Emission Control System

Evaporative Emission Control System - Canister

Emission Control System

  2001 > 1.8L DOHC >



Charcoal canister

1. Visually check for damage and replace the charcoal canister necessary.

Emission Control System

Evaporative Emission Control System -  Purge
Control Solenoid Valve (PCSV)

Emission Control System

  2001 > 1.8L DOHC >



Inspection

1. Disconnect vacuum hosews from EVAP canister purge solenoid valve.

2. Verify that no air flows through valve.

3. Disconnect valve connector and apply 12 volt battery voltage as shown in figure.

4. Verify that air flows through valve.

5. If no air flows, replace the valve.

6. Reinstall valve connector.

7. Reconnect vacuum hoses.
