Acura RL (1996-2004 year). Manual - part 142

2004 American Honda Motor Co., Inc.

103. Below Right Side of Dash

C456
(20-BLU)
JUNCTION
CONNECTOR

C464
(20-BLK)
JUNCTION
CONNECTOR

FAN CONTROL
UNIT
(BEHIND)

2004 American Honda Motor Co., Inc.

104. Below Right Side of Dash

PCM
CONNECTOR B
(16-GRY)

PCM
CONNECTOR D
(22-GRY)

PCM
CONNECTOR A
(26-BLU)

PCM
CONNECTOR F
(8-BLK)

PCM
CONNECTOR C
(12-GRY)

PCM
CONNECTOR E
(26-BLU)

2004 American Honda Motor Co., Inc.

105. Below Steering Column

C427
(3-GRN/GRY)

2004 American Honda Motor Co., Inc.

106. Behind Right Kick Panel

G402

G404
