traveled major highway where you can maintain a speed

of 50 mph (80 km/h) over for at least 20 minutes. Drive on the highway in

(

D

with SPORT mode. Do not use cruise control.

8. Drive in city or suburban traffic for at least 10 minutes. When traffic conditions

allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.

9. Park the vehicle and leave the power system off for 40 minutes.

17 NSX-31T6N6000.book  460 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

461

Continued

Info

rm

ation

Warranty Coverages

■

U.S.Owners

Your new vehicle is covered by these warranties:

New Vehicle Limited Warranty – covers your new vehicle, except for the
emissions control systems and accessories, against defects in materials and
workmanship.

Emissions Control Systems Defects Warranty and Emissions Performance
Warranty – these two warranties cover your vehicle’s emissions control systems.
Time, mileage, and coverage are conditional. Please read your warranty booklet for
exact information.

Seat Belt Limited Warranty – a seat belt that fails to function properly is covered
by a limited warranty. Please read your warranty booklet for details.

Rust Perforation Limited Warranty – all exterior body panels are covered for
rust-through from the inside for the specified time period with no mileage limit.

Accessory Limited Warranty – Acura accessories are covered under this warranty.
Time and mileage limits depend on the type of accessory and other factors. Please
read your warranty booklet for details.

Replacement Parts Limited Warranty – covers all Acura replacement parts
against defects in materials and workmanship.

17 NSX-31T6N6000.book  461 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

462

uu

Warranty Coverages

u

Info

rm

ation

Replacement 12-Volt Battery Limited Warranty – provides prorated coverage
for a replacement battery purchased from an authorized Acura NSX dealer.

Replacement Muffler Lifetime Limited Warranty – provides coverage for as
long as the purchaser of the muffler owns the vehicle.

Restrictions and exclusions apply to all these warranties. Please read the Acura
warranty information booklet that came with your vehicle for precise information on
warranty coverages. Your vehicle’s original tires are covered by their manufacturer.
Tire warranty information is in a separate booklet.

■

Canadian Owners

Please refer to the warranty manual that came with your vehicle.

■

EPA Contact Information

An owner may obtain further information concerning emission warranties or report
violations of the terms of the emission warranties by contacting:

U.S. Environmental Protection Agency
Office of Transportation and Air Quality
Compliance Division, Light-Duty Vehicle Group
Attn: Warranty Complaints
2000 Traverwood Drive
Ann Arbor, MI 48105
Email: complianceinfo@epa.gov

17 NSX-31T6N6000.book  462 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

463

Info

rm

ation

Authorized Manuals

■

Service Express

For electronic copies of service publications, you can purchase a subscription to
Service Express. Visit www.techinfo.honda.com for pricing and options.

■

For U.S. Owners

Manuals can be purchased from Helm Incorporated. You can order a manual by
phone at (800) 782-4356 (credit card orders only), or online at www.helminc.com.

■

For Canadian Owners

Please contact an authorized Acura NSX dealer to order any manuals that you may
require.

17 NSX-31T6N6000.book  463 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

464

Info

rm

ation

Client Service Information

Authorized Acura NSX dealership personnel are trained professionals who should be
able to deal with any problems you may encounter with your vehicle. If, however,
you are faced with a problem that they cannot resolve to your satisfaction, contact
Acura Client Relations/Services.

U.S. Owners

Canadian Owners

American Honda Motor Co., Inc.

Honda Canada Inc.

Acura Client Relations

Acura Client Services

Mail Stop 500-2N-7E

180 Honda Boulevard

1919 Torrance Blvd.

Markham, ON

Torrance, CA 90501-2746

L6C 0H9

Tel: 1-844-68-ACURA

Tel: 1-888-9-ACURA-9

(1-844-682-2872)

1-844-9-MYNSX-9 (NSX-
specific)

Fax: 1-877-939-0909
E-mail: acura_cr@ch.honda.com

In Puerto Rico and the U.S. Virgin Islands
Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546

1

Client Service Information

When you call or write, please give us the following
information:

•

Vehicle Identification Number

2 Vehicle Identification Number (VIN),

Engine Number, Motor Number, and
Transmission Number P. 456

•

Date of purchase

•

Odometer reading of your vehicle

•

Your name, address, and telephone number

•

A detailed description of the problem

•

Name of the authorized Acura NSX dealer who sold
the vehicle to you

17 NSX-31T6N6000.book  464 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

Index

465

In

dex

Index

Numbers

12-Volt Battery Charging System

Indicator ...................................................  75

A

AAC...........................................................  208
ABS (Anti-lock Brake System)..................  349
Accessories and Modifications ................  412
Accessory Power Socket...........................  154
Active Damper System Indicator...............  74
AcuraLink .................................................  292
Adding the Coolant .................................  383
Additives

Coolant ..........................................  382, 384
Engine Oil ...............................................  376
Washer ...................................................  386

Additives, Engine Oil ...............................  376
Adjusting

Mirrors....................................................  141
Seats.......................................................  144
Steering Wheel .......................................  140
Temperature ...........................................  100

Agile Handling Assist System ..................  337
Air Conditioning System (Climate Control

System)....................................................  156

Changing the Mode................................  157
Defrosting the Windshield and

Windows ..............................................  158

Dust and Pollen Filters.............................  405
Recirculation/Fresh Air Mode...................  157

Sensors.................................................... 160
Synchronized Mode ................................. 159
Using Automatic Climate Control ............ 156

Air Pressure ....................................... 394, 455
Airbags ........................................................ 43

Advanced Airbags ..................................... 49
Airbag Care ............................................... 57
Driver’s Knee Airbag .................................. 50
Event Data Recorder .................................... 0
Front Airbags (SRS) .................................... 46
Indicator .............................................. 55, 78
Passenger Airbag Off Indicator .................. 56
Sensors...................................................... 43
Side Airbags .............................................. 52
Side Curtain Airbags .................................. 54

Android Auto............................................ 219
Anti-lock Brake System (ABS) .................. 349

Indicator .................................................... 78

Apple CarPlay ........................................... 216
Audio Remote Controls............................ 165
Audio System ............................................ 162

Adjusting the Sound ................................ 181
Changing the Home Screen Icon

Layout ................................................... 170

Closing Apps ........................................... 180
Error Messages ........................................ 223
General Information ................................ 226
Home Screen ........................................... 173
iPod......................................................... 199
Limitations for Manual Operation ............ 183
MP3/WMA/AAC ...................................... 208

Reactivating ............................................  164
Recommended Devices............................  227
Remote Controls .....................................  165
Security Code..........................................  164
Selecting an Audio Source.......................  183
Status Area .............................................  179
Theft Protection ......................................  164
USB Flash Drives ......................................  227
USB Ports ................................................  163
Wallpaper Setup......................................  171

Audio/Information Screen .......................  167
Authorized Manuals ................................  463
Auto Door Locking/Unlocking.................  118
Auto Engine Stop/Start ..............................  13
Automatic Brake Hold .............................  347

Indicator............................................  72, 347

Automatic Brake Hold System

Indicator............................................  72, 347

Automatic Operation (automatic lighting

control)....................................................  132

Average Fuel Economy ............................  101
Average Speed .........................................  101

B

Battery

12-Volt....................................................  403
12-Volt Battery Charging System

Indicator..........................................  75, 438

Charging (AGM Battery)..........................  403
High Voltage ...........................................  343

17 NSX-31T6N6000.book  465 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

466

In

dex

Jump Starting .......................................... 434
Maintenance (Checking the 12-Volt

Battery).................................................. 403

Maintenance (Replacing).......................... 404

Battery Types .............................................. 12
Belts (Seat) .................................................. 36
Beverage Holders...................................... 153
Bluetooth® Audio ..................................... 211
Bluetooth® HandsFreeLink® ..................... 258
Booster Seats (For Children)....................... 66
Brake System............................................. 344

Anti-lock Brake System (ABS) ................... 349
Automatic Brake Hold.............................. 347
Brake Assist System ................................. 350
Fluid ........................................................ 386
Foot Brake ............................................... 346
Parking Brake .......................................... 344

Brake System (Amber)

Indicator .................................................... 73

Brake System (Red)

Indicator ............................................ 70, 439

Brake Wear

Indicator .................................................... 74

Bulb Replacement..................................... 387

Back-Up Lights......................................... 388
Daytime Running Lights ........................... 387
Front Side Marker Lights .......................... 387
Front Turn Signal/Parking Lights............... 387
Headlights ............................................... 387
High-Mount Brake Light .......................... 389
Rear License Plate Lights .......................... 389

Rear Side Marker Lights...........................  388
Rear Turn Signal Lights ............................  388
Side Turn Signal/Emergency Indicator

Lights ....................................................  387

Taillights..................................................  388

Bulb Specifications ...................................  454

C

Carbon Monoxide Gas ...............................  67
Carrying Cargo .................................  299, 301
Certification Label....................................  456
Changing Bulbs ........................................  387
Charging System Indicator.................  75, 438
Child Safety.................................................  58

Emergency Hatch Opener........................  121

Child Seat....................................................  58

Booster Seats ............................................  66
Child Seat for Infants.................................  60
Child Seat for Small Children.....................  61
Installing a Child Seat ................................  63
Larger Children .........................................  65
Selecting a Forward-facing Child Seat........  62
Using a Tether...........................................  64

Cleaning the Exterior ...............................  408
Cleaning the Interior................................  406
Client Service Information .......................  464
Climate Control System............................  156

Defrosting the Windshield and

Windows...............................................  158

Dust and Pollen Filters .............................  405

Recirculation/Fresh Air Mode...................  157
Sensors ...................................................  160
Synchronized Mode ................................  159
Using Automatic Climate Control............  156

Clock .........................................................  104
Cold Weather ...........................................  402
Console Compartment.............................  152
Controls ....................................................  103
Coolant (Engine) ......................................  382

Adding the Coolant ................................  383
Checking the Coolant .............................  382
Overheating ............................................  436

Coolant (Inverter) ....................................  384
Creeping (Dual Clutch Transmission) ......  313
Cruise Control ..........................................  330
CRUISE CONTROL Indicator .......................  82
CRUISE MAIN Indicator ..............................  82
Cup Holders ..............................................  153
Customized Features ...............................  232

D

Daytime Running Lights ..........................  134
Dead Battery (12-Volt).............................  434
Defrosting the Windshield and

Windows .................................................  158

Devices that Emit Radio Waves ...............  457
Dimming

Headlights ..............................................  131
Rearview Mirror ......................................  141

Dipstick (Engine Oil) ........................  372, 379

17 NSX-31T6N6000.book  466 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

467

In

dex

Directional Signals (Turn Signal).............  130
Door Mirrors.............................................  142
Doors ........................................................  105

Auto Door Locking..................................  118
Auto Door Unlocking ..............................  118
Door Open Message .................................  35
Keys........................................................  105
Locking/Unlocking the Doors from

the Inside ........................................  18, 115

Locking/Unlocking the Doors from

the Outside ...........................................  107

Lockout Prevention System .....................  114

DOT Tire Quality Grading........................  396
Driver Information Interface.....................  98
Driver’s Knee Airbag..................................  50
Driving ......................................................  297

Braking ...................................................  344
Cold Weather .........................................  402
Cruise Control ........................................  330
Dual Clutch Transmission ........................  313
Shifting Gear ..........................................  314
Turning on the Power .............................  309

Driving Position Memory System ............  138
Dual Clutch Transmission ........................  313

Creeping.................................................  313
Fluids ..............................................  385, 455
Kickdown ...............................................  313
Operating the Shift Button ................  23, 316
Shifting...................................................  314

Dust and Pollen Filters.............................  405

E

Elapsed Time ............................................. 101
Electric Parking Brake .............................. 344

Indicator .................................................... 71

Electric Parking Brake System

Indicator ............................................ 71, 440

Electric Power Steering (EPS) System

Indicator ............................................ 78, 439

Electronic Stability Control (ESC) ............. 333
Emergency ................................................ 448
Emergency Hatch Opener ........................ 121
Emissions Testing (Readiness Codes) ....... 459
Energy Efficiency ........................................ 12
Engine ....................................................... 456

Coolant ........................................... 382, 455
Jump Starting .......................................... 434
Oil ................................................... 376, 455

Engine Compartment Cover .................... 375
Engine Coolant ......................................... 382

Adding the Coolant ................................. 383
Checking the Coolant.............................. 382
Overheating ............................................ 436

Engine Oil

Adding .................................................... 380
Changing ................................................ 381
Checking ................................................. 377
Displaying Oil Life .................................... 366
Low Oil Level Symbol ............................... 442
Low Oil Pressure Indicator.......................... 70
Recommended Engine Oil........................ 376

Temperature Gauge ..................................  97

EPS (Electric Power Steering) System ........  78
Exhaust Gas Hazard (Carbon

Monoxide).................................................  67

Exterior Care (Cleaning)...........................  408
Exterior Mirrors ........................................  142

F

Features ....................................................  161
Filters

Dust and Pollen .......................................  405
Oil...........................................................  381

Flat Tire .....................................................  419
Floor Mats.................................................  407
Fluids

Brake ..............................................  386, 455
Dual Clutch Transmission ................  385, 455
Engine Coolant ...............................  382, 455
Inverter Coolant ..............................  384, 455
Twin Motor Unit..............................  385, 455
Windshield Washer .........................  386, 454

FM Radio...................................................  188
Foot Brake ................................................  346
Front Airbags (SRS).....................................  46
Fuel......................................................  25, 357

Economy .................................................  359
Gauge.......................................................  95
Instant Fuel Economy ..............................  101
Low Fuel Indicator .....................................  77
Range .....................................................  101

17 NSX-31T6N6000.book  467 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

468

In

dex

Refueling ................................................. 357
Requirement.................................... 357, 454

Fuel Economy............................................ 359
Fuel Fill Door....................................... 25, 358
Fuses .......................................................... 443

Inspecting and Changing ......................... 447
Locations ................................. 443, 445, 446

G

Gasoline (Fuel)

Economy ................................................. 359
Gauge ....................................................... 95
Information ............................................. 357
Instant Fuel Economy............................... 101
Low Fuel Indicator ..................................... 77
Refueling ................................................. 357

Gauges......................................................... 95
Gear Position Indicator....................... 76, 316
Gear Shift Positions

Dual Clutch Transmission......................... 314

Glass (care) ........................................ 406, 409
Glove Box .................................................. 151

H

Handling the Unexpected ........................ 417
HandsFreeLink® (HFL) ............................... 258

Automatic Import of Cellular Phonebook and

Call History ............................................ 271

Displaying Messages ................................ 287

HFL Buttons.............................................  258
HFL Menus ..............................................  261
HFL Status Display ...................................  260
Limitations for Manual Operation ............  260
Making a Call..........................................  280
Options During a Call ..............................  284
Phone Setup............................................  266
Phonebook Phonetic Modification ...........  275
Receiving a Call .......................................  284
Receiving a Text/E-mail Message..............  285
Ring Tone................................................  270
Roadside Assistance ................................  291
Selecting a Mail Account .........................  286
Speed Dial...............................................  272
To Set Up Text/E-mail Message Options...  269

Hatch.........................................................  119

Unable to Open.......................................  450

Hazard Warning Button ..............................  4
Headlights.................................................  131

Aiming ....................................................  387
Automatic Operation (automatic lighting

control) .................................................  132

Dimming .........................................  131, 134
Operating................................................  131

Heaters (Seat) ...........................................  155
HFL (HandsFreeLink®)...............................  258
High Beam Indicator ..................................  81
High Voltage Battery ...............................  343
High-Performance Driving.......................  303
Hill Start Assist System .............................  311
HomeLink® Universal Transceiver............  255

Hybrid Vehicle

SPORT HYBRID Super Handling-All Wheel

Drive

TM

 (SPORT HYBRID SH-AWD®)............  9

I

Identification Numbers

Engine, Motor, and Transmission ............  456
Vehicle Identification...............................  456

Immobilizer System..................................  122

Indicator ...................................................  81

Indicators ....................................................  70

12-Volt Battery Charging System ......  75, 438
Active Damper System ..............................  74
Anti-lock Brake System (ABS) ....................  78
Automatic Brake Hold .......................  72, 347
Automatic Brake Hold System ...........  72, 347
Brake System (Amber) ...............................  73
Brake System (Red) ...........................  70, 439
Brake Wear...............................................  74
CRUISE CONTROL .............................  82, 331
CRUISE MAIN....................................  82, 330
Door and Trunk (Hatch) Open ...................  35
Electric Parking Brake ................................  71
Electric Parking Brake System ............  71, 440
Electric Power Steering (EPS)

System ............................................  78, 439

Gear Position ............................................  76
High Beam ................................................  81
Immobilizer System ...................................  81
Keyless Access System...............................  82

17 NSX-31T6N6000.book  468 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

469

In

dex

Lights On ..................................................  81
Low Fuel ...................................................  77
Low Oil Pressure .......................................  70
Low Tire Pressure/TPMS ............  80, 339, 341
Malfunction Indicator Lamp ..............  75, 438
POWER SYSTEM .......................................  74
READY......................................................  74
Seat Belt Reminder..............................  37, 77
Security System Alarm...............................  82
Supplemental Restraint System ...........  55, 78
System Message .......................................  80
Transmission System .................................  76
Turn Signal ...............................................  81
Vehicle Stability Assist (VSA®)

System ............................................  79, 333

VSA® OFF..........................................  79, 334

Information ..............................................  453
Instant Fuel Economy ..............................  101
Instrument Panel........................................  69
Integrated Dynamics System (IDS) ..........  323

QUIET Mode ...........................................  326
SPORT Mode...........................................  326
SPORT+ Mode ........................................  327
TRACK Mode..........................................  327

Interior Lights...........................................  149
Interior Rearview Mirror .........................  141
Inverter Coolant...............................  384, 455

J

Jump Starting...........................................  434

K

Key Number Tag ....................................... 106
Keyless Access System............................... 107
Keyless Lockout Prevention ..................... 114
Keys ........................................................... 105

Lockout Prevention .................................. 114
Number Tag ............................................ 106
Remote Transmitter ................................. 112
Types and Functions ................................ 105

Kickdown (Dual Clutch Transmission) ..... 313

L

Language (HFL)......................................... 260
Launch Control ......................................... 328
Lights ................................................. 131, 387

Automatic Operation (automatic lighting

control).................................................. 132

Bulb Replacement.................................... 387
Daytime Running Lights ........................... 134
High Beam Indicator .................................. 81
Interior .................................................... 149
Light Switches ......................................... 131
Lights On Indicator .................................... 81
Turn Signals............................................. 130

Load Limits ................................................ 301
Locking/Unlocking .................................... 105

Auto Door Locking/Unlocking .................. 118
From Inside.............................................. 115
From Outside........................................... 107
Keys ........................................................ 105

Using a Key .............................................  114

Lockout Prevention System .....................  114
Low Battery Charge (12-Volt)..................  438
Low Fuel Indicator......................................  77
Low Keyless Access Remote Signal

Strength ..................................................  106

Low Oil Level ............................................  442
Low Oil Pressure Indicator .........................  70
Luggage (Maximum Load Limit) .............  301
Lumbar Support .......................................  145

M

Maintenance.............................................  361

12-Volt Battery........................................  403
Brake Fluid ..............................................  386
Cleaning .................................................  406
Climate Control System...........................  405
Coolant...........................................  382, 384
Cooling System .......................................  382
Inverter Coolant ......................................  384
Maintenance Minder

TM

............................  365

Oil...........................................................  377
Precautions .............................................  362
Remote Transmitter.................................  404
Replacing Light Bulbs ..............................  387
Safety......................................................  363
Service Items ...........................................  368
Tires ........................................................  393
Transmission Fluids..................................  385
Under the Hood and Hatch .....................  371

17 NSX-31T6N6000.book  469 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

470

In

dex

Malfunction Indicator Lamp .............. 75, 438
Map Lights ................................................ 150
Maximum Load Limit................................ 301
Meters, Gauges ........................................... 95
Mirrors....................................................... 141

Adjusting................................................. 141
Door........................................................ 142
Exterior.................................................... 142
Interior Rearview...................................... 141

Modifications (and Accessories)............... 412
MP3............................................................ 208
Multi-View Rear Camera .......................... 356

N

Numbers (Identification) .......................... 456

O

Odometer.................................................. 100
Oil (Engine) ....................................... 376, 455

Adding .................................................... 380
Checking ................................................. 377
Displaying Oil Life .................................... 366
Low Oil Level Symbol ............................... 442
Low Oil Pressure Indicator.......................... 70
Recommended Engine Oil................ 376, 455
Viscosity .......................................... 376, 455

Open Source Licenses ............................... 230
Opening

Hatch ...................................... 119, 373, 450

Opening/Closing

Hatch ..............................................  119, 373
Hood.......................................................  374
Power Windows ......................................  125

Operating the Switches Around the Steering

Wheel ......................................................  127

Outside Temperature Display..................  100
Overheating..............................................  436

P

Paddle Shifters (Sequential Mode)..........  322
Pandora®...................................................  206
Panic Mode ...............................................  124
Parking......................................................  351
Parking Brake ...........................................  344
Parking Sensor System .............................  352
Passenger Airbag Off Indicator .................  56
Passing Indicators .....................................  131
POWER Button .........................................  127
Power System

Turning on ..............................................  309

POWER SYSTEM Indicator..........................  74
Power Windows .......................................  125
Precautions While Driving

In Snow and Ice.......................................  312
Rain ........................................................  312

Pregnant Women .......................................  41
Puncture (Tire)..........................................  419

R

Radio (FM) ................................................  188
Radio (SiriusXM®) .....................................  192
Radio Data System (RDS) .........................  191
Range........................................................  101
RDS (Radio Data System) .........................  191
Readiness Codes (Emissions Testing) ......  459
READY Indicator ........................................  74
Rear Defogger/Heated Door Mirror

Button.....................................................  137

Rearview Mirror .......................................  141
Refueling ..................................................  357

Fuel Gauge ...............................................  95
Gasoline .........................................  357, 454
Low Fuel Indicator.....................................  77

Regenerative Energy and Regenerative

Braking .....................................................  12

Regulations ..............................  341, 396, 457
Remote Transmitter .................................  112
Replacement

Battery....................................................  404
Bulbs ......................................................  387
Fuses ......................................  443, 445, 446
Tires........................................................  399
Wiper Blade Rubber ................................  390

Reporting Safety Defects.........................  458
Resetting a Trip Meter.............................  100
Reverse Tilt Door Mirror ..........................  143
Right Selector Wheel .................................  98

17 NSX-31T6N6000.book  470 ページ  ２０１６年４月２２日　金曜日　午後３時４４分
