Acura MDX Hybrid (2017 year). Manual - part 18

uu

When Driving

u

Lane Keeping Assist System (LKAS)

280

Driving

Provides assistance to keep the vehicle in the center of the lane. When the vehicle
nears a white or yellow line, steering force of the electric power steering will become
stronger.

When the vehicle enters the warning area, the LKAS alerts you with slight steering
wheel vibration as well as a warning display.

■

Lane Keep Support Function

1

Lane Keeping Assist System (LKAS)

When it fails to detect lanes, the system will
temporarily be canceled. When lane is detected,
system will recover automatically.

■

Lane Departure Warning Function

Warning Area

Warning Area

17 ACURA MDX E-AWD-31TRX6000.book  280 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

Continued

281

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

The system can be used when the following conditions are met.
• The lane in which you are driving has detectable lane markers on both sides, and

your vehicle is in the center of the lane.

• The vehicle speed is between 45 and 90 mph (72 and 145 km/h).
• You are driving on a straight or slightly curved road.
• The turn signals are off.
• The brake pedal is not depressed.
• The wipers are not in continuous operation.

■

How to activate the system

1. Press the MAIN button.

u

The LKAS is on in the MID.
The system is ready to use.

2. Press the LKAS button.

u

Lane outlines appear on the MID.
The system is activated.

■

When the System can be Used

1

Lane Keeping Assist System (LKAS)

If the vehicle drifts toward either left or right lane line
due to the system applying torque, turn off the LKAS
and have your vehicle checked by a dealer.

MAIN Button

LKAS Button

17 ACURA MDX E-AWD-31TRX6000.book  281 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

uu

When Driving

u

Lane Keeping Assist System (LKAS)

282

Driving

3. Keep your vehicle near the center of the

lane while driving.

u

The dotted outer lines change to solid
ones once the system starts operating
after detecting the left and right lane
markings.

To cancel the LKAS:
Press the MAIN or LKAS button.

The LKAS is turned off every time you turn the
power system off, even if you turned it on the
last time you drove the vehicle.

■

To cancel

1

When the System can be Used

The LKAS temporarily deactivates when it fails to
detect lane lines. When the system detects the lines
again, it comes back on automatically.

1

To cancel

Pressing the MAIN button also turns ACC with LSF
on and off.

MAIN Button

LKAS Button

17 ACURA MDX E-AWD-31TRX6000.book  282 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

283

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Continued

Driving

■

The system operation is suspended if
you:

• Set the wipers to continuous operation.

u

Turning the wipers off resumes the
LKAS.

• Decrease the vehicle speed to about 40

mph (64 km/h) or less.

u

Increasing the vehicle speed to about 45
mph (72 km/h) or more resumes the
LKAS.

• Depress the brake pedal.

u

The LKAS resumes and starts detecting
the lane lines again once you release the
brake pedal.

• Set the wiper switch to AUTO and the

wipers operate continuously.

u

The LKAS resumes when the wipers stop
or operate intermittently.

When the LKAS is suspended,
the lane lines on the MID
change to contour lines.

17 ACURA MDX E-AWD-31TRX6000.book  283 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

284

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

■

The LKAS may automatically be suspended when:

• The system fails to detect lane lines.
• The steering wheel is quickly turned.
• You fail to steer the vehicle.
• The vehicle runs on a curved road over the speed limit.

Once these conditions no longer exist, the LKAS automatically resumes.

■

The LKAS may automatically be canceled when:

• The camera temperature gets extremely high or low.
• The camera behind the rearview mirror, or the area around the camera, including

the windshield, gets dirty.

• Driving through a sharp curve.
• Driving at a speed in excess of approximately 90 mph (145 km/h).
• The ABS or VSA® system engages.

The beeper sounds if the LKAS is automatically canceled.

17 ACURA MDX E-AWD-31TRX6000.book  284 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

285

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Continued

Driving

The system may not detect lane markings and therefore may not keep the vehicle in
the middle of a lane under certain conditions, including the following:

■

Environmental conditions

• Driving in bad weather (rain, fog, snow, etc.).
• Sudden changes between light and dark, such as an entrance or exit of a tunnel.
• There is little contrast between lane lines and the roadway surface.
• Driving into low sunlight (e.g., at dawn or dusk).
• Strong light is reflected onto the roadway.
• Driving in the shadows of trees, buildings, etc.
• Shadows of adjacent objects are parallel to lane markings.
• Roadway objects or structures are misinterpreted as lane markers.
• Reflections on the interior of the windshield.
• Driving at night or in a dark condition such as a tunnel.

■

LKAS Conditions and Limitations

17 ACURA MDX E-AWD-31TRX6000.book  285 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

286

uu

When Driving

u

Lane Keeping Assist System (LKAS)

Driving

■

Roadway conditions

• Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,

reflected lights, road spray, high contrast).

• Driving on a road with temporary lane markings.
• Faint, multiple, or varied lane markings are visible on the roadway due to road

repairs or old lane markings.

• The roadway has merging, split, or crossing lines (e.g., such as at an intersection

or crosswalk).

• The lane markings are extremely narrow, wide, or changing.
• The vehicle in front of you is driving near the lane lines.
• The road is hilly or the vehicle is approaching the crest of a hill.
• Driving on rough or unpaved roads, or over bumpy surfaces.
• When objects on the road (curb, guard rail, pylons, etc.) are recognized as white

lines (or yellow lines).

• Driving on roads with double lines.

■

Vehicle conditions

• Headlight lenses are dirty or the headlights are not properly adjusted.
• The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet

snow, etc.

• The inside of the windshield is fogged.
• The camera temperature gets too high.
• An abnormal tire or wheel condition (wrong sized, varied size or construction,

improperly inflated, compact spare tire

*

, etc.).

• The vehicle is tilted due to a heavy load or suspension modifications.

* Not available on all models

17 ACURA MDX E-AWD-31TRX6000.book  286 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

287

uu

When Driving

u

Vehicle Stability Assist (VSA®), aka Electronic Stability Control (ESC), System

Continued

Driving

Vehicle Stability Assist (VSA®), aka Electronic
Stability Control (ESC), System

VSA® helps to stabilize the vehicle during cornering if the vehicle turns more or less
than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating engine and motor output and selectively applying the
brakes.

When VSA® activates, you may notice that the
engine and motor do not respond to the
accelerator. You may also notice some noise
from the hydraulic system. You will also see
the indicator blink.

■

VSA® Operation

1

Vehicle Stability Assist (VSA®), aka Electronic Stability Control
(ESC), System

The VSA® may not function properly if tire type and
size are mixed. Make sure to use the same size and
type of tire, and the air pressures as specified.

When the VSA® system indicator comes on and stays
on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

VSA® cannot enhance stability in all driving situations
and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA® system is generally
known as Electronic Stability Control (ESC). The
system also includes a traction control function.

VSA® System
Indicator

17 ACURA MDX E-AWD-31TRX6000.book  287 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

uu

When Driving

u

Vehicle Stability Assist (VSA®), aka Electronic Stability Control (ESC), System

288

Driving

This button is on the driver side control panel.
To partially disable VSA® functionality/
features, press and hold it until you hear a
beep.

The traction control stops fully functioning,
allowing the wheels to spin more freely at low
speed. The VSA® OFF indicator will also come
on.

To restore VSA® functionality/features, press
the

(VSA® OFF) button until you hear a

beep.

VSA® is turned on every time you turn the
power system on, even if you turned it off the
last time you drove the vehicle.

■

VSA® On and Off

1

Vehicle Stability Assist (VSA®), aka Electronic Stability Control
(ESC), System

With the

 button pressed, your vehicle will have

normal braking and cornering ability, but VSA®
traction and stability enhancement becomes less
effective.

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA® temporarily switched off.

When the

 button is pressed, the traction control

function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA® off if
you are not able to free it when the VSA® is on.

Immediately after freeing your vehicle, be sure to
switch VSA® on again. We do not recommend driving
your vehicle with the VSA® system switched off.

You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after turning the power
system on or while driving. This is normal.

VSA® OFF Indicator

17 ACURA MDX E-AWD-31TRX6000.book  288 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

289

uu

When Driving

u

Agile Handling Assist

Driving

Agile Handling Assist

Lightly brakes each of the front and rear wheels, as needed, when you turn the
steering wheel, and helps support the vehicle’s stability and performance during
cornering.

1

Agile Handling Assist

The agile handling assist cannot enhance stability in
all driving situations. You still need to drive and
corner at speeds appropriate for the conditions and
always leave a sufficient margin of safety.

When the VSA® system indicator comes on and stays
on while driving, the agile handling assist does not
activate.

You may hear a sound coming from the engine
compartment while the agile handling assist is
activated. This is normal.

17 ACURA MDX E-AWD-31TRX6000.book  289 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

290

uu

When Driving

u

SPORT HYBRID Super Handling-All Wheel Drive

TM

 (SPORT HYBRID SH-AWD®)

Driving

SPORT HYBRID Super Handling-All Wheel Drive

TM



(SPORT HYBRID SH-AWD®)

The system controls and transfers varying amounts of motor and/or engine torque
to each wheel in accordance with the driving conditions.

SPORT HYBRID SH-AWD® helps to enhance driving stability, and lets you handle
situations like slippery surfaces, such as snow, sand, mud, and steep hills, better
than when driving with standard two wheel drive. However, the system does not
help to enhance braking. Be cautious about the following:
• It is still your responsibility to drive safely when you steer, accelerate, and apply

brakes.

• Leave a sufficient margin when braking on slippery surfaces.

1

SPORT HYBRID Super Handling-All Wheel Drive

TM

 (SPORT

HYBRID SH-AWD®)

Do not drive through deep water.

The SPORT HYBRID SH-AWD® system may not
function properly if tire type and size are mixed.
Make sure to use the same size and type of tire, and
the air pressures as specified.

2 Tire and Wheel Replacement P. 367

17 ACURA MDX E-AWD-31TRX6000.book  290 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

291

uu

When Driving

u

Blind spot information (BSI) System

Continued

Driving

Blind spot information (BSI) System

Is designed to detect vehicles in specified alert zones adjacent to your vehicle,
particularly in harder to see areas commonly known as “blind spots.”

When the system detects vehicles approaching from behind in adjacent lanes, the
appropriate indicator comes on for a few seconds, providing assistance when you
change lanes.

■

How the system works

1

Blind spot information (BSI) System

Important Safety Reminder
Like all assistance systems, BSI has limitations. Over
reliance on BSI may result in a collision.

The system is for your convenience only. Even if an
object is within the alert zone, the following
situations may occur.

•

The BSI alert indicator may not come on due to
obstruction (splashes, etc.) even without the Blind
Spot Info Not Available MID appearing.

•

The BSI alert indicator may come on even with the
message appearing.

3

WARNING

Failure to visually confirm that it is safe to
change lanes before doing so may result in
a crash and serious injury or death.
Do not rely only on the blind spot
information system when changing lanes.

Always look in your mirrors, to either side
of your vehicle, and behind you for other
vehicles before changing lanes.

Alert zone range
A: Approx. 1.6 ft. (0.5 m)
B: Approx. 10 ft. (3 m)
C: Approx. 10 ft. (3 m)

Radar Sensors:
underneath the
rear bumper
corners

Alert Zone

A

B

C

●

The transmission is in

(

D or

(

S.

●

Your vehicle speed is
between 20 mph (32
km/h) and 100 mph
(160 km/h)

17 ACURA MDX E-AWD-31TRX6000.book  291 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

uu

When Driving

u

Blind spot information (BSI) System

292

Driving

■

When the system detects a vehicle

BSI Alert Indicator: Located near the outside
rearview mirror on both sides.

Comes on when:
• A vehicle enters the alert zone from behind

to overtake you with a speed difference of
no more than 31 mph (50 km/h) from your
vehicle.

• You pass a vehicle with a speed difference

of no more than 12 mph (20 km/h).

Blinks and a beeper sounds when:
You move the turn signal lever in the direction
of the detected vehicle. The beeper sounds
three times.

1

Blind spot information (BSI) System

The BSI alert indicator may not come on under the
following conditions:

•

A vehicle does not stay in the alert zone for more
than two seconds.

•

A vehicle is parked in a side lane.

•

The speed difference between your vehicle and the
vehicle you are passing is greater than 6 mph (10
km/h).

•

An object not detected by the radar sensors
approaches or passes your vehicle.

•

A vehicle running in the adjacent lane is a
motorcycle or other small vehicle.

You can turn off the audible alert, or all the BSI alert
using the audio/information screen or MID.

2 Customizable Features P. 128

BSI may be adversely affected when:

•

Objects (guard rails, poles, trees, etc,.) are
detected.

•

An object that does not reflect radio waves well,
such as a motorcycle, is in the alert zone.

•

Driving on a curved road.

•

A vehicle is moving from a far lane to the adjacent
lane.

•

The system picks up external electrical interference.

•

The rear bumper or the sensors have been
improperly repaired or the rear bumper has been
deformed.

•

The orientation of the sensors has been changed.

•

In bad weather (Heavy rain, snow, and fog).

Comes On

Blinks

17 ACURA MDX E-AWD-31TRX6000.book  292 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

293

uu

When Driving

u

Blind spot information (BSI) System

Driving

1

Blind spot information (BSI) System

For a proper BSI operation:

•

Always keep the rear bumper corner area clean.

•

Do not cover the rear bumper corner area with
labels or stickers of any kind.

•

Take your vehicle to a dealer if you need the rear
bumper corner area or the radar sensors to be
repaired, or the rear bumper corner area is strongly
impacted.

The system does not operate when in

(

R.

17 ACURA MDX E-AWD-31TRX6000.book  293 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

294

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) with Tire Fill Assist

Driving

Tire Pressure Monitoring System (TPMS) with Tire
Fill Assist

Monitors the tire pressure while you are
driving. If your vehicle’s tire pressure becomes
significantly low, the low tire pressure/TPMS
indicator comes on and a message appears on
the MID.

1

Tire Pressure Monitoring System (TPMS) with Tire Fill Assist

Conditions such as low ambient temperature and
altitude change directly affect tire pressure and can
trigger the low tire pressure/TPMS indicator to come
on.

2 If the Low Tire Pressure/TPMS Indicator

Comes On or Blinks P. 416

Tire pressure checked and inflated in:

•

Warm weather can become under-inflated in
colder weather.

•

Cold weather can become over-inflated in warmer
weather.

The low tire pressure/TPMS indicator will not come
on as a result of over inflation.

The TPMS audibly and visually informs you of
changes in tire pressure of the individual tire that you
are adjusting using audible and visual indications.

If a change in tire pressure has been significant, the
system beeps and the hazard lights flash continuously
for five seconds when the specified tire pressure is
reached. Stop filling the tire.

17 ACURA MDX E-AWD-31TRX6000.book  294 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

295

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) with Tire Fill Assist

Driving

To select the tire pressure monitor, set the power
mode to ON, and roll the multi-function
steering-wheel controls until you see the tire
pressure screen.

The pressure for each tire is displayed in psi
(U.S.) or kPa (Canada).

Tire Pressures Low is displayed when a tire
has significantly low pressure. The specific tire
is displayed on the screen.

■

Tire Pressure Monitor

1

Tire Pressure Monitor

The pressure displayed on the MID can be slightly
different from the actual pressure as measured by a
gauge. If there is a significant difference between the
two values, or if the low tire pressure/TPMS indicator
and the message on the MID do not go off after you
have inflated the tire to the specified pressure, have
the system checked by a dealer.

Tire Pressure Monitor Problem may appear if you
drive with the compact spare tire

*

, or there is a

problem with the TPMS.

* Not available on all models

17 ACURA MDX E-AWD-31TRX6000.book  295 ページ  ２０１７年１月２０日　金曜日　午後２時５３分
