Kia Carens. Manual

2001 > 1.8L DOHC >

Removal

Rear buckle assembly

1. Pull safety belts to rear through seats.

2. Remove one bolt from rear buckle assembly mounting bracket.

Removal

Rear lap/shoulder belt assembly

1. Remove one bolt from lap belt mounting bracket.

2. Remove anchor bolt.

3. Remove rear quarter trim. Refer to "trim" in this section.

4. Remove one bolt and one sheet metal screw to attach retractor assembly.

Installation

Rear buckle assembly

1. Install mounting bolt through bracket.

Tightening mounting : 40~47 Ib·ft (54~64 N·m, 5.5~6.5 kg·m)

2. Feed buckle between seat back and cushion without any twists.

Installation

Rear lap/shoulder belt assembly

1. Install retractor mounting bolt and sheet metal screw.

Tightening torque : bolt : 40~47 lb-ft (54~64 N-m, 5.5~6.5 kg-m)

2. Install rear quarter trim. Refer to "trim" in this section.

3. Install anchor bolt.

Tightening torque : 40~47 lb-ft (54~64 N-m, 5.5~6.5 kg-m)

4. Install one bolt from lap belt mounting bracket.

Tightening torque : 40~47 lb-ft (54~64 N-m, 5.5~6.5 kg-m)

Inspection

1. Inspect three buckle assembly mountings to ensure that they are secure. (This is done from rear of vehicle.)

2. Inspect remaining belt's mounting to ensure that it is secure. (This is done from rear of vehicle.)

3. Pull seat belts to rear between seatback and cushion.

4. Inspect outboard lap belt mountings to ensure that they are secure.

5. Remove rear quarter trim.

6. Inspect retractor assembly mountings to ensure that they are secure.

Kia Carens. Manual - part 256
