*02 02 *03 *04 Special Tools Required 13-47 A B D A B C A C B A 07746-0030100 • Driver, 40 mm I.D. 07746-0030100 NOTE: Refer to the Exploded View as needed during 1. Clean all the parts in solvent, dry them, and apply lubricant to all contact surfaces except the 3rd/4th 2. Install the needle bearing and 3rd gear on the mainshaft. 3. 5-speed model: Install the synchro ring (A) and the synchro spring (B). 4. 6-speed model: Install the double cone synchro assembly (A) by aligning the synchro cone fingers 5. Install the 3rd/4th synchro hub (A) by aligning the synchro ring grooves (B) with the fingers in the 6. Install the 3rd/4th synchro hub (A) using the special tool. (cont’d) 05/06/27 18:10:14 61S6M040_130_0047 |
