344

uu

Maintenance Under the Hood

u

Adding Engine Oil

Main

tenan

ce

Adding Engine Oil

1. Unscrew and remove the engine oil fill cap.
2. Add oil slowly.
3. Reinstall the engine oil fill cap, and tighten

it securely.

4. Wait for three minutes and recheck the

engine oil dipstick.

1

Adding Engine Oil

NOTICE

Do not fill the engine oil above the upper mark.
Overfilling the engine oil can result in leaks and
engine damage.

If any oil spills, wipe it away immediately. Spilled oil
may damage the engine compartment components.

Engine Oil Fill Cap

17 ACURA MDX E-AWD-31TRX6000.book  344 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

345

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

Continued

Main

tenan

ce

Changing the Engine Oil and Oil Filter

You must change the engine oil and oil filter regularly in order to maintain the
engine’s lubrication. The engine may be damaged if they are not changed regularly.

Change the oil and filter in accordance with the maintenance message on the multi-
information display.

1. Run the engine until it reaches normal

operating temperature, and then turn the
engine off.

2. Open the hood and remove the engine oil

fill cap.

3. Remove the drain bolt and washer from

the bottom of the engine, and drain the
oil into a suitable container.

1

Changing the Engine Oil and Oil Filter

NOTICE

You may damage the environment if you do not
dispose of the oil in a suitable way. If you are
changing the oil by yourself, appropriately dispose of
the used oil. Put the oil in a sealed container and take
it to a recycling center. Do not throw the oil away
into a garbage can or onto the ground.

Washer

Drain Bolt

17 ACURA MDX E-AWD-31TRX6000.book  345 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

346

Main

tenan

ce

4. Remove the oil filter and dispose of the

remaining oil.

5. Check that the filter gasket is not stuck to

the engine contact surface.

u

If it is stuck, you must detach it.

6. Wipe away dirt and dust adhering to the

contact surface of the engine block, and
install a new oil filter.

u

Apply a light coat of new engine oil to
the filter gasket.

7. Put a new washer on the drain bolt, then

reinstall the drain bolt.

u

Tightening torque:
29 lbf∙ft (39 N∙m, 4.0 kgf∙m)

8. Pour the recommended engine oil into the

engine.

u

Engine oil change capacity (including
filter):
4.5 US qt (4.3 ℓ)

9. Reinstall the engine oil fill cap securely and

start the engine.

10. Run the engine for a few minutes, and

then check that there is no leak from the
drain bolt or oil filter.

11. Stop the engine, wait for three minutes,

and then check the oil level on the
dipstick.

u

If necessary, add more engine oil.

1

Changing the Engine Oil and Oil Filter

You will need a special wrench to replace the oil
filter. You can buy this wrench from a dealer.

When installing the new oil filter, follow the
instructions supplied with the oil filter.

Reinstall the engine oil fill cap. Start the engine. The
low oil pressure indicator should go off within five
seconds. If it does not, turn off the engine, and check
your work.

Oil Filter

17 ACURA MDX E-AWD-31TRX6000.book  346 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

347

uu

Maintenance Under the Hood

u

Cooling System

Continued

Main

tenan

ce

Cooling System

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the engine coolant level every time you refuel. Check the
reserve tank first. If it is completely empty, also check the coolant level in the
radiator. Add the engine coolant accordingly.

1. Make sure the engine and radiator are cool.
2. Check the amount of coolant in the reserve

tank.

u

If the coolant level is below the MIN
mark, add the specified coolant until it
reaches the MAX mark.

2 Engine Compartment Cover P. 341

3. Inspect the cooling system for leaks.

Specified coolant: Acura Long Life Antifreeze/Coolant Type 2

■

Reserve Tank

1

Cooling System

NOTICE

Genuine Acura engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about –31°F (–35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Acura antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Acura coolant can result in
corrosion, causing the cooling system to malfunction
or fail. Have the cooling system flushed and refilled
with Acura antifreeze/coolant as soon as possible.

Do not add rust inhibitors or other additives to your
vehicle’s cooling system. They may not be compatible
with the coolant or with the engine components.

3

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

MAX

MIN

17 ACURA MDX E-AWD-31TRX6000.book  347 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

uu

Maintenance Under the Hood

u

Cooling System

348

Main

tenan

ce

1. Make sure the engine and radiator are

cool.

2. Remove the engine compartment cover.

2 Engine Compartment Cover P. 341

3. Turn the radiator cap 1/8 turn counter-

clockwise and relieve any pressure in the
coolant system.

4. Push down and turn the radiator cap

counter-clockwise to remove it.

5. The coolant level should be up to the base

of the filler neck. Add coolant if it is low.

6. Put the radiator cap back on, and tighten it

fully.

■

Radiator

1

Radiator

NOTICE

Pour the fluid slowly and carefully so you do not spill
any. Clean up any spills immediately; they can
damage components in the engine compartment.

Radiator Cap

17 ACURA MDX E-AWD-31TRX6000.book  348 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

349

uu

Maintenance Under the Hood

u

Inverter Coolant

Main

tenan

ce

Inverter Coolant

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the inverter coolant level every time you refuel. Check
the filler tank. Add the inverter coolant accordingly.

Have a dealer replace the inverter coolant.

1. Check the fluid level in the tank.
2. If the coolant level has dropped below the

MIN level, have your vehicle serviced at a
dealer.

u

Only a properly trained technician can
refill the coolant and check the system
for leaks.

Specified coolant: Acura Long Life Antifreeze/Coolant Type 2

■

Checking the Coolant

1

Inverter Coolant

NOTICE

Genuine Acura engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about –31°F (–35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Acura antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Acura coolant can result in
corrosion, causing the cooling system to malfunction
or fail. Have the cooling system flushed and refilled
with Acura antifreeze/coolant as soon as possible.

Do not add rust inhibitors or other additives to your
vehicle’s coolant system. They may not be compatible
with the coolant or with the motor components.

MAX

MIN

Filler Tank

17 ACURA MDX E-AWD-31TRX6000.book  349 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

350

uu

Maintenance Under the Hood

u

Transmission Fluid

Main

tenan

ce

Transmission Fluid

Have a dealer check the fluid level and replace if necessary.

Do not attempt to check or change the dual clutch transmission fluid yourself.

■

Dual Clutch Transmission Fluid

Specified fluid: Acura Automatic Transmission Fluid ATF DW-1

1

Dual Clutch Transmission Fluid

NOTICE

Do not mix Acura ATF DW-1 with other
transmission fluids.
Using a transmission fluid other than Acura ATF
DW-1 may adversely affect the operation and
durability of your vehicle’s transmission, and damage
the transmission.
Any damage caused by using a transmission fluid that
is not equivalent to Acura ATF DW-1 is not covered
by Acura’s new vehicle limited warranty.

17 ACURA MDX E-AWD-31TRX6000.book  350 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

351

uu

Maintenance Under the Hood

u

Brake Fluid

Main

tenan

ce

Brake Fluid

The fluid level should be between the MIN
and MAX marks on the side of the reserve
tank.

Refilling Window Washer Fluid

If the washer fluid is low, a message appears on the MID.
Pour the washer fluid carefully. Do not overflow the reservoir.

Specified fluid: Acura Heavy Duty Brake Fluid DOT 3

■

Checking the Brake Fluid

1

Brake Fluid

NOTICE

Brake fluid marked DOT 5 is not compatible with your
vehicle’s braking system and can cause extensive
damage.

If the specified brake fluid is not available, you should
use only DOT 3 or DOT 4 fluid from a sealed
container as a temporary replacement.

Using any non-Acura brake fluid can cause corrosion
and decrease the longevity of the system. Have the
brake system flushed and refilled with Acura Heavy
Duty Brake Fluid DOT 3 as soon as possible.

If the brake fluid level is at or below the MIN mark,
have a dealer inspect the vehicle for leaks or worn
brake pads as soon as possible.

Brake Reserve Tank

MIN

MAX

1

Refilling Window Washer Fluid

NOTICE

Do not use engine antifreeze or a vinegar/water
solution in the windshield washer reservoir.
Antifreeze can damage your vehicle’s paint. A
vinegar/water solution can damage the windshield
washer pump.

17 ACURA MDX E-AWD-31TRX6000.book  351 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

352

Main

tenan

ce

Replacing Light Bulbs

Headlights

Headlights are LED type. Have an authorized Acura dealer inspect and replace the
light assembly.

Front Turn Signal/Parking, Daytime Running and
Front Side Marker Lights

Front turn signal/parking, daytime running and front side marker lights are LED type.
Have an authorized Acura dealer inspect and replace the light assembly.

Fog Lights

*

Fog lights are LED type. Have an authorized Acura dealer inspect and replace the
light assembly.

Side Turn Signal/Emergency Indicator Lights

Door mirror side turn lights are LED type. Have an authorized Acura dealer inspect
and replace the light assembly.

1

Headlights

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the cargo area, have the aiming
readjusted at a dealer or by a qualified technician.

* Not available on all models

17 ACURA MDX E-AWD-31TRX6000.book  352 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

353

uu

Replacing Light Bulbs

u

Brake Light and Rear Turn Signal Light Bulbs

Continued

Main

tenan

ce

Brake Light and Rear Turn Signal Light Bulbs

When replacing, use the following bulbs.

1. Remove the cover.

u

Starting at the bottom, carefully pull the
cover straight out, working upward until
all pins are removed from their
grommets.

u

The grommets should remain in the
body.

2. Use a Phillip-head screwdriver to remove

the bolts.

3. Pull the light assembly out of the rear pillar.

Brake Light: 21 W
Rear Turn Signal Light: 21 W

Bolts

17 ACURA MDX E-AWD-31TRX6000.book  353 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

354

uu

Replacing Light Bulbs

u

Taillights/Rear Side Maker Lights

Main

tenan

ce

4. Turn the socket counter-clockwise and

remove it. Remove the old bulb.

5. Insert a new bulb.
6. Slide the light assembly onto the guide on

the body.

7. Align the pins with the body grommets,

then push in until they fully seat.

Taillights/Rear Side Maker Lights

Taillights/rear side maker lights are the LED type. Have an authorized Acura dealer
inspect and replace the light assembly.

Bulb

Socket

17 ACURA MDX E-AWD-31TRX6000.book  354 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

355

uu

Replacing Light Bulbs

u

Back-Up Light Bulbs

Main

tenan

ce

Back-Up Light Bulbs

When replacing, use the following bulbs.

1. Remove the cover by prying on the edge

using a flat-tip screwdriver.

u

Wrap the flat-tip screwdriver with a cloth
to prevent scratches.

2. Turn the socket counter-clockwise and

remove it. Remove the old bulb.

3. Insert a new bulb.

Taillights

Taillights are the LED type. Have an authorized Acura dealer inspect and replace the
light assembly.

Back-Up Light: 21 W

Bulb

Socket

17 ACURA MDX E-AWD-31TRX6000.book  355 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

356

uu

Replacing Light Bulbs

u

Rear License Plate Lights

Main

tenan

ce

Rear License Plate Lights

Rear license plate lights are LED type. Have an authorized Acura dealer inspect and
replace the light assembly.

High-Mount Brake Light

High-mount brake light is LED type. Have an authorized Acura dealer inspect and
replace the light assembly.

Puddle Lights

Puddle lights are LED type. Have an authorized Acura dealer inspect and replace the
light assembly.

17 ACURA MDX E-AWD-31TRX6000.book  356 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

357

Continued

Main

tenan

ce

Checking and Maintaining Wiper Blades

Checking Wiper Blades

If the wiper blade rubber has deteriorated, it will leave streaks and the hard surfaces
of the blade may scratch the window glass.

Changing the Front Wiper Blade Rubber

1. Lift the driver side wiper arm first, then the

passenger side.

2. Pry on the edge of the lock tab using a flat-

tip screwdriver to push it up.
Wrap the flat-tip screwdriver with a cloth to
prevent scratches.

3. Slide the holder off the wiper arm.

1

Changing the Front Wiper Blade Rubber

NOTICE

Avoid dropping the wiper arm onto the windshield, it
may damage the wiper arm and/or the windshield.

Lock Tab

17 ACURA MDX E-AWD-31TRX6000.book  357 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

358

uu

Checking and Maintaining Wiper Blades

u

Changing the Front Wiper Blade Rubber

Main

tenan

ce

4. Slide the wiper blade out of the holder by

pulling the tabbed end out.

5. Remove the retainers from the wiper blade

that has been removed, and mount to a
new wiper blade.

u

Correctly align the wiper blade
protrusion and the retainer grooves.

6. Slide the new wiper blade onto the holder

from the bottom end.

u

The tab on the holder should fit in the
indent of the wiper blade.

7. Slide the holder onto the wiper arm, then

push down the lock tab.

8. Lower the passenger side wiper arm first,

then the driver side.

Blade

Retainer

Blade

17 ACURA MDX E-AWD-31TRX6000.book  358 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

359

uu

Checking and Maintaining Wiper Blades

u

Changing the Rear Wiper Blade Rubber

Continued

Main

tenan

ce

Changing the Rear Wiper Blade Rubber

1. Raise the wiper arm off.

2. Slide the wiper blade out from the end with

the indent.

3. Remove the retainers from wiper blade and

mount to a new rubber blade.

1

Changing the Rear Wiper Blade Rubber

NOTICE

Avoid dropping the wiper arm, it may damage the
rear window.

Blade

Retainer

Rubber

17 ACURA MDX E-AWD-31TRX6000.book  359 ページ  ２０１７年１月２０日　金曜日　午後２時５３分
