Acura RL (1996-2004 year). Manual - part 117

2004 American Honda Motor Co., Inc.

3. Behind Front Grille

LEFT
HORN
(’96-’98)

C212
(2-GRY)

OUTSIDE AIR
TEMPERATURE
SENSOR

2004 American Honda Motor Co., Inc.

4. Behind Front Bumper (’96-’98)

G21

CORNERING
LIGHT
CONTROL UNIT

2004 American Honda Motor Co., Inc.

5. Center Front of Engine

TCS OR VSA
CONTROL VALVE
ANGLE SENSOR

TCS OR VSA
CONTROL
VALVE
ACTUATOR

C122
(2-GRY)

2004 American Honda Motor Co., Inc.

6. Center Front of Engine

C114
(14-GRY)
JUNCTION
CONNECTOR

IGNITION CONTROL
MODULE (ICM)
