Acura ILX Hybrid (2015 year). Manual - part 2
Steering Wheel
(P132)
Trunk
(P114)
Power Windows
(P120)
● To adjust, pull the adjustment lever
● With the power mode in ON, open and
towards you, adjust to the desired
close the power windows.
position, then lock the lever back in place.
● If the power window lock button is in the
off position, each passenger's window
can be opened and closed with its own
switch.
● If the power window lock button is in the
on position (indicator is on), each
passenger's window switch is disabled.
Trunk Release
Power Window Lock Button
Indicator
● To unlock and open the trunk:
• Pull the trunk release.
• Press the trunk release button on the
keyless access remote.
• Press the trunk release button on the
Unlocking the Front
trunk lid.
Doors from the Inside
Power Door Mirrors
(P111)
Window Switch
(P134)
● Pull either front door inner handle to
unlock and open it in one motion.
● With the power mode in ON, move the
selector switch to L or R.
● Push the appropriate edge of the
adjustment switch to adjust the mirror.
Selector Switch
Adjustment Switch
17
Climate Control System
(P 146)
Clock
(P 104)
● Press the AUTO button to activate the climate control system.
Models without navigation system
● Press the
button to turn the system on or off.
a Press the CLOCK (AUX) button until the
● Press the
button to defrost the windshield.
displayed time begins flashing.
On models with navigation system
b Press Preset 4 (Hour) or 5 (Minute)
The climate control system is voice operable. See the Navigation System Manual for
to set the time. Press Preset 6 (Reset)
complete details.
to set the time to the nearest hour.
/
(Fan Control) Buttons
c Press the CLOCK button again to set
the time.
(ON/OFF) Button
(Windshield Defroster) Button
Models with navigation system
The navigation system receives signals from
GPS satellites, updating the clock
Driver's Side
Passenger's Side
automatically.
Temperature
Temperature
Control Dial
Control Dial
AUTO Button
MODE Control Button
SYNC (Synchronized) Button
A/C (Air Conditioning) Button
(Recirculation) Button
Air flows from dashboard vents.
Air flows from floor and
dashboard vents.
Air flows from floor vents.
Air flows from floor and
windshield defroster vents.
18
● Audio Remote Controls
(P 159)
Features
(P151)
VOL Button
MODE Button
Audio system
(P 152) For navigation system operation
() See the Navigation System Manual
Audio/
Information Screen
CH Button
● VOL (Volume) Button
Press
/
to adjust the volume up/
AM Button*
VOL /
(Volume/Power) Knob
down.
FM Button*
● MODE Button
CD Slot
(CD Eject) Button
Press to change the audio mode: FM1/
FM2/AM/XM1*/XM2*/CD/AUX.
(XM®) Button*
● CH (Channel) Button
CD Button
FM/AM Button*
Radio:Press to change the preset station.
AUX Button
Press and hold to select the next or
previous strong station.
Preset Buttons
CD/USB device:
FOLDER Bar*
SKIP Bar
Press to skip to the beginning of
the next song or return to the
beginning of the current song.
A.SEL (Auto Select)
*
Press and hold to change a folder.
CATEGORY Bar
Button
SCAN Button
DISPLAY Button
BACK Button
PHONE Button
SETUP Button
Selector Knob
* Not available on all models
19
Driving
(P219)
Continuous Variable Transmission
7-Speed Manual Shift Mode
(P233)
● Allows you to manually shift the transmission up or down without
(CVT)
(P231 )
removing your hands from the steering wheel.
● Shift to P and depress the brake pedal when starting the
When the shift lever is in
engine.
Shift Lever
● Pulling a paddle shifter temporarily
● Shifting
Release Button
changes the mode from continuous
Shift Lever
Park
variable transmission (CVT) to 7-speed
Turn off or start the engine.
Position
manual shift mode. The selected
Transmission is locked.
Indicator
speed number is displayed in the shift
indicator.
Reverse
Selected Speed
Used when reversing.
When the shift lever is in
Number
Neutral
● Pulling a paddle shifter changes the
Transmission is not locked.
M Indicator
mode from continuous variable
transmission (CVT) to 7-speed manual
Drive
• Normal driving.
shift mode. The M indicator and the
• 7-speed mode can be used temporarily.
selected speed number are displayed
in the shift indicator.
Drive (S)
Shift Down -
Shift Up +
L (Low) Mode
(P235)
Used for:
Paddle Shifter
Paddle Shifter
● Use Low to get more power when
• Better acceleration
climbing steep hills.
• Increased engine braking
● With the shift lever in S, pull the +
• Going up or down hills
and - paddle shifters at the same
• Driving in the 7-speed manual shift mode
• Driving in L mode
time until the shift indicator display
changes to L.
Depress the brake pedal and press the
release button to move out of P.
Press the release button to move the
shift lever.
Move the shift lever without pressing
the release button.
20
VSA® OFF Button
(P244)
Refueling
(P254)
● The vehicle stability assist (VSA®) system
Fuel recommendation: Unleaded premium gasoline with a pump octane
helps stabilize the vehicle during
number 91 or higher recommended
cornering, and helps maintain traction
while accelerating on loose or slippery
Fuel tank capacity: 13.2 US gal (50 L)
road surfaces.
a Push the fuel fill door
● VSA® comes on automatically every time
release handle.
you start the engine.
● To turn VSA® on or off, press and hold
the button until you hear a beep.
Cruise Control
(P240)
● Cruise control allows you to maintain a
set speed without keeping your foot on
the accelerator pedal.
● To use cruise control, press the CRUISE
button, then press DECEL/SET once you
have achieved the desired speed (above
b Turn the fuel fill cap
25 mph or 40 km/h).
slowly to remove the
cap.
Tire Pressure Monitoring
System (TPMS)
(P245)
U.S. models only
c Place the cap in the
● The TPMS monitors tire pressure.
holder on the fuel fill
● The TPMS is turned on automatically
door.
every time you start the engine.
d After refueling, screw
the cap back on until it
clicks at least once.
21
Maintenance
(P259)
Under the Hood
(P268)
● Check engine oil, engine coolant, and windshield washer
Wiper Blades
(P292)
fluid. Add when necessary.
● Check brake fluid.
● Replace blades if they leave streaks
● Check the 12 volt battery condition monthly.
across the windshield.
a Pull the hood release handle under the corner of the
dashboard.
b Locate the hood latch lever, slide the lever and lift up the
hood.
Lights
(P282)
● Inspect all lights regularly.
Tires
(P294)
● Inspect tires and wheels regularly.
● Check tire pressures regularly.
● Install snow tires for winter driving.
c When finished, close the hood and make sure it is firmly
locked in place.
22
Handling the Unexpected
(P311)
Flat Tire
(P313)
Engine Won't Start
(P329)
Overheating
(P335)
● Park in a safe location and repair the flat
● If the battery is dead, jump start using a
● Park in a safe location. If you do not see
tire using the tire repair kit.
booster battery.
steam under the hood, open the hood,
and let the engine cool down.
Indicators Come On
Blown Fuse
(P341)
Emergency Towing
(P344)
● Check for a blown fuse if an electrical
● Call a professional towing service if you
(P337)
device does not operate.
need to tow your vehicle.
● Identify the indicator and consult the
owner's manual.
23
What to Do If
The power mode does not
● The steering wheel may be locked.
change from VEHICLE OFF
● Move the steering wheel left and right after
(LOCK) to ACCESSORY.
pressing the ENGINE START/STOP button.
Why?
The power mode does not
The shift lever should be moved to P.
change from ON to
VEHICLE OFF (LOCK). Why?
Why does the brake pedal
This can occur when the ABS activates, and does not indicate a
pulsate slightly when
problem. Apply firm, steady pressure on the brake pedal. Never
applying the brakes?
pump the brake pedal.
The rear door cannot be
Check if the childproof lock is in the
opened from inside the
LOCK position. If so, open the rear
vehicle. Why?
door with the outside door handle.
To cancel this function, push the lever
to the UNLOCK position.
24
Why do the doors lock
If you do not open the doors within 30 seconds, the doors are
after I unlocked the doors
relocked automatically for security.
using a remote
transmitter?
Why does the beeper
The beeper sounds when:
sound when I open the
● The power mode is in ACCESSORY.
driver's door?
● The exterior lights are left on.
● The Auto Idle Stop is in operation.
Why does the beeper
The beeper sounds when:
sound when I start driving?
● Driver and/or front passenger are not wearing their seat belts.
● The parking brake lever is not fully released.
Why do I hear a screeching
The brake pads may need to be replaced. Have your vehicle
sound when I apply the
inspected by a dealer.
brake pedal?
Is it possible to use
Unleaded gasoline with a Pump Octane Number (PON) of 91 or
unleaded gasoline with a
higher is recommended.
Pump Octane Number
Use of lower octane gasoline can cause occasional metallic
(PON) of 87 or higher on
knocking noise in the engine and will result in decreased engine
this vehicle?
performance.
Use of gasoline with a pump octane less than 87 can lead to
engine damage.
25
For Safe Driving
The following pages explain your vehicle's safety features and how to use them
properly. The safety precautions below are ones that we consider to be among the
most important.
Important Safety Precautions
1Important Safety Precautions
■ Always wear your seat belt
Some states, provinces and territories prohibit the use
of cell phones other than hands-free devices by the
A seat belt is your best protection in all types of collisions. Airbags are designed to
driver while driving.
supplement seat belts, not replace them. So even though your vehicle is equipped
with airbags, make sure you and your passengers always wear your seat belts, and
wear them properly.
■ Restrain all children
Children ages 12 and under should ride properly restrained in a back seat, not the
front seat. Infants and small children should be restrained in a child seat. Larger
children should use a booster seat and a lap/shoulder seat belt until they can use the
belt properly without a booster seat.
■ Be aware of airbag hazards
While airbags can save lives, they can cause serious or fatal injuries to occupants
who sit too close to them, or are not properly restrained. Infants, young children,
and short adults are at the greatest risk. Be sure to follow all instructions and
warnings in this manual.
■ Don't drink and drive
Alcohol and driving don't mix. Even one drink can reduce your ability to respond to
changing conditions, and your reaction time gets worse with every additional drink.
So don't drink and drive, and don't let your friends drink and drive, either.
28
uuFor Safe DrivinguImportant Safety Precautions
■ Pay appropriate attention to the task of driving safely
Engaging in cell phone conversation or other activities that keep you from paying
close attention to the road, other vehicles, and pedestrians could lead to a crash.
Remember, situations can change quickly, and only you can decide when it is safe to
divert some attention away from driving.
■ Control your speed
Excessive speed is a major factor in crash injuries and deaths. Generally, the higher
the speed, the greater the risk, but serious injuries can also occur at lower speeds.
Never drive faster than is safe for current conditions, regardless of the maximum
speed posted.
■ Keep your vehicle in safe condition
Having a tire blowout or a mechanical failure can be extremely hazardous.
To reduce the possibility of such problems, check your tire pressures and condition
frequently, and perform all regularly scheduled maintenance.
29
uuFor Safe DrivinguYour Vehicle's Safety Features
Your Vehicle's Safety Features
1Your Vehicle's Safety Features
9
h8
12
9
Your vehicle is equipped with many features that
work together to help protect you and your
passengers during a crash.
Some features do not require any action on your part.
6
These include a strong steel framework that forms a
10
safety cage around the passenger compartment,
7
front and rear crush zones, a collapsible steering
8
column, and tensioners that tighten the front seat
belts in a sufficient crash.
10
However, you and your passengers cannot take full
11
advantage of these features unless you remain seated
in the correct position and always wear your seat
belts. In fact, some safety features can contribute to
Safety Cage
injuries if they are not used properly.
Crush Zones
7
Seats and Seat-Backs
Head Restraints
Collapsible Steering Column
6
Seat Belts
7
Front Airbags
8
Side Airbags
9
Side Curtain Airbags
10
Door Locks
11
Seat Belt Tensioners
12
Occupant Position Detection
System (OPDS) Sensor
The following checklist will help you take an active role in protecting yourself and
your passengers.
30
uuFor Safe Driving uYour Vehicle's Safety Features
1Safety Checklist
■ Safety Checklist
If the door and trunk open indicator is on, a door
For the safety of you and your passengers, make a habit of checking these items
and/or the trunk is not completely closed. Close all
each time before you drive.
doors and the trunk tightly until the indicator goes
•
After everyone has entered the vehicle, be sure all doors are closed and locked.
off.
Locking the doors helps prevent an occupant from being ejected and an outsider
2
Door and Trunk Open Indicator P.
75
from unexpectedly opening a door.
2 Locking/Unlocking the Doors from the Inside P. 111
•
Adjust your seat to a position suitable for driving. Be sure the front seats are
adjusted as far to the rear as possible while allowing the driver to control the
vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a
crash.
2 Adjusting the Seats P. 135
•
Adjust head restraints to the proper position. Head restraints are most effective
when the center of the head restraint aligns with the center of your head. Taller
persons should adjust their head restraint to the highest position.
2 Adjusting the Head Restraints P. 138
•
Always wear your seat belt, and make sure you wear it properly. Confirm that any
passengers are properly belted as well.
2 Fastening a Seat Belt P. 35
•
Protect children by using seat belts or child seats according to a child's age, height
and weight.
2 Child Safety P. 54
31
Seat Belts
About Your Seat Belts
Seat belts are the single most effective safety device because they keep you
1About Your Seat Belts
connected to the vehicle so that you can take advantage of many built-in safety
3WARNING
features. They also help keep you from being thrown against the inside of the
vehicle, against other passengers, or out of the vehicle. When worn properly, seat
Not wearing a seat belt properly increases
belts also keep your body properly positioned in a crash so that you can take full
the chance of serious injury or death in a
advantage of the additional protection provided by the airbags.
crash, even though your vehicle has
airbags.
In addition, seat belts help protect you in almost every type of crash, including:
- frontal impacts
Be sure you and your passengers always
- side impacts
wear seat belts and wear them properly.
- rear impacts
- rollovers
Seat belts cannot completely protect you in every
crash. But in most cases, seat belts can reduce your
risk of serious injury.
■ Lap/shoulder seat belts
All five seating positions are equipped with lap/shoulder seat belts with emergency
Most states and all Canadian provinces and territories
locking retractors. In normal driving the retractor lets you move freely while keeping
require you to wear seat belts.
some tension on the belt. During a collision or sudden stop the retractor locks to
restrain your body. The front passenger's and rear seat belts also have a lockable
retractor for use with child seats.
2 Installing a Child Seat with a Lap/Shoulder Seat Belt P. 61
32
uuSeat BeltsuAbout Your Seat Belts
■ Proper use of seat belts
1About Your Seat Belts
Follow these guidelines for proper use:
If a rear seat passenger moves around and extends
• All occupants should sit upright, well back in the seat, and remain in that position
the seat belt, the lockable retractor may activate. If
for the duration of the trip. Slouching and leaning reduces the effectiveness of
this happens, release the retractor by unfastening the
the belt and can increase the chance of serious injury in a crash.
seat belt and allow the belt to retract completely.
Then refasten the belt.
• Never place the shoulder part of a lap/shoulder seat belt under your arm or
behind your back. This could cause very serious injuries in a crash.
• Two people should never use the same seat belt. If they do, they could be very
seriously injured in a crash.
• Do not put any accessories on the seat belts. Devices intended to improve comfort
or reposition the shoulder part of a seat belt can reduce the protective capability
and increase the chance of serious injury in a crash.
■ Seat Belt Reminder
1Seat Belt Reminder
The indicator will also come on if a front passenger
Your vehicle monitors front seat belt use. If
does not fasten their seat belt within 6 seconds after
the power mode is set to ON before the
the power mode is set to ON.
driver's seat belt is fastened, a beeper will
When no one is sitting in the front passenger's seat,
sound and the indicator will blink. If the driver
or a child or small adult is riding there, the indicator
does not fasten the belt before the beeper
will not come on.
stops, the indicator will remain on.
This is because the weight sensors in the seat cannot
detect their presence.
The beeper will also periodically sound and
the indicator will blink while driving until the
driver's and front passenger’s seat belts are
fastened.
Continued
33
uuSeat BeltsuAbout Your Seat Belts
1Automatic Seat Belt Tensioners
■ Automatic Seat Belt Tensioners
The seat belt tensioners can only operate once.
The front seats are equipped with automatic seat belt tensioners to enhance safety.
If a tensioner is activated, the SRS indicator will come
on. Have a dealer replace the tensioner and
The tensioners automatically tighten the front seat belts during a moderate-to-
thoroughly inspect the seat belt system as it may not
severe frontal collision, sometimes even if the collision is not severe enough to
offer protection in a subsequent crash.
inflate the front airbags.
During a moderate-to-severe side impact, the
tensioner on that side of the vehicle also activates.
34
uuSeat Belts uFastening a Seat Belt
Fastening a Seat Belt
After adjusting a front seat to the proper position, and while sitting upright and well
1Fastening a Seat Belt
back in the seat:
No one should sit in a seat with an inoperative seat
2 Adjusting the Seats P. 135
belt or one that does not appear to be working
1. Pull the seat belt out slowly.
correctly. Using a seat belt that is not working
Pull out slowly.
properly may not protect the occupant in a crash.
Have a dealer check the belt as soon as possible.
Correct
Seated
Never insert any foreign objects into the buckle or
Posture
retractor mechanism.
2. Insert the latch plate into the buckle, then
Latch
tug on the belt to make sure the buckle is
Plate
secure.
u Make sure that the belt is not twisted or
caught on anything.
Buckle
Continued
35
