SNR9A0DJ10300000000FAAT23 SNR9A0DJ10300000000FAAT24 − − − − − − − − Special Tools Required YES NO YES NO Special Tools Required YES NO YES NO Audio disc does not play Audio disc skips 23-229 23-229 Diagnostics CD 07AAZ-SDBA100 NOTE: • Check the vehicle battery condition first. terminals. 1. Try loading a known-good disc. Go to step 2. Go to audio disc does not load (see page 23-228). 2. Insert the diagnostics CD (T/N: 07AAZ-SDBA100) in the navigation unit or audio unit. The original disc is faulty, or has an unreadable format. • With navigation: Replace the navigation unit (see page 23-355). • Without navigation: Replace the audio unit (see page 23-256). • Diagnostics CD 07AAZ-SDBA100 1. Confirm the vehicles tires are properly inflated. 2. Check the client’s CD for scratches, fingerprints, and marks. NOTE: Do this following test with audio unit bass 3. Test drive to identify when the CD skips. The diagnostics CD (T/N: 07AAZ-SDBA100) can be used Go to step 4. Operation is normal. 4. Compare the clients CD that skips in a known-good vehicle under the same conditions. Operation is normal. Go to step 5. NOTE: Do this following test with vehicle parked Does the disc load? Does the disc play? Does the CD skip? Does the CD skip in the known-good vehicle under 08/08/21 14:10:51 61SNR030_230_0232 |
