Removal
Installation
23-144
SRS
Front Impact Sensor Replacement
B
C
A
C
B
A
9.8 N·m
(1.0 kgf·m, 7.2 lbf·ft)
1. Disconnect the battery negative cable, and wait at
least 3 minutes before beginning work.
2. Remove the front inner fender (see page 20-111).
3. Disconnect the engine compartment wire harness
2P connector (A), and remove the two Torx bolts (B)
using a Torx T30 bit, then remove the front impact
sensor (C).
1. Install the new front impact sensor with new Torx
bolts (A), then connect the engine compartment
wire harness 2P connector (B) to the front impact
sensor (C).
2. Reconnect the battery negative cable.
3. After installing the front impact sensor, confirm
proper system operation: Turn the ignition switch
ON (II); the SRS indicator should come on for about
6 seconds and then go off.
