TASK MANAGEMENT

Because all tasks have access to the GDT, it also is possible to create shared segments accessed through segment

descriptors in this table.

If paging is enabled, the CR3 register (PDBR) field in the TSS allows each task to have its own set of page tables

for mapping linear addresses to physical addresses. Or, several tasks can share the same set of page tables.

8.5.1

Mapping Tasks to the Linear and Physical Address Spaces

Tasks can be mapped to the linear address space and physical address space in one of two ways:

• One linear-to-physical address space mapping is shared among all tasks. - When paging is not

enabled, this is the only choice. Without paging, all linear addresses map to the same physical addresses. When

paging is enabled, this form of linear-to-physical address space mapping is obtained by using one page

directory for all tasks. The linear address space may exceed the available physical space if demand-paged

virtual memory is supported.

• Each task has its own linear address space that is mapped to the physical address space. - This form

of mapping is accomplished by using a different page directory for each task. Because the PDBR (control

The linear address spaces of different tasks may map to completely distinct physical addresses. If the entries of

different page directories point to different page tables and the page tables point to different pages of physical

memory, then the tasks do not share physical addresses.

With either method of mapping task linear address spaces, the TSSs for all tasks must lie in a shared area of the

physical space, which is accessible to all tasks. This mapping is required so that the mapping of TSS addresses does

not change while the processor is reading and updating the TSSs during a task switch. The linear address space

mapped by the GDT also should be mapped to a shared area of the physical space; otherwise, the purpose of the

GDT is defeated. Figure 8-9 shows how the linear address spaces of two tasks can overlap in the physical space by

sharing page tables.

TSS

Page Directories

Page Tables

Page Frames

Task A

Task A TSS

Task A

PTE

PDBR

PDE

PTE

Task A

PDE

Shared PT

Shared

PTE

Shared

Task B TSS

Task B

PDBR

PDE

PTE

PDE

PTE

Task B

Figure 8-9. Overlapping Linear-to-Physical Mappings

Vol. 3A

8-17

TASK MANAGEMENT

8.5.2

Task Logical Address Space

To allow the sharing of data among tasks, use the following techniques to create shared logical-to-physical

address-space mappings for data segments:

• Through the segment descriptors in the GDT - All tasks must have access to the segment descriptors in

the GDT. If some segment descriptors in the GDT point to segments in the linear-address space that are

mapped into an area of the physical-address space common to all tasks, then all tasks can share the data and

code in those segments.

• Through a shared LDT - Two or more tasks can use the same LDT if the LDT fields in their TSSs point to the

same LDT. If some segment descriptors in a shared LDT point to segments that are mapped to a common area

of the physical address space, the data and code in those segments can be shared among the tasks that share

the LDT. This method of sharing is more selective than sharing through the GDT, because the sharing can be

limited to specific tasks. Other tasks in the system may have different LDTs that do not give them access to the

shared segments.

• Through segment descriptors in distinct LDTs that are mapped to common addresses in linear

address space - If this common area of the linear address space is mapped to the same area of the physical

address space for each task, these segment descriptors permit the tasks to share segments. Such segment

descriptors are commonly called aliases. This method of sharing is even more selective than those listed above,

because, other segment descriptors in the LDTs may point to independent linear addresses which are not

shared.

8.6

16-BIT TASK-STATE SEGMENT (TSS)

The 32-bit IA-32 processors also recognize a 16-bit TSS format like the one used in Intel 286 processors (see

Figure 8-10). This format is supported for compatibility with software written to run on earlier IA-32 processors.

The following information is important to know about the 16-bit TSS.

• Do not use a 16-bit TSS to implement a virtual-8086 task.

• The valid segment limit for a 16-bit TSS is 2CH.

• The 16-bit TSS does not contain a field for the base address of the page directory, which is loaded into control

dispatched, the page-table structure for the previous task is used.

• The I/O base address is not included in the 16-bit TSS. None of the functions of the I/O map are supported.

• When task state is saved in a 16-bit TSS, the upper 16 bits of the EFLAGS register and the EIP register are lost.

• When the general-purpose registers are loaded or saved from a 16-bit TSS, the upper 16 bits of the registers

are modified and not maintained.

8-18

Vol. 3A

TASK MANAGEMENT

Task LDT Selector

DS Selector

SS Selector

CS Selector

ES Selector

FLAG Word

IP (Entry Point)

SS2

SP2

SS1

SP1

SS0

SP0

Previous Task Link

Figure 8-10. 16-Bit TSS Format

8.7

TASK MANAGEMENT IN 64-BIT MODE

In 64-bit mode, task structure and task state are similar to those in protected mode. However, the task switching

mechanism available in protected mode is not supported in 64-bit mode. Task management and switching must be

performed by software. The processor issues a general-protection exception (#GP) if the following is attempted in

64-bit mode:

• Control transfer to a TSS or a task gate using JMP, CALL, INT n, INT3, INTO, INT1, or interrupt.

• An IRET with EFLAGS.NT (nested task) set to 1.

Although hardware task-switching is not supported in 64-bit mode, a 64-bit task state segment (TSS) must exist.

Figure 8-11 shows the format of a 64-bit TSS. The TSS holds information important to 64-bit mode and that is not

directly related to the task-switch mechanism. This information includes:

• RSPn - The full 64-bit canonical forms of the stack pointers (RSP) for privilege levels 0-2.

• ISTn - The full 64-bit canonical forms of the interrupt stack table (IST) pointers.

• I/O map base address - The 16-bit offset to the I/O permission bit map from the 64-bit TSS base.

The operating system must create at least one 64-bit TSS after activating IA-32e mode. It must execute the LTR

instruction (in 64-bit mode) to load the TR register with a pointer to the 64-bit TSS responsible for both 64-bit-

mode programs and compatibility-mode programs.

Vol. 3A

8-19

CHAPTER 9

MULTIPLE-PROCESSOR MANAGEMENT

The Intel 64 and IA-32 architectures provide mechanisms for managing and improving the performance of multiple

processors connected to the same system bus. These include:

• Bus locking and/or cache coherency management for performing atomic operations on system memory.

• Serializing instructions.

• An advance programmable interrupt controller (APIC) located on the processor chip (see Chapter 11,

“Advanced Programmable Interrupt Controller (APIC)”). This feature was introduced by the Pentium processor.

• A second-level cache (level 2, L2). For the Pentium 4, Intel Xeon, and P6 family processors, the L2 cache is

included in the processor package and is tightly coupled to the processor. For the Pentium and Intel486

processors, pins are provided to support an external L2 cache.

• A third-level cache (level 3, L3). For Intel Xeon processors, the L3 cache is included in the processor package

and is tightly coupled to the processor.

• Intel Hyper-Threading Technology. This extension to the Intel 64 and IA-32 architectures enables a single

processor core to execute two or more threads concurrently (see Section 9.5, “Intel® Hyper-Threading

Technology and Intel® Multi-Core Technology”).

These mechanisms are particularly useful in symmetric-multiprocessing (SMP) systems. However, they can also be

used when an Intel 64 or IA-32 processor and a special-purpose processor (such as a communications, graphics,

or video processor) share the system bus.

These multiprocessing mechanisms have the following characteristics:

• To maintain system memory coherency - When two or more processors are attempting simultaneously to

access the same address in system memory, some communication mechanism or memory access protocol

must be available to promote data coherency and, in some instances, to allow one processor to temporarily lock

a memory location.

• To maintain cache consistency - When one processor accesses data cached on another processor, it must not

receive incorrect data. If it modifies data, all other processors that access that data must receive the modified

data.

• To allow predictable ordering of writes to memory - In some circumstances, it is important that memory writes

be observed externally in precisely the same order as programmed.

• To distribute interrupt handling among a group of processors - When several processors are operating in a

system in parallel, it is useful to have a centralized mechanism for receiving interrupts and distributing them to

available processors for servicing.

• To increase system performance by exploiting the multi-threaded and multi-process nature of contemporary

operating systems and applications.

The caching mechanism and cache consistency of Intel 64 and IA-32 processors are discussed in Chapter 12. The

APIC architecture is described in Chapter 11. Bus and memory locking, serializing instructions, memory ordering,

and Intel Hyper-Threading Technology are discussed in the following sections.

9.1

LOCKED ATOMIC OPERATIONS

The 32-bit IA-32 processors support locked atomic operations on locations in system memory. These operations

are typically used to manage shared data structures (such as semaphores, segment descriptors, system segments,

or page tables) in which two or more processors may try simultaneously to modify the same field or flag. The

processor uses three interdependent mechanisms for carrying out locked atomic operations:

• Guaranteed atomic operations.

• Bus locking, using the LOCK# signal and the LOCK instruction prefix.

Vol. 3A

9-1

MULTIPLE-PROCESSOR MANAGEMENT

• Cache coherency protocols that ensure that atomic operations can be carried out on cached data structures

(cache lock); this mechanism is present in the Pentium 4, Intel Xeon, and P6 family processors.

These mechanisms are interdependent in the following ways. Certain basic memory transactions (such as reading

or writing a byte in system memory) are always guaranteed to be handled atomically. That is, once started, the

processor guarantees that the operation will be completed before another processor or bus agent is allowed access

to the memory location. The processor also supports bus locking for performing selected memory operations (such

as a read-modify-write operation in a shared area of memory) that typically need to be handled atomically, but are

not automatically handled this way. Because frequently used memory locations are often cached in a processor’s L1

or L2 caches, atomic operations can often be carried out inside a processor’s caches without asserting the bus lock.

Here the processor’s cache coherency protocols ensure that other processors that are caching the same memory

locations are managed properly while atomic operations are performed on cached memory locations.

NOTE

Where there are contested lock accesses, software may need to implement algorithms that ensure

fair access to resources in order to prevent lock starvation. The hardware provides no resource that

guarantees fairness to participating agents. It is the responsibility of software to manage the

fairness of semaphores and exclusive locking functions.

The mechanisms for handling locked atomic operations have evolved with the complexity of IA-32 processors. More

recent IA-32 processors (such as the Pentium 4, Intel Xeon, and P6 family processors) and Intel 64 provide a more

refined locking mechanism than earlier processors. These mechanisms are described in the following sections.

9.1.1

Guaranteed Atomic Operations

The Intel486 processor (and newer processors since) guarantees that the following basic memory operations will

always be carried out atomically:

• Reading or writing a byte.

• Reading or writing a word aligned on a 16-bit boundary.

• Reading or writing a doubleword aligned on a 32-bit boundary.

The Pentium processor (and newer processors since) guarantees that the following additional memory operations

will always be carried out atomically:

• Reading or writing a quadword aligned on a 64-bit boundary.

•

16-bit accesses to uncached memory locations that fit within a 32-bit data bus.

The P6 family processors (and newer processors since) guarantee that the following additional memory operation

will always be carried out atomically:

• Unaligned 16-, 32-, and 64-bit accesses to cached memory that fit within a cache line.

Processors that enumerate support for Intel^® AVX (by setting the feature flag CPUID.01H:ECX.AVX[bit 28]) guar-

antee that the 16-byte memory operations performed by the following instructions will always be carried out atom-

ically:

• MOVAPD, MOVAPS, and MOVDQA.

• VMOVAPD, VMOVAPS, and VMOVDQA when encoded with VEX.128.

• VMOVAPD, VMOVAPS, VMOVDQA32, and VMOVDQA64 when encoded with EVEX.128 and k0 (masking

disabled).

(Note that these instructions require the linear addresses of their memory operands to be 16-byte aligned.)

Accesses to cacheable memory that are split across cache lines and page boundaries are not guaranteed to be

atomic by the Intel Core 2 Duo, Intel Atom, Intel Core Duo, Pentium M, Pentium 4, Intel Xeon, P6 family, Pentium,

and Intel486 processors. The Intel Core 2 Duo, Intel Atom, Intel Core Duo, Pentium M, Pentium 4, Intel Xeon, and

P6 family processors provide bus control signals that permit external memory subsystems to make split accesses

atomic; however, nonaligned data accesses will seriously impact the performance of the processor and should be

avoided.

9-2

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

Except as noted above, an x87 instruction or an SSE instruction that accesses data larger than a quadword may be

implemented using multiple memory accesses. If such an instruction stores to memory, some of the accesses may

complete (writing to memory) while another causes the operation to fault for architectural reasons (e.g., due an

page-table entry that is marked “not present”). In this case, the effects of the completed accesses may be visible

to software even though the overall instruction caused a fault. If TLB invalidation has been delayed (see Section

4.10.4.4), such page faults may occur even if all accesses are to the same page.

9.1.2

Bus Locking

Intel 64 and IA-32 processors provide a LOCK# signal that is asserted automatically during certain critical memory

operations to lock the system bus or equivalent link. Assertion of this signal is called a bus lock. While this output

signal is asserted, requests from other processors or bus agents for control of the bus are blocked. Software can

specify other occasions when the LOCK semantics are to be followed by prepending the LOCK prefix to an instruc-

tion.

In the case of the Intel386, Intel486, and Pentium processors, explicitly locked instructions will result in the asser-

tion of the LOCK# signal. It is the responsibility of the hardware designer to make the LOCK# signal available in

system hardware to control memory accesses among processors.

For the P6 and more recent processor families, if the memory area being accessed is cached internally in the

processor, the LOCK# signal is generally not asserted; instead, locking is only applied to the processor’s caches

(see Section 9.1.4, “Effects of a LOCK Operation on Internal Processor Caches”). These processors will assert a bus

lock for a locked access in either of the following situations: (1) the access is to multiple cache lines (a split lock);

or (2) the access uses a memory type other than WB (a UC lock)¹.

9.1.2.1

Automatic Locking

The operations on which the processor automatically follows the LOCK semantics are as follows:

• When executing an XCHG instruction that references memory.

• When switching to a task, the processor tests and sets the busy flag in the type field of the TSS descriptor. To

ensure that two processors do not switch to the same task simultaneously, the processor follows the LOCK

semantics while testing and setting this flag.

• When loading a segment descriptor, the processor sets the accessed flag in the segment descriptor if the flag is

clear. During this operation, the processor follows the LOCK semantics so that the descriptor will not be

modified by another processor while it is being updated. For this action to be effective, operating-system

procedures that update descriptors should use the following steps:

- Use a locked operation to modify the access-rights byte to indicate that the segment descriptor is not-

present, and specify a value for the type field that indicates that the descriptor is being updated.

- Update the fields of the segment descriptor. (This operation may require several memory accesses;

therefore, locked operations cannot be used.)

- Use a locked operation to modify the access-rights byte to indicate that the segment descriptor is valid and

present.

- The Intel386 processor always updates the accessed flag in the segment descriptor, whether it is clear or

not. The Pentium 4, Intel Xeon, P6 family, Pentium, and Intel486 processors only update this flag if it is not

already set.

• The processor uses locked cycles to set the accessed and dirty flag in paging-structure entries.

• After an interrupt request, an interrupt controller may use the data bus to send the interrupt’s vector to the

processor. The processor follows the LOCK semantics during this time to ensure that no other data appears on

the data bus while the vector is being transmitted.

1. The term “UC lock” is used because the most common situation regards accesses to UC memory. Despite the name, locked accesses

to WC, WP, and WT memory also cause bus locks.

Vol. 3A

9-3

MULTIPLE-PROCESSOR MANAGEMENT

9.1.2.2

Software Controlled Bus Locking

To explicitly force the LOCK semantics, software can use the LOCK prefix with the following instructions when they

are used to modify a memory location. An invalid-opcode exception (#UD) is generated when the LOCK prefix is

used with any other instruction or when no write operation is made to memory (that is, when the destination

operand is in a register).

• The bit test and modify instructions (BTS, BTR, and BTC).

• The exchange instructions (XADD, CMPXCHG, CMPXCHG8B, and CMPXCHG16B).

• The LOCK prefix is automatically assumed for XCHG instruction.

• The following single-operand arithmetic and logical instructions: INC, DEC, NOT, and NEG.

• The following two-operand arithmetic and logical instructions: ADD, ADC, SUB, SBB, AND, OR, and XOR.

A locked instruction is guaranteed to lock only the area of memory defined by the destination operand, but may be

interpreted by the system as a lock for a larger memory area.

Software should access semaphores (shared memory used for signalling between multiple processors) using iden-

tical addresses and operand lengths. For example, if one processor accesses a semaphore using a word access,

other processors should not access the semaphore using a byte access.

NOTE

Do not implement semaphores using the WC memory type. Do not perform non-temporal stores to

a cache line containing a location used to implement a semaphore.

The integrity of a bus lock is not affected by the alignment of the memory field. The LOCK semantics are followed

for as many bus cycles as necessary to update the entire operand. However, it is recommend that locked accesses

be aligned on their natural boundaries for better system performance:

• Any boundary for an 8-bit access (locked or otherwise).

•

16-bit boundary for locked word accesses.

•

32-bit boundary for locked doubleword accesses.

•

64-bit boundary for locked quadword accesses.

Locked operations are atomic with respect to all other memory operations and all externally visible events. Only

instruction fetch and page table accesses can pass locked instructions. Locked instructions can be used to synchro-

nize data written by one processor and read by another processor.

For the P6 family processors, locked operations serialize all outstanding load and store operations (that is, wait for

them to complete). This rule is also true for the Pentium 4 and Intel Xeon processors, with one exception. Load

operations that reference weakly ordered memory types (such as the WC memory type) may not be serialized.

Locked instructions should not be used to ensure that data written can be fetched as instructions.

NOTE

The locked instructions for the current versions of the Pentium 4, Intel Xeon, P6 family, Pentium,

and Intel486 processors allow data written to be fetched as instructions. However, Intel

recommends that developers who require the use of self-modifying code use a different synchro-

nizing mechanism, described in the following sections.

9.1.2.3

Features to Disable Bus Locks

Because bus locks may adversely affect performance in certain situations, processors may support two features

that system software can use to disable bus locking. These are called UC-lock disable and split-lock disable.

A processor enumerates support for UC-lock disable by setting bit 4 of the IA32_CORE_CAPABILITIES MSR (MSR

index CFH). Support for split-lock disable is enumerated by IA32_CORE_CAPABILITIES[5].

Software enables UC-lock disable by setting bit 28 of the MSR_MEMORY_CTRL MSR (MSR index 33H). When this bit

is set, a locked access using a memory type other than WB causes a general-protection exception (#GP) with a

zero error code. The locked access does not occur.

9-4

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

Software enables split-lock disable by setting MSR_MEMORY_CTRL[29]. When this bit is set, a locked access to

multiple cache lines causes an alignment-check exception (#AC) with a zero error code.¹ The locked access does

not occur.

If both features are enabled, a locked access to multiple cache lines causes #AC(0) regardless of the memory

type(s) being accessed.

While MSR_MEMORY_CTRL is not an architectural MSR, the behavior described above is consistent across

processor models that enumerate the support in IA32_CORE_CAPABILITIES.

In addition to these features that disable bus locks, there are features that allow software to detect when a bus lock

has occurred. See Section 18.3.1.6 for information about OS bus-lock detection and Section 26.2 for information

about the VMM bus-lock detection.

9.1.3

Handling Self- and Cross-Modifying Code

The act of a processor writing data into a currently executing code segment with the intent of executing that data

as code is called self-modifying code. IA-32 processors exhibit model-specific behavior when executing self-

modified code, depending upon how far ahead of the current execution pointer the code has been modified.

As processor microarchitectures become more complex and start to speculatively execute code ahead of the retire-

ment point (as in P6 and more recent processor families), the rules regarding which code should execute, pre- or

post-modification, become blurred. To write self-modifying code and ensure that it is compliant with current and

future versions of the IA-32 architectures, use one of the following coding options:

(* OPTION 1 *)

Store modified code (as data) into code segment;

Jump to new code or an intermediate location;

Execute new code;

(* OPTION 2 *)

Store modified code (as data) into code segment;

Execute a serializing instruction; (* For example, CPUID instruction *)

Execute new code;

The use of one of these options is not required for programs intended to run on the Pentium or Intel486 processors,

but are recommended to ensure compatibility with the P6 and more recent processor families.

Self-modifying code will execute at a lower level of performance than non-self-modifying or normal code. The

degree of the performance deterioration will depend upon the frequency of modification and specific characteristics

of the code.

The act of one processor writing data into the currently executing code segment of a second processor with the

intent of having the second processor execute that data as code is called cross-modifying code. As with self-

modifying code, IA-32 processors exhibit model-specific behavior when executing cross-modifying code,

depending upon how far ahead of the executing processors current execution pointer the code has been modified.

To write cross-modifying code and ensure that it is compliant with current and future versions of the IA-32 archi-

tecture, the following processor synchronization algorithm must be implemented:

(* Action of Modifying Processor *)

Memory_Flag := 0; (* Set Memory_Flag to value other than 1 *)

Store modified code (as data) into code segment;

Memory_Flag := 1;

(* Action of Executing Processor *)

WHILE (Memory_Flag ≠ 1)

Wait for code to update;

1. Other alignment-check exceptions occur only if CR0.AM = 1, EFLAGS.AC = 1, and CPL = 3. The alignment-check exceptions resulting

from split-lock disable may occur even if CR0.AM = 0, EFLAGS.AC = 0, or CPL < 3.

Vol. 3A

9-5

MULTIPLE-PROCESSOR MANAGEMENT

ELIHW;

Execute serializing instruction; (* For example, CPUID instruction *)

Begin executing modified code;

(The use of this option is not required for programs intended to run on the Intel486 processor, but is recommended

to ensure compatibility with the Pentium 4, Intel Xeon, P6 family, and Pentium processors.)

Like self-modifying code, cross-modifying code will execute at a lower level of performance than non-cross-modi-

fying (normal) code, depending upon the frequency of modification and specific characteristics of the code.

The restrictions on self-modifying code and cross-modifying code also apply to the Intel 64 architecture.

9.1.4

Effects of a LOCK Operation on Internal Processor Caches

For the Intel486 and Pentium processors, the LOCK# signal is always asserted on the bus during a LOCK operation,

even if the area of memory being locked is cached in the processor.

For the P6 and more recent processor families, if the area of memory being locked during a LOCK operation is

cached in the processor that is performing the LOCK operation as write-back memory and is completely contained

in a cache line, the processor may not assert the LOCK# signal on the bus. Instead, it will modify the memory loca-

tion internally and allow it’s cache coherency mechanism to ensure that the operation is carried out atomically. This

operation is called “cache locking.” The cache coherency mechanism automatically prevents two or more proces-

sors that have cached the same area of memory from simultaneously modifying data in that area.

9.2

MEMORY ORDERING

The term memory ordering refers to the order in which the processor issues reads (loads) and writes (stores)

through the system bus to system memory. The Intel 64 and IA-32 architectures support several memory-ordering

models depending on the implementation of the architecture. For example, the Intel386 processor enforces

program ordering (generally referred to as strong ordering), where reads and writes are issued on the system

bus in the order they occur in the instruction stream under all circumstances.

To allow performance optimization of instruction execution, the IA-32 architecture allows departures from strong-

ordering model called processor ordering in Pentium 4, Intel Xeon, and P6 family processors. These processor-

ordering variations (called here the memory-ordering model) allow performance enhancing operations such as

allowing reads to go ahead of buffered writes. The goal of any of these variations is to increase instruction execu-

tion speeds, while maintaining memory coherency, even in multiple-processor systems.

Section 9.2.1 and Section 9.2.2 describe the memory-ordering implemented by Intel486, Pentium, Intel Core 2

Duo, Intel Atom, Intel Core Duo, Pentium 4, Intel Xeon, and P6 family processors. Section 9.2.3 gives examples

illustrating the behavior of the memory-ordering model on IA-32 and Intel-64 processors. Section 9.2.4 considers

the special treatment of stores for string operations and Section 9.2.5 discusses how memory-ordering behavior

may be modified through the use of specific instructions.

9.2.1

Memory Ordering in the Intel® Pentium® and Intel486™ Processors

The Pentium and Intel486 processors follow the processor-ordered memory model; however, they operate as

strongly-ordered processors under most circumstances. Reads and writes always appear in programmed order at

the system bus-except for the following situation where processor ordering is exhibited. Read misses are

permitted to go ahead of buffered writes on the system bus when all the buffered writes are cache hits and, there-

fore, are not directed to the same address being accessed by the read miss.

In the case of I/O operations, both reads and writes always appear in programmed order.

Software intended to operate correctly in processor-ordered processors (such as the Pentium 4, Intel Xeon, and P6

family processors) should not depend on the relatively strong ordering of the Pentium or Intel486 processors.

Instead, it should ensure that accesses to shared variables that are intended to control concurrent execution

among processors are explicitly required to obey program ordering through the use of appropriate locking or seri-

alizing operations (see Section 9.2.5, “Strengthening or Weakening the Memory-Ordering Model”).

9-6

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

9.2.2

Memory Ordering in P6 and More Recent Processor Families

The Intel Core 2 Duo, Intel Atom, Intel Core Duo, Pentium 4, and P6 family processors also use a processor-

ordered memory-ordering model that can be further defined as “write ordered with store-buffer forwarding.” This

model can be characterized as follows.

In a single-processor system for memory regions defined as write-back cacheable, the memory-ordering model

respects the following principles (Note the memory-ordering principles for single-processor and multiple-

processor systems are written from the perspective of software executing on the processor, where the term

“processor” refers to a logical processor. For example, a physical processor supporting multiple cores and/or Intel

Hyper-Threading Technology is treated as a multi-processor systems.):

• Reads are not reordered with other reads.

• Writes are not reordered with older reads.

• Writes to memory are not reordered with other writes, with the following exceptions:

- streaming stores (writes) executed with the non-temporal move instructions (MOVNTI, MOVNTQ,

MOVNTDQ, MOVNTPS, and MOVNTPD); and

- string operations (see Section 9.2.4.1).

• No write to memory may be reordered with an execution of the CLFLUSH instruction; a write may be reordered

with an execution of the CLFLUSHOPT instruction that flushes a cache line other than the one being written.¹

Executions of the CLFLUSH instruction are not reordered with each other. Executions of CLFLUSHOPT that

access different cache lines may be reordered with each other. An execution of CLFLUSHOPT may be reordered

with an execution of CLFLUSH that accesses a different cache line.

• Reads may be reordered with older writes to different locations but not with older writes to the same location.

• Reads or writes cannot be reordered with I/O instructions, locked instructions, or serializing instructions.

• Reads cannot pass earlier LFENCE and MFENCE instructions.

• Writes and executions of CLFLUSH and CLFLUSHOPT cannot pass earlier LFENCE, SFENCE, and MFENCE

instructions.

• LFENCE instructions cannot pass earlier reads.

• SFENCE instructions cannot pass earlier writes or executions of CLFLUSH and CLFLUSHOPT.

• MFENCE instructions cannot pass earlier reads, writes, or executions of CLFLUSH and CLFLUSHOPT.

In a multiple-processor system, the following ordering principles apply:

• Individual processors use the same ordering principles as in a single-processor system.

• Writes by a single processor are observed in the same order by all processors.

• Writes from an individual processor are NOT ordered with respect to the writes from other processors.

• Memory ordering obeys causality (memory ordering respects transitive visibility).

• Any two stores are seen in a consistent order by processors other than those performing the stores

• Locked instructions have a total order.

See the example in Figure 9-1. Consider three processors in a system and each processor performs three writes,

one to each of three defined locations (A, B, and C). Individually, the processors perform the writes in the same

program order, but because of bus arbitration and other memory access mechanisms, the order that the three

processors write the individual memory locations can differ each time the respective code sequences are executed

on the processors. The final values in location A, B, and C would possibly vary on each execution of the write

sequence.

The processor-ordering model described in this section is virtually identical to that used by the Pentium and

Intel486 processors. The only enhancements in the Pentium 4, Intel Xeon, and P6 family processors are:

• Added support for speculative reads, while still adhering to the ordering principles above.

• Store-buffer forwarding, when a read passes a write to the same memory location.

1. Earlier versions of this manual specified that writes to memory may be reordered with executions of the CLFLUSH instruction. No

processors implementing the CLFLUSH instruction allow such reordering.

Vol. 3A

9-7

MULTIPLE-PROCESSOR MANAGEMENT

• Out of order store from long string store and string move operations (see Section 9.2.4, “Fast-String Operation

and Out-of-Order Stores,” below).

Order of Writes From Individual Processors

Processor #1

Processor #2

Processor #3

Each processor

Write A.1

Write A.2

Write A.3

is guaranteed to

Write B.1

Write B.2

Write B.3

perform writes in

Write C.1

Write C.2

Write C.3

program order.

Example of order of actual writes

from all processors to memory

Writes are in order

Write A.1

with respect to

Write B.1

individual processes.

Write A.2

Writes from all

Write A.3

processors are

Write C.1

not guaranteed

Write B.2

to occur in a

particular order.

Write C.2

Write B.3

Write C.3

Figure 9-1. Example of Write Ordering in Multiple-Processor Systems

NOTE

In P6 processor family, store-buffer forwarding to reads of WC memory from streaming stores to

the same address does not occur due to errata.

9.2.3

Examples Illustrating the Memory-Ordering Principles

This section provides a set of examples that illustrate the behavior of the memory-ordering principles introduced in

Section 9.2.2. They are designed to give software writers an understanding of how memory ordering may affect the

results of different sequences of instructions.

These examples are limited to accesses to memory regions defined as write-back cacheable (WB). (Section 9.2.3.1

describes other limitations on the generality of the examples.) The reader should understand that they describe

only software-visible behavior. A logical processor may reorder two accesses even if one of examples indicates that

they may not be reordered. Such an example states only that software cannot detect that such a reordering

occurred. Similarly, a logical processor may execute a memory access more than once as long as the behavior

visible to software is consistent with a single execution of the memory access.

9.2.3.1

Assumptions, Terminology, and Notation

As noted above, the examples in this section are limited to accesses to memory regions defined as write-back

cacheable (WB). They apply only to ordinary loads stores and to locked read-modify-write instructions. They do not

necessarily apply to any of the following: out-of-order stores for string instructions (see Section 9.2.4); accesses

with a non-temporal hint; reads from memory by the processor as part of address translation (e.g., page walks);

and updates to segmentation and paging structures by the processor (e.g., to update “accessed” bits).

The principles underlying the examples in this section apply to individual memory accesses and to locked read-

modify-write instructions. The Intel-64 memory-ordering model guarantees that, for each of the following

memory-access instructions, the constituent memory operation appears to execute as a single memory access:

• Instructions that read or write a single byte.

• Instructions that read or write a word (2 bytes) whose address is aligned on a 2 byte boundary.

9-8

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

• Instructions that read or write a doubleword (4 bytes) whose address is aligned on a 4 byte boundary.

• Instructions that read or write a quadword (8 bytes) whose address is aligned on an 8 byte boundary.

Any locked instruction (either the XCHG instruction or another read-modify-write instruction with a LOCK prefix)

appears to execute as an indivisible and uninterruptible sequence of load(s) followed by store(s) regardless of

alignment.

Other instructions may be implemented with multiple memory accesses. From a memory-ordering point of view,

there are no guarantees regarding the relative order in which the constituent memory accesses are made. There is

also no guarantee that the constituent operations of a store are executed in the same order as the constituent

operations of a load.

Section 9.2.3.2 through Section 9.2.3.7 give examples using the MOV instruction. The principles that underlie

these examples apply to load and store accesses in general and to other instructions that load from or store to

memory. Section 9.2.3.8 and Section 9.2.3.9 give examples using the XCHG instruction. The principles that

underlie these examples apply to other locked read-modify-write instructions.

This section uses the term “processor” is to refer to a logical processor. The examples are written using Intel-64

assembly-language syntax and use the following notational conventions:

• Arguments beginning with an “r”, such as r1 or r2 refer to registers (e.g., EAX) visible only to the processor

being considered.

• Memory locations are denoted with x, y, z.

• Stores are written as mov [ _x], val, which implies that val is being stored into the memory location x.

• Loads are written as mov r, [ _x], which implies that the contents of the memory location x are being loaded

into the register r.

As noted earlier, the examples refer only to software visible behavior. When the succeeding sections make state-

ment such as “the two stores are reordered,” the implication is only that “the two stores appear to be reordered

from the point of view of software.”

9.2.3.2

Neither Loads Nor Stores Are Reordered with Like Operations

The Intel-64 memory-ordering model allows neither loads nor stores to be reordered with the same kind of opera-

tion. That is, it ensures that loads are seen in program order and that stores are seen in program order. This is illus-

trated by the following example:

Example 9-1. Stores Are Not Reordered with Other Stores

Processor 0

Processor 1

mov [ _x], 1

mov r1, [ _y]

mov [ _y], 1

mov r2, [ _x]

Initially x = y = 0

r1 = 1 and r2 = 0 is not allowed

The disallowed return values could be exhibited only if processor 0’s two stores are reordered (with the two loads

occurring between them) or if processor 1’s two loads are reordered (with the two stores occurring between them).

If r1 = 1, the store to y occurs before the load from y. Because the Intel-64 memory-ordering model does not allow

stores to be reordered, the earlier store to x occurs before the load from y. Because the Intel-64 memory-ordering

model does not allow loads to be reordered, the store to x also occurs before the later load from x. This r2 = 1.

9.2.3.3

Stores Are Not Reordered With Earlier Loads

The Intel-64 memory-ordering model ensures that a store by a processor may not occur before a previous load by

the same processor. This is illustrated in Example 9-2.

Vol. 3A

9-9

MULTIPLE-PROCESSOR MANAGEMENT

Example 9-2. Stores Are Not Reordered with Older Loads

Processor 0

Processor 1

mov r1, [ _x]

mov r2, [ _y]

mov [ _y], 1

mov [ _x], 1

Initially x = y = 0

r1 = 1 and r2 = 1 is not allowed

Assume r1 = 1.

• Because r1 = 1, processor 1’s store to x occurs before processor 0’s load from x.

• Because the Intel-64 memory-ordering model prevents each store from being reordered with the earlier load

by the same processor, processor 1’s load from y occurs before its store to x.

• Similarly, processor 0’s load from x occurs before its store to y.

• Thus, processor 1’s load from y occurs before processor 0’s store to y, implying r2 = 0.

9.2.3.4

Loads May Be Reordered with Earlier Stores to Different Locations

The Intel-64 memory-ordering model allows a load to be reordered with an earlier store to a different location.

However, loads are not reordered with stores to the same location.

The fact that a load may be reordered with an earlier store to a different location is illustrated by the following

example:

Example 9-3. Loads May be Reordered with Older Stores

Processor 0

Processor 1

mov [ _x], 1

mov [ _y], 1

mov r1, [ _y]

mov r2, [ _x]

Initially x = y = 0

r1 = 0 and r2 = 0 is allowed

At each processor, the load and the store are to different locations and hence may be reordered. Any interleaving

of the operations is thus allowed. One such interleaving has the two loads occurring before the two stores. This

would result in each load returning value 0.

The fact that a load may not be reordered with an earlier store to the same location is illustrated by the following

example:

Example 9-4. Loads Are not Reordered with Older Stores to the Same Location

Processor 0

mov [ _x], 1

mov r1, [ _x]

Initially x = 0

r1 = 0 is not allowed

The Intel-64 memory-ordering model does not allow the load to be reordered with the earlier store because the

accesses are to the same location. Therefore, r1 = 1 must hold.

9-10

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

9.2.3.5

Intra-Processor Forwarding Is Allowed

The memory-ordering model allows concurrent stores by two processors to be seen in different orders by those two

processors; specifically, each processor may perceive its own store occurring before that of the other. This is illus-

trated by the following example:

Example 9-5. Intra-Processor Forwarding is Allowed

Processor 0

Processor 1

mov [ _x], 1

mov [ _y], 1

mov r1, [ _x]

mov r3, [ _y]

mov r2, [ _y]

mov r4, [ _x]

Initially x = y = 0

r2 = 0 and r4 = 0 is allowed

The memory-ordering model imposes no constraints on the order in which the two stores appear to execute by the

two processors. This fact allows processor 0 to see its store before seeing processor 1's, while processor 1 sees its

store before seeing processor 0's. (Each processor is self consistent.) This allows r2 = 0 and r4 = 0.

In practice, the reordering in this example can arise as a result of store-buffer forwarding. While a store is tempo-

rarily held in a processor's store buffer, it can satisfy the processor's own loads but is not visible to (and cannot

satisfy) loads by other processors.

9.2.3.6

Stores Are Transitively Visible

The memory-ordering model ensures transitive visibility of stores; stores that are causally related appear to all

processors to occur in an order consistent with the causality relation. This is illustrated by the following example:

Example 9-6. Stores Are Transitively Visible

Processor 0

Processor 1

Processor 2

mov [ _x], 1

mov r1, [ _x]

mov [ _y], 1

mov r2, [ _y]

mov r3, [_x]

Initially x = y = 0

r1 = 1, r2 = 1, r3 = 0 is not allowed

Assume that r1 = 1 and r2 = 1.

• Because r1 = 1, processor 0’s store occurs before processor 1’s load.

• Because the memory-ordering model prevents a store from being reordered with an earlier load (see Section

9.2.3.3), processor 1’s load occurs before its store. Thus, processor 0’s store causally precedes processor 1’s

store.

• Because processor 0’s store causally precedes processor 1’s store, the memory-ordering model ensures that

processor 0’s store appears to occur before processor 1’s store from the point of view of all processors.

• Because r2 = 1, processor 1’s store occurs before processor 2’s load.

• Because the Intel-64 memory-ordering model prevents loads from being reordered (see Section 9.2.3.2),

processor 2’s load occur in order.

• The above items imply that processor 0’s store to x occurs before processor 2’s load from x. This implies that

r3 = 1.

Vol. 3A

9-11

MULTIPLE-PROCESSOR MANAGEMENT

9.2.3.7

Stores Are Seen in a Consistent Order by Other Processors

As noted in Section 9.2.3.5, the memory-ordering model allows stores by two processors to be seen in different

orders by those two processors. However, any two stores must appear to execute in the same order to all proces-

sors other than those performing the stores. This is illustrated by the following example:

Example 9-7. Stores Are Seen in a Consistent Order by Other Processors

Processor 0

Processor 1

Processor 2

Processor 3

mov [ _x], 1

mov [ _y], 1

mov r1, [ _x]

mov r3, [_y]

mov r2, [ _y]

mov r4, [_x]

Initially x = y =0

r1 = 1, r2 = 0, r3 = 1, r4 = 0 is not allowed

By the principles discussed in Section 9.2.3.2:

• Processor 2’s first and second load cannot be reordered.

• Processor 3’s first and second load cannot be reordered.

• If r1 = 1 and r2 = 0, processor 0’s store appears to precede processor 1’s store with respect to processor 2.

• Similarly, r3 = 1 and r4 = 0 imply that processor 1’s store appears to precede processor 0’s store with respect

to processor 1.

Because the memory-ordering model ensures that any two stores appear to execute in the same order to all

processors (other than those performing the stores), this set of return values is not allowed.

9.2.3.8

Locked Instructions Have a Total Order

The memory-ordering model ensures that all processors agree on a single execution order of all locked instructions,

including those that are larger than 8 bytes or are not naturally aligned. This is illustrated by the following example:

Example 9-8. Locked Instructions Have a Total Order

Processor 0

Processor 1

Processor 2

Processor 3

xchg [ _x], r1

xchg [ _y], r2

mov r3, [ _x]

mov r5, [_y]

mov r4, [ _y]

mov r6, [_x]

Initially r1 = r2 = 1, x = y = 0

r3 = 1, r4 = 0, r5 = 1, r6 = 0 is not allowed

Processor 2 and processor 3 must agree on the order of the two executions of XCHG. Without loss of generality,

suppose that processor 0’s XCHG occurs first.

• If r5 = 1, processor 1’s XCHG into y occurs before processor 3’s load from y.

• Because the Intel-64 memory-ordering model prevents loads from being reordered (see Section 9.2.3.2),

processor 3’s loads occur in order and, therefore, processor 1’s XCHG occurs before processor 3’s load from x.

• Since processor 0’s XCHG into x occurs before processor 1’s XCHG (by assumption), it occurs before

processor 3’s load from x. Thus, r6 = 1.

A similar argument (referring instead to processor 2’s loads) applies if processor 1’s XCHG occurs before

processor 0’s XCHG.

9.2.3.9

Loads and Stores Are Not Reordered with Locked Instructions

The memory-ordering model prevents loads and stores from being reordered with locked instructions that execute

earlier or later. The examples in this section illustrate only cases in which a locked instruction is executed before a

9-12

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

load or a store. The reader should note that reordering is prevented also if the locked instruction is executed after

a load or a store.

The first example illustrates that loads may not be reordered with earlier locked instructions:

Example 9-9. Loads Are not Reordered with Locks

Processor 0

Processor 1

xchg [ _x], r1

xchg [ _y], r3

mov r2, [ _y]

mov r4, [ _x]

Initially x = y = 0, r1 = r3 = 1

r2 = 0 and r4 = 0 is not allowed

As explained in Section 9.2.3.8, there is a total order of the executions of locked instructions. Without loss of

generality, suppose that processor 0’s XCHG occurs first.

Because the Intel-64 memory-ordering model prevents processor 1’s load from being reordered with its earlier

XCHG, processor 0’s XCHG occurs before processor 1’s load. This implies r4 = 1.

A similar argument (referring instead to processor 2’s accesses) applies if processor 1’s XCHG occurs before

processor 0’s XCHG.

The second example illustrates that a store may not be reordered with an earlier locked instruction:

Example 9-10. Stores Are not Reordered with Locks

Processor 0

Processor 1

xchg [ _x], r1

mov r2, [ _y]

mov [ _y], 1

mov r3, [ _x]

Initially x = y = 0, r1 = 1

r2 = 1 and r3 = 0 is not allowed

Assume r2 = 1.

• Because r2 = 1, processor 0’s store to y occurs before processor 1’s load from y.

• Because the memory-ordering model prevents a store from being reordered with an earlier locked instruction,

processor 0’s XCHG into x occurs before its store to y. Thus, processor 0’s XCHG into x occurs before

processor 1’s load from y.

• Because the memory-ordering model prevents loads from being reordered (see Section 9.2.3.2), processor 1’s

loads occur in order and, therefore, processor 1’s XCHG into x occurs before processor 1’s load from x. Thus,

r3 = 1.

9.2.4

Fast-String Operation and Out-of-Order Stores

Section 7.3.9.3 of Intel^® 64 and IA-32 Architectures Software Developer’s Manual, Volume 1, described an optimi-

zation of repeated string operations called fast-string operation.

As explained in that section, the stores produced by fast-string operation may appear to execute out of order. Soft-

ware dependent upon sequential store ordering should not use string operations for the entire data structure to be

stored. Data and semaphores should be separated. Order-dependent code should write to a discrete semaphore

variable after any string operations to allow correctly ordered data to be seen by all processors. Atomicity of load

and store operations is guaranteed only for native data elements of the string with native data size, and only if they

are included in a single cache line.

Section 9.2.4.1 and Section 9.2.4.2 provide further explain and examples.

9.2.4.1

Memory-Ordering Model for String Operations on Write-Back (WB) Memory

This section deals with the memory-ordering model for string operations on write-back (WB) memory for the Intel

64 architecture.

Vol. 3A

9-13

MULTIPLE-PROCESSOR MANAGEMENT

The memory-ordering model respects the follow principles:

1. Stores within a single string operation may be executed out of order.

2. Stores from separate string operations (for example, stores from consecutive string operations) do not execute

out of order. All the stores from an earlier string operation will complete before any store from a later string

operation.

3. String operations are not reordered with other store operations.

Fast string operations (e.g., string operations initiated with the MOVS/STOS instructions and the REP prefix) may

be interrupted by exceptions or interrupts. The interrupts are precise but may be delayed - for example, the inter-

ruptions may be taken at cache line boundaries, after every few iterations of the loop, or after operating on every

few bytes. Different implementations may choose different options, or may even choose not to delay interrupt

handling, so software should not rely on the delay. When the interrupt/trap handler is reached, the source/destina-

tion registers point to the next string element to be operated on, while the EIP stored in the stack points to the

string instruction, and the ECX register has the value it held following the last successful iteration. The return from

that trap/interrupt handler should cause the string instruction to be resumed from the point where it was inter-

rupted.

The string operation memory-ordering principles, (item 2 and 3 above) should be interpreted by taking the incor-

ruptibility of fast string operations into account. For example, if a fast string operation gets interrupted after k iter-

ations, then stores performed by the interrupt handler will become visible after the fast string stores from iteration

0 to k, and before the fast string stores from the (k+1)th iteration onward.

Stores within a single string operation may execute out of order (item 1 above) only if fast string operation is

enabled. Fast string operations are enabled/disabled through the IA32_MISC_ENABLE model specific register.

9.2.4.2

Examples Illustrating Memory-Ordering Principles for String Operations

The following examples uses the same notation and convention as described in Section 9.2.3.1.

In Example 9-11, processor 0 does one round of (128 iterations) doubleword string store operation via rep:stosd,

writing the value 1 (value in EAX) into a block of 512 bytes from location _x (kept in ES:EDI) in ascending order.

Since each operation stores a doubleword (4 bytes), the operation is repeated 128 times (value in ECX). The block

of memory initially contained 0. Processor 1 is reading two memory locations that are part of the memory block

being updated by processor 0, i.e, reading locations in the range _x to (_x+511).

Example 9-11. Stores Within a String Operation May be Reordered

Processor 0

Processor 1

rep:stosd [ _x]

mov r1, [ _z]

mov r2, [ _y]

Initially on processor 0: EAX = 1, ECX=128, ES:EDI =_x

Initially [_x] to 511[_x]= 0, _x <= _y < _z < _x+512

r1 = 1 and r2 = 0 is allowed

It is possible for processor 1 to perceive that the repeated string stores in processor 0 are happening out of order.

Assume that fast string operations are enabled on processor 0.

In Example 9-12, processor 0 does two separate rounds of rep stosd operation of 128 doubleword stores, writing

the value 1 (value in EAX) into the first block of 512 bytes from location _x (kept in ES:EDI) in ascending order. It

then writes 1 into a second block of memory from (_x+512) to (_x+1023). All of the memory locations initially

contain 0. The block of memory initially contained 0. Processor 1 performs two load operations from the two blocks

of memory.

9-14

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

Example 9-12. Stores Across String Operations Are not Reordered

Processor 0

Processor 1

rep:stosd [ _x]

mov r1, [ _z]

mov ecx, $128

mov r2, [ _y]

rep:stosd 512[ _x]

Initially on processor 0: EAX = 1, ECX=128, ES:EDI =_x

Initially [_x] to 1023[_x]= 0, _x <= _y < _x+512 < _z < _x+1024

r1 = 1 and r2 = 0 is not allowed

It is not possible in the above example for processor 1 to perceive any of the stores from the later string operation

(to the second 512 block) in processor 0 before seeing the stores from the earlier string operation to the first 512

block.

The above example assumes that writes to the second block (_x+512 to _x+1023) does not get executed while

processor 0’s string operation to the first block has been interrupted. If the string operation to the first block by

processor 0 is interrupted, and a write to the second memory block is executed by the interrupt handler, then that

change in the second memory block will be visible before the string operation to the first memory block resumes.

In Example 9-13, processor 0 does one round of (128 iterations) doubleword string store operation via rep:stosd,

writing the value 1 (value in EAX) into a block of 512 bytes from location _x (kept in ES:EDI) in ascending order. It

then writes to a second memory location outside the memory block of the previous string operation. Processor 1

performs two read operations, the first read is from an address outside the 512-byte block but to be updated by

processor 0, the second ready is from inside the block of memory of string operation.

Example 9-13. String Operations Are not Reordered with later Stores

Processor 0

Processor 1

rep:stosd [ _x]

mov r1, [ _z]

mov [_z], $1

mov r2, [ _y]

Initially on processor 0: EAX = 1, ECX=128, ES:EDI =_x

Initially [_y] = [_z] = 0, [_x] to 511[_x]= 0, _x <= _y < _x+512, _z is a separate memory location

r1 = 1 and r2 = 0 is not allowed

Processor 1 cannot perceive the later store by processor 0 until it sees all the stores from the string operation.

Example 9-13 assumes that processor 0’s store to [_z] is not executed while the string operation has been inter-

rupted. If the string operation is interrupted and the store to [_z] by processor 0 is executed by the interrupt

handler, then changes to [_z] will become visible before the string operation resumes.

Example 9-14 illustrates the visibility principle when a string operation is interrupted.

Example 9-14. Interrupted String Operation

Processor 0

Processor 1

rep:stosd [ _x] // interrupted before es:edi reach _y

mov r1, [ _z]

mov [_z], $1 // interrupt handler

mov r2, [ _y]

Initially on processor 0: EAX = 1, ECX=128, ES:EDI =_x

Initially [_y] = [_z] = 0, [_x] to 511[_x]= 0, _x <= _y < _x+512, _z is a separate memory location

r1 = 1 and r2 = 0 is allowed

Vol. 3A

9-15

MULTIPLE-PROCESSOR MANAGEMENT

In Example 9-14, processor 0 started a string operation to write to a memory block of 512 bytes starting at address

_x. Processor 0 got interrupted after k iterations of store operations. The address _y has not yet been updated by

processor 0 when processor 0 got interrupted. The interrupt handler that took control on processor 0 writes to the

address _z. Processor 1 may see the store to _z from the interrupt handler, before seeing the remaining stores to

the 512-byte memory block that are executed when the string operation resumes.

Example 9-15 illustrates the ordering of string operations with earlier stores. No store from a string operation can

be visible before all prior stores are visible.

Example 9-15. String Operations Are not Reordered with Earlier Stores

Processor 0

Processor 1

mov [_z], $1

mov r1, [ _y]

rep:stosd [ _x]

mov r2, [ _z]

Initially on processor 0: EAX = 1, ECX=128, ES:EDI =_x

Initially [_y] = [_z] = 0, [_x] to 511[_x]= 0, _x <= _y < _x+512, _z is a separate memory location

r1 = 1 and r2 = 0 is not allowed

9.2.5

Strengthening or Weakening the Memory-Ordering Model

The Intel 64 and IA-32 architectures provide several mechanisms for strengthening or weakening the memory-

ordering model to handle special programming situations. These mechanisms include:

• The I/O instructions, locked instructions, the LOCK prefix, and serializing instructions force stronger ordering

on the processor.

• The SFENCE instruction (introduced to the IA-32 architecture in the Pentium III processor) and the LFENCE and

MFENCE instructions (introduced in the Pentium 4 processor) provide memory-ordering and serialization

capabilities for specific types of memory operations.

• The memory type range registers (MTRRs) can be used to strengthen or weaken memory ordering for specific

area of physical memory (see Section 12.11, “Memory Type Range Registers (MTRRs)”). MTRRs are available

only in the Pentium 4, Intel Xeon, and P6 family processors.

• The page attribute table (PAT) can be used to strengthen memory ordering for a specific page or group of pages

(see Section 12.12, “Page Attribute Table (PAT)”). The PAT is available only in the Pentium 4, Intel Xeon, and

Pentium III processors.

These mechanisms can be used as follows:

Memory mapped devices and other I/O devices on the bus are often sensitive to the order of writes to their I/O

buffers. I/O instructions can be used to (the IN and OUT instructions) impose strong write ordering on such

accesses as follows. Prior to executing an I/O instruction, the processor waits for all previous instructions in the

program to complete and for all buffered writes to drain to memory. Only instruction fetch and page tables walks

can pass I/O instructions. Execution of subsequent instructions do not begin until the processor determines that

the I/O instruction has been completed.

Synchronization mechanisms in multiple-processor systems may depend upon a strong memory-ordering model.

Here, a program can use a locked instruction such as the XCHG instruction or the LOCK prefix to ensure that a read-

modify-write operation on memory is carried out atomically. Locked instructions typically operate like I/O instruc-

tions in that they wait for all previous memory accesses to complete and for all buffered writes to drain to memory

(see Section 9.1.2, “Bus Locking”). Unlike I/O operations, locked instructions do not wait for all previous instruc-

tions to complete execution.

Program synchronization can also be carried out with serializing instructions (see Section 9.3). These instructions

are typically used at critical procedure or task boundaries to force completion of all previous instructions before a

jump to a new section of code or a context switch occurs. Like the I/O instructions, the processor waits until all

previous instructions have been completed and all buffered writes have been drained to memory before executing

the serializing instruction.

9-16

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

The SFENCE, LFENCE, and MFENCE instructions provide a performance-efficient way of ensuring load and store

memory ordering between routines that produce weakly-ordered results and routines that consume that data. The

functions of these instructions are as follows:

• SFENCE - Serializes all store (write) operations that occurred prior to the SFENCE instruction in the program

instruction stream, but does not affect load operations.

• LFENCE - Serializes all load (read) operations that occurred prior to the LFENCE instruction in the program

instruction stream, but does not affect store operations.¹

• MFENCE - Serializes all store and load operations that occurred prior to the MFENCE instruction in the

program instruction stream.

Note that the SFENCE, LFENCE, and MFENCE instructions provide a more efficient method of controlling memory

ordering than the CPUID instruction.

The MTRRs were introduced in the P6 family processors to define the cache characteristics for specified areas of

physical memory. The following are two examples of how memory types set up with MTRRs can be used strengthen

or weaken memory ordering for the Pentium 4, Intel Xeon, and P6 family processors:

• The strong uncached (UC) memory type forces a strong-ordering model on memory accesses. Here, all reads

and writes to the UC memory region appear on the bus and out-of-order or speculative accesses are not

performed. This memory type can be applied to an address range dedicated to memory mapped I/O devices to

force strong memory ordering.

• For areas of memory where weak ordering is acceptable, the write back (WB) memory type can be chosen.

Here, reads can be performed speculatively and writes can be buffered and combined. For this type of memory,

cache locking is performed on atomic (locked) operations that do not split across cache lines, which helps to

reduce the performance penalty associated with the use of the typical synchronization instructions, such as

XCHG, that lock the bus during the entire read-modify-write operation. With the WB memory type, the XCHG

instruction locks the cache instead of the bus if the memory access is contained within a cache line.

The PAT was introduced in the Pentium III processor to enhance the caching characteristics that can be assigned to

pages or groups of pages. The PAT mechanism typically used to strengthen caching characteristics at the page level

with respect to the caching characteristics established by the MTRRs. Table 12-7 shows the interaction of the PAT

with the MTRRs.

Intel recommends that software written to run on Intel Core 2 Duo, Intel Atom, Intel Core Duo, Pentium 4, Intel

Xeon, and P6 family processors assume the processor-ordering model or a weaker memory-ordering model. The

Intel Core 2 Duo, Intel Atom, Intel Core Duo, Pentium 4, Intel Xeon, and P6 family processors do not implement a

strong memory-ordering model, except when using the UC memory type. Despite the fact that Pentium 4, Intel

Xeon, and P6 family processors support processor ordering, Intel does not guarantee that future processors will

support this model. To make software portable to future processors, it is recommended that operating systems

provide critical region and resource control constructs and API’s (application program interfaces) based on I/O,

locking, and/or serializing instructions be used to synchronize access to shared areas of memory in multiple-

processor systems. Also, software should not depend on processor ordering in situations where the system hard-

ware does not support this memory-ordering model.

9.3

SERIALIZING INSTRUCTIONS

The Intel 64 and IA-32 architectures define several serializing instructions. These instructions force the

processor to complete all modifications to flags, registers, and memory by previous instructions and to drain all

buffered writes to memory before the next instruction is fetched and executed. For example, when a MOV to

control register instruction is used to load a new value into control register CR0 to enable protected mode, the

processor must perform a serializing operation before it enters protected mode. This serializing operation ensures

1. Specifically, LFENCE does not execute until all prior instructions have completed locally, and no later instruction begins execution

until LFENCE completes. As a result, an instruction that loads from memory and that precedes an LFENCE receives data from mem-

ory prior to completion of the LFENCE. An LFENCE that follows an instruction that stores to memory might complete before the data

being stored have become globally visible. Instructions following an LFENCE may be fetched from memory before the LFENCE, but

they will not execute until the LFENCE completes.

Vol. 3A

9-17

MULTIPLE-PROCESSOR MANAGEMENT

that all operations that were started while the processor was in real-address mode are completed before the switch

to protected mode is made.

The concept of serializing instructions was introduced into the IA-32 architecture with the Pentium processor to

support parallel instruction execution. Serializing instructions have no meaning for the Intel486 and earlier proces-

sors that do not implement parallel instruction execution.

It is important to note that executing of serializing instructions on P6 and more recent processor families constrain

speculative execution because the results of speculatively executed instructions are discarded. The following

instructions are serializing instructions:

• Privileged serializing instructions - INVD, INVEPT, INVLPG, INVVPID, LGDT, LIDT, LLDT, LTR, MOV (to

control register, with the exception of MOV CR8¹), MOV (to debug register), WBINVD, and WRMSR².

• Non-privileged serializing instructions - CPUID, IRET, RSM, and SERIALIZE.

When the processor serializes instruction execution, it ensures that all pending memory transactions are completed

(including writes stored in its store buffer) before it executes the next instruction. Nothing can pass a serializing

instruction and a serializing instruction cannot pass any other instruction (read, write, instruction fetch, or I/O). For

example, CPUID can be executed at any privilege level to serialize instruction execution with no effect on program

flow, except that the EAX, EBX, ECX, and EDX registers are modified.

The following instructions are memory-ordering instructions, not serializing instructions. These drain the data

memory subsystem. They do not serialize the instruction execution stream:³

• Non-privileged memory-ordering instructions - SFENCE, LFENCE, and MFENCE.

The SFENCE, LFENCE, and MFENCE instructions provide more granularity in controlling the serialization of memory

loads and stores (see Section 9.2.5, “Strengthening or Weakening the Memory-Ordering Model”).

The following additional information is worth noting regarding serializing instructions:

• The processor does not write back the contents of modified data in its data cache to external memory when it

serializes instruction execution. Software can force modified data to be written back by executing the WBINVD

instruction, which is a serializing instruction. The amount of time or cycles for WBINVD to complete will vary

due to the size of different cache hierarchies and other factors. As a consequence, the use of the WBINVD

instruction can have an impact on interrupt/event response time.

• When an instruction is executed that enables or disables paging (that is, changes the PG flag in control register

CR0), the instruction should be followed by a jump instruction. The target instruction of the jump instruction is

fetched with the new setting of the PG flag (that is, paging is enabled or disabled), but the jump instruction

itself is fetched with the previous setting. The Pentium 4, Intel Xeon, and P6 family processors do not require

the jump operation following the move to register CR0 (because any use of the MOV instruction in a Pentium 4,

Intel Xeon, or P6 family processor to write to CR0 is completely serializing). However, to maintain backwards

and forward compatibility with code written to run on other IA-32 processors, it is recommended that the jump

operation be performed.

• Whenever an instruction is executed to change the contents of CR3 while paging is enabled, the next instruction

is fetched using the translation tables that correspond to the new value of CR3. Therefore the next instruction

and the sequentially following instructions should have a mapping based upon the new value of CR3. (Global

entries in the TLBs are not invalidated, see Section 4.10.4, “Invalidation of TLBs and Paging-Structure

Caches.”)

• The Pentium processor and more recent processor families use branch-prediction techniques to improve

performance by prefetching the destination of a branch instruction before the branch instruction is executed.

Consequently, instruction execution is not deterministically serialized when a branch instruction is executed.

1. MOV CR8 is not defined architecturally as a serializing instruction.

2. An execution of WRMSR to any non-serializing MSR is not serializing. Non-serializing MSRs include the following: IA32_SPEC_CTRL

MSR (MSR index 48H), IA32_PRED_CMD MSR (MSR index 49H), IA32_TSX_CTRL MSR (MSR index 122H), IA32_TSC_DEADLINE MSR

(MSR index 6E0H), IA32_PKRS MSR (MSR index 6E1H), IA32_HWP_REQUEST MSR (MSR index 774H), or any of the x2APIC MSRs

(MSR indices 802H to 83FH).

3. LFENCE does provide some guarantees on instruction ordering. It does not execute until all prior instructions have completed locally,

and no later instruction begins execution until LFENCE completes.

9-18

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

9.4

MULTIPLE-PROCESSOR (MP) INITIALIZATION

The IA-32 architecture (beginning with the P6 family processors) defines a multiple-processor (MP) initialization

protocol called the Multiprocessor Specification Version 1.4. This specification defines the boot protocol to be used

by IA-32 processors in multiple-processor systems. (Here, multiple processors is defined as two or more proces-

sors.) The MP initialization protocol has the following important features:

• It supports controlled booting of multiple processors without requiring dedicated system hardware.

• It allows hardware to initiate the booting of a system without the need for a dedicated signal or a predefined

boot processor.

• It allows all IA-32 processors to be booted in the same manner, including those supporting Intel Hyper-

Threading Technology.

• The MP initialization protocol also applies to MP systems using Intel 64 processors.

The mechanism for carrying out the MP initialization protocol differs depending on the Intel processor generations.

The following bullets summarizes the evolution of the changes:

• For P6 family or older processors supporting MP operations- The selection of the BSP and APs (see

Section 9.4.1, “BSP and AP Processors”) is handled through arbitration on the APIC bus, using BIPI and FIPI

messages. These processor generations have CPUID signatures of (family=06H, extended_model=0,

model<=0DH), or family <06H. See Section 9.11.1, “Overview of the MP Initialization Process for P6 Family

Processors,” for a complete discussion of MP initialization for P6 family processors.

• Early generations of IA processors with family 0FH - The selection of the BSP and APs (see Section

9.4.1, “BSP and AP Processors”) is handled through arbitration on the system bus, using BIPI and FIPI

messages (see Section 9.4.3, “MP Initialization Protocol Algorithm for MP Systems”). These processor

generations have CPUID signatures of family=0FH, model=0H, stepping<=09H.

• Later generations of IA processors with family 0FH, and IA processors with system bus - The

selection of the BSP and APs is handled through a special system bus cycle, without using BIPI and FIPI

message arbitration (see Section 9.4.3, “MP Initialization Protocol Algorithm for MP Systems”). These

processor generations have CPUID signatures of family=0FH with (model=0H, stepping>=0AH) or (model >0,

all steppings); or family=06H, extended_model=0, model>=0EH.

• All other modern IA processor generations supporting MP operations- The selection of the BSP and

APs in the system is handled by platform-specific arrangement of the combination of hardware, BIOS, and/or

configuration input options. The basis of the selection mechanism is similar to those of the Later generations of

family 0FH and other Intel processor using system bus (see Section 9.4.3, “MP Initialization Protocol Algorithm

for MP Systems”). These processor generations have CPUID signatures of family=06H, extended_model>0.

The family, model, and stepping ID for a processor is given in the EAX register when the CPUID instruction is

executed with a value of 1 in the EAX register.

9.4.1

BSP and AP Processors

The MP initialization protocol defines two classes of processors: the bootstrap processor (BSP) and the application

processors (APs). Following a power-up or RESET of an MP system, system hardware dynamically selects one of

the processors on the system bus as the BSP. The remaining processors are designated as APs.

As part of the BSP selection mechanism, the BSP flag is set in the IA32_APIC_BASE MSR (see Figure 11-5) of the

BSP, indicating that it is the BSP. This flag is cleared for all other processors.

The BSP executes the BIOS’s boot-strap code to configure the APIC environment, sets up system-wide data struc-

tures, and starts and initializes the APs. When the BSP and APs are initialized, the BSP then begins executing the

operating-system initialization code.

Following a power-up or reset, the APs complete a minimal self-configuration, then wait for a startup signal (a SIPI

message) from the BSP processor. Upon receiving a SIPI message, an AP executes the BIOS AP configuration code,

which ends with the AP being placed in halt state.

For Intel 64 and IA-32 processors supporting Intel Hyper-Threading Technology, the MP initialization protocol treats

each of the logical processors on the system bus or coherent link domain as a separate processor (with a unique

Vol. 3A

9-19

MULTIPLE-PROCESSOR MANAGEMENT

APIC ID). During boot-up, one of the logical processors is selected as the BSP and the remainder of the logical

processors are designated as APs.

9.4.2

MP Initialization Protocol Requirements and Restrictions

The MP initialization protocol imposes the following requirements and restrictions on the system:

• The MP protocol is executed only after a power-up or RESET. If the MP protocol has completed and a BSP is

chosen, subsequent INITs (either to a specific processor or system wide) do not cause the MP protocol to be

repeated. Instead, each logical processor examines its BSP flag (in the IA32_APIC_BASE MSR) to determine

whether it should execute the BIOS boot-strap code (if it is the BSP) or enter a wait-for-SIPI state (if it is an

AP).

• All devices in the system that are capable of delivering interrupts to the processors must be inhibited from

doing so for the duration of the MP initialization protocol. The time during which interrupts must be inhibited

includes the window between when the BSP issues an INIT-SIPI-SIPI sequence to an AP and when the AP

responds to the last SIPI in the sequence.

9.4.3

MP Initialization Protocol Algorithm for MP Systems

Following a power-up or RESET of an MP system, the processors in the system execute the MP initialization protocol

algorithm to initialize each of the logical processors on the system bus or coherent link domain. In the course of

executing this algorithm, the following boot-up and initialization operations are carried out:

Each logical processor is assigned a unique APIC ID, based on system topology. The unique ID is a 32-bit value

if the processor supports CPUID leaf 0BH, otherwise the unique ID is an 8-bit value. (see Section 9.4.5, “Identi-

fying Logical Processors in an MP System”).

Each logical processor is assigned a unique arbitration priority based on its APIC ID.

Each logical processor executes its internal BIST simultaneously with the other logical processors in the

system.

Upon completion of the BIST, the logical processors use a hardware-defined selection mechanism to select the

BSP and the APs from the available logical processors on the system bus. The BSP selection mechanism differs

depending on the family, model, and stepping IDs of the processors, as follows:

- Later generations of IA processors within family 0FH (see Section 9.4), IA processors with system bus

(family=06H, extended_model=0, model>=0EH), or all other modern Intel processors (family=06H,

extended_model>0):

• The logical processors begin monitoring the BNR# signal, which is toggling. When the BNR# pin stops

toggling, each processor attempts to issue a NOP special cycle on the system bus.

• The logical processor with the highest arbitration priority succeeds in issuing a NOP special cycle and is

nominated the BSP. This processor sets the BSP flag in its IA32_APIC_BASE MSR, then fetches and

begins executing BIOS boot-strap code, beginning at the reset vector (physical address FFFF FFF0H).

• The remaining logical processors (that failed in issuing a NOP special cycle) are designated as APs. They

leave their BSP flags in the clear state and enter a “wait-for-SIPI state.”

- Early generations of IA processors within family 0FH (family=0FH, model=0H, stepping<=09H), P6 family

or older processors supporting MP operations (family=06H, extended_model=0, model<=0DH; or family

<06H):

• Each processor broadcasts a BIPI to “all including self.” The first processor that broadcasts a BIPI (and

thus receives its own BIPI vector), selects itself as the BSP and sets the BSP flag in its IA32_APIC_BASE

MSR. (See Section 9.11.1, “Overview of the MP Initialization Process for P6 Family Processors,” for a

description of the BIPI, FIPI, and SIPI messages.)

• The remainder of the processors (which were not selected as the BSP) are designated as APs. They

leave their BSP flags in the clear state and enter a “wait-for-SIPI state.”

• The newly established BSP broadcasts an FIPI message to “all including self,” which the BSP and APs

treat as an end of MP initialization signal. Only the processor with its BSP flag set responds to the FIPI

9-20

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

message. It responds by fetching and executing the BIOS boot-strap code, beginning at the reset

vector (physical address FFFF FFF0H).

5. As part of the boot-strap code, the BSP creates an ACPI table and/or an MP table and adds its initial APIC ID to

these tables as appropriate.

6. At the end of the boot-strap procedure, the BSP sets a processor counter to 1, then broadcasts a SIPI message

to all the APs in the system. Here, the SIPI message contains a vector to the BIOS AP initialization code (at

000VV000H, where VV is the vector contained in the SIPI message).

7. The first action of the AP initialization code is to set up a race (among the APs) to a BIOS initialization

semaphore. The first AP to the semaphore begins executing the initialization code. (See Section 9.4.4, “MP

Initialization Example,” for semaphore implementation details.) As part of the AP initialization procedure, the

AP adds its APIC ID number to the ACPI and/or MP tables as appropriate and increments the processor counter

by 1. At the completion of the initialization procedure, the AP executes a CLI instruction and halts itself.

8. When each of the APs has gained access to the semaphore and executed the AP initialization code, the BSP

establishes a count for the number of processors connected to the system bus, completes executing the BIOS

boot-strap code, and then begins executing operating-system boot-strap and start-up code.

9. While the BSP is executing operating-system boot-strap and start-up code, the APs remain in the halted state.

In this state they will respond only to INITs, NMIs, and SMIs. They will also respond to snoops and to assertions

of the STPCLK# pin.

The following section gives an example (with code) of the MP initialization protocol for of multiple processors oper-

ating in an MP configuration.

Chapter 2, “Model-Specific Registers (MSRs)‚” in the Intel^® 64 and IA-32 Architectures Software Developer’s

Manual, Volume 4, describes how to program the LINT[0:1] pins of the processor’s local APICs after an MP config-

uration has been completed.

9.4.4

MP Initialization Example

The following example illustrates the use of the MP initialization protocol used to initialize processors in an MP

system after the BSP and APs have been established. The code runs on Intel 64 or IA-32 processors that use a

protocol. This includes P6 Family processors, Pentium 4 processors, Intel Core Duo, Intel Core 2 Duo and Intel Xeon

processors.

The following constants and data definitions are used in the accompanying

code examples. They are based on the addresses of the APIC registers defined in Table 11-1.

ICR_LOW

EQU 0FEE00300H

SVR

EQU 0FEE000F0H

APIC_ID

EQU 0FEE00020H

LVT3

EQU 0FEE00370H

APIC_ENABLED

EQU 0100H

BOOT_ID

DD ?

COUNT

EQU 00H

VACANT

EQU 00H

9.4.4.1

Typical BSP Initialization Sequence

After the BSP and APs have been selected (by means of a hardware protocol, see Section 9.4.3, “MP Initialization

Protocol Algorithm for MP Systems”), the BSP begins executing BIOS boot-strap code (POST) at the normal IA-32

architecture starting address (FFFF FFF0H). The boot-strap code typically performs the following operations:

1. Initializes memory.

2. Loads the microcode update into the processor.

3. Initializes the MTRRs.

4. Enables the caches.

Vol. 3A

9-21

MULTIPLE-PROCESSOR MANAGEMENT

Executes the CPUID instruction with a value of 0H in the EAX register, then reads the EBX, ECX, and EDX

registers to determine if the BSP is “GenuineIntel.”

Executes the CPUID instruction with a value of 1H in the EAX register, then saves the values in the EAX, ECX,

and EDX registers in a system configuration space in RAM for use later.

Loads start-up code for the AP to execute into a 4-KByte page in the lower 1 MByte of memory.

Switches to protected mode and ensures that the APIC address space is mapped to the strong uncacheable

(UC) memory type.

Determine the BSP’s APIC ID from the local APIC ID register (default is 0), the code snippet below is an

example that applies to logical processors in a system whose local APIC units operate in xAPIC mode that APIC

registers are accessed using memory mapped interface:

MOV ESI, APIC_ID; Address of local APIC ID register

MOV EAX, [ESI];

AND EAX, 0FF000000H; Zero out all other bits except APIC ID

MOV BOOT_ID, EAX; Save in memory

Saves the APIC ID in the ACPI and/or MP tables and optionally in the system configuration space in RAM.

10. Converts the base address of the 4-KByte page for the AP’s bootup code into 8-bit vector. The 8-bit vector

defines the address of a 4-KByte page in the real-address mode address space (1-MByte space). For example,

a vector of 0BDH specifies a start-up memory address of 000BD000H.

11. Enables the local APIC by setting bit 8 of the APIC spurious vector register (SVR).

MOV ESI, SVR; Address of SVR

MOV EAX, [ESI];

OR EAX, APIC_ENABLED; Set bit 8 to enable (0 on reset)

MOV [ESI], EAX;

12. Sets up the LVT error handling entry by establishing an 8-bit vector for the APIC error handler.

MOV ESI, LVT3;

MOV EAX, [ESI];

AND EAX, FFFFFF00H; Clear out previous vector.

OR EAX, 000000xxH; xx is the 8-bit vector the APIC error handler.

MOV [ESI], EAX;

13. Initializes the Lock Semaphore variable VACANT to 00H. The APs use this semaphore to determine the order in

which they execute BIOS AP initialization code.

14. Performs the following operation to set up the BSP to detect the presence of APs in the system and the number

of processors (within a finite duration, minimally 100 milliseconds):

- Sets the value of the COUNT variable to 1.

- In the AP BIOS initialization code, the AP will increment the COUNT variable to indicate its presence. The

finite duration while waiting for the COUNT to be updated can be accomplished with a timer. When the timer

expires, the BSP checks the value of the COUNT variable. If the timer expires and the COUNT variable has

not been incremented, no APs are present or some error has occurred.

15. Broadcasts an INIT-SIPI-SIPI IPI sequence to the APs to wake them up and initialize them. Alternatively,

following a power-up or RESET, since all APs are already in the “wait-for-SIPI state,” the BSP can broadcast just

a single SIPI IPI to the APs to wake them up and initialize them. If software knows how many logical processors

it expects to wake up, it may choose to poll the COUNT variable. If the expected processors show up before the

100 millisecond timer expires, the timer can be canceled and skip to step 16.

The left-hand-side of the procedure illustrated in Table 9-1 provides an algorithm when the expected processor

count is unknown. The right-hand-side of Table 9-1 can be used when the expected processor count is known.

9-22

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

Table 9-1. Broadcast INIT-SIPI-SIPI Sequence and Choice of Timeouts

INIT-SIPI-SIPI when the expected processor count is unknown

INIT-SIPI-SIPI when the expected processor count is known

MOV ESI, ICR_LOW; Load address of ICR low dword into ESI.

MOV EAX, 000C4500H; Load ICR encoding for broadcast INIT IPI

; to all APs into EAX.

MOV [ESI], EAX; Broadcast INIT IPI to all APs

; 10-millisecond delay loop.

MOV EAX, 000C46XXH; Load ICR encoding for broadcast SIPI IP

; to all APs into EAX, where xx is the vector computed in step 10.

MOV [ESI], EAX; Broadcast SIPI IPI to all APs

; 200-microsecond delay loop

; 200 microsecond delay loop with check to see if COUNT has

MOV [ESI], EAX; Broadcast second SIPI IPI to all APs

; reached the expected processor count. If COUNT reaches

;Waits for the timer interrupt until the timer expires

; expected processor count, cancel timer and go to step 16.

MOV [ESI], EAX; Broadcast second SIPI IPI to all APs

; Wait for the timer interrupt polling COUNT. If COUNT reaches

; expected processor count, cancel timer and go to step 16.

; If timer expires, go to step 16.

16. Reads and evaluates the COUNT variable and establishes a processor count.

17. If necessary, reconfigures the APIC and continues with the remaining system diagnostics as appropriate.

9.4.4.2

Typical AP Initialization Sequence

When an AP receives the SIPI, it begins executing BIOS AP initialization code at the vector encoded in the SIPI. The

AP initialization code typically performs the following operations:

1. Waits on the BIOS initialization Lock Semaphore. When control of the semaphore is attained, initialization

continues.

2. Loads the microcode update into the processor.

3. Initializes the MTRRs (using the same mapping that was used for the BSP).

4. Enables the cache.

5. Executes the CPUID instruction with a value of 0H in the EAX register, then reads the EBX, ECX, and EDX

registers to determine if the AP is “GenuineIntel.”

6. Executes the CPUID instruction with a value of 1H in the EAX register, then saves the values in the EAX, ECX,

and EDX registers in a system configuration space in RAM for use later.

7. Switches to protected mode and ensures that the APIC address space is mapped to the strong uncacheable

(UC) memory type.

8. Determines the AP’s APIC ID from the local APIC ID register, and adds it to the MP and ACPI tables and

optionally to the system configuration space in RAM.

9. Initializes and configures the local APIC by setting bit 8 in the SVR register and setting up the LVT3 (error LVT)

for error handling (as described in steps 9 and 10 in Section 9.4.4.1, “Typical BSP Initialization Sequence”).

10. Configures the APs SMI execution environment. (Each AP and the BSP must have a different SMBASE address.)

11. Increments the COUNT variable by 1.

12. Releases the semaphore.

13. Executes one of the following:

Vol. 3A

9-23

MULTIPLE-PROCESSOR MANAGEMENT

- the CLI and HLT instructions (if MONITOR/MWAIT is not supported), or

- the CLI, MONITOR, and MWAIT sequence to enter a deep C-state.

14. Waits for an INIT IPI.

9.4.5

Identifying Logical Processors in an MP System

After the BIOS has completed the MP initialization protocol, each logical processor can be uniquely identified by its

local APIC ID. Software can access these APIC IDs in either of the following ways:

• Read APIC ID for a local APIC - Code running on a logical processor can read APIC ID in one of two ways

depending on the local APIC unit is operating in x2APIC mode or in xAPIC mode:

- If the local APIC unit supports x2APIC and is operating in x2APIC mode, 32-bit APIC ID can be read by

executing a RDMSR instruction to read the processor’s x2APIC ID register. This method is equivalent to

executing CPUID leaf 0BH described below.

- If the local APIC unit is operating in xAPIC mode, 8-bit APIC ID can be read by executing a MOV instruction

to read the processor’s local APIC ID register (see Section 11.4.6, “Local APIC ID”). This is the ID to use for

directing physical destination mode interrupts to the processor.

• Read ACPI or MP table - As part of the MP initialization protocol, the BIOS creates an ACPI table and an MP

table. These tables are defined in the Multiprocessor Specification Version 1.4 and provide software with a list

of the processors in the system and their local APIC IDs. The format of the ACPI table is derived from the ACPI

specification, which is an industry standard power management and platform configuration specification for MP

systems.

• Read Initial APIC ID (If the processor does not support CPUID leaf 0BH) - An APIC ID is assigned to a logical

processor during power up. This is the initial APIC ID reported by CPUID.1:EBX[31:24] and may be different

from the current value read from the local APIC. The initial APIC ID can be used to determine the topological

relationship between logical processors for multi-processor systems that do not support CPUID leaf 0BH.

Bits in the 8-bit initial APIC ID can be interpreted using several bit masks. Each bit mask can be used to extract

an identifier to represent a hierarchical domain of the multi-threading resource topology in an MP system (See

Section 9.9.1, “Hierarchical Mapping of Shared Resources”). The initial APIC ID may consist of up to four bit-

fields. In a non-clustered MP system, the field consists of up to three bit fields.

• Read 32-bit APIC ID from CPUID leaf 0BH (If the processor supports CPUID leaf 0BH) - A unique APIC ID

is assigned to a logical processor during power up. This APIC ID is reported by CPUID.0BH:EDX[31:0] as a 32-

bit value. Use the 32-bit APIC ID and CPUID leaf 0BH to determine the topological relationship between logical

processors if the processor supports CPUID leaf 0BH.

Bits in the 32-bit x2APIC ID can be extracted into sub-fields using CPUID leaf 0BH parameters. (See Section

9.9.1, “Hierarchical Mapping of Shared Resources”).

Figure 9-2 shows two examples of APIC ID bit fields in earlier single-core processors. In single-core Intel Xeon

processors, the APIC ID assigned to a logical processor during power-up and initialization is 8 bits. Bits 2:1 form a

2-bit physical package identifier (which can also be thought of as a socket identifier). In systems that configure

physical processors in clusters, bits 4:3 form a 2-bit cluster ID. Bit 0 is used in the Intel Xeon processor MP to iden-

tify the two logical processors within the package (see Section 9.9.3, “Hierarchical ID of Logical Processors in an MP

System”). For Intel Xeon processors that do not support Intel Hyper-Threading Technology, bit 0 is always set to 0;

for Intel Xeon processors supporting Intel Hyper-Threading Technology, bit 0 performs the same function as it does

for Intel Xeon processor MP.

For more recent multi-core processors, see Section 9.9.1, “Hierarchical Mapping of Shared Resources,” for a

complete description of the topological relationships between logical processors and bit field locations within an

initial APIC ID across Intel 64 and IA-32 processor families.

Note the number of bit fields and the width of bit-fields are dependent on processor and platform hardware capa-

bilities. Software should determine these at runtime. When initial APIC IDs are assigned to logical processors, the

value of APIC ID assigned to a logical processor will respect the bit-field boundaries corresponding core, physical

package, etc. Additional examples of the bit fields in the initial APIC ID of multi-threading capable systems are

shown in Section 9.9.

9-24

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

APIC ID Format for Intel Xeon Processors that

do not Support Intel Hyper-Threading Technology

Reserved

Cluster

Processor ID

APIC ID Format for P6 Family Processors

Reserved

Cluster

Processor ID

Figure 9-2. Interpretation of APIC ID in Early MP Systems

For P6 family processors, the APIC ID that is assigned to a processor during power-up and initialization is 4 bits

(see Figure 9-2). Here, bits 0 and 1 form a 2-bit processor (or socket) identifier and bits 2 and 3 form a 2-bit cluster

ID.

9.5

INTEL® HYPER-THREADING TECHNOLOGY AND INTEL® MULTI-CORE

TECHNOLOGY

Intel Hyper-Threading Technology and Intel multi-core technology are extensions to Intel 64 and IA-32 architec-

tures that enable a single physical processor to execute two or more separate code streams (called threads)

concurrently. In Intel Hyper-Threading Technology, a single processor core provides two logical processors that

share execution resources (see Section 9.7, “Intel® Hyper-Threading Technology Architecture”). In Intel multi-

core technology, a physical processor package provides two or more processor cores. Both configurations require

chipsets and a BIOS that support the technologies.

Software should not rely on processor names to determine whether a processor supports Intel Hyper-Threading

Technology or Intel multi-core technology. Use the CPUID instruction to determine processor capability (see

Section 9.6.2, “Initializing Multi-Core Processors”).

9.6

DETECTING HARDWARE MULTI-THREADING SUPPORT AND TOPOLOGY

Use the CPUID instruction to detect the presence of hardware multi-threading support in a physical processor.

Hardware multi-threading can support several varieties of multigrade and/or Intel Hyper-Threading Technology.

CPUID instruction provides several sets of parameter information to aid software enumerating topology informa-

tion. The relevant topology enumeration parameters provided by CPUID include:

• Hardware Multi-Threading feature flag (CPUID.1:EDX[28] = 1) - Indicates when set that the physical

package is capable of supporting Intel Hyper-Threading Technology and/or multiple cores.

• Processor topology enumeration parameters for 8-bit APIC ID:

- Addressable IDs for Logical processors in the same Package (CPUID.1:EBX[23:16]) - Indicates

the maximum number of addressable ID for logical processors in a physical package. Within a physical

package, there may be addressable IDs that are not occupied by any logical processors. This parameter

does not represents the hardware capability of the physical processor.¹

Vol. 3A

9-25

MULTIPLE-PROCESSOR MANAGEMENT

• Addressable IDs for processor cores in the same Package¹ (CPUID.(EAX=4, ECX=0²):EAX[31:26] +

1 = Y) - Indicates the maximum number of addressable IDs attributable to processor cores (Y) in the physical

package.

• Extended Processor Topology Enumeration parameters for 32-bit APIC ID: Intel 64 processors

supporting CPUID leaf 0BH will assign unique APIC IDs to each logical processor in the system. CPUID leaf 0BH

reports the 32-bit APIC ID and provide topology enumeration parameters. See CPUID instruction reference

pages in Intel^® 64 and IA-32 Architectures Software Developer’s Manual, Volume 2A.

The CPUID feature flag may indicate support for hardware multi-threading when only one logical processor avail-

able in the package. In this case, the decimal value represented by bits 16 through 23 in the EBX register will have

a value of 1.

Software should note that the number of logical processors enabled by system software may be less than the value

of “Addressable IDs for Logical processors”. Similarly, the number of cores enabled by system software may be less

than the value of “Addressable IDs for processor cores”.

Software can detect the availability of the CPUID extended topology enumeration leaf (0BH) by performing two

steps:

• Check maximum input value for basic CPUID information by executing CPUID with EAX= 0. If CPUID.0H:EAX is

greater than or equal or 11 (0BH), then proceed to next step,

• Check CPUID.EAX=0BH, ECX=0H:EBX is non-zero.

If both of the above conditions are true, extended topology enumeration leaf is available. Note the presence of

CPUID leaf 0BH in a processor does not guarantee support that the local APIC supports x2APIC. If

CPUID.(EAX=0BH, ECX=0H):EBX returns zero and maximum input value for basic CPUID information is greater

than 0BH, then CPUID.0BH leaf is not supported on that processor.

9.6.1

Initializing Processors Supporting Intel® Hyper-Threading Technology

The initialization process for an MP system that contains processors supporting Intel Hyper-Threading Technology

is the same as for conventional MP systems (see Section 9.4, “Multiple-Processor (MP) Initialization”). One logical

processor in the system is selected as the BSP and other processors (or logical processors) are designated as APs.

The initialization process is identical to that described in Section 9.4.3, “MP Initialization Protocol Algorithm for MP

Systems,” and Section 9.4.4, “MP Initialization Example.”

During initialization, each logical processor is assigned an APIC ID that is stored in the local APIC ID register for

each logical processor. If two or more processors supporting Intel Hyper-Threading Technology are present, each

logical processor on the system bus is assigned a unique ID (see Section 9.9.3, “Hierarchical ID of Logical Proces-

sors in an MP System”). Once logical processors have APIC IDs, software communicates with them by sending APIC

IPI messages.

9.6.2

Initializing Multi-Core Processors

The initialization process for an MP system that contains multi-core Intel 64 or IA-32 processors is the same as for

conventional MP systems (see Section 9.4, “Multiple-Processor (MP) Initialization”). A logical processor in one core

is selected as the BSP; other logical processors are designated as APs.

During initialization, each logical processor is assigned an APIC ID. Once logical processors have APIC IDs, software

may communicate with them by sending APIC IPI messages.

1. Operating system and BIOS may implement features that reduce the number of logical processors available in a platform to applica-

tions at runtime to less than the number of physical packages times the number of hardware-capable logical processors per package.

1. Software must check CPUID for its support of leaf 4 when implementing support for multi-core. If CPUID leaf 4 is not available at run-

time, software should handle the situation as if there is only one core per package.

2. Maximum number of cores in the physical package must be queried by executing CPUID with EAX=4 and a valid ECX input value.

Valid ECX input values start from 0.

9-26

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

9.6.3

Executing Multiple Threads on an Intel® 64 or IA-32 Processor Supporting Hardware

Multi-Threading

Upon completing the operating system boot-up procedure, the bootstrap processor (BSP) executes operating

system code. Other logical processors are placed in the halt state. To execute a code stream (thread) on a halted

logical processor, the operating system issues an interprocessor interrupt (IPI) addressed to the halted logical

processor. In response to the IPI, the processor wakes up and begins executing the code identified by the vector

received as part of the IPI.

To manage execution of multiple threads on logical processors, an operating system can use conventional

symmetric multiprocessing (SMP) techniques. For example, the operating-system can use a time-slice or load

balancing mechanism to periodically interrupt each of the active logical processors. Upon interrupting a logical

processor, the operating system checks its run queue for a thread waiting to be executed and dispatches the thread

to the interrupted logical processor.

9.6.4

Handling Interrupts on an IA-32 Processor Supporting Hardware Multi-Threading

Interrupts are handled on processors supporting Intel Hyper-Threading Technology as they are on conventional MP

systems. External interrupts are received by the I/O APIC, which distributes them as interrupt messages to specific

logical processors (see Figure 9-3).

Logical processors can also send IPIs to other logical processors by writing to the ICR register of its local APIC (see

Section 11.6, “Issuing Interprocessor Interrupts”). This also applies to dual-core processors.

Intel Processor with Intel

Hyper-Threading Technology

Logical

Processor 0

Processor 1

Processor 0

Processor 1

Processor Core

Local APIC

Bus Interface

Interrupt

IPIs

Messages

Interrupt Messages

Bridge

PCI

I/O APIC

External

Interrupts

System Chipset

Figure 9-3. Local APICs and I/O APIC in MP System Supporting Intel HT Technology

9.7

INTEL® HYPER-THREADING TECHNOLOGY ARCHITECTURE

Figure 9-4 shows a generalized view of an Intel processor supporting Intel Hyper-Threading Technology, using the

original Intel Xeon processor MP as an example. This implementation of the Intel Hyper-Threading Technology

Vol. 3A

9-27

MULTIPLE-PROCESSOR MANAGEMENT

consists of two logical processors (each represented by a separate architectural state) which share the processor’s

execution engine and the bus interface. Each logical processor also has its own advanced programmable interrupt

controller (APIC).

Logical

Processor 0

Processor 1

Architectural

State

Execution Engine

Local

APIC

Local APIC

Bus Interface

System Bus

Figure 9-4. IA-32 Processor with Two Logical Processors Supporting Intel HT Technology

9.7.1

State of the Logical Processors

The following features are part of the architectural state of logical processors within Intel 64 or IA-32 processors

supporting Intel Hyper-Threading Technology. The features can be subdivided into three groups:

• Duplicated for each logical processor

• Shared by logical processors in a physical processor

• Shared or duplicated, depending on the implementation

The following features are duplicated for each logical processor:

• General purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, and EBP)

• Segment registers (CS, DS, SS, ES, FS, and GS)

• EFLAGS and EIP registers. Note that the CS and EIP/RIP registers for each logical processor point to the

instruction stream for the thread being executed by the logical processor.

• x87 FPU registers (ST0 through ST7, status word, control word, tag word, data operand pointer, and instruction

pointer)

• MMX registers (MM0 through MM7)

• XMM registers (XMM0 through XMM7) and the MXCSR register

• Control registers and system table pointer registers (GDTR, LDTR, IDTR, task register)

• Debug registers (DR0, DR1, DR2, DR3, DR6, DR7) and the debug control MSRs

• Machine check global status (IA32_MCG_STATUS) and machine check capability (IA32_MCG_CAP) MSRs

• Thermal clock modulation and ACPI Power management control MSRs

• Time stamp counter MSRs

• Most of the other MSR registers, including the page attribute table (PAT). See the exceptions below.

• Local APIC registers.

• Additional general purpose registers (R8-R15), XMM registers (XMM8-XMM15), control register, IA32_EFER on

Intel 64 processors.

The following features are shared by logical processors:

9-28

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

• Memory type range registers (MTRRs)

Whether the following features are shared or duplicated is implementation-specific:

• IA32_MISC_ENABLE MSR (MSR address 1A0H)

• Machine check architecture (MCA) MSRs (except for the IA32_MCG_STATUS and IA32_MCG_CAP MSRs)

• Performance monitoring control and counter MSRs

9.7.2

APIC Functionality

When a processor supporting Intel Hyper-Threading Technology support is initialized, each logical processor is

assigned a local APIC ID (see Table 11-1). The local APIC ID serves as an ID for the logical processor and is stored

in the logical processor’s APIC ID register. If two or more processors supporting Intel Hyper-Threading Technology

are present in a dual processor (DP) or MP system, each logical processor on the system bus is assigned a unique

local APIC ID (see Section 9.9.3, “Hierarchical ID of Logical Processors in an MP System”).

Software communicates with local processors using the APIC’s interprocessor interrupt (IPI) messaging facility.

Setup and programming for APICs is identical in processors that support and do not support Intel Hyper-Threading

Technology. See Chapter 11, “Advanced Programmable Interrupt Controller (APIC),” for a detailed discussion.

9.7.3

Memory Type Range Registers (MTRR)

MTRRs in a processor supporting Intel Hyper-Threading Technology are shared by logical processors. When one

logical processor updates the setting of the MTRRs, settings are automatically shared with the other logical proces-

sors in the same physical package.

The architectures require that all MP systems based on Intel 64 and IA-32 processors (this includes logical proces-

sors) must use an identical MTRR memory map. This gives software a consistent view of memory, independent of

the processor on which it is running. See Section 12.11, “Memory Type Range Registers (MTRRs),” for information

on setting up MTRRs.

9.7.4

Page Attribute Table (PAT)

Each logical processor has its own PAT MSR (IA32_PAT). However, as described in Section 12.12, “Page Attribute

Table (PAT),” the PAT MSR settings must be the same for all processors in a system, including the logical proces-

sors.

9.7.5

Machine Check Architecture

In the Intel HT Technology context as implemented by processors based on Intel NetBurst^® microarchitecture, all

of the machine check architecture (MCA) MSRs (except for the IA32_MCG_STATUS and IA32_MCG_CAP MSRs) are

duplicated for each logical processor. This permits logical processors to initialize, configure, query, and handle

machine-check exceptions simultaneously within the same physical processor. The design is compatible with

machine check exception handlers that follow the guidelines given in Chapter 16, “Machine-Check Architecture.”

The IA32_MCG_STATUS MSR is duplicated for each logical processor so that its machine check in progress bit field

(MCIP) can be used to detect recursion on the part of MCA handlers. In addition, the MSR allows each logical

processor to determine that a machine-check exception is in progress independent of the actions of another logical

processor in the same physical package.

Because the logical processors within a physical package are tightly coupled with respect to shared hardware

resources, both logical processors are notified of machine check errors that occur within a given physical processor.

If machine-check exceptions are enabled when a fatal error is reported, all the logical processors within a physical

package are dispatched to the machine-check exception handler. If machine-check exceptions are disabled, the

logical processors enter the shutdown state and assert the IERR# signal.

When enabling machine-check exceptions, the MCE flag in control register CR4 should be set for each logical

processor.

Vol. 3A

9-29

MULTIPLE-PROCESSOR MANAGEMENT

On Intel Atom family processors that support Intel Hyper-Threading Technology, the MCA facilities are shared

between all logical processors on the same processor core.

9.7.6

Debug Registers and Extensions

Each logical processor has its own set of debug registers (DR0, DR1, DR2, DR3, DR6, DR7) and its own debug

control MSR. These can be set to control and record debug information for each logical processor independently.

Each logical processor also has its own last branch records (LBR) stack.

9.7.7

Performance Monitoring Counters

Performance counters and their companion control MSRs are shared between the logical processors within a

processor core for processors based on Intel NetBurst microarchitecture. As a result, software must manage the

use of these resources. The performance counter interrupts, events, and precise event monitoring support can be

set up and allocated on a per thread (per logical processor) basis.

See Section 20.6.4, “Performance Monitoring and Intel® Hyper-Threading Technology in Processors Based on Intel

NetBurst® Microarchitecture,” for a discussion of performance monitoring in the Intel Xeon processor MP.

In Intel Atom processor family that support Intel Hyper-Threading Technology, the performance counters (general-

purpose and fixed-function counters) and their companion control MSRs are duplicated for each logical processor.

9.7.8

IA32_MISC_ENABLE MSR

The IA32_MISC_ENABLE MSR (MSR address 1A0H) is generally shared between the logical processors in a

processor core supporting Intel Hyper-Threading Technology. However, some bit fields within IA32_MISC_ENABLE

MSR may be duplicated per logical processor. The partition of shared or duplicated bit fields within IA32_MISC_EN-

ABLE is implementation dependent. Software should program duplicated fields carefully on all logical processors in

the system to ensure consistent behavior.

9.7.9

Memory Ordering

The logical processors in an Intel 64 or IA-32 processor supporting Intel Hyper-Threading Technology obey the

same rules for memory ordering as Intel 64 or IA-32 processors without Intel HT Technology (see Section 9.2,

“Memory Ordering”). Each logical processor uses a processor-ordered memory model that can be further defined

as “write-ordered with store buffer forwarding.” All mechanisms for strengthening or weakening the memory-

ordering model to handle special programming situations apply to each logical processor.

9.7.10 Serializing Instructions

As a general rule, when a logical processor in a processor supporting Intel Hyper-Threading Technology executes a

serializing instruction, only that logical processor is affected by the operation. An exception to this rule is the execu-

tion of the WBINVD, INVD, and WRMSR instructions; and the MOV CR instruction when the state of the CD flag in

control register CR0 is modified. Here, both logical processors are serialized.

9.7.11 Microcode Update Resources

In an Intel processor supporting Intel Hyper-Threading Technology, the microcode update facilities are shared

between the logical processors; either logical processor can initiate an update. Each logical processor has its own

BIOS signature MSR (IA32_BIOS_SIGN_ID at MSR address 8BH). When a logical processor performs an update for

the physical processor, the IA32_BIOS_SIGN_ID MSRs for resident logical processors are updated with identical

information. If logical processors initiate an update simultaneously, the processor core provides the necessary

synchronization needed to ensure that only one update is performed at a time.

9-30

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

NOTE

Some processors (prior to the introduction of Intel 64 Architecture and based on Intel NetBurst

microarchitecture) do not support simultaneous loading of microcode update to the sibling logical

processors in the same core. All other processors support logical processors initiating an update

simultaneously. Intel recommends a common approach that the microcode loader use the

sequential technique described in Section 10.11.6.3.

9.7.12 Self Modifying Code

Intel processors supporting Intel Hyper-Threading Technology support self-modifying code, where data writes

modify instructions cached or currently in flight. They also support cross-modifying code, where on an MP system

writes generated by one processor modify instructions cached or currently in flight on another. See Section 9.1.3,

“Handling Self- and Cross-Modifying Code,” for a description of the requirements for self- and cross-modifying code

in an IA-32 processor.

9.7.13 Implementation-Specific Intel® HT Technology Facilities

The following non-architectural facilities are implementation-specific in IA-32 processors supporting Intel Hyper-

Threading Technology:

• Caches.

• Translation lookaside buffers (TLBs).

• Thermal monitoring facilities.

The Intel Xeon processor MP implementation is described in the following sections.

9.7.13.1 Processor Caches

For processors supporting Intel Hyper-Threading Technology, the caches are shared. Any cache manipulation

instruction that is executed on one logical processor has a global effect on the cache hierarchy of the physical

processor. Note the following:

• WBINVD instruction - The entire cache hierarchy is invalidated after modified data is written back to

memory. All logical processors are stopped from executing until after the write-back and invalidate operation is

completed. A special bus cycle is sent to all caching agents. The amount of time or cycles for WBINVD to

complete will vary due to the size of different cache hierarchies and other factors. As a consequence, the use of

the WBINVD instruction can have an impact on interrupt/event response time.

• INVD instruction - The entire cache hierarchy is invalidated without writing back modified data to memory.

All logical processors are stopped from executing until after the invalidate operation is completed. A special bus

cycle is sent to all caching agents.

• CLFLUSH and CLFLUSHOPT instructions - The specified cache line is invalidated from the cache hierarchy

after any modified data is written back to memory and a bus cycle is sent to all caching agents, regardless of

which logical processor caused the cache line to be filled.

• CD flag in control register CR0 - Each logical processor has its own CR0 control register, and thus its own

CD flag in CR0. The CD flags for the two logical processors are ORed together, such that when any logical

processor sets its CD flag, the entire cache is nominally disabled.

9.7.13.2 Processor Translation Lookaside Buffers (TLBs)

In processors supporting Intel Hyper-Threading Technology, data cache TLBs are shared. The instruction cache TLB

may be duplicated or shared in each logical processor, depending on implementation specifics of different

processor families.

Entries in the TLBs are tagged with an ID that indicates the logical processor that initiated the translation. This tag

applies even for translations that are marked global using the page-global feature for memory paging. See Section

4.10, “Caching Translation Information,” for information about global translations.

Vol. 3A

9-31

MULTIPLE-PROCESSOR MANAGEMENT

When a logical processor performs a TLB invalidation operation, only the TLB entries that are tagged for that logical

processor are guaranteed to be flushed. This protocol applies to all TLB invalidation operations, including writes to

control registers CR3 and CR4 and uses of the INVLPG instruction.

9.7.13.3 Thermal Monitor

In a processor that supports Intel Hyper-Threading Technology, logical processors share the catastrophic shutdown

detector and the automatic thermal monitoring mechanism (see Section 15.8, “Thermal Monitoring and Protec-

tion”). Sharing results in the following behavior:

• If the processor’s core temperature rises above the preset catastrophic shutdown temperature, the processor

core halts execution, which causes both logical processors to stop execution.

• When the processor’s core temperature rises above the preset automatic thermal monitor trip temperature, the

frequency of the processor core is automatically modulated, which effects the execution speed of both logical

processors.

For software controlled clock modulation, each logical processor has its own IA32_CLOCK_MODULATION MSR,

allowing clock modulation to be enabled or disabled on a logical processor basis. Typically, if software controlled

clock modulation is going to be used, the feature must be enabled for all the logical processors within a physical

processor and the modulation duty cycle must be set to the same value for each logical processor. If the duty cycle

values differ between the logical processors, the processor clock will be modulated at the highest duty cycle

selected.

9.7.13.4 External Signal Compatibility

This section describes the constraints on external signals received through the pins of a processor supporting Intel

Hyper-Threading Technology and how these signals are shared between its logical processors.

• STPCLK# - A single STPCLK# pin is provided on the physical package of the Intel Xeon processor MP. External

control logic uses this pin for power management within the system. When the STPCLK# signal is asserted, the

processor core transitions to the stop-grant state, where instruction execution is halted but the processor core

continues to respond to snoop transactions. Regardless of whether the logical processors are active or halted

when the STPCLK# signal is asserted, execution is stopped on both logical processors and neither will respond

to interrupts.

In MP systems, the STPCLK# pins on all physical processors are generally tied together. As a result this signal

affects all the logical processors within the system simultaneously.

• LINT0 and LINT1 pins - A processor supporting Intel Hyper-Threading Technology has only one set of LINT0

and LINT1 pins, which are shared between the logical processors. When one of these pins is asserted, both

logical processors respond unless the pin has been masked in the APIC local vector tables for one or both of the

logical processors.

Typically in MP systems, the LINT0 and LINT1 pins are not used to deliver interrupts to the logical processors.

Instead all interrupts are delivered to the local processors through the I/O APIC.

• A20M# pin - On an IA-32 processor, the A20M# pin is typically provided for compatibility with the Intel 286

processor. Asserting this pin causes bit 20 of the physical address to be masked (forced to zero) for all external

bus memory accesses. Processors supporting Intel Hyper-Threading Technology provide one A20M# pin, which

affects the operation of both logical processors within the physical processor.

The functionality of A20M# is used primarily by older operating systems and not used by modern operating

systems. On newer Intel 64 processors, A20M# may be absent.

9.8

MULTI-CORE ARCHITECTURE

This section describes the architecture of Intel 64 and IA-32 processors supporting dual-core and quad-core tech-

nology. The discussion is applicable to the Intel Pentium processor Extreme Edition, Pentium D, Intel Core Duo,

Intel Core 2 Duo, Dual-core Intel Xeon processor, Intel Core 2 Quad processors, and quad-core Intel Xeon proces-

sors. Features vary across different microarchitectures and are detectable using CPUID.

9-32

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

In general, each processor core has dedicated microarchitectural resources identical to a single-processor imple-

mentation of the underlying microarchitecture without hardware multi-threading capability. Each logical processor

in a dual-core processor (whether supporting Intel Hyper-Threading Technology or not) has its own APIC function-

ality, PAT, machine check architecture, debug registers and extensions. Each logical processor handles serialization

instructions or self-modifying code on its own. Memory order is handled the same way as in Intel Hyper-Threading

Technology.

The topology of the cache hierarchy (with respect to whether a given cache level is shared by one or more

processor cores or by all logical processors in the physical package) depends on the processor implementation.

Software must use the deterministic cache parameter leaf of CPUID instruction to discover the cache-sharing

topology between the logical processors in a multi-threading environment.

9.8.1

Logical Processor Support

The topological composition of processor cores and logical processors in a multi-core processor can be discovered

using CPUID. Within each processor core, one or more logical processors may be available.

System software must follow the requirement MP initialization sequences (see Section 9.4, “Multiple-Processor

(MP) Initialization”) to recognize and enable logical processors. At runtime, software can enumerate those logical

processors enabled by system software to identify the topological relationships between these logical processors.

(See Section 9.9.5, “Identifying Topological Relationships in an MP System”).

9.8.2

Memory Type Range Registers (MTRR)

MTRR is shared between two logical processors sharing a processor core if the physical processor supports Intel

Hyper-Threading Technology. MTRR is not shared between logical processors located in different cores or different

physical packages.

The Intel 64 and IA-32 architectures require that all logical processors in an MP system use an identical MTRR

memory map. This gives software a consistent view of memory, independent of the processor on which it is

running.

See Section 12.11, “Memory Type Range Registers (MTRRs).”

9.8.3

Performance Monitoring Counters

Performance counters and their companion control MSRs are shared between two logical processors sharing a

processor core if the processor core supports Intel Hyper-Threading Technology and is based on Intel NetBurst

microarchitecture. They are not shared between logical processors in different cores or different physical packages.

As a result, software must manage the use of these resources, based on the topology of performance monitoring

resources. Performance counter interrupts, events, and precise event monitoring support can be set up and allo-

cated on a per thread (per logical processor) basis.

See Section 20.6.4, “Performance Monitoring and Intel® Hyper-Threading Technology in Processors Based on Intel

NetBurst® Microarchitecture.”

9.8.4

IA32_MISC_ENABLE MSR

Some bit fields in IA32_MISC_ENABLE MSR (MSR address 1A0H) may be shared between two logical processors

sharing a processor core, or may be shared between different cores in a physical processor. See Chapter 2, “Model-

Specific Registers (MSRs)‚” in the Intel^® 64 and IA-32 Architectures Software Developer’s Manual, Volume 4.

9.8.5

Microcode Update Resources

Microcode update facilities are shared between two logical processors sharing a processor core if the physical

package supports Intel Hyper-Threading Technology. They are not shared between logical processors in different

Vol. 3A

9-33

MULTIPLE-PROCESSOR MANAGEMENT

cores or different physical packages. Either logical processor that has access to the microcode update facility can

initiate an update.

Each logical processor has its own BIOS signature MSR (IA32_BIOS_SIGN_ID at MSR address 8BH). When a logical

processor performs an update for the physical processor, the IA32_BIOS_SIGN_ID MSRs for resident logical

processors are updated with identical information.

All microcode update steps during processor initialization should use the same update data on all cores in all phys-

ical packages of the same stepping. Any subsequent microcode update must apply consistent update data to all

cores in all physical packages of the same stepping. If the processor detects an attempt to load an older microcode

update when a newer microcode update had previously been loaded, it may reject the older update to stay with the

newer update.

NOTE

Some processors (prior to the introduction of Intel 64 Architecture and based on Intel NetBurst

microarchitecture) do not support simultaneous loading of microcode update to the sibling logical

processors in the same core. All other processors support logical processors initiating an update

simultaneously. Intel recommends a common approach that the microcode loader use the

sequential technique described in Section 10.11.6.3.

9.9

PROGRAMMING CONSIDERATIONS FOR HARDWARE MULTI-THREADING

CAPABLE PROCESSORS

In a multi-threading environment, there may be certain hardware resources that are physically shared at some

level of the hardware topology. In the multi-processor systems, typically bus and memory sub-systems are physi-

cally shared between multiple sockets. Within a hardware multi-threading capable processors, certain resources

are provided for each processor core, while other resources may be provided for each logical processors (see

Section 9.7, “Intel® Hyper-Threading Technology Architecture,” and Section 9.8, “Multi-Core Architecture”).

From a software programming perspective, control transfer of processor operation is managed at the granularity of

logical processor (operating systems dispatch a runnable task by allocating an available logical processor on the

platform). To manage the topology of shared resources in a multi-threading environment, it may be useful for soft-

ware to understand and manage resources that are shared by more than one logical processors.

9.9.1

Hierarchical Mapping of Shared Resources

The APIC_ID value associated with each logical processor in a multi-processor system is unique (see Section 9.6,

“Detecting Hardware Multi-Threading Support and Topology”). This 8-bit or 32-bit value can be decomposed into

sub-fields, where each sub-field corresponds a hierarchical domain of the topological mapping of hardware

resources.

The decomposition of an APIC_ID may consist of several sub fields representing the topology within a physical

processor package, the higher-order bits of an APIC ID may also be used by cluster vendors to represent the

topology of cluster nodes of each coherent multiprocessor systems:

• Cluster - Some multi-threading environments consists of multiple clusters of multi-processor systems. The

CLUSTER_ID sub-field is usually supported by vendor firmware to distinguish different clusters. For non-

clustered systems, CLUSTER_ID is usually 0 and system topology is reduced.

• Package - A physical processor package mates with a socket. A package may contain one or more software

visible die. The PACKAGE_ID sub-field distinguishes different physical packages within a cluster.

• Die - A software-visible chip inside a package. The DIE_ID sub-field distinguishes different die within a

package. If there are no software visible die, the width of this bit field is 0.

• DieGrp - A group of die that share certain resources.

• Tile - A set of cores that share certain resources. The TILE_ID sub-field distinguishes different tiles. If there

are no software visible tiles, the width of this bit field is 0.

9-34

Vol. 3A

MULTIPLE-PROCESSOR MANAGEMENT

• Module - A set of cores that share certain resources. The MODULE_ID sub-field distinguishes different

modules. If there are no software visible modules, the width of this bit field is 0.

• Core - Processor cores may be contained within modules, within tiles, on software-visible die, or appear

directly at the package domain. The CORE_ID sub-field distinguishes processor cores. For a single-core

processor, the width of this bit field is 0.

• Logical Processor - A processor core provides one or more logical processors sharing execution resources.

The LOGICAL_PROCESSOR_ID sub-field distinguishes logical processors in a core. The width of this bit field is

non-zero if a processor core provides more than one logical processors.

The LOGICAL_PROCESSOR_ID and CORE_ID sub-fields are bit-wise contiguous in the APIC_ID field (see

Figure 9-5).

Reserved

CLUSTER_ID

PACKAGE_ID

DIE_ID

TILE_ID

MODULE_ID

CORE_ID

LOGICAL_PROCESSOR_ID

X=31 if x2APIC is supported, otherwise X= 7

Figure 9-5. Generalized Seven-Domain Interpretation of the APIC ID

If the processor supports CPUID leaf 0BH and leaf 1FH, the 32-bit APIC ID can represent cluster plus several

domains of topology within the physical processor package. The exact number of hierarchical domains within a

physical processor package must be enumerated through CPUID leaf 0BH and leaf 1FH. Common processor fami-

lies may employ a topology similar to that represented by the 8-bit Initial APIC ID. In general, CPUID leaf 0BH and

leaf 1FH can support a topology enumeration algorithm that decompose a 32-bit APIC ID into more than four sub-

fields (see Figure 9-6).

NOTE

CPUID leaf 0BH and leaf 1FH can have differences in the number of domain types reported (CPUID

leaf 1FH defines additional domain types). If the processor supports CPUID leaf 1FH, usage of this

leaf is preferred over leaf 0BH. CPUID leaf 0BH is available for legacy compatibility going forward.

The width of each sub-field depends on hardware and software configurations. Field widths can be determined at

runtime using the algorithm discussed below (Example 9-16 through Example 9-21).

Figure 7-6 depicts the relationships of three of the hierarchical sub-fields in a hypothetical MP system. The value of

valid APIC_IDs need not be contiguous across package boundary or core boundaries.

Vol. 3A

9-35

MULTIPLE-PROCESSOR MANAGEMENT

PACKAGE

CORE

Reserved

LOGICAL

PROCESSOR

CLUSTER_ID

PACKAGE_ID

Q_ID

R_ID

CORE_ID

Physical Processor Topology

LOGICAL_PROCESSOR_ID

32-bit APIC ID Composition

Figure 9-6. Conceptual Six-Domain Topology and 32-bit APIC ID Composition

9.9.2

Hierarchical Mapping of CPUID Extended Topology Leaf

CPUID leaf 0BH and leaf 1FH provide enumeration parameters for software to identify each hierarchy of the

processor topology in a deterministic manner. Each hierarchical domain of the topology starting from the Logical

Processor domain is represented numerically by a sub-leaf index within the CPUID 0BH leaf and 1FH leaf. Each

domain of the topology is mapped to a sub-field in the APIC ID, following the general relationship depicted in

Figure 9-6. This mechanism allows software to query the exact number of domains within a physical processor

package and the bit-width of each sub-field of x2APIC ID directly. For example,

• Starting from sub-leaf index 0 and incrementing ECX until CPUID.(EAX=0BH or 1FH, ECX=N):ECX[15:8]

returns an invalid “domain type” encoding. The number of domains within the physical processor package is “N”

(excluding PACKAGE). Using Figure 9-6 as an example, CPUID.(EAX=0BH or 1FH, ECX=4):ECX[15:8] will

report 00H, indicating sub leaf 04H is invalid. This is also depicted by a pseudo code example:

Example 9-16. Number of Domains Below the Physical Processor Package

Word NumberOfDomainsBelowPackage = 0;

DWord Subleaf = 0;

EAX = 0BH or 1FH; // query each sub leaf of CPUID leaf 0BH or 1FH; CPUID leaf 1FH is preferred over leaf 0BH if available.

ECX = Subleaf;

CPUID;

while(EBX != 0) // Enumerate until EBX reports 0

{

if(EAX[4:0] != 0)

// A Shift Value of 0 indicates this domain does not exist.

// (Such as no SMT_ID, which is required entry at sub-leaf 0.)

{

NumberOfDomainsBelowPackage++;

}

Subleaf++;

EAX = 0BH or 1FH;

ECX = Subleaf;

CPUID;

}

// NumberOfDomainsBelowPackage contains the absolute number of domains that exist below package.

N = Subleaf;

// Sub-leaf supplies the number of entries CPUID will return.

9-36

Vol. 3A

Intel 64 and IA-32 Architectures. Software Developer’s Manual (Collection, 2023) - page 48
