2007 ACURA

RL

BUZZERS, RELAYS & TIMERS

BUZZERS, RELAYS & TIMERS LOCATION

Component

Location

Accessory Power Socket Relay (20)

In driver's under-dash fuse/relay box. See Fig.

188.

A/C Compressor Clutch Relay (2)

In under-hood fuse/relay box. See Fig. 186.

ACC Relay (2)

In auxiliary under-dash relay box. See Fig. 190.

Adaptive Cruise Control Relay (3)

In auxiliary under-hood relay box. See Fig. 187.

A/F Sensor Relay (21)

In driver's under-dash fuse/relay box. See Fig.

188.

Blower Motor Relay (1)

In under-hood fuse/relay box. See Fig. 186.

DRL Relay (1)

In auxiliary under-hood relay box. See Fig. 187.

Fog Light Relay (14)

In under-hood fuse/relay box. See Fig. 186.

Fuel Fill Door Opener Relay (5)

In passenger's under-dash fuse/relay box. See Fig.

189.

HVAC Control Motor Relay

Behind right side of dash. See Fig. 88.

Ignition Coil Relay (24)

In driver's under-dash fuse/relay box. See Fig.

188.

IG2 Relay (1)

In auxiliary under-dash relay box. See Fig. 190.

Keyless Answer Back Buzzer

Behind middle of rear bumper. See Fig. 163.

Optional Relay (12)

In passenger's under-dash fuse/relay box. See Fig.

189.

PGM-FI Main Relay 1 (22)

In driver's under-dash fuse/relay box. See Fig.

188.

PGM-FI Main Relay 2 (25)

In driver's under-dash fuse/relay box. See Fig.

188.

Radiator Fan Control (RFC) Unit Relay (2)

In auxiliary under-hood relay box. See Fig. 187.

Rear Window Defogger Relay (3)

In under-hood fuse/relay box. See Fig. 186.

Seat Heater Relay (4)

In passenger's under-dash fuse/relay box. See Fig.

189.

SH-AWD Relay

Behind rear seat. See Fig. 146.

Starter Cut Relay 1 (1)

In auxiliary under-dash relay holder. See Fig. 197.

Starter Cut Relay 2 (19)

In driver's under-dash fuse/relay box. See Fig.

188.

Throttle Actuator Control Module Relay (13)

In passenger's under-dash fuse/relay box. See Fig.

189.

Turn Signal/Hazard Relay 2 (Sounder)

Under left side of dash. See Fig. 42.

Turn Signal/Hazard Relay (4)

In driver's under-dash fuse/relay box. See Fig.

188.

Windshield Wiper Motor Relay (15)

In under-hood fuse/relay box. See Fig. 186.



2007 Acura RL

2007 ACURA RL





2007 Acura RL

2007 ACURA RL



me



Friday, June 05, 2009 3:07:16 PM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

me



Friday, June 05, 2009 3:07:22 PM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

CIRCUIT PROTECTION DEVICES

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

CONTROL UNITS LOCATION

Component

Location

Auxiliary Under-Dash Fuse Holder

Under left side of dash. See Fig. 62.

Auxiliary Under-Dash Relay Box

Under left side of dash. See Fig. 41.

Auxiliary Under-Dash Relay Holder

Under left side of dash. See Fig. 62.

Auxiliary Under-Hood Relay Box

Left side of engine compartment. See Fig. 34.

Battery Terminal Fuse Box (+)

In battery terminal fuse box. See Fig. 32.

Driver's Under-Dash Fuse/Relay Box

Behind left kick panel. See Fig. 59.

Passenger's Under-Dash Fuse/Relay Box

Behind right kick panel. See Fig. 93.

Under-Hood Fuse/Relay Box

Left rear of engine compartment. See Fig. 30.

Component

Location

Active Noise Control Unit

Right side of trunk. See Fig. 160.

AcuraLink Control Unit (XM Receiver)

On left side of trunk. See Fig. 152.

Adaptive Cruise Control Unit

Behind right side of dash. See Fig. 195.

Adaptive Front Lighting Control Unit

Under left side of dash. See Fig. 63.

Driver's MPCS Unit

In driver's door. See Fig. 130.

DRL Control Unit

Under left side of dash. See Fig. 64.

ECPS Control Unit

Under left side of dash. See Fig. 63.

E-Pretensioner Unit

Under middle of dash. See Fig. 193.

Front Passenger's MPCS Unit

In front passenger's door. See Fig. 131.

Fuel Pump Control Module

In left "C" pillar. See Fig. 145.

Hands FreeLink Control Unit

Behind right kick panel. See Fig. 95.

Headlight Leveling Control Unit

Under left side of dash. See Fig. 63.

Immobilizer Control Unit-Receiver

On right side of steering column. See Fig. 48.

Imoes Unit

Under middle of dash. See Fig. 73.

Keyless Access Control Unit

Under left side of dash. See Fig. 58.

Keyless Access RF Unit 1

Behind middle of dash. See Fig. 71.

Keyless Access RF Unit 2

Middle of rear shelf. See Fig. 156.

Main Antenna Module

In right "C" pillar. See Fig. 138.

Moonroof Control Unit

Rear of roof. See Fig. 137.

Navigation Unit

In trunk, below left side of package tray. See Fig.

153.

OPDS Unit

In front passenger's seat back. See Fig. 106.

PCM

Under middle of dash. See Fig. 78.

Power Rear Window Sunshade Control Unit

Middle of rear shelf. See Fig. 155.

Power Seat Control Unit

Under driver's seat. See Fig. 102.

Power Tilt/Telescopic Steering Control Unit

Under left side of dash. See Fig. 41.

RFC Unit

Front middle of engine compartment. See Fig. 28.



2007 Acura RL

2007 ACURA RL



me



Friday, June 05, 2009 3:07:16 PM

Page 2

© 2005 Mitchell Repair Information Company, LLC.

MOTORS

MOTORS LOCATION

SENDING UNITS & SENSORS

SH-AWD Control Unit

Behind rear seat. See Fig. 149.

SRS Unit

Under lower middle of dash. See Fig. 76.

Sub-Antenna Module

In left "C" pillar. See Fig. 142.

Throttle Actuator Control Module

Behind right kick panel. See Fig. 96.

TPMS Control Unit

Right side of rear shelf. See Fig. 158.

VSA Modulator-Control Unit

On right side of engine compartment. See Fig. 2.

Component

Location

Blower Motor

Under right side of dash. See Fig. 90.

Center/Left/Right Rear Headrest Actuator

Behind respective rear seat headrest. See Fig. 113.

Driver's Air Mix Control Motor

Below left side of dash. See Fig. 66.

Driver's Cool Vent Control Motor

Under left side of dash. See Fig. 65.

Driver's Lumbar Support Motor Connector

Under right side of driver's seat. See Fig. 99.

Driver's Power Seat Slide Motor

Under driver's seat. See Fig. 102.

Driver's Power Window Motor

Center of driver's door. See Fig. 128.

Front Passenger's Air Mix Control Motor

Behind right side of dash. See Fig. 85.

Front Passenger's Cool Vent Control Motor

Behind right side of dash. See Fig. 85.

Front Passenger's Lumbar Support Motor
Connector

Under front passenger's seat. See Fig. 107.

Front Passenger's Power Seat Recline Motor

Under front passenger's seat. See Fig. 107.

Front Passenger's Power Seat Slide Motor

Under front passenger's seat. See Fig. 110.

Front Passenger's Power Window Motor

Center of front passenger's door. See Fig. 128.

Fuel Tank Unit

Under left side of rear seat. See Fig. 118.

Left Power Mirror Connector

In driver's door. See Fig. 125.

Left Rear Door Lock Actuator Connector

Rear of left rear door. See Fig. 199.

Left Rear Power Window Motor

Center of left rear door. See Fig. 133.

Left/Right Adaptive Front Lighting Gear Box

Behind respective headlight assembly. See Fig.

26.

Left/Right Headlight Leveling Motor

Behind respective headlight assembly. See Fig.

27.

Mode Control Motor

Under left side of dash. See Fig. 64.

Rear Vent Control Motor

Under middle of dash. See Fig. 79.

Recirculation Control Motor

Behind glove box. See Fig. 88.

Right Rear Door Lock Actuator Connector

Rear of right rear door.

Right Rear Power Window Motor

Center of right rear door. See Fig. 133.

Starter

Left side of engine. See Fig. 22.

Windshield Washer Motor

In bottom of washer reservoir. See Fig. 164.

Windshield Wiper Motor

Left rear of engine compartment, under cowl

cover. See Fig. 37.
