Intel 64 and IA-32 Architectures. Software Developer’s Manual (Collection, 2023) - page 18





INSTRUCTION SET REFERENCE, A-L
AESENCWIDE128KL-Perform Ten Rounds of AES Encryption Flow With Key Locker on 8 Blocks
Using 128-Bit Key
Opcode/
Op/
64/32-bit
CPUID Feature
Description
Instruction
En
Mode
Flag
F3 0F 38 D8 !(11):000:bbb
A
V/V
AESKLE WIDE_KL
Encrypt XMM0-7 using 128-bit AES key indicated
AESENCWIDE128KL m384, <XMM0-7>
by handle at m384 and store each resultant block
back to its corresponding register.
Instruction Operand Encoding
Op/En
Tuple
Operand 1
Operands 2-9
A
N/A
ModRM:r/m (r)
Implicit XMM0-7 (r, w)
Description
The AESENCWIDE128KL1 instruction performs ten rounds of AES to encrypt each of the eight blocks in XMM0-7
using the 128-bit key indicated by the handle from the second operand. It replaces each input block in XMM0-7
with its corresponding encrypted block if the operation succeeds (e.g., does not run into a handle violation failure).
Operation
AESENCWIDE128KL
Handle := UnalignedLoad of 384 bit (SRC);
// Load is not guaranteed to be atomic.
Illegal Handle = (
HandleReservedBitSet (Handle) ||
(Handle[0] AND (CPL > 0)) ||
Handle [1] ||
HandleKeyType (Handle) != HANDLE_KEY_TYPE_AES128
);
IF (Illegal Handle)
THEN RFLAGS.ZF := 1;
ELSE
(UnwrappedKey, Authentic) := UnwrapKeyAndAuthenticate384 (Handle[383:0], IWKey);
IF Authentic == 0
THEN RFLAGS.ZF := 1;
ELSE
XMM0 := AES128Encrypt (XMM0, UnwrappedKey) ;
XMM1 := AES128Encrypt (XMM1, UnwrappedKey) ;
XMM2 := AES128Encrypt (XMM2, UnwrappedKey) ;
XMM3 := AES128Encrypt (XMM3, UnwrappedKey) ;
XMM4 := AES128Encrypt (XMM4, UnwrappedKey) ;
XMM5 := AES128Encrypt (XMM5, UnwrappedKey) ;
XMM6 := AES128Encrypt (XMM6, UnwrappedKey) ;
XMM7 := AES128Encrypt (XMM7, UnwrappedKey) ;
RFLAGS.ZF := 0;
FI;
FI;
RFLAGS.OF, SF, AF, PF, CF := 0;
1. Further details on Key Locker and usage of this instruction can be found here:
AESENCWIDE128KL-Perform Ten Rounds of AES Encryption Flow With Key Locker on 8 Blocks Using 128-Bit Key
Vol. 2A
3-71
INSTRUCTION SET REFERENCE, A-L
Flags Affected
ZF is set to 0 if the operation succeeded and set to 1 if the operation failed due to a handle violation. The other
arithmetic flags (OF, SF, AF, PF, CF) are cleared to 0.
Intel C/C++ Compiler Intrinsic Equivalent
AESENCWIDE128KLunsigned char _mm_aesencwide128kl_u8(__m128i odata[8], const __m128i idata[8], const void* h);
Exceptions (All Operating Modes)
#UD
If the LOCK prefix is used.
If CPUID.07H:ECX.KL [bit 23] = 0.
If CR4.KL = 0.
If CPUID.AESKLE = 0.
If CR0.EM = 1.
If CR4.OSFXSR = 0.
If CPUID.19H:EBX.WIDE_KL [bit 2] = 0.
#NM
If CR0.TS = 1.
#PF
If a page fault occurs.
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the DS, ES, FS, or GS register is used to access memory and it contains a NULL segment
selector.
If the memory address is in a non-canonical form.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
If a memory address referencing the SS segment is in a non-canonical form.
3-72
Vol. 2A
AESENCWIDE128KL-Perform Ten Rounds of AES Encryption Flow With Key Locker on 8 Blocks Using 128-Bit Key
INSTRUCTION SET REFERENCE, A-L
AESENCWIDE256KL-Perform 14 Rounds of AES Encryption Flow With Key Locker on 8 Blocks
Using 256-Bit Key
Opcode/
Op/
64/32-bit
CPUID Feature
Description
Instruction
En
Mode
Flag
F3 0F 38 D8 !(11):010:bbb
A
V/V
AESKLE WIDE_KL
Encrypt XMM0-7 using 256-bit AES key indicated
AESENCWIDE256KL m512, <XMM0-7>
by handle at m512 and store each resultant block
back to its corresponding register.
Instruction Operand Encoding
Op/En
Tuple
Operand 1
Operands 2-9
A
N/A
ModRM:r/m (r)
Implicit XMM0-7 (r, w)
Description
The AESENCWIDE256KL1 instruction performs 14 rounds of AES to encrypt each of the eight blocks in XMM0-7
using the 256-bit key indicated by the handle from the second operand. It replaces each input block in XMM0-7
with its corresponding encrypted block if the operation succeeds (e.g., does not run into a handle violation failure).
Operation
AESENCWIDE256KL
Handle := UnalignedLoad of 512 bit (SRC);
// Load is not guaranteed to be atomic.
Illegal Handle = (
HandleReservedBitSet (Handle) ||
(Handle[0] AND (CPL > 0)) ||
Handle [1] ||
HandleKeyType (Handle) != HANDLE_KEY_TYPE_AES256
);
IF (Illegal Handle)
THEN RFLAGS.ZF := 1;
ELSE
(UnwrappedKey, Authentic) := UnwrapKeyAndAuthenticate512 (Handle[511:0], IWKey);
IF (Authentic == 0)
THEN RFLAGS.ZF := 1;
ELSE
XMM0 := AES256Encrypt (XMM0, UnwrappedKey) ;
XMM1 := AES256Encrypt (XMM1, UnwrappedKey) ;
XMM2 := AES256Encrypt (XMM2, UnwrappedKey) ;
XMM3 := AES256Encrypt (XMM3, UnwrappedKey) ;
XMM4 := AES256Encrypt (XMM4, UnwrappedKey) ;
XMM5 := AES256Encrypt (XMM5, UnwrappedKey) ;
XMM6 := AES256Encrypt (XMM6, UnwrappedKey) ;
XMM7 := AES256Encrypt (XMM7, UnwrappedKey) ;
RFLAGS.ZF := 0;
FI;
FI;
RFLAGS.OF, SF, AF, PF, CF := 0;
1. Further details on Key Locker and usage of this instruction can be found here:
AESENCWIDE256KL-Perform 14 Rounds of AES Encryption Flow With Key Locker on 8 Blocks Using 256-Bit Key
Vol. 2A
3-73
INSTRUCTION SET REFERENCE, A-L
Flags Affected
ZF is set to 0 if the operation succeeded and set to 1 if the operation failed due to a handle violation. The other
arithmetic flags (OF, SF, AF, PF, CF) are cleared to 0.
Intel C/C++ Compiler Intrinsic Equivalent
AESENCWIDE256KLunsigned char _mm_aesencwide256kl_u8(__m128i odata[8], const __m128i idata[8], const void* h);
Exceptions (All Operating Modes)
#UD
If the LOCK prefix is used.
If CPUID.07H:ECX.KL [bit 23] = 0.
If CR4.KL = 0.
If CPUID.19H:EBX.AESKLE [bit 0] = 0.
If CR0.EM = 1.
If CR4.OSFXSR = 0.
If CPUID.19H:EBX.WIDE_KL [bit 2] = 0.
#NM
If CR0.TS = 1.
#PF
If a page fault occurs.
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the DS, ES, FS, or GS register is used to access memory and it contains a NULL segment
selector.
If the memory address is in a non-canonical form.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
If a memory address referencing the SS segment is in a non-canonical form.
3-74
Vol. 2A
AESENCWIDE256KL-Perform 14 Rounds of AES Encryption Flow With Key Locker on 8 Blocks Using 256-Bit Key
INSTRUCTION SET REFERENCE, A-L
AESIMC-Perform the AES InvMixColumn Transformation
Opcode/
Op/
64/32-bit
CPUID
Description
Instruction
En
Mode
Feature
Flag
66 0F 38 DB /r
RM
V/V
AES
Perform the InvMixColumn transformation on
AESIMC xmm1, xmm2/m128
a 128-bit round key from xmm2/m128 and
store the result in xmm1.
VEX.128.66.0F38.WIG DB /r
RM
V/V
Both AES
Perform the InvMixColumn transformation on
VAESIMC xmm1, xmm2/m128
and
a 128-bit round key from xmm2/m128 and
AVX flags
store the result in xmm1.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (w)
ModRM:r/m (r)
N/A
N/A
Description
Perform the InvMixColumns transformation on the source operand and store the result in the destination operand.
The destination operand is an XMM register. The source operand can be an XMM register or a 128-bit memory loca-
tion.
Note: the AESIMC instruction should be applied to the expanded AES round keys (except for the first and last round
key) in order to prepare them for decryption using the “Equivalent Inverse Cipher” (defined in FIPS 197).
128-bit Legacy SSE version: Bits (MAXVL-1:128) of the corresponding YMM destination register remain
unchanged.
VEX.128 encoded version: Bits (MAXVL-1:128) of the destination YMM register are zeroed.
Note: In VEX-encoded versions, VEX.vvvv is reserved and must be 1111b, otherwise instructions will #UD.
Operation
AESIMC
DEST[127:0] := InvMixColumns( SRC );
DEST[MAXVL-1:128] (Unmodified)
VAESIMC
DEST[127:0] := InvMixColumns( SRC );
DEST[MAXVL-1:128] := 0;
Intel C/C++ Compiler Intrinsic Equivalent
(V)AESIMC __m128i _mm_aesimc (__m128i)
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-21, “Type 4 Class Exception Conditions,” additionally:
#UD
If VEX.vvvv ≠ 1111B.
AESIMC-Perform the AES InvMixColumn Transformation
Vol. 2A
3-75
INSTRUCTION SET REFERENCE, A-L
AESKEYGENASSIST-AES Round Key Generation Assist
Opcode/
Op/
64/32-bit
CPUID
Description
Instruction
En
Mode
Feature
Flag
66 0F 3A DF /r ib
RMI
V/V
AES
Assist in AES round key generation using an 8
AESKEYGENASSIST xmm1, xmm2/m128, imm8
bits Round Constant (RCON) specified in the
immediate byte, operating on 128 bits of data
specified in xmm2/m128 and stores the
result in xmm1.
VEX.128.66.0F3A.WIG DF /r ib
RMI
V/V
Both AES
Assist in AES round key generation using 8
VAESKEYGENASSIST xmm1, xmm2/m128, imm8
and
bits Round Constant (RCON) specified in the
AVX flags
immediate byte, operating on 128 bits of data
specified in xmm2/m128 and stores the
result in xmm1.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RMI
ModRM:reg (w)
ModRM:r/m (r)
imm8
N/A
Description
Assist in expanding the AES cipher key, by computing steps towards generating a round key for encryption, using
128-bit data specified in the source operand and an 8-bit round constant specified as an immediate, store the result
in the destination operand.
The destination operand is an XMM register. The source operand can be an XMM register or a 128-bit memory loca-
tion.
128-bit Legacy SSE version: Bits (MAXVL-1:128) of the corresponding YMM destination register remain unchanged.
VEX.128 encoded version: Bits (MAXVL-1:128) of the destination YMM register are zeroed.
Note: In VEX-encoded versions, VEX.vvvv is reserved and must be 1111b, otherwise instructions will #UD.
Operation
AESKEYGENASSIST
X3[31:0] := SRC [127: 96];
X2[31:0] := SRC [95: 64];
X1[31:0] := SRC [63: 32];
X0[31:0] := SRC [31: 0];
RCON[31:0] := ZeroExtend(imm8[7:0]);
DEST[31:0] := SubWord(X1);
DEST[63:32 ] := RotWord( SubWord(X1) ) XOR RCON;
DEST[95:64] := SubWord(X3);
DEST[127:96] := RotWord( SubWord(X3) ) XOR RCON;
DEST[MAXVL-1:128] (Unmodified)
3-76
Vol. 2A
AESKEYGENASSIST-AES Round Key Generation Assist
INSTRUCTION SET REFERENCE, A-L
VAESKEYGENASSIST
X3[31:0] := SRC [127: 96];
X2[31:0] := SRC [95: 64];
X1[31:0] := SRC [63: 32];
X0[31:0] := SRC [31: 0];
RCON[31:0] := ZeroExtend(imm8[7:0]);
DEST[31:0] := SubWord(X1);
DEST[63:32 ] := RotWord( SubWord(X1) ) XOR RCON;
DEST[95:64] := SubWord(X3);
DEST[127:96] := RotWord( SubWord(X3) ) XOR RCON;
DEST[MAXVL-1:128] := 0;
Intel C/C++ Compiler Intrinsic Equivalent
(V)AESKEYGENASSIST __m128i _mm_aeskeygenassist (__m128i, const int)
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-21, “Type 4 Class Exception Conditions,” additionally:
#UD
If VEX.vvvv ≠ 1111B.
AESKEYGENASSIST-AES Round Key Generation Assist
Vol. 2A
3-77
INSTRUCTION SET REFERENCE, A-L
AND-Logical AND
Opcode
Instruction
Op/
64-bit
Compat/
Description
En
Mode
Leg Mode
24 ib
AND AL, imm8
I
Valid
Valid
AL AND imm8.
25 iw
AND AX, imm16
I
Valid
Valid
AX AND imm16.
25 id
AND EAX, imm32
I
Valid
Valid
EAX AND imm32.
REX.W + 25 id
AND RAX, imm32
I
Valid
N.E.
RAX AND imm32 sign-extended to 64-bits.
80 /4 ib
AND r/m8, imm8
MI
Valid
Valid
r/m8 AND imm8.
REX + 80 /4 ib
AND r/m8*, imm8
MI
Valid
N.E.
r/m8 AND imm8.
81 /4 iw
AND r/m16, imm16
MI
Valid
Valid
r/m16 AND imm16.
81 /4 id
AND r/m32, imm32
MI
Valid
Valid
r/m32 AND imm32.
REX.W + 81 /4 id
AND r/m64, imm32
MI
Valid
N.E.
r/m64 AND imm32 sign extended to 64-bits.
83 /4 ib
AND r/m16, imm8
MI
Valid
Valid
r/m16 AND imm8 (sign-extended).
83 /4 ib
AND r/m32, imm8
MI
Valid
Valid
r/m32 AND imm8 (sign-extended).
REX.W + 83 /4 ib
AND r/m64, imm8
MI
Valid
N.E.
r/m64 AND imm8 (sign-extended).
20 /r
AND r/m8, r8
MR
Valid
Valid
r/m8 AND r8.
REX + 20 /r
AND r/m8*, r8*
MR
Valid
N.E.
r/m64 AND r8 (sign-extended).
21 /r
AND r/m16, r16
MR
Valid
Valid
r/m16 AND r16.
21 /r
AND r/m32, r32
MR
Valid
Valid
r/m32 AND r32.
REX.W + 21 /r
AND r/m64, r64
MR
Valid
N.E.
r/m64 AND r32.
22 /r
AND r8, r/m8
RM
Valid
Valid
r8 AND r/m8.
REX + 22 /r
AND r8*, r/m8*
RM
Valid
N.E.
r/m64 AND r8 (sign-extended).
23 /r
AND r16, r/m16
RM
Valid
Valid
r16 AND r/m16.
23 /r
AND r32, r/m32
RM
Valid
Valid
r32 AND r/m32.
REX.W + 23 /r
AND r64, r/m64
RM
Valid
N.E.
r64 AND r/m64.
NOTES:
*In 64-bit mode, r/m8 can not be encoded to access the following byte registers if a REX prefix is used: AH, BH, CH, DH.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (r, w)
ModRM:r/m (r)
N/A
N/A
MR
ModRM:r/m (r, w)
ModRM:reg (r)
N/A
N/A
MI
ModRM:r/m (r, w)
imm8/16/32
N/A
N/A
I
AL/AX/EAX/RAX
imm8/16/32
N/A
N/A
Description
Performs a bitwise AND operation on the destination (first) and source (second) operands and stores the result in
the destination operand location. The source operand can be an immediate, a register, or a memory location; the
destination operand can be a register or a memory location. (However, two memory operands cannot be used in
one instruction.) Each bit of the result is set to 1 if both corresponding bits of the first and second operands are 1;
otherwise, it is set to 0.
This instruction can be used with a LOCK prefix to allow the it to be executed atomically.
In 64-bit mode, the instruction’s default operation size is 32 bits. Using a REX prefix in the form of REX.R permits
access to additional registers (R8-R15). Using a REX prefix in the form of REX.W promotes operation to 64 bits. See
the summary chart at the beginning of this section for encoding data and limits.
3-78
Vol. 2A
AND-Logical AND
INSTRUCTION SET REFERENCE, A-L
Operation
DEST := DEST AND SRC;
Flags Affected
The OF and CF flags are cleared; the SF, ZF, and PF flags are set according to the result. The state of the AF flag is
undefined.
Protected Mode Exceptions
#GP(0)
If the destination operand points to a non-writable segment.
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the DS, ES, FS, or GS register contains a NULL segment selector.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
#UD
If the LOCK prefix is used but the destination is not a memory operand.
Real-Address Mode Exceptions
#GP
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS
If a memory operand effective address is outside the SS segment limit.
#UD
If the LOCK prefix is used but the destination is not a memory operand.
Virtual-8086 Mode Exceptions
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made.
#UD
If the LOCK prefix is used but the destination is not a memory operand.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#SS(0)
If a memory address referencing the SS segment is in a non-canonical form.
#GP(0)
If the memory address is in a non-canonical form.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
#UD
If the LOCK prefix is used but the destination is not a memory operand.
AND-Logical AND
Vol. 2A
3-79
INSTRUCTION SET REFERENCE, A-L
ANDN-Logical AND NOT
Opcode/Instruction
Op/
64/32-
CPUID
Description
En
bit
Feature
Mode
Flag
VEX.LZ.0F38.W0 F2 /r
RVM
V/V
BMI1
Bitwise AND of inverted r32b with r/m32, store result in r32a.
ANDN r32a, r32b, r/m32
VEX.LZ. 0F38.W1 F2 /r
RVM
V/NE
BMI1
Bitwise AND of inverted r64b with r/m64, store result in r64a.
ANDN r64a, r64b, r/m64
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RVM
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
N/A
Description
Performs a bitwise logical AND of inverted second operand (the first source operand) with the third operand (the
second source operand). The result is stored in the first operand (destination operand).
This instruction is not supported in real mode and virtual-8086 mode. The operand size is always 32 bits if not in
64-bit mode. In 64-bit mode operand size 64 requires VEX.W1. VEX.W1 is ignored in non-64-bit modes. An attempt
to execute this instruction with VEX.L not equal to 0 will cause #UD.
Operation
DEST := (NOT SRC1) bitwiseAND SRC2;
SF := DEST[OperandSize -1];
ZF := (DEST = 0);
Flags Affected
SF and ZF are updated based on result. OF and CF flags are cleared. AF and PF flags are undefined.
Intel C/C++ Compiler Intrinsic Equivalent
Auto-generated from high-level language.
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-29, “Type 13 Class Exception Conditions.”
3-80
Vol. 2A
ANDN-Logical AND NOT
INSTRUCTION SET REFERENCE, A-L
ANDPD-Bitwise Logical AND of Packed Double Precision Floating-Point Values
Opcode/
Op /
64/32 bit
CPUID
Description
Instruction
En
Mode
Feature
Support
Flag
66 0F 54 /r
A
V/V
SSE2
Return the bitwise logical AND of packed double precision
ANDPD xmm1, xmm2/m128
floating-point values in xmm1 and xmm2/mem.
VEX.128.66.0F 54 /r
B
V/V
AVX
Return the bitwise logical AND of packed double precision
VANDPD xmm1, xmm2, xmm3/m128
floating-point values in xmm2 and xmm3/mem.
VEX.256.66.0F 54 /r
B
V/V
AVX
Return the bitwise logical AND of packed double precision
VANDPD ymm1, ymm2, ymm3/m256
floating-point values in ymm2 and ymm3/mem.
EVEX.128.66.0F.W1 54 /r
C
V/V
AVX512VL
Return the bitwise logical AND of packed double precision
VANDPD xmm1 {k1}{z}, xmm2,
AVX512DQ
floating-point values in xmm2 and xmm3/m128/m64bcst
xmm3/m128/m64bcst
subject to writemask k1.
EVEX.256.66.0F.W1 54 /r
C
V/V
AVX512VL
Return the bitwise logical AND of packed double precision
VANDPD ymm1 {k1}{z}, ymm2,
AVX512DQ
floating-point values in ymm2 and ymm3/m256/m64bcst
ymm3/m256/m64bcst
subject to writemask k1.
EVEX.512.66.0F.W1 54 /r
C
V/V
AVX512DQ
Return the bitwise logical AND of packed double precision
VANDPD zmm1 {k1}{z}, zmm2,
floating-point values in zmm2 and zmm3/m512/m64bcst
zmm3/m512/m64bcst
subject to writemask k1.
Instruction Operand Encoding
Op/En
Tuple Type
Operand 1
Operand 2
Operand 3
Operand 4
A
N/A
ModRM:reg (r, w)
ModRM:r/m (r)
N/A
N/A
B
N/A
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
N/A
C
Full
ModRM:reg (w)
EVEX.vvvv (r)
ModRM:r/m (r)
N/A
Description
Performs a bitwise logical AND of the two, four or eight packed double precision floating-point values from the first
source operand and the second source operand, and stores the result in the destination operand.
EVEX encoded versions: The first source operand is a ZMM/YMM/XMM register. The second source operand can be
a ZMM/YMM/XMM register, a 512/256/128-bit memory location, or a 512/256/128-bit vector broadcasted from a
64-bit memory location. The destination operand is a ZMM/YMM/XMM register conditionally updated with
writemask k1.
VEX.256 encoded version: The first source operand is a YMM register. The second source operand is a YMM register
or a 256-bit memory location. The destination operand is a YMM register. The upper bits (MAXVL-1:256) of the
corresponding ZMM register destination are zeroed.
VEX.128 encoded version: The first source operand is an XMM register. The second source operand is an XMM
register or 128-bit memory location. The destination operand is an XMM register. The upper bits (MAXVL-1:128) of
the corresponding ZMM register destination are zeroed.
128-bit Legacy SSE version: The second source can be an XMM register or an 128-bit memory location. The desti-
nation is not distinct from the first source XMM register and the upper bits (MAXVL-1:128) of the corresponding
register destination are unmodified.
ANDPD-Bitwise Logical AND of Packed Double Precision Floating-Point Values
Vol. 2A
3-81
INSTRUCTION SET REFERENCE, A-L
Operation
VANDPD (EVEX Encoded Versions)
(KL, VL) = (2, 128), (4, 256), (8, 512)
FOR j := 0 TO KL-1
i := j * 64
IF k1[j] OR *no writemask*
THEN
IF (EVEX.b == 1) AND (SRC2 *is memory*)
THEN
DEST[i+63:i] := SRC1[i+63:i] BITWISE AND SRC2[63:0]
ELSE
DEST[i+63:i] := SRC1[i+63:i] BITWISE AND SRC2[i+63:i]
FI;
ELSE
IF *merging-masking*
; merging-masking
THEN *DEST[i+63:i] remains unchanged*
ELSE
; zeroing-masking
DEST[i+63:i] = 0
FI;
FI;
ENDFOR
DEST[MAXVL-1:VL] := 0
VANDPD (VEX.256 Encoded Version)
DEST[63:0] := SRC1[63:0] BITWISE AND SRC2[63:0]
DEST[127:64] := SRC1[127:64] BITWISE AND SRC2[127:64]
DEST[191:128] := SRC1[191:128] BITWISE AND SRC2[191:128]
DEST[255:192] := SRC1[255:192] BITWISE AND SRC2[255:192]
DEST[MAXVL-1:256] := 0
VANDPD (VEX.128 Encoded Version)
DEST[63:0] := SRC1[63:0] BITWISE AND SRC2[63:0]
DEST[127:64] := SRC1[127:64] BITWISE AND SRC2[127:64]
DEST[MAXVL-1:128] := 0
ANDPD (128-bit Legacy SSE Version)
DEST[63:0] := DEST[63:0] BITWISE AND SRC[63:0]
DEST[127:64] := DEST[127:64] BITWISE AND SRC[127:64]
DEST[MAXVL-1:128] (Unmodified)
Intel C/C++ Compiler Intrinsic Equivalent
VANDPD __m512d _mm512_and_pd (__m512d a, __m512d b);
VANDPD __m512d _mm512_mask_and_pd (__m512d s, __mmask8 k, __m512d a, __m512d b);
VANDPD __m512d _mm512_maskz_and_pd (__mmask8 k, __m512d a, __m512d b);
VANDPD __m256d _mm256_mask_and_pd (__m256d s, __mmask8 k, __m256d a, __m256d b);
VANDPD __m256d _mm256_maskz_and_pd (__mmask8 k, __m256d a, __m256d b);
VANDPD __m128d _mm_mask_and_pd (__m128d s, __mmask8 k, __m128d a, __m128d b);
VANDPD __m128d _mm_maskz_and_pd (__mmask8 k, __m128d a, __m128d b);
VANDPD __m256d _mm256_and_pd (__m256d a, __m256d b);
ANDPD __m128d _mm_and_pd (__m128d a, __m128d b);
SIMD Floating-Point Exceptions
None.
3-82
Vol. 2A
ANDPD-Bitwise Logical AND of Packed Double Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
Other Exceptions
VEX-encoded instruction, see Table 2-21, “Type 4 Class Exception Conditions.”
EVEX-encoded instruction, see Table 2-49, “Type E4 Class Exception Conditions.”
ANDPD-Bitwise Logical AND of Packed Double Precision Floating-Point Values
Vol. 2A
3-83
INSTRUCTION SET REFERENCE, A-L
ANDPS-Bitwise Logical AND of Packed Single Precision Floating-Point Values
Opcode/
Op /
64/32 bit
CPUID
Description
Instruction
En
Mode
Feature Flag
Support
NP 0F 54 /r
A
V/V
SSE
Return the bitwise logical AND of packed single precision
ANDPS xmm1, xmm2/m128
floating-point values in xmm1 and xmm2/mem.
VEX.128.0F 54 /r
B
V/V
AVX
Return the bitwise logical AND of packed single precision
VANDPS xmm1,xmm2,
floating-point values in xmm2 and xmm3/mem.
xmm3/m128
VEX.256.0F 54 /r
B
V/V
AVX
Return the bitwise logical AND of packed single precision
VANDPS ymm1, ymm2,
floating-point values in ymm2 and ymm3/mem.
ymm3/m256
EVEX.128.0F.W0 54 /r
C
V/V
AVX512VL
Return the bitwise logical AND of packed single precision
VANDPS xmm1 {k1}{z}, xmm2,
AVX512DQ
floating-point values in xmm2 and xmm3/m128/m32bcst
xmm3/m128/m32bcst
subject to writemask k1.
EVEX.256.0F.W0 54 /r
C
V/V
AVX512VL
Return the bitwise logical AND of packed single precision
VANDPS ymm1 {k1}{z}, ymm2,
AVX512DQ
floating-point values in ymm2 and ymm3/m256/m32bcst
ymm3/m256/m32bcst
subject to writemask k1.
EVEX.512.0F.W0 54 /r
C
V/V
AVX512DQ
Return the bitwise logical AND of packed single precision
VANDPS zmm1 {k1}{z}, zmm2,
floating-point values in zmm2 and zmm3/m512/m32bcst
zmm3/m512/m32bcst
subject to writemask k1.
Instruction Operand Encoding
Op/En
Tuple Type
Operand 1
Operand 2
Operand 3
Operand 4
A
N/A
ModRM:reg (r, w)
ModRM:r/m (r)
N/A
N/A
B
N/A
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
N/A
C
Full
ModRM:reg (w)
EVEX.vvvv (r)
ModRM:r/m (r)
N/A
Description
Performs a bitwise logical AND of the four, eight or sixteen packed single precision floating-point values from the
first source operand and the second source operand, and stores the result in the destination operand.
EVEX encoded versions: The first source operand is a ZMM/YMM/XMM register. The second source operand can be
a ZMM/YMM/XMM register, a 512/256/128-bit memory location, or a 512/256/128-bit vector broadcasted from a
32-bit memory location. The destination operand is a ZMM/YMM/XMM register conditionally updated with
writemask k1.
VEX.256 encoded version: The first source operand is a YMM register. The second source operand is a YMM register
or a 256-bit memory location. The destination operand is a YMM register. The upper bits (MAXVL-1:256) of the
corresponding ZMM register destination are zeroed.
VEX.128 encoded version: The first source operand is an XMM register. The second source operand is an XMM
register or 128-bit memory location. The destination operand is an XMM register. The upper bits (MAXVL-1:128) of
the corresponding ZMM register destination are zeroed.
128-bit Legacy SSE version: The second source can be an XMM register or an 128-bit memory location. The desti-
nation is not distinct from the first source XMM register and the upper bits (MAXVL-1:128) of the corresponding
ZMM register destination are unmodified.
3-84
Vol. 2A
ANDPS-Bitwise Logical AND of Packed Single Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
Operation
VANDPS (EVEX Encoded Versions)
(KL, VL) = (4, 128), (8, 256), (16, 512)
FOR j := 0 TO KL-1
i := j * 32
IF k1[j] OR *no writemask*
IF (EVEX.b == 1) AND (SRC2 *is memory*)
THEN
DEST[i+63:i] := SRC1[i+31:i] BITWISE AND SRC2[31:0]
ELSE
DEST[i+31:i] := SRC1[i+31:i] BITWISE AND SRC2[i+31:i]
FI;
ELSE
IF *merging-masking*
; merging-masking
THEN *DEST[i+31:i] remains unchanged*
ELSE
; zeroing-masking
DEST[i+31:i] := 0
FI;
FI;
ENDFOR
DEST[MAXVL-1:VL] := 0;
VANDPS (VEX.256 Encoded Version)
DEST[31:0] := SRC1[31:0] BITWISE AND SRC2[31:0]
DEST[63:32] := SRC1[63:32] BITWISE AND SRC2[63:32]
DEST[95:64] := SRC1[95:64] BITWISE AND SRC2[95:64]
DEST[127:96] := SRC1[127:96] BITWISE AND SRC2[127:96]
DEST[159:128] := SRC1[159:128] BITWISE AND SRC2[159:128]
DEST[191:160] := SRC1[191:160] BITWISE AND SRC2[191:160]
DEST[223:192] := SRC1[223:192] BITWISE AND SRC2[223:192]
DEST[255:224] := SRC1[255:224] BITWISE AND SRC2[255:224].
DEST[MAXVL-1:256] := 0;
VANDPS (VEX.128 Encoded Version)
DEST[31:0] := SRC1[31:0] BITWISE AND SRC2[31:0]
DEST[63:32] := SRC1[63:32] BITWISE AND SRC2[63:32]
DEST[95:64] := SRC1[95:64] BITWISE AND SRC2[95:64]
DEST[127:96] := SRC1[127:96] BITWISE AND SRC2[127:96]
DEST[MAXVL-1:128] := 0;
ANDPS (128-bit Legacy SSE Version)
DEST[31:0] := DEST[31:0] BITWISE AND SRC[31:0]
DEST[63:32] := DEST[63:32] BITWISE AND SRC[63:32]
DEST[95:64] := DEST[95:64] BITWISE AND SRC[95:64]
DEST[127:96] := DEST[127:96] BITWISE AND SRC[127:96]
DEST[MAXVL-1:128] (Unmodified)
ANDPS-Bitwise Logical AND of Packed Single Precision Floating-Point Values
Vol. 2A
3-85
INSTRUCTION SET REFERENCE, A-L
Intel C/C++ Compiler Intrinsic Equivalent
VANDPS __m512 _mm512_and_ps (__m512 a, __m512 b);
VANDPS __m512 _mm512_mask_and_ps (__m512 s, __mmask16 k, __m512 a, __m512 b);
VANDPS __m512 _mm512_maskz_and_ps (__mmask16 k, __m512 a, __m512 b);
VANDPS __m256 _mm256_mask_and_ps (__m256 s, __mmask8 k, __m256 a, __m256 b);
VANDPS __m256 _mm256_maskz_and_ps (__mmask8 k, __m256 a, __m256 b);
VANDPS __m128 _mm_mask_and_ps (__m128 s, __mmask8 k, __m128 a, __m128 b);
VANDPS __m128 _mm_maskz_and_ps (__mmask8 k, __m128 a, __m128 b);
VANDPS __m256 _mm256_and_ps (__m256 a, __m256 b);
ANDPS __m128 _mm_and_ps (__m128 a, __m128 b);
SIMD Floating-Point Exceptions
None.
Other Exceptions
VEX-encoded instruction, see Table 2-21, “Type 4 Class Exception Conditions.”
EVEX-encoded instruction, see Table 2-49, “Type E4 Class Exception Conditions.”
3-86
Vol. 2A
ANDPS-Bitwise Logical AND of Packed Single Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
ANDNPD-Bitwise Logical AND NOT of Packed Double Precision Floating-Point Values
Opcode/
Op /
64/32 bit
CPUID
Description
Instruction
En
Mode
Feature
Support
Flag
66 0F 55 /r
A
V/V
SSE2
Return the bitwise logical AND NOT of packed double
ANDNPD xmm1, xmm2/m128
precision floating-point values in xmm1 and xmm2/mem.
VEX.128.66.0F 55 /r
B
V/V
AVX
Return the bitwise logical AND NOT of packed double
VANDNPD xmm1, xmm2,
precision floating-point values in xmm2 and xmm3/mem.
xmm3/m128
VEX.256.66.0F 55/r
B
V/V
AVX
Return the bitwise logical AND NOT of packed double
VANDNPD ymm1, ymm2,
precision floating-point values in ymm2 and ymm3/mem.
ymm3/m256
EVEX.128.66.0F.W1 55 /r
C
V/V
AVX512VL
Return the bitwise logical AND NOT of packed double
VANDNPD xmm1 {k1}{z}, xmm2,
AVX512DQ
precision floating-point values in xmm2 and
xmm3/m128/m64bcst
xmm3/m128/m64bcst subject to writemask k1.
EVEX.256.66.0F.W1 55 /r
C
V/V
AVX512VL
Return the bitwise logical AND NOT of packed double
VANDNPD ymm1 {k1}{z}, ymm2,
AVX512DQ
precision floating-point values in ymm2 and
ymm3/m256/m64bcst
ymm3/m256/m64bcst subject to writemask k1.
EVEX.512.66.0F.W1 55 /r
C
V/V
AVX512DQ
Return the bitwise logical AND NOT of packed double
VANDNPD zmm1 {k1}{z}, zmm2,
precision floating-point values in zmm2 and
zmm3/m512/m64bcst
zmm3/m512/m64bcst subject to writemask k1.
Instruction Operand Encoding
Op/En
Tuple Type
Operand 1
Operand 2
Operand 3
Operand 4
A
N/A
ModRM:reg (r, w)
ModRM:r/m (r)
N/A
N/A
B
N/A
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
N/A
C
Full
ModRM:reg (w)
EVEX.vvvv (r)
ModRM:r/m (r)
N/A
Description
Performs a bitwise logical AND NOT of the two, four or eight packed double precision floating-point values from the
first source operand and the second source operand, and stores the result in the destination operand.
EVEX encoded versions: The first source operand is a ZMM/YMM/XMM register. The second source operand can be
a ZMM/YMM/XMM register, a 512/256/128-bit memory location, or a 512/256/128-bit vector broadcasted from a
64-bit memory location. The destination operand is a ZMM/YMM/XMM register conditionally updated with
writemask k1.
VEX.256 encoded version: The first source operand is a YMM register. The second source operand is a YMM register
or a 256-bit memory location. The destination operand is a YMM register. The upper bits (MAXVL-1:256) of the
corresponding ZMM register destination are zeroed.
VEX.128 encoded version: The first source operand is an XMM register. The second source operand is an XMM
register or 128-bit memory location. The destination operand is an XMM register. The upper bits (MAXVL-1:128) of
the corresponding ZMM register destination are zeroed.
128-bit Legacy SSE version: The second source can be an XMM register or an 128-bit memory location. The desti-
nation is not distinct from the first source XMM register and the upper bits (MAXVL-1:128) of the corresponding
register destination are unmodified.
ANDNPD-Bitwise Logical AND NOT of Packed Double Precision Floating-Point Values
Vol. 2A
3-87
INSTRUCTION SET REFERENCE, A-L
Operation
VANDNPD (EVEX Encoded Versions)
(KL, VL) = (2, 128), (4, 256), (8, 512)
FOR j := 0 TO KL-1
i := j * 64
IF k1[j] OR *no writemask*
IF (EVEX.b == 1) AND (SRC2 *is memory*)
THEN
DEST[i+63:i] := (NOT(SRC1[i+63:i])) BITWISE AND SRC2[63:0]
ELSE
DEST[i+63:i] := (NOT(SRC1[i+63:i])) BITWISE AND SRC2[i+63:i]
FI;
ELSE
IF *merging-masking*
; merging-masking
THEN *DEST[i+63:i] remains unchanged*
ELSE
; zeroing-masking
DEST[i+63:i] = 0
FI;
FI;
ENDFOR
DEST[MAXVL-1:VL] := 0
VANDNPD (VEX.256 Encoded Version)
DEST[63:0] := (NOT(SRC1[63:0])) BITWISE AND SRC2[63:0]
DEST[127:64] := (NOT(SRC1[127:64])) BITWISE AND SRC2[127:64]
DEST[191:128] := (NOT(SRC1[191:128])) BITWISE AND SRC2[191:128]
DEST[255:192] := (NOT(SRC1[255:192])) BITWISE AND SRC2[255:192]
DEST[MAXVL-1:256] := 0
VANDNPD (VEX.128 Encoded Version)
DEST[63:0] := (NOT(SRC1[63:0])) BITWISE AND SRC2[63:0]
DEST[127:64] := (NOT(SRC1[127:64])) BITWISE AND SRC2[127:64]
DEST[MAXVL-1:128] := 0
ANDNPD (128-bit Legacy SSE Version)
DEST[63:0] := (NOT(DEST[63:0])) BITWISE AND SRC[63:0]
DEST[127:64] := (NOT(DEST[127:64])) BITWISE AND SRC[127:64]
DEST[MAXVL-1:128] (Unmodified)
Intel C/C++ Compiler Intrinsic Equivalent
VANDNPD __m512d _mm512_andnot_pd (__m512d a, __m512d b);
VANDNPD __m512d _mm512_mask_andnot_pd (__m512d s, __mmask8 k, __m512d a, __m512d b);
VANDNPD __m512d _mm512_maskz_andnot_pd (__mmask8 k, __m512d a, __m512d b);
VANDNPD __m256d _mm256_mask_andnot_pd (__m256d s, __mmask8 k, __m256d a, __m256d b);
VANDNPD __m256d _mm256_maskz_andnot_pd (__mmask8 k, __m256d a, __m256d b);
VANDNPD __m128d _mm_mask_andnot_pd (__m128d s, __mmask8 k, __m128d a, __m128d b);
VANDNPD __m128d _mm_maskz_andnot_pd (__mmask8 k, __m128d a, __m128d b);
VANDNPD __m256d _mm256_andnot_pd (__m256d a, __m256d b);
ANDNPD __m128d _mm_andnot_pd (__m128d a, __m128d b);
SIMD Floating-Point Exceptions
None.
3-88
Vol. 2A
ANDNPD-Bitwise Logical AND NOT of Packed Double Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
Other Exceptions
VEX-encoded instruction, see Table 2-21, “Type 4 Class Exception Conditions.”
EVEX-encoded instruction, see Table 2-49, “Type E4 Class Exception Conditions.”
ANDNPD-Bitwise Logical AND NOT of Packed Double Precision Floating-Point Values
Vol. 2A
3-89
INSTRUCTION SET REFERENCE, A-L
ANDNPS-Bitwise Logical AND NOT of Packed Single Precision Floating-Point Values
Opcode/
Op /
64/32 bit
CPUID
Description
Instruction
En
Mode
Feature
Support
Flag
NP 0F 55 /r
A
V/V
SSE
Return the bitwise logical AND NOT of packed single precision
ANDNPS xmm1, xmm2/m128
floating-point values in xmm1 and xmm2/mem.
VEX.128.0F 55 /r
B
V/V
AVX
Return the bitwise logical AND NOT of packed single precision
VANDNPS xmm1, xmm2,
floating-point values in xmm2 and xmm3/mem.
xmm3/m128
VEX.256.0F 55 /r
B
V/V
AVX
Return the bitwise logical AND NOT of packed single precision
VANDNPS ymm1, ymm2,
floating-point values in ymm2 and ymm3/mem.
ymm3/m256
EVEX.128.0F.W0 55 /r
C
V/V
AVX512VL
Return the bitwise logical AND of packed single precision
VANDNPS xmm1 {k1}{z}, xmm2,
AVX512DQ
floating-point values in xmm2 and xmm3/m128/m32bcst
xmm3/m128/m32bcst
subject to writemask k1.
EVEX.256.0F.W0 55 /r
C
V/V
AVX512VL
Return the bitwise logical AND of packed single precision
VANDNPS ymm1 {k1}{z}, ymm2,
AVX512DQ
floating-point values in ymm2 and ymm3/m256/m32bcst
ymm3/m256/m32bcst
subject to writemask k1.
EVEX.512.0F.W0 55 /r
C
V/V
AVX512DQ
Return the bitwise logical AND of packed single precision
VANDNPS zmm1 {k1}{z}, zmm2,
floating-point values in zmm2 and zmm3/m512/m32bcst
zmm3/m512/m32bcst
subject to writemask k1.
Instruction Operand Encoding
Op/En
Tuple Type
Operand 1
Operand 2
Operand 3
Operand 4
A
N/A
ModRM:reg (r, w)
ModRM:r/m (r)
N/A
N/A
B
N/A
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
N/A
C
Full
ModRM:reg (w)
EVEX.vvvv (r)
ModRM:r/m (r)
N/A
Description
Performs a bitwise logical AND NOT of the four, eight or sixteen packed single precision floating-point values from
the first source operand and the second source operand, and stores the result in the destination operand.
EVEX encoded versions: The first source operand is a ZMM/YMM/XMM register. The second source operand can be
a ZMM/YMM/XMM register, a 512/256/128-bit memory location, or a 512/256/128-bit vector broadcasted from a
32-bit memory location. The destination operand is a ZMM/YMM/XMM register conditionally updated with
writemask k1.
VEX.256 encoded version: The first source operand is a YMM register. The second source operand is a YMM register
or a 256-bit memory location. The destination operand is a YMM register. The upper bits (MAXVL-1:256) of the
corresponding ZMM register destination are zeroed.
VEX.128 encoded version: The first source operand is an XMM register. The second source operand is an XMM
register or 128-bit memory location. The destination operand is an XMM register. The upper bits (MAXVL-1:128) of
the corresponding ZMM register destination are zeroed.
128-bit Legacy SSE version: The second source can be an XMM register or an 128-bit memory location. The desti-
nation is not distinct from the first source XMM register and the upper bits (MAXVL-1:128) of the corresponding
ZMM register destination are unmodified.
3-90
Vol. 2A
ANDNPS-Bitwise Logical AND NOT of Packed Single Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
Operation
VANDNPS (EVEX Encoded Versions)
(KL, VL) = (4, 128), (8, 256), (16, 512)
FOR j := 0 TO KL-1
i := j * 32
IF k1[j] OR *no writemask*
IF (EVEX.b == 1) AND (SRC2 *is memory*)
THEN
DEST[i+31:i] := (NOT(SRC1[i+31:i])) BITWISE AND SRC2[31:0]
ELSE
DEST[i+31:i] := (NOT(SRC1[i+31:i])) BITWISE AND SRC2[i+31:i]
FI;
ELSE
IF *merging-masking*
; merging-masking
THEN *DEST[i+31:i] remains unchanged*
ELSE
; zeroing-masking
DEST[i+31:i] = 0
FI;
FI;
ENDFOR
DEST[MAXVL-1:VL] := 0
VANDNPS (VEX.256 Encoded Version)
DEST[31:0] := (NOT(SRC1[31:0])) BITWISE AND SRC2[31:0]
DEST[63:32] := (NOT(SRC1[63:32])) BITWISE AND SRC2[63:32]
DEST[95:64] := (NOT(SRC1[95:64])) BITWISE AND SRC2[95:64]
DEST[127:96] := (NOT(SRC1[127:96])) BITWISE AND SRC2[127:96]
DEST[159:128] := (NOT(SRC1[159:128])) BITWISE AND SRC2[159:128]
DEST[191:160] := (NOT(SRC1[191:160])) BITWISE AND SRC2[191:160]
DEST[223:192] := (NOT(SRC1[223:192])) BITWISE AND SRC2[223:192]
DEST[255:224] := (NOT(SRC1[255:224])) BITWISE AND SRC2[255:224].
DEST[MAXVL-1:256] := 0
VANDNPS (VEX.128 Encoded Version)
DEST[31:0] := (NOT(SRC1[31:0])) BITWISE AND SRC2[31:0]
DEST[63:32] := (NOT(SRC1[63:32])) BITWISE AND SRC2[63:32]
DEST[95:64] := (NOT(SRC1[95:64])) BITWISE AND SRC2[95:64]
DEST[127:96] := (NOT(SRC1[127:96])) BITWISE AND SRC2[127:96]
DEST[MAXVL-1:128] := 0
ANDNPS (128-bit Legacy SSE Version)
DEST[31:0] := (NOT(DEST[31:0])) BITWISE AND SRC[31:0]
DEST[63:32] := (NOT(DEST[63:32])) BITWISE AND SRC[63:32]
DEST[95:64] := (NOT(DEST[95:64])) BITWISE AND SRC[95:64]
DEST[127:96] := (NOT(DEST[127:96])) BITWISE AND SRC[127:96]
DEST[MAXVL-1:128] (Unmodified)
ANDNPS-Bitwise Logical AND NOT of Packed Single Precision Floating-Point Values
Vol. 2A
3-91
INSTRUCTION SET REFERENCE, A-L
Intel C/C++ Compiler Intrinsic Equivalent
VANDNPS __m512 _mm512_andnot_ps (__m512 a, __m512 b);
VANDNPS __m512 _mm512_mask_andnot_ps (__m512 s, __mmask16 k, __m512 a, __m512 b);
VANDNPS __m512 _mm512_maskz_andnot_ps (__mmask16 k, __m512 a, __m512 b);
VANDNPS __m256 _mm256_mask_andnot_ps (__m256 s, __mmask8 k, __m256 a, __m256 b);
VANDNPS __m256 _mm256_maskz_andnot_ps (__mmask8 k, __m256 a, __m256 b);
VANDNPS __m128 _mm_mask_andnot_ps (__m128 s, __mmask8 k, __m128 a, __m128 b);
VANDNPS __m128 _mm_maskz_andnot_ps (__mmask8 k, __m128 a, __m128 b);
VANDNPS __m256 _mm256_andnot_ps (__m256 a, __m256 b);
ANDNPS __m128 _mm_andnot_ps (__m128 a, __m128 b);
SIMD Floating-Point Exceptions
None.
Other Exceptions
VEX-encoded instruction, see Table 2-21, “Type 4 Class Exception Conditions.”
EVEX-encoded instruction, see Table 2-49, “Type E4 Class Exception Conditions.”
3-92
Vol. 2A
ANDNPS-Bitwise Logical AND NOT of Packed Single Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
ARPL-Adjust RPL Field of Segment Selector
Opcode
Instruction
Op/
64-bit
Compat/
Description
En
Mode
Leg Mode
63 /r
ARPL r/m16, r16
MR
N. E.
Valid
Adjust RPL of r/m16 to not less than RPL of
r16.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
MR
ModRM:r/m (w)
ModRM:reg (r)
N/A
N/A
Description
Compares the RPL fields of two segment selectors. The first operand (the destination operand) contains one
segment selector and the second operand (source operand) contains the other. (The RPL field is located in bits 0
and 1 of each operand.) If the RPL field of the destination operand is less than the RPL field of the source operand,
the ZF flag is set and the RPL field of the destination operand is increased to match that of the source operand.
Otherwise, the ZF flag is cleared and no change is made to the destination operand. (The destination operand can
be a word register or a memory location; the source operand must be a word register.)
The ARPL instruction is provided for use by operating-system procedures (however, it can also be used by applica-
tions). It is generally used to adjust the RPL of a segment selector that has been passed to the operating system
by an application program to match the privilege level of the application program. Here the segment selector
passed to the operating system is placed in the destination operand and segment selector for the application
program’s code segment is placed in the source operand. (The RPL field in the source operand represents the priv-
ilege level of the application program.) Execution of the ARPL instruction then ensures that the RPL of the segment
selector received by the operating system is no lower (does not have a higher privilege) than the privilege level of
the application program (the segment selector for the application program’s code segment can be read from the
stack following a procedure call).
This instruction executes as described in compatibility mode and legacy mode. It is not encodable in 64-bit mode.
See “Checking Caller Access Privileges” in Chapter 3, “Protected-Mode Memory Management,” of the Intel® 64 and
IA-32 Architectures Software Developer’s Manual, Volume 3A, for more information about the use of this instruc-
tion.
Operation
IF 64-BIT MODE
THEN
See MOVSXD;
ELSE
IF DEST[RPL] < SRC[RPL]
THEN
ZF := 1;
DEST[RPL] := SRC[RPL];
ELSE
ZF := 0;
FI;
FI;
Flags Affected
The ZF flag is set to 1 if the RPL field of the destination operand is less than that of the source operand; otherwise,
it is set to 0.
ARPL-Adjust RPL Field of Segment Selector
Vol. 2A
3-93
INSTRUCTION SET REFERENCE, A-L
Protected Mode Exceptions
#GP(0)
If the destination is located in a non-writable segment.
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the DS, ES, FS, or GS register is used to access memory and it contains a NULL segment
selector.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
#UD
If the LOCK prefix is used.
Real-Address Mode Exceptions
#UD
The ARPL instruction is not recognized in real-address mode.
If the LOCK prefix is used.
Virtual-8086 Mode Exceptions
#UD
The ARPL instruction is not recognized in virtual-8086 mode.
If the LOCK prefix is used.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
Not applicable.
3-94
Vol. 2A
ARPL-Adjust RPL Field of Segment Selector
INSTRUCTION SET REFERENCE, A-L
BEXTR-Bit Field Extract
Opcode/Instruction
Op/
64/32-
CPUID
Description
En
bit
Feature
Mode
Flag
VEX.LZ.0F38.W0 F7 /r
RMV
V/V
BMI1
Contiguous bitwise extract from r/m32 using r32b as control; store
BEXTR r32a, r/m32, r32b
result in r32a.
VEX.LZ.0F38.W1 F7 /r
RMV
V/N.E.
BMI1
Contiguous bitwise extract from r/m64 using r64b as control; store
BEXTR r64a, r/m64, r64b
result in r64a.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RMV
ModRM:reg (w)
ModRM:r/m (r)
VEX.vvvv (r)
N/A
Description
Extracts contiguous bits from the first source operand (the second operand) using an index value and length value
specified in the second source operand (the third operand). Bit 7:0 of the second source operand specifies the
starting bit position of bit extraction. A START value exceeding the operand size will not extract any bits from the
second source operand. Bit 15:8 of the second source operand specifies the maximum number of bits (LENGTH)
beginning at the START position to extract. Only bit positions up to (OperandSize -1) of the first source operand are
extracted. The extracted bits are written to the destination register, starting from the least significant bit. All higher
order bits in the destination operand (starting at bit position LENGTH) are zeroed. The destination register is
cleared if no bits are extracted.
This instruction is not supported in real mode and virtual-8086 mode. The operand size is always 32 bits if not in
64-bit mode. In 64-bit mode operand size 64 requires VEX.W1. VEX.W1 is ignored in non-64-bit modes. An
attempt to execute this instruction with VEX.L not equal to 0 will cause #UD.
Operation
START := SRC2[7:0];
LEN := SRC2[15:8];
TEMP := ZERO_EXTEND_TO_512 (SRC1 );
DEST := ZERO_EXTEND(TEMP[START+LEN -1: START]);
ZF := (DEST = 0);
Flags Affected
ZF is updated based on the result. AF, SF, and PF are undefined. All other flags are cleared.
Intel C/C++ Compiler Intrinsic Equivalent
BEXTR unsigned __int32 _bextr_u32(unsigned __int32 src, unsigned __int32 start. unsigned __int32 len);
BEXTR unsigned __int64 _bextr_u64(unsigned __int64 src, unsigned __int32 start. unsigned __int32 len);
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-29, “Type 13 Class Exception Conditions,” additionally:
#UD
If VEX.W = 1.
BEXTR-Bit Field Extract
Vol. 2A
3-95
INSTRUCTION SET REFERENCE, A-L
BLENDPD-Blend Packed Double Precision Floating-Point Values
Opcode/
Op/
64/32-bit
CPUID
Description
Instruction
En
Mode
Feature
Flag
66 0F 3A 0D /r ib
RMI
V/V
SSE4_1
Select packed double precision floating-point
values from xmm1 and xmm2/m128 from
BLENDPD xmm1, xmm2/m128, imm8
mask specified in imm8 and store the values
into xmm1.
VEX.128.66.0F3A.WIG 0D /r ib
RVMI
V/V
AVX
Select packed double precision floating-point
Values from xmm2 and xmm3/m128 from
VBLENDPD xmm1, xmm2, xmm3/m128, imm8
mask in imm8 and store the values in xmm1.
VEX.256.66.0F3A.WIG 0D /r ib
RVMI
V/V
AVX
Select packed double precision floating-point
Values from ymm2 and ymm3/m256 from
VBLENDPD ymm1, ymm2, ymm3/m256, imm8
mask in imm8 and store the values in ymm1.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RMI
ModRM:reg (r, w)
ModRM:r/m (r)
imm8
N/A
RVMI
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
imm8[3:0]
Description
Double-precision floating-point values from the second source operand (third operand) are conditionally merged
with values from the first source operand (second operand) and written to the destination operand (first operand).
The immediate bits [3:0] determine whether the corresponding double precision floating-point value in the desti-
nation is copied from the second source or first source. If a bit in the mask, corresponding to a word, is ”1”, then
the double precision floating-point value in the second source operand is copied, else the value in the first source
operand is copied.
128-bit Legacy SSE version: The second source can be an XMM register or an 128-bit memory location. The desti-
nation is not distinct from the first source XMM register and the upper bits (MAXVL-1:128) of the corresponding
YMM register destination are unmodified.
VEX.128 encoded version: the first source operand is an XMM register. The second source operand is an XMM
register or 128-bit memory location. The destination operand is an XMM register. The upper bits (MAXVL-1:128) of
the corresponding YMM register destination are zeroed.
VEX.256 encoded version: The first source operand is a YMM register. The second source operand can be a YMM
register or a 256-bit memory location. The destination operand is a YMM register.
Operation
BLENDPD (128-bit Legacy SSE Version)
IF (IMM8[0] = 0)THEN DEST[63:0] := DEST[63:0]
ELSE DEST [63:0] := SRC[63:0] FI
IF (IMM8[1] = 0) THEN DEST[127:64] := DEST[127:64]
ELSE DEST [127:64] := SRC[127:64] FI
DEST[MAXVL-1:128] (Unmodified)
VBLENDPD (VEX.128 Encoded Version)
IF (IMM8[0] = 0)THEN DEST[63:0] := SRC1[63:0]
ELSE DEST [63:0] := SRC2[63:0] FI
IF (IMM8[1] = 0) THEN DEST[127:64] := SRC1[127:64]
ELSE DEST [127:64] := SRC2[127:64] FI
DEST[MAXVL-1:128] := 0
3-96
Vol. 2A
BLENDPD-Blend Packed Double Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
VBLENDPD (VEX.256 Encoded Version)
IF (IMM8[0] = 0)THEN DEST[63:0] := SRC1[63:0]
ELSE DEST [63:0] := SRC2[63:0] FI
IF (IMM8[1] = 0) THEN DEST[127:64] := SRC1[127:64]
ELSE DEST [127:64] := SRC2[127:64] FI
IF (IMM8[2] = 0) THEN DEST[191:128] := SRC1[191:128]
ELSE DEST [191:128] := SRC2[191:128] FI
IF (IMM8[3] = 0) THEN DEST[255:192] := SRC1[255:192]
ELSE DEST [255:192] := SRC2[255:192] FI
Intel C/C++ Compiler Intrinsic Equivalent
BLENDPD __m128d _mm_blend_pd (__m128d v1, __m128d v2, const int mask);
VBLENDPD __m256d _mm256_blend_pd (__m256d a, __m256d b, const int mask);
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-21, “Type 4 Class Exception Conditions.”
BLENDPD-Blend Packed Double Precision Floating-Point Values
Vol. 2A
3-97
INSTRUCTION SET REFERENCE, A-L
BLENDPS-Blend Packed Single Precision Floating-Point Values
Opcode/
Op/
64/32-bit
CPUID
Description
Instruction
En
Mode
Feature
Flag
66 0F 3A 0C /r ib
RMI
V/V
SSE4_1
Select packed single precision floating-point
values from xmm1 and xmm2/m128 from
BLENDPS xmm1, xmm2/m128, imm8
mask specified in imm8 and store the values
into xmm1.
VEX.128.66.0F3A.WIG 0C /r ib
RVMI
V/V
AVX
Select packed single precision floating-point
values from xmm2 and xmm3/m128 from
VBLENDPS xmm1, xmm2, xmm3/m128, imm8
mask in imm8 and store the values in xmm1.
VEX.256.66.0F3A.WIG 0C /r ib
RVMI
V/V
AVX
Select packed single precision floating-point
values from ymm2 and ymm3/m256 from
VBLENDPS ymm1, ymm2, ymm3/m256, imm8
mask in imm8 and store the values in ymm1.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RMI
ModRM:reg (r, w)
ModRM:r/m (r)
imm8
N/A
RVMI
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
imm8
Description
Packed single precision floating-point values from the second source operand (third operand) are conditionally
merged with values from the first source operand (second operand) and written to the destination operand (first
operand). The immediate bits [7:0] determine whether the corresponding single precision floating-point value in
the destination is copied from the second source or first source. If a bit in the mask, corresponding to a word, is “1”,
then the single precision floating-point value in the second source operand is copied, else the value in the first
source operand is copied.
128-bit Legacy SSE version: The second source can be an XMM register or an 128-bit memory location. The desti-
nation is not distinct from the first source XMM register and the upper bits (MAXVL-1:128) of the corresponding
YMM register destination are unmodified.
VEX.128 encoded version: The first source operand an XMM register. The second source operand is an XMM register
or 128-bit memory location. The destination operand is an XMM register. The upper bits (MAXVL-1:128) of the
corresponding YMM register destination are zeroed.
VEX.256 encoded version: The first source operand is a YMM register. The second source operand can be a YMM
register or a 256-bit memory location. The destination operand is a YMM register.
Operation
BLENDPS (128-bit Legacy SSE Version)
IF (IMM8[0] = 0) THEN DEST[31:0] :=DEST[31:0]
ELSE DEST [31:0] := SRC[31:0] FI
IF (IMM8[1] = 0) THEN DEST[63:32] := DEST[63:32]
ELSE DEST [63:32] := SRC[63:32] FI
IF (IMM8[2] = 0) THEN DEST[95:64] := DEST[95:64]
ELSE DEST [95:64] := SRC[95:64] FI
IF (IMM8[3] = 0) THEN DEST[127:96] := DEST[127:96]
ELSE DEST [127:96] := SRC[127:96] FI
DEST[MAXVL-1:128] (Unmodified)
3-98
Vol. 2A
BLENDPS-Blend Packed Single Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
VBLENDPS (VEX.128 Encoded Version)
IF (IMM8[0] = 0) THEN DEST[31:0] :=SRC1[31:0]
ELSE DEST [31:0] := SRC2[31:0] FI
IF (IMM8[1] = 0) THEN DEST[63:32] := SRC1[63:32]
ELSE DEST [63:32] := SRC2[63:32] FI
IF (IMM8[2] = 0) THEN DEST[95:64] := SRC1[95:64]
ELSE DEST [95:64] := SRC2[95:64] FI
IF (IMM8[3] = 0) THEN DEST[127:96] := SRC1[127:96]
ELSE DEST [127:96] := SRC2[127:96] FI
DEST[MAXVL-1:128] := 0
VBLENDPS (VEX.256 Encoded Version)
IF (IMM8[0] = 0) THEN DEST[31:0] :=SRC1[31:0]
ELSE DEST [31:0] := SRC2[31:0] FI
IF (IMM8[1] = 0) THEN DEST[63:32] := SRC1[63:32]
ELSE DEST [63:32] := SRC2[63:32] FI
IF (IMM8[2] = 0) THEN DEST[95:64] := SRC1[95:64]
ELSE DEST [95:64] := SRC2[95:64] FI
IF (IMM8[3] = 0) THEN DEST[127:96] := SRC1[127:96]
ELSE DEST [127:96] := SRC2[127:96] FI
IF (IMM8[4] = 0) THEN DEST[159:128] := SRC1[159:128]
ELSE DEST [159:128] := SRC2[159:128] FI
IF (IMM8[5] = 0) THEN DEST[191:160] := SRC1[191:160]
ELSE DEST [191:160] := SRC2[191:160] FI
IF (IMM8[6] = 0) THEN DEST[223:192] := SRC1[223:192]
ELSE DEST [223:192] := SRC2[223:192] FI
IF (IMM8[7] = 0) THEN DEST[255:224] := SRC1[255:224]
ELSE DEST [255:224] := SRC2[255:224] FI.
Intel C/C++ Compiler Intrinsic Equivalent
BLENDPS __m128 _mm_blend_ps (__m128 v1, __m128 v2, const int mask);
VBLENDPS __m256 _mm256_blend_ps (__m256 a, __m256 b, const int mask);
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-21, “Type 4 Class Exception Conditions.”
BLENDPS-Blend Packed Single Precision Floating-Point Values
Vol. 2A
3-99
INSTRUCTION SET REFERENCE, A-L
BLENDVPD-Variable Blend Packed Double Precision Floating-Point Values
Opcode/
Op/
64/32-bit
CPUID
Description
Instruction
En
Mode
Feature
Flag
66 0F 38 15 /r
RM0
V/V
SSE4_1
Select packed double precision floating-point
values from xmm1 and xmm2 from mask specified
BLENDVPD xmm1, xmm2/m128 , <XMM0>
in XMM0 and store the values in xmm1.
VEX.128.66.0F3A.W0 4B /r /is4
RVMR
V/V
AVX
Conditionally copy double precision floating-point
values from xmm2 or xmm3/m128 to xmm1, based
VBLENDVPD xmm1, xmm2, xmm3/m128, xmm4
on mask bits in the mask operand, xmm4.
VEX.256.66.0F3A.W0 4B /r /is4
RVMR
V/V
AVX
Conditionally copy double precision floating-point
values from ymm2 or ymm3/m256 to ymm1, based
VBLENDVPD ymm1, ymm2, ymm3/m256, ymm4
on mask bits in the mask operand, ymm4.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM0
ModRM:reg (r, w)
ModRM:r/m (r)
implicit XMM0
N/A
RVMR
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
imm8[7:4]
Description
Conditionally copy each quadword data element of double precision floating-point value from the second source
operand and the first source operand depending on mask bits defined in the mask register operand. The mask bits
are the most significant bit in each quadword element of the mask register.
Each quadword element of the destination operand is copied from:
the corresponding quadword element in the second source operand, if a mask bit is “1”; or
the corresponding quadword element in the first source operand, if a mask bit is “0”
The register assignment of the implicit mask operand for BLENDVPD is defined to be the architectural register
XMM0.
128-bit Legacy SSE version: The first source operand and the destination operand is the same. Bits (MAXVL-1:128)
of the corresponding YMM destination register remain unchanged. The mask register operand is implicitly defined
to be the architectural register XMM0. An attempt to execute BLENDVPD with a VEX prefix will cause #UD.
VEX.128 encoded version: The first source operand and the destination operand are XMM registers. The second
source operand is an XMM register or 128-bit memory location. The mask operand is the third source register, and
encoded in bits[7:4] of the immediate byte(imm8). The bits[3:0] of imm8 are ignored. In 32-bit mode, imm8[7] is
ignored. The upper bits (MAXVL-1:128) of the corresponding YMM register (destination register) are zeroed. VEX.W
must be 0, otherwise, the instruction will #UD.
VEX.256 encoded version: The first source operand and destination operand are YMM registers. The second source
operand can be a YMM register or a 256-bit memory location. The mask operand is the third source register, and
encoded in bits[7:4] of the immediate byte(imm8). The bits[3:0] of imm8 are ignored. In 32-bit mode, imm8[7] is
ignored. VEX.W must be 0, otherwise, the instruction will #UD.
VBLENDVPD permits the mask to be any XMM or YMM register. In contrast, BLENDVPD treats XMM0 implicitly as the
mask and do not support non-destructive destination operation.
3-100
Vol. 2A
BLENDVPD-Variable Blend Packed Double Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
Operation
BLENDVPD (128-bit Legacy SSE Version)
MASK := XMM0
IF (MASK[63] = 0) THEN DEST[63:0] := DEST[63:0]
ELSE DEST [63:0] := SRC[63:0] FI
IF (MASK[127] = 0) THEN DEST[127:64] := DEST[127:64]
ELSE DEST [127:64] := SRC[127:64] FI
DEST[MAXVL-1:128] (Unmodified)
VBLENDVPD (VEX.128 Encoded Version)
MASK := SRC3
IF (MASK[63] = 0) THEN DEST[63:0] := SRC1[63:0]
ELSE DEST [63:0] := SRC2[63:0] FI
IF (MASK[127] = 0) THEN DEST[127:64] := SRC1[127:64]
ELSE DEST [127:64] := SRC2[127:64] FI
DEST[MAXVL-1:128] := 0
VBLENDVPD (VEX.256 Encoded Version)
MASK := SRC3
IF (MASK[63] = 0) THEN DEST[63:0] := SRC1[63:0]
ELSE DEST [63:0] := SRC2[63:0] FI
IF (MASK[127] = 0) THEN DEST[127:64] := SRC1[127:64]
ELSE DEST [127:64] := SRC2[127:64] FI
IF (MASK[191] = 0) THEN DEST[191:128] := SRC1[191:128]
ELSE DEST [191:128] := SRC2[191:128] FI
IF (MASK[255] = 0) THEN DEST[255:192] := SRC1[255:192]
ELSE DEST [255:192] := SRC2[255:192] FI
Intel C/C++ Compiler Intrinsic Equivalent
BLENDVPD __m128d _mm_blendv_pd(__m128d v1, __m128d v2, __m128d v3);
VBLENDVPD __m128 _mm_blendv_pd (__m128d a, __m128d b, __m128d mask);
VBLENDVPD __m256 _mm256_blendv_pd (__m256d a, __m256d b, __m256d mask);
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-21, “Type 4 Class Exception Conditions,” additionally:
#UD
If VEX.W = 1.
BLENDVPD-Variable Blend Packed Double Precision Floating-Point Values
Vol. 2A
3-101
INSTRUCTION SET REFERENCE, A-L
BLENDVPS-Variable Blend Packed Single Precision Floating-Point Values
Opcode/
Op/
64/32-bit
CPUID
Description
Instruction
En
Mode
Feature
Flag
66 0F 38 14 /r
RM0
V/V
SSE4_1
Select packed single precision floating-point values
from xmm1 and xmm2/m128 from mask specified
BLENDVPS xmm1, xmm2/m128, <XMM0>
in XMM0 and store the values into xmm1.
VEX.128.66.0F3A.W0 4A /r /is4
RVMR
V/V
AVX
Conditionally copy single precision floating-point
values from xmm2 or xmm3/m128 to xmm1, based
VBLENDVPS xmm1, xmm2, xmm3/m128, xmm4
on mask bits in the specified mask operand, xmm4.
VEX.256.66.0F3A.W0 4A /r /is4
RVMR
V/V
AVX
Conditionally copy single precision floating-point
values from ymm2 or ymm3/m256 to ymm1, based
VBLENDVPS ymm1, ymm2, ymm3/m256, ymm4
on mask bits in the specified mask register, ymm4.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM0
ModRM:reg (r, w)
ModRM:r/m (r)
implicit XMM0
N/A
RVMR
ModRM:reg (w)
VEX.vvvv (r)
ModRM:r/m (r)
imm8[7:4]
Description
Conditionally copy each dword data element of single precision floating-point value from the second source
operand and the first source operand depending on mask bits defined in the mask register operand. The mask bits
are the most significant bit in each dword element of the mask register.
Each quadword element of the destination operand is copied from:
the corresponding dword element in the second source operand, if a mask bit is “1”; or
the corresponding dword element in the first source operand, if a mask bit is “0”.
The register assignment of the implicit mask operand for BLENDVPS is defined to be the architectural register
XMM0.
128-bit Legacy SSE version: The first source operand and the destination operand is the same. Bits (MAXVL-1:128)
of the corresponding YMM destination register remain unchanged. The mask register operand is implicitly defined
to be the architectural register XMM0. An attempt to execute BLENDVPS with a VEX prefix will cause #UD.
VEX.128 encoded version: The first source operand and the destination operand are XMM registers. The second
source operand is an XMM register or 128-bit memory location. The mask operand is the third source register, and
encoded in bits[7:4] of the immediate byte(imm8). The bits[3:0] of imm8 are ignored. In 32-bit mode, imm8[7] is
ignored. The upper bits (MAXVL-1:128) of the corresponding YMM register (destination register) are zeroed. VEX.W
must be 0, otherwise, the instruction will #UD.
VEX.256 encoded version: The first source operand and destination operand are YMM registers. The second source
operand can be a YMM register or a 256-bit memory location. The mask operand is the third source register, and
encoded in bits[7:4] of the immediate byte(imm8). The bits[3:0] of imm8 are ignored. In 32-bit mode, imm8[7] is
ignored. VEX.W must be 0, otherwise, the instruction will #UD.
VBLENDVPS permits the mask to be any XMM or YMM register. In contrast, BLENDVPS treats XMM0 implicitly as the
mask and do not support non-destructive destination operation.
3-102
Vol. 2A
BLENDVPS-Variable Blend Packed Single Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
Operation
BLENDVPS (128-bit Legacy SSE Version)
MASK := XMM0
IF (MASK[31] = 0) THEN DEST[31:0] := DEST[31:0]
ELSE DEST [31:0] := SRC[31:0] FI
IF (MASK[63] = 0) THEN DEST[63:32] := DEST[63:32]
ELSE DEST [63:32] := SRC[63:32] FI
IF (MASK[95] = 0) THEN DEST[95:64] := DEST[95:64]
ELSE DEST [95:64] := SRC[95:64] FI
IF (MASK[127] = 0) THEN DEST[127:96] := DEST[127:96]
ELSE DEST [127:96] := SRC[127:96] FI
DEST[MAXVL-1:128] (Unmodified)
VBLENDVPS (VEX.128 Encoded Version)
MASK := SRC3
IF (MASK[31] = 0) THEN DEST[31:0] := SRC1[31:0]
ELSE DEST [31:0] := SRC2[31:0] FI
IF (MASK[63] = 0) THEN DEST[63:32] := SRC1[63:32]
ELSE DEST [63:32] := SRC2[63:32] FI
IF (MASK[95] = 0) THEN DEST[95:64] := SRC1[95:64]
ELSE DEST [95:64] := SRC2[95:64] FI
IF (MASK[127] = 0) THEN DEST[127:96] := SRC1[127:96]
ELSE DEST [127:96] := SRC2[127:96] FI
DEST[MAXVL-1:128] := 0
VBLENDVPS (VEX.256 Encoded Version)
MASK := SRC3
IF (MASK[31] = 0) THEN DEST[31:0] := SRC1[31:0]
ELSE DEST [31:0] := SRC2[31:0] FI
IF (MASK[63] = 0) THEN DEST[63:32] := SRC1[63:32]
ELSE DEST [63:32] := SRC2[63:32] FI
IF (MASK[95] = 0) THEN DEST[95:64] := SRC1[95:64]
ELSE DEST [95:64] := SRC2[95:64] FI
IF (MASK[127] = 0) THEN DEST[127:96] := SRC1[127:96]
ELSE DEST [127:96] := SRC2[127:96] FI
IF (MASK[159] = 0) THEN DEST[159:128] := SRC1[159:128]
ELSE DEST [159:128] := SRC2[159:128] FI
IF (MASK[191] = 0) THEN DEST[191:160] := SRC1[191:160]
ELSE DEST [191:160] := SRC2[191:160] FI
IF (MASK[223] = 0) THEN DEST[223:192] := SRC1[223:192]
ELSE DEST [223:192] := SRC2[223:192] FI
IF (MASK[255] = 0) THEN DEST[255:224] := SRC1[255:224]
ELSE DEST [255:224] := SRC2[255:224] FI
Intel C/C++ Compiler Intrinsic Equivalent
BLENDVPS __m128 _mm_blendv_ps(__m128 v1, __m128 v2, __m128 v3);
VBLENDVPS __m128 _mm_blendv_ps (__m128 a, __m128 b, __m128 mask);
VBLENDVPS __m256 _mm256_blendv_ps (__m256 a, __m256 b, __m256 mask);
SIMD Floating-Point Exceptions
None.
BLENDVPS-Variable Blend Packed Single Precision Floating-Point Values
Vol. 2A
3-103
INSTRUCTION SET REFERENCE, A-L
Other Exceptions
See Table 2-21, “Type 4 Class Exception Conditions,” additionally:
#UD
If VEX.W = 1.
3-104
Vol. 2A
BLENDVPS-Variable Blend Packed Single Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-L
BLSI-Extract Lowest Set Isolated Bit
Opcode/Instruction
Op/
64/32-
CPUID
Description
En
bit
Feature
Mode
Flag
VEX.LZ.0F38.W0 F3 /3
VM
V/V
BMI1
Extract lowest set bit from r/m32 and set that bit in r32.
BLSI r32, r/m32
VEX.LZ.0F38.W1 F3 /3
VM
V/N.E.
BMI1
Extract lowest set bit from r/m64, and set that bit in r64.
BLSI r64, r/m64
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
VM
VEX.vvvv (w)
ModRM:r/m (r)
N/A
N/A
Description
Extracts the lowest set bit from the source operand and set the corresponding bit in the destination register. All
other bits in the destination operand are zeroed. If no bits are set in the source operand, BLSI sets all the bits in
the destination to 0 and sets ZF and CF.
This instruction is not supported in real mode and virtual-8086 mode. The operand size is always 32 bits if not in
64-bit mode. In 64-bit mode operand size 64 requires VEX.W1. VEX.W1 is ignored in non-64-bit modes. An
attempt to execute this instruction with VEX.L not equal to 0 will cause #UD.
Operation
temp := (-SRC) bitwiseAND (SRC);
SF := temp[OperandSize -1];
ZF := (temp = 0);
IF SRC = 0
CF := 0;
ELSE
CF := 1;
FI
DEST := temp;
Flags Affected
ZF and SF are updated based on the result. CF is set if the source is not zero. OF flags are cleared. AF and PF
flags are undefined.
Intel C/C++ Compiler Intrinsic Equivalent
BLSI unsigned __int32 _blsi_u32(unsigned __int32 src);
BLSI unsigned __int64 _blsi_u64(unsigned __int64 src);
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-29, “Type 13 Class Exception Conditions.”
BLSI-Extract Lowest Set Isolated Bit
Vol. 2A
3-105
INSTRUCTION SET REFERENCE, A-L
BLSMSK-Get Mask Up to Lowest Set Bit
Opcode/Instruction
Op/
64/32-
CPUID
Description
En
bit
Feature
Mode
Flag
VEX.LZ.0F38.W0 F3 /2
VM
V/V
BMI1
Set all lower bits in r32 to “1” starting from bit 0 to lowest set bit in
BLSMSK r32, r/m32
r/m32.
VEX.LZ.0F38.W1 F3 /2
VM
V/N.E.
BMI1
Set all lower bits in r64 to “1” starting from bit 0 to lowest set bit in
BLSMSK r64, r/m64
r/m64.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
VM
VEX.vvvv (w)
ModRM:r/m (r)
N/A
N/A
Description
Sets all the lower bits of the destination operand to “1” up to and including lowest set bit (=1) in the source
operand. If source operand is zero, BLSMSK sets all bits of the destination operand to 1 and also sets CF to 1.
This instruction is not supported in real mode and virtual-8086 mode. The operand size is always 32 bits if not in
64-bit mode. In 64-bit mode operand size 64 requires VEX.W1. VEX.W1 is ignored in non-64-bit modes. An attempt
to execute this instruction with VEX.L not equal to 0 will cause #UD.
Operation
temp := (SRC-1) XOR (SRC) ;
SF := temp[OperandSize -1];
ZF := 0;
IF SRC = 0
CF := 1;
ELSE
CF := 0;
FI
DEST := temp;
Flags Affected
SF is updated based on the result. CF is set if the source if zero. ZF and OF flags are cleared. AF and PF flag are
undefined.
Intel C/C++ Compiler Intrinsic Equivalent
BLSMSK unsigned __int32 _blsmsk_u32(unsigned __int32 src);
BLSMSK unsigned __int64 _blsmsk_u64(unsigned __int64 src);
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-29, “Type 13 Class Exception Conditions.”
3-106
Vol. 2A
BLSMSK-Get Mask Up to Lowest Set Bit
INSTRUCTION SET REFERENCE, A-L
BLSR-Reset Lowest Set Bit
Opcode/Instruction
Op/
64/32-
CPUID
Description
En
bit
Feature
Mode
Flag
VEX.LZ.0F38.W0 F3 /1
VM
V/V
BMI1
Reset lowest set bit of r/m32, keep all other bits of r/m32 and write
BLSR r32, r/m32
result to r32.
VEX.LZ.0F38.W1 F3 /1
VM
V/N.E.
BMI1
Reset lowest set bit of r/m64, keep all other bits of r/m64 and write
BLSR r64, r/m64
result to r64.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
VM
VEX.vvvv (w)
ModRM:r/m (r)
N/A
N/A
Description
Copies all bits from the source operand to the destination operand and resets (=0) the bit position in the destina-
tion operand that corresponds to the lowest set bit of the source operand. If the source operand is zero BLSR sets
CF.
This instruction is not supported in real mode and virtual-8086 mode. The operand size is always 32 bits if not in
64-bit mode. In 64-bit mode operand size 64 requires VEX.W1. VEX.W1 is ignored in non-64-bit modes. An
attempt to execute this instruction with VEX.L not equal to 0 will cause #UD.
Operation
temp := (SRC-1) bitwiseAND ( SRC );
SF := temp[OperandSize -1];
ZF := (temp = 0);
IF SRC = 0
CF := 1;
ELSE
CF := 0;
FI
DEST := temp;
Flags Affected
ZF and SF flags are updated based on the result. CF is set if the source is zero. OF flag is cleared. AF and PF flags
are undefined.
Intel C/C++ Compiler Intrinsic Equivalent
BLSR unsigned __int32 _blsr_u32(unsigned __int32 src);
BLSR unsigned __int64 _blsr_u64(unsigned __int64 src);
SIMD Floating-Point Exceptions
None.
Other Exceptions
See Table 2-29, “Type 13 Class Exception Conditions.”
BLSR-Reset Lowest Set Bit
Vol. 2A
3-107
INSTRUCTION SET REFERENCE, A-L
BNDCL-Check Lower Bound
Opcode/
Op/En
64/32 bit
CPUID
Description
Instruction
Mode
Feature
Support
Flag
F3 0F 1A /r
RM
NE/V
MPX
Generate a #BR if the address in r/m32 is lower than the lower
BNDCL bnd, r/m32
bound in bnd.LB.
F3 0F 1A /r
RM
V/NE
MPX
Generate a #BR if the address in r/m64 is lower than the lower
BNDCL bnd, r/m64
bound in bnd.LB.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
RM
ModRM:reg (w)
ModRM:r/m (r)
N/A
Description
Compare the address in the second operand with the lower bound in bnd. The second operand can be either a
register or memory operand. If the address is lower than the lower bound in bnd.LB, it will set BNDSTATUS to 01H
and signal a #BR exception.
This instruction does not cause any memory access, and does not read or write any flags.
Operation
BNDCL BND, reg
IF reg < BND.LB Then
BNDSTATUS := 01H;
#BR;
FI;
BNDCL BND, mem
TEMP := LEA(mem);
IF TEMP < BND.LB Then
BNDSTATUS := 01H;
#BR;
FI;
Intel C/C++ Compiler Intrinsic Equivalent
BNDCL void _bnd_chk_ptr_lbounds(const void *q)
Flags Affected
None
Protected Mode Exceptions
#BR
If lower bound check fails.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 67H prefix is not used and CS.D=0.
If 67H prefix is used and CS.D=1.
3-108
Vol. 2A
BNDCL-Check Lower Bound
INSTRUCTION SET REFERENCE, A-L
Real-Address Mode Exceptions
#BR
If lower bound check fails.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
Virtual-8086 Mode Exceptions
#BR
If lower bound check fails.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#UD
If ModRM.r/m and REX encodes BND4-BND15 when Intel MPX is enabled.
Same exceptions as in protected mode.
BNDCL-Check Lower Bound
Vol. 2A
3-109
INSTRUCTION SET REFERENCE, A-L
BNDCU/BNDCN-Check Upper Bound
Opcode/
Op/En
64/32 bit
CPUID
Description
Instruction
Mode
Feature
Support
Flag
F2 0F 1A /r
RM
NE/V
MPX
Generate a #BR if the address in r/m32 is higher than the upper
BNDCU bnd, r/m32
bound in bnd.UB (bnb.UB in 1's complement form).
F2 0F 1A /r
RM
V/NE
MPX
Generate a #BR if the address in r/m64 is higher than the upper
BNDCU bnd, r/m64
bound in bnd.UB (bnb.UB in 1's complement form).
F2 0F 1B /r
RM
NE/V
MPX
Generate a #BR if the address in r/m32 is higher than the upper
BNDCN bnd, r/m32
bound in bnd.UB (bnb.UB not in 1's complement form).
F2 0F 1B /r
RM
V/NE
MPX
Generate a #BR if the address in r/m64 is higher than the upper
BNDCN bnd, r/m64
bound in bnd.UB (bnb.UB not in 1's complement form).
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
RM
ModRM:reg (w)
ModRM:r/m (r)
N/A
Description
Compare the address in the second operand with the upper bound in bnd. The second operand can be either a
register or a memory operand. If the address is higher than the upper bound in bnd.UB, it will set BNDSTATUS to
01H and signal a #BR exception.
BNDCU perform 1’s complement operation on the upper bound of bnd first before proceeding with address compar-
ison. BNDCN perform address comparison directly using the upper bound in bnd that is already reverted out of 1’s
complement form.
This instruction does not cause any memory access, and does not read or write any flags.
Effective address computation of m32/64 has identical behavior to LEA
Operation
BNDCU BND, reg
IF reg > NOT(BND.UB) Then
BNDSTATUS := 01H;
#BR;
FI;
BNDCU BND, mem
TEMP := LEA(mem);
IF TEMP > NOT(BND.UB) Then
BNDSTATUS := 01H;
#BR;
FI;
BNDCN BND, reg
IF reg > BND.UB Then
BNDSTATUS := 01H;
#BR;
FI;
3-110
Vol. 2A
BNDCU/BNDCN-Check Upper Bound
INSTRUCTION SET REFERENCE, A-L
BNDCN BND, mem
TEMP := LEA(mem);
IF TEMP > BND.UB Then
BNDSTATUS := 01H;
#BR;
FI;
Intel C/C++ Compiler Intrinsic Equivalent
BNDCU .void _bnd_chk_ptr_ubounds(const void *q)
Flags Affected
None
Protected Mode Exceptions
#BR
If upper bound check fails.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 67H prefix is not used and CS.D=0.
If 67H prefix is used and CS.D=1.
Real-Address Mode Exceptions
#BR
If upper bound check fails.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
Virtual-8086 Mode Exceptions
#BR
If upper bound check fails.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#UD
If ModRM.r/m and REX encodes BND4-BND15 when Intel MPX is enabled.
Same exceptions as in protected mode.
BNDCU/BNDCN-Check Upper Bound
Vol. 2A
3-111
INSTRUCTION SET REFERENCE, A-L
BNDLDX-Load Extended Bounds Using Address Translation
Opcode/
Op/En
64/32 bit
CPUID
Description
Instruction
Mode
Feature
Support
Flag
NP 0F 1A /r
RM
V/V
MPX
Load the bounds stored in a bound table entry (BTE) into bnd with
BNDLDX bnd, mib
address translation using the base of mib and conditional on the
index of mib matching the pointer value in the BTE.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
SIB.base (r): Address of pointer
RM
ModRM:reg (w)
N/A
SIB.index(r)
Description
BNDLDX uses the linear address constructed from the base register and displacement of the SIB-addressing form
of the memory operand (mib) to perform address translation to access a bound table entry and conditionally load
the bounds in the BTE to the destination. The destination register is updated with the bounds in the BTE, if the
content of the index register of mib matches the pointer value stored in the BTE.
If the pointer value comparison fails, the destination is updated with INIT bounds (lb = 0x0, ub = 0x0) (note: as
articulated earlier, the upper bound is represented using 1's complement, therefore, the 0x0 value of upper bound
allows for access to full memory).
This instruction does not cause memory access to the linear address of mib nor the effective address referenced by
the base, and does not read or write any flags.
Segment overrides apply to the linear address computation with the base of mib, and are used during address
translation to generate the address of the bound table entry. By default, the address of the BTE is assumed to be
linear address. There are no segmentation checks performed on the base of mib.
The base of mib will not be checked for canonical address violation as it does not access memory.
Any encoding of this instruction that does not specify base or index register will treat those registers as zero
(constant). The reg-reg form of this instruction will remain a NOP.
The scale field of the SIB byte has no effect on these instructions and is ignored.
The bound register may be partially updated on memory faults. The order in which memory operands are loaded is
implementation specific.
Operation
base := mib.SIB.base ? mib.SIB.base + Disp: 0;
ptr_value := mib.SIB.index ? mib.SIB.index : 0;
Outside 64-bit Mode
A_BDE[31:0] := (Zero_extend32(base[31:12] « 2) + (BNDCFG[31:12] «12 );
A_BT[31:0] := LoadFrom(A_BDE );
IF A_BT[0] equal 0 Then
BNDSTATUS := A_BDE | 02H;
#BR;
FI;
A_BTE[31:0] := (Zero_extend32(base[11:2] « 4) + (A_BT[31:2] « 2 );
Temp_lb[31:0] := LoadFrom(A_BTE);
Temp_ub[31:0] := LoadFrom(A_BTE + 4);
Temp_ptr[31:0] := LoadFrom(A_BTE + 8);
IF Temp_ptr equal ptr_value Then
BND.LB := Temp_lb;
BND.UB := Temp_ub;
3-112
Vol. 2A
BNDLDX-Load Extended Bounds Using Address Translation
INSTRUCTION SET REFERENCE, A-L
ELSE
BND.LB := 0;
BND.UB := 0;
FI;
In 64-bit Mode
A_BDE[63:0] := (Zero_extend64(base[47+MAWA:20] « 3) + (BNDCFG[63:12] «12 );1
A_BT[63:0] := LoadFrom(A_BDE);
IF A_BT[0] equal 0 Then
BNDSTATUS := A_BDE | 02H;
#BR;
FI;
A_BTE[63:0] := (Zero_extend64(base[19:3] « 5) + (A_BT[63:3] « 3 );
Temp_lb[63:0] := LoadFrom(A_BTE);
Temp_ub[63:0] := LoadFrom(A_BTE + 8);
Temp_ptr[63:0] := LoadFrom(A_BTE + 16);
IF Temp_ptr equal ptr_value Then
BND.LB := Temp_lb;
BND.UB := Temp_ub;
ELSE
BND.LB := 0;
BND.UB := 0;
FI;
Intel C/C++ Compiler Intrinsic Equivalent
BNDLDX: Generated by compiler as needed.
Flags Affected
None.
Protected Mode Exceptions
#BR
If the bound directory entry is invalid.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 67H prefix is not used and CS.D=0.
If 67H prefix is used and CS.D=1.
#GP(0)
If a destination effective address of the Bound Table entry is outside the DS segment limit.
If DS register contains a NULL segment selector.
#PF(fault code)
If a page fault occurs.
Real-Address Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
#GP(0)
If a destination effective address of the Bound Table entry is outside the DS segment limit.
1. If CPL < 3, the supervisor MAWA (MAWAS) is used; this value is 0. If CPL = 3, the user MAWA (MAWAU) is used; this value is enumer-
ated in CPUID.(EAX=07H,ECX=0H):ECX.MAWAU[bits 21:17]. See Appendix E.3.1 of Intel® 64 and IA-32 Architectures Software
Developer’s Manual, Volume 1.
BNDLDX-Load Extended Bounds Using Address Translation
Vol. 2A
3-113
INSTRUCTION SET REFERENCE, A-L
Virtual-8086 Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
#GP(0)
If a destination effective address of the Bound Table entry is outside the DS segment limit.
#PF(fault code)
If a page fault occurs.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#BR
If the bound directory entry is invalid.
#UD
If ModRM is RIP relative.
If the LOCK prefix is used.
If ModRM.r/m and REX encodes BND4-BND15 when Intel MPX is enabled.
#GP(0)
If the memory address (A_BDE or A_BTE) is in a non-canonical form.
#PF(fault code)
If a page fault occurs.
3-114
Vol. 2A
BNDLDX-Load Extended Bounds Using Address Translation
INSTRUCTION SET REFERENCE, A-L
BNDMK-Make Bounds
Opcode/
Op/En
64/32 bit
CPUID
Description
Instruction
Mode
Feature
Support
Flag
F3 0F 1B /r
RM
NE/V
MPX
Make lower and upper bounds from m32 and store them in bnd.
BNDMK bnd, m32
F3 0F 1B /r
RM
V/NE
MPX
Make lower and upper bounds from m64 and store them in bnd.
BNDMK bnd, m64
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
RM
ModRM:reg (w)
ModRM:r/m (r)
N/A
Description
Makes bounds from the second operand and stores the lower and upper bounds in the bound register bnd. The
second operand must be a memory operand. The content of the base register from the memory operand is stored
in the lower bound bnd.LB. The 1's complement of the effective address of m32/m64 is stored in the upper bound
b.UB. Computation of m32/m64 has identical behavior to LEA.
This instruction does not cause any memory access, and does not read or write any flags.
If the instruction did not specify base register, the lower bound will be zero. The reg-reg form of this instruction
retains legacy behavior (NOP).
The instruction causes an invalid-opcode exception (#UD) if executed in 64-bit mode with RIP-relative addressing.
Operation
BND.LB := SRCMEM.base;
IF 64-bit mode Then
BND.UB := NOT(LEA.64_bits(SRCMEM));
ELSE
BND.UB := Zero_Extend.64_bits(NOT(LEA.32_bits(SRCMEM)));
FI;
Intel C/C++ Compiler Intrinsic Equivalent
BNDMKvoid * _bnd_set_ptr_bounds(const void * q, size_t size);
Flags Affected
None.
Protected Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 67H prefix is not used and CS.D=0.
If 67H prefix is used and CS.D=1.
Real-Address Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
BNDMK-Make Bounds
Vol. 2A
3-115
INSTRUCTION SET REFERENCE, A-L
Virtual-8086 Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m and REX encodes BND4-BND15 when Intel MPX is enabled.
If RIP-relative addressing is used.
#SS(0)
If the memory address referencing the SS segment is in a non-canonical form.
#GP(0)
If the memory address is in a non-canonical form.
Same exceptions as in protected mode.
3-116
Vol. 2A
BNDMK-Make Bounds
INSTRUCTION SET REFERENCE, A-L
BNDMOV-Move Bounds
Opcode/
Op/En
64/32 bit
CPUID
Description
Instruction
Mode
Feature
Support
Flag
66 0F 1A /r
RM
NE/V
MPX
Move lower and upper bound from bnd2/m64 to bound register
BNDMOV bnd1, bnd2/m64
bnd1.
66 0F 1A /r
RM
V/NE
MPX
Move lower and upper bound from bnd2/m128 to bound register
BNDMOV bnd1, bnd2/m128
bnd1.
66 0F 1B /r
MR
NE/V
MPX
Move lower and upper bound from bnd2 to bnd1/m64.
BNDMOV bnd1/m64, bnd2
66 0F 1B /r
MR
V/NE
MPX
Move lower and upper bound from bnd2 to bound register
BNDMOV bnd1/m128, bnd2
bnd1/m128.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
RM
ModRM:reg (w)
ModRM:r/m (r)
N/A
MR
ModRM:r/m (w)
ModRM:reg (r)
N/A
Description
BNDMOV moves a pair of lower and upper bound values from the source operand (the second operand) to the
destination (the first operand). Each operation is 128-bit move. The exceptions are same as the MOV instruction.
The memory format for loading/store bounds in 64-bit mode is shown in Figure 3-5.
BNDMOV to memory in 64-bit mode
Upper Bound (UB)
Lower Bound (LB)
16
8
0
Byte offset
BNDMOV to memory in 32-bit mode
Upper Bound (UB)
Lower Bound (LB)
16
8
4
0
Byte offset
Figure 3-5. Memory Layout of BNDMOV to/from Memory
This instruction does not change flags.
Operation
BNDMOV register to register
DEST.LB := SRC.LB;
DEST.UB := SRC.UB;
BNDMOV-Move Bounds
Vol. 2A
3-117
INSTRUCTION SET REFERENCE, A-L
BNDMOV from memory
IF 64-bit mode THEN
DEST.LB := LOAD_QWORD(SRC);
DEST.UB := LOAD_QWORD(SRC+8);
ELSE
DEST.LB := LOAD_DWORD_ZERO_EXT(SRC);
DEST.UB := LOAD_DWORD_ZERO_EXT(SRC+4);
FI;
BNDMOV to memory
IF 64-bit mode THEN
DEST[63:0] := SRC.LB;
DEST[127:64] := SRC.UB;
ELSE
DEST[31:0] := SRC.LB;
DEST[63:32] := SRC.UB;
FI;
Intel C/C++ Compiler Intrinsic Equivalent
BNDMOV void * _bnd_copy_ptr_bounds(const void *q, const void *r)
Flags Affected
None.
Protected Mode Exceptions
#UD
If the LOCK prefix is used but the destination is not a memory operand.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 67H prefix is not used and CS.D=0.
If 67H prefix is used and CS.D=1.
#SS(0)
If the memory operand effective address is outside the SS segment limit.
#GP(0)
If the memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the destination operand points to a non-writable segment
If the DS, ES, FS, or GS segment register contains a NULL segment selector.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while CPL is 3.
#PF(fault code)
If a page fault occurs.
Real-Address Mode Exceptions
#UD
If the LOCK prefix is used but the destination is not a memory operand.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
#GP(0)
If the memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS
If the memory operand effective address is outside the SS segment limit.
3-118
Vol. 2A
BNDMOV-Move Bounds
INSTRUCTION SET REFERENCE, A-L
Virtual-8086 Mode Exceptions
#UD
If the LOCK prefix is used but the destination is not a memory operand.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
#GP(0)
If the memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS(0)
If the memory operand effective address is outside the SS segment limit.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while CPL is 3.
#PF(fault code)
If a page fault occurs.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#UD
If the LOCK prefix is used but the destination is not a memory operand.
If ModRM.r/m and REX encodes BND4-BND15 when Intel MPX is enabled.
#SS(0)
If the memory address referencing the SS segment is in a non-canonical form.
#GP(0)
If the memory address is in a non-canonical form.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while CPL is 3.
#PF(fault code)
If a page fault occurs.
BNDMOV-Move Bounds
Vol. 2A
3-119
INSTRUCTION SET REFERENCE, A-L
BNDSTX-Store Extended Bounds Using Address Translation
Opcode/
Op/En
64/32 bit
CPUID
Description
Instruction
Mode
Feature
Support
Flag
NP 0F 1B /r
MR
V/V
MPX
Store the bounds in bnd and the pointer value in the index register
BNDSTX mib, bnd
of mib to a bound table entry (BTE) with address translation using
the base of mib.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
SIB.base (r): Address of pointer
MR
ModRM:reg (r)
N/A
SIB.index(r)
Description
BNDSTX uses the linear address constructed from the displacement and base register of the SIB-addressing form
of the memory operand (mib) to perform address translation to store to a bound table entry. The bounds in the
source operand bnd are written to the lower and upper bounds in the BTE. The content of the index register of mib
is written to the pointer value field in the BTE.
This instruction does not cause memory access to the linear address of mib nor the effective address referenced by
the base, and does not read or write any flags.
Segment overrides apply to the linear address computation with the base of mib, and are used during address
translation to generate the address of the bound table entry. By default, the address of the BTE is assumed to be
linear address. There are no segmentation checks performed on the base of mib.
The base of mib will not be checked for canonical address violation as it does not access memory.
Any encoding of this instruction that does not specify base or index register will treat those registers as zero
(constant). The reg-reg form of this instruction will remain a NOP.
The scale field of the SIB byte has no effect on these instructions and is ignored.
The bound register may be partially updated on memory faults. The order in which memory operands are loaded is
implementation specific.
Operation
base := mib.SIB.base ? mib.SIB.base + Disp: 0;
ptr_value := mib.SIB.index ? mib.SIB.index : 0;
Outside 64-bit Mode
A_BDE[31:0] := (Zero_extend32(base[31:12] « 2) + (BNDCFG[31:12] «12 );
A_BT[31:0] := LoadFrom(A_BDE);
IF A_BT[0] equal 0 Then
BNDSTATUS := A_BDE | 02H;
#BR;
FI;
A_DEST[31:0] := (Zero_extend32(base[11:2] « 4) + (A_BT[31:2] « 2 ); // address of Bound table entry
A_DEST[8][31:0] := ptr_value;
A_DEST[0][31:0] := BND.LB;
A_DEST[4][31:0] := BND.UB;
3-120
Vol. 2A
BNDSTX-Store Extended Bounds Using Address Translation
INSTRUCTION SET REFERENCE, A-L
In 64-bit Mode
A_BDE[63:0] := (Zero_extend64(base[47+MAWA:20] « 3) + (BNDCFG[63:12] «12 );1
A_BT[63:0] := LoadFrom(A_BDE);
IF A_BT[0] equal 0 Then
BNDSTATUS := A_BDE | 02H;
#BR;
FI;
A_DEST[63:0] := (Zero_extend64(base[19:3] « 5) + (A_BT[63:3] « 3 ); // address of Bound table entry
A_DEST[16][63:0] := ptr_value;
A_DEST[0][63:0] := BND.LB;
A_DEST[8][63:0] := BND.UB;
Intel C/C++ Compiler Intrinsic Equivalent
BNDSTX: _bnd_store_ptr_bounds(const void **ptr_addr, const void *ptr_val);
Flags Affected
None.
Protected Mode Exceptions
#BR
If the bound directory entry is invalid.
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 67H prefix is not used and CS.D=0.
If 67H prefix is used and CS.D=1.
#GP(0)
If a destination effective address of the Bound Table entry is outside the DS segment limit.
If DS register contains a NULL segment selector.
If the destination operand points to a non-writable segment
#PF(fault code)
If a page fault occurs.
Real-Address Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
#GP(0)
If a destination effective address of the Bound Table entry is outside the DS segment limit.
Virtual-8086 Mode Exceptions
#UD
If the LOCK prefix is used.
If ModRM.r/m encodes BND4-BND7 when Intel MPX is enabled.
If 16-bit addressing is used.
#GP(0)
If a destination effective address of the Bound Table entry is outside the DS segment limit.
#PF(fault code)
If a page fault occurs.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
1. If CPL < 3, the supervisor MAWA (MAWAS) is used; this value is 0. If CPL = 3, the user MAWA (MAWAU) is used; this value is enumer-
ated in CPUID.(EAX=07H,ECX=0H):ECX.MAWAU[bits 21:17]. See Appendix E.3.1 of Intel® 64 and IA-32 Architectures Software
Developer’s Manual, Volume 1.
BNDSTX-Store Extended Bounds Using Address Translation
Vol. 2A
3-121
INSTRUCTION SET REFERENCE, A-L
64-Bit Mode Exceptions
#BR
If the bound directory entry is invalid.
#UD
If ModRM is RIP relative.
If the LOCK prefix is used.
If ModRM.r/m and REX encodes BND4-BND15 when Intel MPX is enabled.
#GP(0)
If the memory address (A_BDE or A_BTE) is in a non-canonical form.
If the destination operand points to a non-writable segment
#PF(fault code)
If a page fault occurs.
3-122
Vol. 2A
BNDSTX-Store Extended Bounds Using Address Translation
INSTRUCTION SET REFERENCE, A-L
BOUND-Check Array Index Against Bounds
Opcode
Instruction
Op/
64-bit
Compat/
Description
En
Mode
Leg Mode
62 /r
BOUND r16, m16&16
RM
Invalid
Valid
Check if r16 (array index) is within bounds
specified by m16&16.
62 /r
BOUND r32, m32&32
RM
Invalid
Valid
Check if r32 (array index) is within bounds
specified by m32&32.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (r)
ModRM:r/m (r)
N/A
N/A
Description
BOUND determines if the first operand (array index) is within the bounds of an array specified the second operand
(bounds operand). The array index is a signed integer located in a register. The bounds operand is a memory loca-
tion that contains a pair of signed doubleword-integers (when the operand-size attribute is 32) or a pair of signed
word-integers (when the operand-size attribute is 16). The first doubleword (or word) is the lower bound of the
array and the second doubleword (or word) is the upper bound of the array. The array index must be greater than
or equal to the lower bound and less than or equal to the upper bound plus the operand size in bytes. If the index
is not within bounds, a BOUND range exceeded exception (#BR) is signaled. When this exception is generated, the
saved return instruction pointer points to the BOUND instruction.
The bounds limit data structure (two words or doublewords containing the lower and upper limits of the array) is
usually placed just before the array itself, making the limits addressable via a constant offset from the beginning of
the array. Because the address of the array already will be present in a register, this practice avoids extra bus
cycles to obtain the effective address of the array bounds.
This instruction executes as described in compatibility mode and legacy mode. It is not valid in 64-bit mode.
Operation
IF 64bit Mode
THEN
#UD;
ELSE
IF (ArrayIndex < LowerBound OR ArrayIndex > UpperBound) THEN
(* Below lower bound or above upper bound *)
IF <equation for PL enabled> THEN BNDSTATUS := 0
#BR;
FI;
FI;
Flags Affected
None.
BOUND-Check Array Index Against Bounds
Vol. 2A
3-123
INSTRUCTION SET REFERENCE, A-L
Protected Mode Exceptions
#BR
If the bounds test fails.
#UD
If second operand is not a memory location.
If the LOCK prefix is used.
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the DS, ES, FS, or GS register contains a NULL segment selector.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
Real-Address Mode Exceptions
#BR
If the bounds test fails.
#UD
If second operand is not a memory location.
If the LOCK prefix is used.
#GP
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS
If a memory operand effective address is outside the SS segment limit.
Virtual-8086 Mode Exceptions
#BR
If the bounds test fails.
#UD
If second operand is not a memory location.
If the LOCK prefix is used.
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#UD
If in 64-bit mode.
3-124
Vol. 2A
BOUND-Check Array Index Against Bounds
INSTRUCTION SET REFERENCE, A-L
BSF-Bit Scan Forward
Opcode
Instruction
Op/
64-bit
Compat/
Description
En
Mode
Leg Mode
0F BC /r
BSF r16, r/m16
RM
Valid
Valid
Bit scan forward on r/m16.
0F BC /r
BSF r32, r/m32
RM
Valid
Valid
Bit scan forward on r/m32.
REX.W + 0F BC /r
BSF r64, r/m64
RM
Valid
N.E.
Bit scan forward on r/m64.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (w)
ModRM:r/m (r)
N/A
N/A
Description
Searches the source operand (second operand) for the least significant set bit (1 bit). If a least significant 1 bit is
found, its bit index is stored in the destination operand (first operand). The source operand can be a register or a
memory location; the destination operand is a register. The bit index is an unsigned offset from bit 0 of the source
operand. If the content of the source operand is 0, the content of the destination operand is undefined.
In 64-bit mode, the instruction’s default operation size is 32 bits. Using a REX prefix in the form of REX.R permits
access to additional registers (R8-R15). Using a REX prefix in the form of REX.W promotes operation to 64 bits. See
the summary chart at the beginning of this section for encoding data and limits.
Operation
IF SRC = 0
THEN
ZF := 1;
DEST is undefined;
ELSE
ZF := 0;
temp := 0;
WHILE Bit(SRC, temp) = 0
DO
temp := temp + 1;
OD;
DEST := temp;
FI;
Flags Affected
The ZF flag is set to 1 if the source operand is 0; otherwise, the ZF flag is cleared. The CF, OF, SF, AF, and PF flags
are undefined.
Protected Mode Exceptions
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the DS, ES, FS, or GS register contains a NULL segment selector.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
#UD
If the LOCK prefix is used.
BSF-Bit Scan Forward
Vol. 2A
3-125
INSTRUCTION SET REFERENCE, A-L
Real-Address Mode Exceptions
#GP
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS
If a memory operand effective address is outside the SS segment limit.
#UD
If the LOCK prefix is used.
Virtual-8086 Mode Exceptions
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made.
#UD
If the LOCK prefix is used.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#SS(0)
If a memory address referencing the SS segment is in a non-canonical form.
#GP(0)
If the memory address is in a non-canonical form.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
#UD
If the LOCK prefix is used.
3-126
Vol. 2A
BSF-Bit Scan Forward
INSTRUCTION SET REFERENCE, A-L
BSR-Bit Scan Reverse
Opcode
Instruction
Op/
64-bit
Compat/
Description
En
Mode
Leg Mode
0F BD /r
BSR r16, r/m16
RM
Valid
Valid
Bit scan reverse on r/m16.
0F BD /r
BSR r32, r/m32
RM
Valid
Valid
Bit scan reverse on r/m32.
REX.W + 0F BD /r
BSR r64, r/m64
RM
Valid
N.E.
Bit scan reverse on r/m64.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (w)
ModRM:r/m (r)
N/A
N/A
Description
Searches the source operand (second operand) for the most significant set bit (1 bit). If a most significant 1 bit is
found, its bit index is stored in the destination operand (first operand). The source operand can be a register or a
memory location; the destination operand is a register. The bit index is an unsigned offset from bit 0 of the source
operand. If the content source operand is 0, the content of the destination operand is undefined.
In 64-bit mode, the instruction’s default operation size is 32 bits. Using a REX prefix in the form of REX.R permits
access to additional registers (R8-R15). Using a REX prefix in the form of REX.W promotes operation to 64 bits. See
the summary chart at the beginning of this section for encoding data and limits.
Operation
IF SRC = 0
THEN
ZF := 1;
DEST is undefined;
ELSE
ZF := 0;
temp := OperandSize - 1;
WHILE Bit(SRC, temp) = 0
DO
temp := temp - 1;
OD;
DEST := temp;
FI;
Flags Affected
The ZF flag is set to 1 if the source operand is 0; otherwise, the ZF flag is cleared. The CF, OF, SF, AF, and PF flags
are undefined.
Protected Mode Exceptions
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
If the DS, ES, FS, or GS register contains a NULL segment selector.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
#UD
If the LOCK prefix is used.
BSR-Bit Scan Reverse
Vol. 2A
3-127
INSTRUCTION SET REFERENCE, A-L
Real-Address Mode Exceptions
#GP
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS
If a memory operand effective address is outside the SS segment limit.
#UD
If the LOCK prefix is used.
Virtual-8086 Mode Exceptions
#GP(0)
If a memory operand effective address is outside the CS, DS, ES, FS, or GS segment limit.
#SS(0)
If a memory operand effective address is outside the SS segment limit.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made.
#UD
If the LOCK prefix is used.
Compatibility Mode Exceptions
Same exceptions as in protected mode.
64-Bit Mode Exceptions
#SS(0)
If a memory address referencing the SS segment is in a non-canonical form.
#GP(0)
If the memory address is in a non-canonical form.
#PF(fault-code)
If a page fault occurs.
#AC(0)
If alignment checking is enabled and an unaligned memory reference is made while the
current privilege level is 3.
#UD
If the LOCK prefix is used.
3-128
Vol. 2A
BSR-Bit Scan Reverse
INSTRUCTION SET REFERENCE, A-L
BSWAP-Byte Swap
Opcode
Instruction
Op/
64-bit
Compat/
Description
En
Mode
Leg Mode
0F C8+rd
BSWAP r32
O
Valid*
Valid
Reverses the byte order of a 32-bit register.
REX.W + 0F C8+rd
BSWAP r64
O
Valid
N.E.
Reverses the byte order of a 64-bit register.
NOTES:
* See IA-32 Architecture Compatibility section below.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
O
opcode + rd (r, w)
N/A
N/A
N/A
Description
Reverses the byte order of a 32-bit or 64-bit (destination) register. This instruction is provided for converting little-
endian values to big-endian format and vice versa. To swap bytes in a word value (16-bit register), use the XCHG
instruction. When the BSWAP instruction references a 16-bit register, the result is undefined.
In 64-bit mode, the instruction’s default operation size is 32 bits. Using a REX prefix in the form of REX.R permits
access to additional registers (R8-R15). Using a REX prefix in the form of REX.W promotes operation to 64 bits. See
the summary chart at the beginning of this section for encoding data and limits.
IA-32 Architecture Legacy Compatibility
The BSWAP instruction is not supported on IA-32 processors earlier than the Intel486™ processor family. For
compatibility with this instruction, software should include functionally equivalent code for execution on Intel
processors earlier than the Intel486 processor family.
Operation
TEMP := DEST
IF 64-bit mode AND OperandSize = 64
THEN
DEST[7:0] := TEMP[63:56];
DEST[15:8] := TEMP[55:48];
DEST[23:16] := TEMP[47:40];
DEST[31:24] := TEMP[39:32];
DEST[39:32] := TEMP[31:24];
DEST[47:40] := TEMP[23:16];
DEST[55:48] := TEMP[15:8];
DEST[63:56] := TEMP[7:0];
ELSE
DEST[7:0] := TEMP[31:24];
DEST[15:8] := TEMP[23:16];
DEST[23:16] := TEMP[15:8];
DEST[31:24] := TEMP[7:0];
FI;
Flags Affected
None.
Exceptions (All Operating Modes)
#UD
If the LOCK prefix is used.
BSWAP-Byte Swap
Vol. 2A
3-129
INSTRUCTION SET REFERENCE, A-L
BT-Bit Test
Opcode
Instruction
Op/
64-bit
Compat/
Description
En
Mode
Leg Mode
0F A3 /r
BT r/m16, r16
MR
Valid
Valid
Store selected bit in CF flag.
0F A3 /r
BT r/m32, r32
MR
Valid
Valid
Store selected bit in CF flag.
REX.W + 0F A3 /r
BT r/m64, r64
MR
Valid
N.E.
Store selected bit in CF flag.
0F BA /4 ib
BT r/m16, imm8
MI
Valid
Valid
Store selected bit in CF flag.
0F BA /4 ib
BT r/m32, imm8
MI
Valid
Valid
Store selected bit in CF flag.
REX.W + 0F BA /4 ib
BT r/m64, imm8
MI
Valid
N.E.
Store selected bit in CF flag.
Instruction Operand Encoding
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
MR
ModRM:r/m (r)
ModRM:reg (r)
N/A
N/A
MI
ModRM:r/m (r)
imm8
N/A
N/A
Description
Selects the bit in a bit string (specified with the first operand, called the bit base) at the bit-position designated by
the bit offset (specified by the second operand) and stores the value of the bit in the CF flag. The bit base operand
can be a register or a memory location; the bit offset operand can be a register or an immediate value:
If the bit base operand specifies a register, the instruction takes the modulo 16, 32, or 64 of the bit offset
operand (modulo size depends on the mode and register size; 64-bit operands are available only in 64-bit
mode).
If the bit base operand specifies a memory location, the operand represents the address of the byte in memory
that contains the bit base (bit 0 of the specified byte) of the bit string. The range of the bit position that can be
referenced by the offset operand depends on the operand size.
See also: Bit(BitBase, BitOffset) on page 3-11.
Some assemblers support immediate bit offsets larger than 31 by using the immediate bit offset field in combina-
tion with the displacement field of the memory operand. In this case, the low-order 3 or 5 bits (3 for 16-bit oper-
ands, 5 for 32-bit operands) of the immediate bit offset are stored in the immediate bit offset field, and the high-
order bits are shifted and combined with the byte displacement in the addressing mode by the assembler. The
processor will ignore the high order bits if they are not zero.
When accessing a bit in memory, the processor may access 4 bytes starting from the memory address for a 32-bit
operand size, using by the following relationship:
Effective Address + (4 ∗ (BitOffset DIV 32))
Or, it may access 2 bytes starting from the memory address for a 16-bit operand, using this relationship:
Effective Address + (2 ∗ (BitOffset DIV 16))
It may do so even when only a single byte needs to be accessed to reach the given bit. When using this bit
addressing mechanism, software should avoid referencing areas of memory close to address space holes. In partic-
ular, it should avoid references to memory-mapped I/O registers. Instead, software should use the MOV instruc-
tions to load from or store to these addresses, and use the register form of these instructions to manipulate the
data.
In 64-bit mode, the instruction’s default operation size is 32 bits. Using a REX prefix in the form of REX.R permits
access to additional registers (R8-R15). Using a REX prefix in the form of REX.W promotes operation to 64 bit oper-
ands. See the summary chart at the beginning of this section for encoding data and limits.
Operation
CF := Bit(BitBase, BitOffset);
3-130
Vol. 2A
BT-Bit Test















Content      ..     16      17      18      19     ..
