Fig. 10: Telltale Lamp Flashing Pattern
Courtesy of KIA MOTORS AMERICA, INC.
COMPONENT REPLACEMENT AFTER DEPLOYMENT
When the front airbag(s) deployed after a collision, replace the following items.
SRSCM
Deployed airbag(s)
Seat belt pretensioner(s)
Front impact sensors
SRS wiring harnesses
Inspect the clock spring for heat damage.
If any damage found, replace the clock spring.
When the seat belt pretensioner(s) deployed after a collision, replace the following items.
Seat belt pretensioner(s)
SRSCM (if B1658 detected)
Front impact sensors
SRS wiring harnesses
When the side/curtain airbag(s) deployed after a collision, replace the following items.
SRSCM
Deployed airbag(s)
Side impact sensor(s) for the deployed side(s)
SRS wiring harnesses
After the vehicle is completely repaired, confirm the SRS airbag system is OK.
Turn the ignition switch ON, the SRS indicator should come on for about 6 seconds and then go off.
NOTE:
Before doing any SRS repairs, use the Hi-Scan Pro to check for DTCs. Refer to
DIAGNOSTIC TROUBLE CODES (DTC) for repairing of the related DTCs.
