Fig. 16: Identifying Front Stabilizer Link And Nut
Courtesy of KIA MOTORS AMERICA, INC.

4. Install the speed sensor (A) and wire (B) bolts.

Tightening torque N.m (kgf.m, lb-ft):

7-11 (0.7-1.1, 5.1-8.0)

Fig. 17: Identifying Speed Sensor And Wire Bolts
Courtesy of KIA MOTORS AMERICA, INC.

5. Install the brake hose bracket bolt (A, B) to the strut assembly.

Tightening torque N.m (kgf.m, lb-ft):

7-11 (0.7-1.1, 5.1-8.0)



2008 Kia Sedona EX

2008 SUSPENSION Front Suspension - Sedona



Microsoft



Monday, May 24, 2010 3:45:01 PM

Page 10

© 2006 Mitchell Repair Information Company, LLC.

Fig. 18: Identifying Brake Hose Bracket Bolt
Courtesy of KIA MOTORS AMERICA, INC.

6. Install the wheel and the tire (A) to the front hub (B).

Tightening torque N.m (kgf.m, lb-ft):

90-110 (9-11, 65.1-79.5)

Fig. 19: Identifying Wheel & Tire Assembly And Front Hub Assembly
Courtesy of KIA MOTORS AMERICA, INC.

FRONT LOWER ARM

COMPONENTS

CAUTION: Be careful not to damage the hub bolts (C) when installing the front

wheel and tire (A).



2008 Kia Sedona EX

2008 SUSPENSION Front Suspension - Sedona



Microsoft



Monday, May 24, 2010 3:45:01 PM

Page 11

© 2006 Mitchell Repair Information Company, LLC.

Fig. 20: Identifying Front Lower Arm Components With Torque Specifications
Courtesy of KIA MOTORS AMERICA, INC.

REMOVAL

1. Loosen the wheel nuts slightly.

Raise the front of the vehicle, and make sure it is securely supported.

2. Remove the front wheel and tire (A) from front hub (B).



2008 Kia Sedona EX

2008 SUSPENSION Front Suspension - Sedona



Microsoft



Monday, May 24, 2010 3:45:01 PM

Page 12

© 2006 Mitchell Repair Information Company, LLC.

Fig. 21: Identifying Wheel & Tire Assembly And Front Hub Assembly
Courtesy of KIA MOTORS AMERICA, INC.

3. Remove the front lower arm (A) mounting bolt (B) from the knuckle.

Fig. 22: Identifying Front Lower Arm And Mounting Bolt
Courtesy of KIA MOTORS AMERICA, INC.

4. Remove the lower arm mounting bolts (A, B).

CAUTION: Be careful not to damage the hub bolts (C) when removing the front

wheel and tire (A).
