357

Driving

Refueling

Fuel Information

■

Fuel requirement

Use of lower octane gasoline can cause occasional metallic knocking noise in the
engine and will result in decreased engine performance.
We recommend that you use a pump octane of 93 or higher to maximize the
performance of the engine.
Use of gasoline with a pump octane less than 91 can lead to engine damage.

■

Top tier detergent gasoline

Because the level of detergency and additives in gasoline vary in the market, Acura
endorses the use of “TOP TIER Detergent Gasoline” where available to help
maintain the performance and reliability of your vehicle. TOP TIER Detergent
Gasoline meets a new gasoline standard jointly established by leading automotive
manufacturers to meet the needs of today’s advanced engines.

Qualifying gasoline retailers will, in most cases, identify their gasoline as having met
“TOP TIER Detergent Gasoline” standards at the retail location. This fuel is
guaranteed to contain the proper level of detergent additives and be free of metallic
additives. The proper level of detergent additives, and absence of harmful metallic
additives in gasoline, help avoid build-up of deposits in your engine and emission
control system.

For further important fuel-related information for your vehicle, or on information on
gasoline that does not contain MMT, visit Acura Owners at owners.acura.com. In
Canada, visit www.acura.ca for additional information on gasoline. For more
information on top tier gasoline, visit www.toptiergas.com.

■

Fuel tank capacity: 15.6 US gal (59.0 liters)

Unleaded premium gasoline, pump octane number 91 or higher

1

Fuel Information

NOTICE

We recommend quality gasoline containing
detergent additives that help prevent fuel system and
engine deposits. In addition, in order to maintain
good performance, fuel economy, and emissions
control, we strongly recommend the use of gasoline
that does NOT contain harmful manganese-based
fuel additives such as MMT, if such gasoline is
available.

Use of gasoline with these additives may adversely
affect performance, and cause the malfunction
indicator lamp on your instrument panel to come on.
If this happens, contact an authorized Acura NSX
dealer for service.
Some gasoline today is blended with oxygenates such
as ethanol. Your vehicle is designed to operate on
oxygenated gasoline containing up to 15% ethanol
by volume. Do not use gasoline containing methanol.
If you notice any undesirable operating symptoms, try
another service station or switch to another brand of
gasoline.

17 NSX-31T6N6000.book  357 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

358

uu

Refueling

u

How to Refuel

Driving

How to Refuel

Your fuel tank is not equipped with a fuel fill cap. You can insert the filler nozzle
directly into the filler neck. The tank seals itself again when you pull out the filler
nozzle.

1. Stop your vehicle with the service station

pump on the left side of the vehicle in the
rear.

2. Turn off the power system.
3. Press the fuel fill door release button.

u

The fuel fill door opens.

4. Place the end of the filler nozzle on the

lower part of filler opening, then insert it
slowly and fully.

u

Make sure that the end of the filler
nozzle goes down along with the filler
pipe.

u

Keep the filler nozzle level.

u

When the tank is full, the filler nozzle will
click off automatically.

u

After filling, wait about five seconds
before removing the filler nozzle.

5. Shut the fuel fill door by hand.

1

How to Refuel

The fuel filler opening is designed to accept only
service station filler nozzles for refueling. Use of
smaller diameter tubes (e.g., to siphon fuel for other
uses) or other non-service station devices can
damage the area in and around the filler opening.

The filler nozzle automatically stops to leave space in
the fuel tank so that fuel does not overflow as a result
of changes in air temperature.

If the fuel nozzle keeps turning off when the tank is not
full, there may be a problem with the pump’s fuel vapor
recovery system. Try filling at another pump. If this does not
fix the problem, consult an authorized Acura NSX dealer.

Do not continue to add fuel after the nozzle has
automatically stopped. Additional fuel can exceed
the full tank capacity.

If you have to refuel your vehicle from a portable
container, use the funnel provided with your vehicle.

2 Refueling from a Portable Fuel Container P. 451

3

WARNING

Gasoline is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.

• Turn the power system off, and keep

heat, sparks, and flame away.

• Handle fuel only outdoors.
• Wipe up spills immediately.

Press

17 NSX-31T6N6000.book  358 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

359

Driving

Fuel Economy and CO

2

 Emissions

Improving Fuel Economy and Reducing CO

2



Emissions

Achieving fuel economy and reducing CO

2

 emissions is dependent on several

factors, including driving conditions, load weight, idling time, driving habits, and
vehicle condition. Depending on these and other factors, you may not achieve the
rated fuel economy of this vehicle.

You can optimize your fuel economy with proper maintenance of your vehicle.
Always maintain your vehicle in accordance with the messages displayed on the
driver information interface.
• Use the recommended viscosity engine oil, displaying the API Certification Seal.
• Maintain the specified tire pressure.
• Do not load the vehicle with excess cargo.
• Keep your vehicle clean. A buildup of snow or mud on your vehicle’s underside

adds weight and increases wind resistance.

■

Maintenance and Fuel Economy

1

Improving Fuel Economy and Reducing CO

2

 Emissions

Direct calculation is the recommended method to
determine actual fuel consumed while driving.

In Canada, posted fuel economy numbers are
established following a simulated test. For more
information on how this test is performed, please visit
http://oee.nrcan.gc.ca/

Miles driven

Gallons of

fuel

Miles per

Gallon

100

L per 100 km

Liters of

fuel

Kilometers

driven

17 NSX-31T6N6000.book  359 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

360

Driving

Turbo Engine Vehicle

Handling Precautions

The turbocharger is a high-precision device designed to obtain greater horsepower
by delivering a large volume of compressed air into the engine using a turbine driven
by the engine’s exhaust gas pressure.

• When the engine is cold just after starting, avoid hard or sudden

acceleration.

• Always replace the engine oil and engine oil filter according to the

Maintenance Minder

TM

.

The turbine rotates at very high speeds over 100,000 rpm and its temperature
reaches over 1,292°F (700°C). It is lubricated and cooled by engine oil.
If you fail to replace the engine oil and filter at the scheduled distance or interval,
deteriorated engine oil may cause failure such as sticking and abnormal noise of the
turbine bearing.

1

Turbo Engine Vehicle

The scheduled maintenance intervals for replacing
the engine oil and filter is indicated on the
Maintenance Minder

TM

. Follow the information of

when to replace them.

2 Maintenance Minder

TM

 P. 365

2 Recommended Engine Oil P. 376

The temperature gauge needle is at the

 mark

when you restart the engine after driving under high
load conditions such as at high speed or in hilly
terrain. This is normal. The gauge needle goes down
after you idle or drive the vehicle for about one
minute.

H

17 NSX-31T6N6000.book  360 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

361

Maintenance

This chapter discusses basic maintenance.

Before Performing Maintenance

Inspection and Maintenance ............ 362
Safety When Performing Maintenance .... 363
Parts and Fluids Used in Maintenance

Service ........................................... 364

Maintenance Minder

TM

..................... 365

Maintenance Under the Hood and Hatch

Maintenance Items Under the Hood and

Hatch ............................................. 371

Opening the Hatch .......................... 373
Opening the Hood ........................... 374
Engine Compartment Cover............. 375
Recommended Engine Oil ................ 376
Oil Check ......................................... 377
Adding Engine Oil ............................ 380

Cooling System................................ 382
Inverter Coolant............................... 384
Transmission Fluids .......................... 385
Brake Fluid....................................... 386
Refilling Window Washer Fluid......... 386

Replacing Light Bulbs ....................... 387
Checking and Maintaining Wiper Blades.... 390
Checking and Maintaining Tires

Checking Tires ................................. 393
Tire and Loading Information Label ..... 394
Tire Labeling .................................... 394
DOT Tire Quality Grading (U.S. Vehicles)...... 396
Wear Indicators................................ 398
Tire Service Life ................................ 398
Tire and Wheel Replacement............ 399

Tire Rotation.................................... 400
Winter Tires ..................................... 401
Cold Weather Driving ...................... 402

12-Volt Battery ................................. 403
Remote Transmitter Care

Replacing the Button Battery ........... 404

Climate Control System Maintenance .... 405
Cleaning

Interior Care .................................... 406
Exterior Care.................................... 408

Accessories and Modifications

Accessories ...................................... 412
Modifications................................... 413

Storage.............................................. 414

17 NSX-31T6N6000.book  361 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

362

Main

tenan

ce

Before Performing Maintenance

Inspection and Maintenance

For your safety, perform all listed inspections and maintenance to keep your vehicle
in good condition. If you become aware of any abnormality (noise, smell, insufficient
brake fluid, oil residue on the ground, etc.), have your vehicle inspected by an
authorized Acura NSX dealer. (Note, however, that service at an authorized Acura
NSX dealer is not mandatory to keep your warranties in effect.)

■

Daily inspections

Perform inspections before long distance trips, when washing the vehicle, or when
refueling.

■

Periodic inspections

• Check the brake fluid level monthly.

2 Brake Fluid P. 386

• Check the tire pressure monthly. Examine the tread for wear and foreign objects.

2 Checking and Maintaining Tires P. 393

• Check the operation of the exterior lights monthly.

2 Replacing Light Bulbs P. 387

• Check the condition of the wiper blades at least every six months.

2 Checking and Maintaining Wiper Blades P. 390

■

Types of Inspection and Maintenance

1

Inspection and Maintenance

Maintenance, replacement, or repair of
emissions control devices and systems may be
done by any automotive repair establishment or
individuals using parts that are “certified” to
EPA standards.

According to state and federal regulations, failure to
perform maintenance on the maintenance main
items marked with # will not void your emissions
warranties. However, all maintenance services should
be performed in accordance with the intervals
indicated by the driver information interface.

2 Maintenance Service Items P. 368

If you want to perform complex maintenance tasks
that require more skills and tools, you can purchase a
subscription to the Service Express website at
www.techinfo.honda.com.

2 Authorized Manuals P. 463

If you want to perform maintenance yourself, make
sure that you have the necessary tools and skills first.
After performing maintenance, update the records in
the separate maintenance booklet.

U.S. models

17 NSX-31T6N6000.book  362 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

363

uu

Before Performing Maintenance

u

Safety When Performing Maintenance

Main

tenan

ce

Safety When Performing Maintenance

Some of the most important safety precautions are given here.
However, we cannot warn you of every conceivable hazard that can arise in
performing maintenance. Only you can decide whether or not you should perform
a given task.

• To reduce the possibility of fire or explosion, keep cigarettes, sparks, and flames

away from the 12-volt battery, all fuel related parts, and all High Voltage system
related parts.

• Never leave rags, towels, or other flammable objects under the hood and hatch.

u

Heat from the engine and exhaust can ignite them causing a fire.

• To clean parts, use a commercially available degreaser or parts cleaner, not

gasoline.

• Wear eye protection and protective clothing when working with the 12-volt

battery or compressed air.

• Engine exhaust contains carbon monoxide, which is poisonous and can kill you.

u

Operate the engine only when there is sufficient ventilation.

• The vehicle must be in a stationary condition.

u

Make sure your vehicle is parked on level ground, the parking brake is set, and
the power system is turned off.

• Be aware that hot parts can burn you.

u

Make sure to let the power system, including the engine and exhaust system,
cool thoroughly before touching vehicle parts.

• Be aware that moving parts can injure you.

u

Do not activate the power system unless instructed, and keep your hands and
limbs away from moving parts.

■

Maintenance Safety

■

Vehicle Safety

1

Safety When Performing Maintenance

3

WARNING

Improperly maintaining this vehicle or
failing to correct a problem before driving
can cause a crash in which you can be
seriously hurt or killed.

Always follow the inspection and
maintenance recommendations according
to the schedules in this owner’s manual.

3

WARNING

Failure to properly follow maintenance
instructions and precautions can cause you
to be seriously hurt or killed.

Always follow the procedures and
precautions in this owner’s manual.

17 NSX-31T6N6000.book  363 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

364

uu

Before Performing Maintenance

u

Parts and Fluids Used in Maintenance Service

Main

tenan

ce

Parts and Fluids Used in Maintenance Service

The use of Acura genuine parts and fluids is recommended when maintaining and
servicing your vehicle. Acura genuine parts are manufactured according to the same
high quality standards used in Acura vehicles.

17 NSX-31T6N6000.book  364 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

365

Main

tenan

ce

Maintenance Minder

TM

Select the Maintenance Minder to see maintenance items that are due soon and to
see the percentage of life remaining in the engine oil.

When the engine oil life is less than 15%, a Maintenance Minder message will
appear every time you set the power mode to ON, reminding you to bring your
vehicle to an authorized Acura NSX dealer for service.

17 NSX-31T6N6000.book  365 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

366

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

To Use Maintenance Minder

TM

Certain maintenance items due soon, along with the estimated remaining oil life,
appear on the driver information interface.
You can view them on the Maintenance Minder screen at any time.
1. Set the power mode to ON.
2. Roll the right selector wheel until the engine oil life appears on the driver

information interface.

■

Displaying the Engine Oil Life and Maintenance Items

1

Displaying the Engine Oil Life and Maintenance Items

Based on the engine operating conditions and oil
age, the remaining engine oil life is calculated and
displayed as a percentage.

There is a list of maintenance main and sub items you
can view on the driver information interface.

2 Maintenance Service Items P. 368

Displayed Engine Oil

Life (%)

Calculated Engine Oil

Life (%)

100

100 to 91

90

90 to 81

80

80 to 71

70

70 to 61

60

60 to 51

50

50 to 41

40

40 to 31

30

30 to 21

20

20 to 16

15

15 to 11

10

10 to 6

5

5 to 1

0

0

Remaining Engine Oil Life

Maintenance Service Items

Right Selector Wheel

17 NSX-31T6N6000.book  366 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

367

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

The system message indicator (

) comes on along with the Maintenance Minder message.

■

Maintenance Minder Messages on the Driver Information
Interface

Maintenance Message

Oil Life Display

Explanation

Information

Service Due Soon

15 %

The engine oil life indicator starts to appear
along with other due-soon maintenance item
codes when the remaining oil life drops to 15
percent. Once you switch the display by
rolling the right selector wheel, this message
will go off.

The engine oil is approaching the end
of its service life.

Service Due Now

5 %

The remaining engine oil life is 5 to 1
percent. Roll the right selector wheel to
switch to another display.

The engine oil has almost reached
the end of its service life, and the
maintenance items should be
inspected and serviced as soon as
possible.

Service Past Due

Negative Distance

The engine oil life has passed its service life,
and a negative distance appears after driving
over 10 miles (U.S. models) or 10 km
(Canadian models). Roll the right selector
wheel to switch to another display.

The engine oil life has passed.
The maintenance items must be
inspected and serviced immediately.

17 NSX-31T6N6000.book  367 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

368

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

■

Maintenance Service Items

1

Maintenance Service Items

•

Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.

•

Inspect idle speed every 160,000 miles (256,000
km).

•

Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.

•

Inspect direct injection + port injection fuel system
every 3 years or service item B is indicated.

•

Inspect tire condition every 3,100 miles (5,000 km).

Maintenance Minder Message

System Message
Indicator

Main Item

Sub Items

*1: If a message SERVICE does not appear more than 12 months after the display is reset, change the

engine oil every year.

# : See information on maintenance and emissions warranty.

CODE

Maintenance Main Items

A

●

Replace engine oil

*1

B

●

Replace engine oil

*1

 and oil filter

●

Inspect front and rear brakes

●

Check expiration date for temporary tire repair kit
bottle

●

Inspect tie rod ends, steering gearbox, and boots

●

Inspect suspension components

●

Inspect driveshaft boots

●

Inspect brake hoses and lines (Including ABS/VSA)

●

Inspect all fluid levels and condition of fluids

●

Inspect exhaust system

#

●

Inspect fuel lines and connections

#

●

Inspect direct injection + port injection fuel system

*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and

from diesel-powered vehicles, replace the dust and pollen filters every 15,000 miles (24,000 km) or
every year.

*4: Driving in mountainous areas at very low vehicle speeds results in higher transmission temperature.

This requires transmission fluid and clutch fluid changes more frequently than recommended by the
Maintenance Minder. If you regularly drive your vehicle under this condition, have the transmission
fluid and clutch fluid changed every 20,000 miles (32,000 km).

*5: Driving in mountainous areas at very low vehicle speeds results in higher level of mechanical (Shear)

stress to fluid. This requires Twin Motor Unit fluid changes more frequently than recommended by the
Maintenance Minder. If you regularly drive your vehicle under these conditions, have the Twin Motor
Unit fluid changed at 7,500 miles (12,000 km), then every 15,000 miles (24,000 km).

CODE

Maintenance Sub Items

1

●

Inspect tire condition

2

●

Replace air cleaner element

*2

●

Replace dust and pollen filters

*3

3

●

Replace transmission fluid

*4

●

Replace clutch fluid

*4

4

●

Replace spark plugs

●

Inspect valve clearance

●

Inspect Active Exhaust Valve function

●

Replace Intake Sound Control

5

●

Replace engine coolant

6

●

Replace Twin Motor Unit fluid

*5

17 NSX-31T6N6000.book  368 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

Continued

369

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

Reset the Maintenance Minder display if you have performed the maintenance
service.

1. Set the power mode to ON.
2. Roll the right selector wheel until the engine oil life appears on the driver

information interface.

3. With all doors closed, press and hold the right selector wheel for more than 10

seconds to enter the reset mode.

4. Select All Due Items with the right selector wheel, then press the right selector

wheel.

u

The displayed maintenance items disappear, and the engine oil life display
returns to 100%.

To cancel the oil life reset mode, select Cancel with the right selector wheel, then
press the right selector wheel.

■

Resetting the Display

1

Resetting the Display

NOTICE

Failure to reset the Maintenance Minder

TM

 display

after a maintenance service results in the system
showing incorrect maintenance intervals, which can
lead to serious mechanical problems.

An authorized Acura NSX dealer will reset the
Maintenance Minder

TM

 display after completing the

required maintenance service. If someone other than
an authorized Acura NSX dealer performs
maintenance service, reset the Maintenance
Minder

TM

 display yourself.

Right Selector
Wheel

Using the driver information interface

17 NSX-31T6N6000.book  369 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

370

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

1. Set the power mode to ON.
2. Select

 on the audio/information screen.

3. Select Settings.
4. Select Vehicle, then Maintenance Info.
5. Select Reset.

u

A confirmation message appears on the screen.

6. Select Reset.

u

The engine oil life display returns to 100%.

To cancel the oil life reset mode, select Cancel.

Using the audio/information screen

17 NSX-31T6N6000.book  370 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

371

Continued

Main

tenan

ce

Maintenance Under the Hood and Hatch

Maintenance Items Under the Hood and Hatch

Hood

Brake Fluid
(Black Cap)

Washer Fluid
(Black Cap)

12-Volt Battery

Inverter Coolant
Filler Tank

17 NSX-31T6N6000.book  371 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

372

uu

Maintenance Under the Hood and Hatch

u

Maintenance Items Under the Hood and Hatch

Main

tenan

ce

Hatch

Engine Oil Fill Cap

Engine Coolant
Reserve Tank Cap

Engine Oil Dipstick
(Orange)

Engine Coolant
Reserve Tank

17 NSX-31T6N6000.book  372 ページ  ２０１６年４月２２日　金曜日　午後３時４４分
