119. At Right Rear Pillar

KEYLESS
RECEIVER
ANTENNA
CONNECTOR
(1-BLK)
(’96-’01)

KEYLESS RECEIVER
ANTENNA SHIELD GROUND
(’96-’01)

REAR WINDOW
DEFOGGER CONNECTOR
(1-WHT or BLK)

2004 American Honda Motor Co., Inc.

120. Center Rear of Roof

RADIO
ANTENNA
SHIELD
GROUND

RADIO
WINDOW
ANTENNA
CONNECTOR
(1-BLK)

2004 American Honda Motor Co., Inc.

121. At Left Rear Pillar

REAR
WINDOW
DEFOGGER
CONNECTOR
(1-WHT or BLK)

2004 American Honda Motor Co., Inc.

122. Underside of Driver’s Seat

FRONT
UP-DOWN
MOTOR
and
POSITION
SENSOR

C689
(2-GRN)

C690
(3-GRY)
