6. Jump the SCS line with the HDS.
7. Remove the front console cover (A) (see step 5 under CENTER CONSOLE
REMOVAL/INSTALLATION ) and pull back the carpet.
Fig. 12: Identifying Front Console Cover, Ducts, PCM Connectors And PCM With Torque
Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.
8. Remove the ducts (B).
9. Disconnect the PCM connectors (C).
10. Remove the two bolts (D), and remove the PCM (E).
11. Install a known-good PCM in the reverse order of removal.
12. Open the SCS with the HDS.
13. Turn the ignition switch to ON (II).
14. Manually input the VIN to the PCM with the HDS.
15. Update the PCM if it does not have the latest software.
16. Select the IMMOBI SYSTEM with the HDS.
17. Enter the immobilizer code using the PCM replacement procedure in the HDS; this allows you to start the
engine.
18. Reset the PCM with the HDS.
19. If the TP POSITION CHECK failed in step 6, clean the throttle body (see THROTTLE BODY
CLEANING ).
20. Do the PCM idle learn procedure (see PCM IDLE LEARN PROCEDURE ).
procedure.
NOTE:
DTC P0630 "VIN Not Programmed or Mismatch" may be stored because
the VIN has not been programmed into the PCM; ignore it, and continue
this procedure.
