K20A2, K20Z1 Engines
7-30
7-30
Engine Block
Oil Pan Installation (cont’d)
5. Tighten the bolts in two or three steps. In the final
step, tighten all bolts in sequence to 12 N·m
(1.2 kgf·m, 8.7 lbf·ft). Wipe off the excess liquid
gasket on the each side of crankshaft pulley and
flywheel/drive plate.
NOTE:
• Wait at least 30 minutes before filling the engine
with oil.
• Do not run the engine for at least 3 hours after
installing the oil pan.
6. If the engine is still in the vehicle, install the
subframe.
–1 Install the subframe. Align the reference lines
on the subframe with the bolt head center, then
tighten the bolts (see step 4 on page 5-12).
–2 Install the automatic transmission (ATF) filter
mounting bolt (see step 24 on page 5-16).
–3 Tighten the rear mount mounting bolts (see
step 5 on page 5-13).
–4 Tighten the new front mount mounting bolt
(see step 11 on page 5-15).
–5 Connect the suspension lower arm ball joints
(see step 10 on page 18-13).
1. Remove all of the old liquid gasket from the oil pan
mating surfaces, bolts, and bolt holes.
2. Clean and dry the oil pan mating surfaces.
3. Apply liquid gasket, P/N 08717-0004, 08718-0001,
08718-0002, 08718-0003 or 08718-0009, evenly to
the engine block mating surface of the oil pan.
NOTE: Do not install components if too much time
has passed after applying the liquid gasket (for P/N
08718-0002, no more than 4 minutes, for all others,
no more than 5 minutes). Instead, remove the old
residue and reapply the liquid gasket.
4. Install the oil pan.
Apply liquid gasket
along the broken line.
