FANUC Series Series 16i-TB, Series 18i-TB, Series 160i-TB, Series 180i-TB. OPERATOR’S MANUAL - page 22
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
8.8.2
The contents of the specified file number are read to the memory of NC.
Reading Files
Procedure for Reading Files
1
Press the EDIT switch on the machine operator’s panel.
For the two-path control, select the tool post for which a file is to be
input in memory with the tool post selection switch.
2
Press function key
PROG
3
Press the rightmost soft key
(next-menu key).
4
Press soft key [FLOPPY].
5
Press soft key [(OPRT)].
6
Press soft key [READ].
DIRECTORY (FLOPPY)
O0001 N00000
NO. FILE NAME
(METER) VOL
READ
FILE NO. =
PROGRAM NO. =
>_
EDIT
* * * *
* * *
* * *
11 : 55 : 04
F SET
O SET
STOP
CAN
EXEC
7
Enter a file number.
8
Press soft key [F SET].
9
To modify the program number, enter the program number, then press
soft key [O SET].
10
Press soft key [EXEC]. The file number indicated in the lower-left
corner of the screen is automatically incremented by one.
11
Press soft key [CAN] to return to the soft key display shown in the
screen of Fig. 8.8.1. (b).
609
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
8.8.3
Any program in the memory of the CNC unit can be output to a floppy
as a file.
Outputting Programs
Procedure for Outputting Programs
1
Press the EDIT switch on the machine operator’s panel.
For the two-path control, select the tool post for which a program is to
be output from floppy with the tool post selection switch.
2
Press function key
PROG
3
Press the rightmost soft key
(next-menu key).
4
Press soft key [FLOPPY].
5
Press soft key [(OPRT)].
6
Press soft key [PUNCH]
DIRECTORY (FLOPPY)
O0002 N01000
NO. FILE NAME
(METER) VOL
PUNCH
FILE NO. =
PROGRAM NO. =
>_
EDIT
* * * *
* * *
* * *
11 : 55 : 26
F SET
O SET
STOP
CAN
EXEC
7
Enter a program number. To write all programs into a single file, enter
-9999 in the program number field. In this case, the file name
“ALL.PROGRAM” is registered.
8
Press soft key [O SET].
9
Press soft key [EXEC]. The program or programs specified in step 7
are written after the last file on the floppy. To output the program after
deleting files starting with an existing file number, key in the file
number, then press soft key [F SET] followed by soft key [EXEC].
10
Press soft key [CAN] to return to the soft key display shown in the
screen of Fig. 8.8.1 (b).
610
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
8.8.4
The file with the specified file number is deleted.
Deleting Files
Procedure for Deleting Files
1
Press the EDIT switch on the machine operator’s panel.
2
Press function key
PROG
3
Press the rightmost soft key
(next-menu key).
4
Press soft key [FLOPPY].
5
Press soft key [(OPRT)].
6
Press soft key [DELETE].
DIRECTORY (FLOPPY)
O0001 N00000
NO. FILE NAME
(METER) VOL
DELETE
FILE NO. =
NAME=
>_
EDIT
* * * *
* * *
* * *
11 : 55 : 51
F SET
F
NAME
CAN
EXEC
7
Specify the file to be deleted.
When specifying the file with a file number, type the number and
press soft key [F SET]. When specifying the file with a file name,
type the name and press soft key [F NAME].
8
Press soft key [EXEC].
The file specified in the file number field is deleted. When a file is
deleted, the file numbers after the deleted file are each decremented
by one.
9
Press soft key [CAN] to return to the soft key display shown in the
screen of Fig. 8.8.1 (b).
611
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
Limitations
D Inputting file numbers
If
[F SET] or [O SET] is pressed without key inputting file number and
and program numbers
program number, file number or program number shows blank. When
with keys
0 is entered for file numbers or program numbers, 1 is displayed.
D I/O devices
To use channel 0 ,set a device number in parameter 102.
Set the I/O device number to parameter No. 0112 when channel 1 is used.
Set it to No. 0122 when channel 2 is used.
D Significant
For the numeral input in the data input area with FILE NO. and
digits
PROGRAM NO., only lower 4 digits become valid.
D Collation
When the data protection key on the machine operator’s panel is ON, no
programs are read from the floppy. They are verified against the contents
of the memory of the CNC instead.
ALARM
No.
Contents
An invalid file number or program number was entered.
71
(Specified program number is not found.)
Verification operation found a mismatch between a program
79
loaded into memory and the contents of the floppy
The datas et-ready signal (DR) for the input/output device is
turned off. (The no file error or duplicate file error occurred on
86
the input/output device because an invalid file number, pro-
gram number, or file name was entered.
612
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
CNC programs stored in memory can be grouped according to their
8.9
names, thus enabling the output of CNC programs in group units. Section
OUTPUTTING A
III-11.3.3 explains the display of a program listing for a specified group.
PROGRAM LIST FOR
A SPECIFIED GROUP
Procedure for Outputting a Program List for a Specified Group
Procedure
1
Display the program list screen for a group of programs, as described
in Section III-11.3.3.
PROGRAM DIRECTORY (GROUP)
O0001 N00010
PROGRAM (NUM.)
MEMORY (CHAR.)
USED:
60
3321
FREE:
2
429
O0020 (GEAR-1000 MAIN
)
O0040 (GEAR-1000 SUB-1
)
O0200 (GEAR-1000 SUB-2
)
O2000 (GEAR-1000 SUB-3
)
>_
EDIT
* * * *
* * *
* * *
* * *
16 : 52 : 13
PRGRM
DIR
(OPRT)
2
Press the [(OPRT)] operation soft key.
BG-EDT O-SRH
GROUP
3
Press the right-most soft key
(continuous menu key).
READ
PUNCH
4
Press the [PUNCH] operation soft key.
5
Press the [AL-GRP] operation soft key.
AL-GRP
STOP
CAN EXEC
The CNC programs in the group for which a search is made are
output. When these programs are output to a floppy disk, they are
output to a file named GROUP.PROGRAM.
613
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
To input/output a particular type of data, the corresponding screen is
8.10
usually selected. For example, the parameter screen is used for parameter
DATA INPUT/OUTPUT
input from or output to an external input/output unit, while the program
ON THE ALL IO
screen is used for program input or output. However, programs,
SCREEN
parameters, offset data, and macro variables can all be input and output
using a single common screen, that is, the ALL IO screen.
READ/PUNCH (PROGRAM)
O1234 N12345
I/O CHANNEL
3
TV CHECK
OFF
DEVICE NUM.
0
PUNCH CODE
ISO
BAUDRATE
4800
INPUT CODE
ASCII
STOP BIT
2
FEED OUTPUT
FEED
NULL INPUT (EIA)
NO
EOB OUTPUT (ISO) CR
TV CHECK (NOTES)
ON
BAUDRATE CLK. INNER
CD CHECK (232C)
OFF
RESET/ALARM
ON
PARITY BIT
OFF
SAT COMMAND HOST
INTERFACE
RS422
COM PROTCOL
A
END CODE
EXT
COM CODE
ASCII
(0:EIA
1:ISO)>1_
MDI
* * * *
* * *
* * *
* * *
12:34:56
PRGRM
PARAM
OFFSET
MACRO
(OPRT)
Fig. 8.10
ALL IO screen
(when channel 3 is being used for input/output)
614
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
8.10.1
Input/output-related parameters can be set on the ALL IO screen.
Parameters can be set, regardless of the mode.
Setting
Input/Output-Related
Parameters
Setting input/output-related parameters
Procedure
1
Press function key
SYSTEM
2
Press the rightmost soft key
(next-menu key) several times.
3
Press soft key [ALL IO] to display the ALL IO screen.
NOTE
1
If program or floppy is selected in EDIT mode, the program
directory or floppy screen is displayed.
2
When the power is first turned on, program is selected by
default.
READ/PUNCH (PROGRAM)
O1234 N12345
I/O CHANNEL
3
TV CHECK
OFF
DEVICE NUM.
0
PUNCH CODE
ISO
BAUDRATE
4800
INPUT CODE
ASCII
STOP BIT
2
FEED OUTPUT
FEED
NULL INPUT (EIA)
NO
EOB OUTPUT (ISO) CR
TV CHECK (NOTES)
ON
BAUDRATE CLK. INNER
CD CHECK (232C)
OFF
RESET/ALARM
ON
PARITY BIT
OFF
SAT COMMAND HOST
INTERFACE
RS422
COM PROTCOL
A
END CODE
EXT
COM CODE
ASCII
(0:EIA
1:ISO)>1_
MDI
* * * *
* * *
* * *
* * *
12:34:56
PRGRM
PARAM
OFFSET
MACRO
(OPRT)
NOTE
Baud rate clock, CD check (232C), reset/alarm report, and
the parity bit for parameter No.
134, as well as the
communication code, end code, communication protocol,
interface, and SAT command for parameter No. 135 are
displayed only when channel
3 is being used for
input/output.
4
Select the soft key corresponding to the desired type of data (program,
parameter, and so forth).
5
Set the parameters corresponding to the type of input/output unit to be
used.
(Parameter setting is possible regardless of the mode.)
615
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
8.10.2
A program can be input and output using the ALL IO screen.
When entering a program using a cassette or card, the user must specify
Inputting and
the input file containing the program (file search).
Outputting Programs
File search
Procedure
1
Press soft key [PRGRM] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode. A program directory is displayed.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
D A program directory is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
O0001 N00010
PROGRAM (NUM.)
MEMORY (CHAR.)
USED
:
60
3321
FREE
:
2
429
O0010 O0001 O0003 O0002 O0555 O0999
O0062 O0004 O0005 O1111 O0969 O6666
O0021 O1234 O0588 O0020 O0040
>_
EDIT
* * * *
* * *
* * *
* * *
14:46:09
F SRH
READ
PUNCH
DELETE
(OPRT)
4
Enter address N.
5
Enter the number of the file to be found.
D N0
The first floppy file is found.
D One of N1 to N9999
Among the files numbered from 1 to 9999, a specified file is found.
D N-9999
The file immediately after that used most recently is found.
D N-9998
When -9998 is specified, the next file is found. Then, each time
a file input/output operation is performed, N-9999 is automatically
inserted. This means that subsequent files can be sequentially
found automatically.
This state is canceled by specifying N0, N1 to N9999, or N-9999,
or upon a reset.
6
Press soft keys [F SRH] and [EXEC].
The specified file is found.
CAN
EXEC
616
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Explanations
D Difference between N0
When a file already exists in a cassette or card, specifying N0 or N1 has
and N1
the same effect. If N1 is specified when there is no file on the cassette or
card, an alarm is issued because the first file cannot be found. Specifying
N0 places the head at the start of the cassette or card, regardless of whether
the cassette/card already contains files. So, no alarm is issued in this case.
N0 can be used, for example, when a program is written into a new
cassette or card, or when a previously used cassette or card is used once
all the files it contains have been erased.
D Alarm issue during file
If an alarm (file search failure, for example) is generated during file
search
search, the CNC does not issue an alarm immediately. However, a P/S
alarm (No. 086) is issued if input/output is subsequently performed on
that file.
D File search using N-9999
Instead of sequentially searching for files by specifying actual file
numbers every time, the user can specify the first file number, then find
the subsequent files by specifying N-9999. When N-9999 is specified,
the time required for file search can be reduced.
Inputting a program
Procedure
1
Press soft key [PRGRM] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode. A program directory is displayed.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
D A program directory is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
O0001 N00010
PROGRAM (NUM.)
MEMORY (CHAR.)
USED
:
60
3321
FREE
:
2
429
O0010 O0001 O0003 O0002 O0555 O0999
O0062 O0004 O0005 O1111 O0969 O6666
O0021 O1234 O0588 O0020 O0040
>_
EDIT
* * * *
* * *
* * *
* * *
14:46:09
F SRH
READ
PUNCH
DELETE
(OPRT)
4
To specify a program number to be assigned to an input program,
enter address O, followed by the desired program number.
If no program number is specified, the program number in the file or
on the NC tape is assigned as is.
617
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
5
Press soft key [READ], then [EXEC].
STOP
CAN
EXEC
The program is input with the program number specified in step 4
assigned.
To cancel input, press soft key [CAN].
To stop input prior to its completion, press soft key [STOP].
Outputting a program
Procedure
1
Press soft key [PRGRM] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode. A program directory is displayed.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
D A program directory is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
O0001 N00010
PROGRAM (NUM.)
MEMORY (CHAR.)
USED
:
60
3321
FREE
:
2
429
O0010 O0001 O0003 O0002 O0555 O0999
O0062 O0004 O0005 O1111 O0969 O6666
O0021 O1234 O0588 O0020 O0040
>_
EDIT
* * * *
* * *
* * *
* * *
14:46:09
F SRH
READ
PUNCH
DELETE
(OPRT)
4
Enter address O.
5
Enter a desired program number.
If -9999 is entered, all programs in memory are output.
To output a range of programs, enter O
, Ojjjj. The
programs numbered from
to jjjj are output.
When bit 4 (SOR) of parameter No. 3107 for sorted display is set to 1
on the program library screen, programs are output in order, starting
from those having the smallest program numbers.
6
Press soft key [PUNCH], then [EXEC].
STOP
CAN
EXEC
The specified program or programs are output. If steps 4 and 5 are
omitted, the currently selected program is output.
To cancel output, press soft key [CAN].
To stop output prior to its completion, press soft key [STOP].
618
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Deleting files
Procedure
1
Press soft key [PRGRM] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode. A program directory is displayed.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
D A program directory is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
O0001 N00010
PROGRAM (NUM.)
MEMORY (CHAR.)
USED
:
60
3321
FREE
:
2
429
O0010 O0001 O0003 O0002 O0555 O0999
O0062 O0004 O0005 O1111 O0969 O6666
O0021 O1234 O0588 O0020 O0040
>_
EDIT
* * * *
* * *
* * *
* * *
14:46:09
F SRH
READ
PUNCH
DELETE
(OPRT)
4
Press soft key [DELETE].
5
Enter a file number, from 1 to 9999, to indicate the file to be deleted.
6
Press soft key [EXEC].
CAN
EXEC
The k-th file, specified in step 5, is deleted.
Explanations
D File numbers after
After deletion of the k-th file, the previous file numbers (k+1) to n are
deletion
decremented by 1 to k to (n-1).
Before deletion After deletion
1 to (k-1)
1 to (k-1)
k
Deleted
(k+1) to n
k to (n-1)
D Write protect
Before a file can be deleted, the write protect switch of the cassette must
be set to make the cassette writable.
619
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
8.10.3
Parameters can be input and output using the ALL IO screen.
Inputting and
Outputting Parameters
Inputting parameters
Procedure
1
Press soft key [PARAM] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
READ/PUNCH (PARAMETER)
O1234 N12345
I/O CHANNEL
3
TV CHECK
OFF
DEVICE NUM.
0
PUNCH CODE
ISO
BAUDRATE
4800
INPUT CODE
ASCII
STOP BIT
2
FEED OUTPUT
FEED
NULL INPUT (EIA)
NO
EOB OUTPUT (ISO) CR
TV CHECK (NOTES)
ON
BAUDRATE CLK. INNER
CD CHECK (232C)
OFF
RESET/ALARM
ON
PARITY BIT
OFF
COM CODE
ASCII
END CODE
EXT
COM PROTCOL
A
INTERFACE
RS422
SAT COMMAND HOST
(0:EIA 1:ISO)>1_
MDI
* * * *
* * *
* * *
* * *
12:34:56
READ
PUNCH
4
Press soft key [READ], then [EXEC].
CAN
EXEC
The parameters are read, and the “INPUT” indicator blinks at the
lower-right corner of the screen. Upon the completion of input, the
“INPUT” indicator is cleared from the screen.
To cancel input, press soft key [CAN].
620
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Outputting parameters
Procedure
1
Press soft key [PARAM] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
READ/PUNCH (PARAMETER)
O1234 N12345
I/O CHANNEL
3
TV CHECK
OFF
DEVICE NUM.
0
PUNCH CODE
ISO
BAUDRATE
4800
INPUT CODE
ASCII
STOP BIT
2
FEED OUTPUT
FEED
NULL INPUT (EIA)
NO
EOB OUTPUT (ISO) CR
TV CHECK (NOTES)
ON
BAUDRATE CLK. INNER
CD CHECK (232C)
OFF
RESET/ALARM
ON
PARITY BIT
OFF
COM CODE
ASCII
END CODE
EXT
COM PROTCOL
A
INTERFACE
RS422
SAT COMMAND HOST
(0:EIA 1:ISO)>1_
MDI
* * * *
* * *
* * *
* * *
12:34:56
READ
PUNCH
4
Press soft key [PUNCH], then [EXEC].
CAN
EXEC
The parameters are output, and the “OUTPUT” indicator blinks at the
lower-right corner of the screen. Upon the completion of output, the
“OUTPUT” indicator is cleared from the screen.
To cancel output, press soft key [CAN].
621
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
8.10.4
Offset data can be input and output using the ALL IO screen.
Inputting and
Outputting Offset Data
Inputting offset data
Procedure
1
Press soft key [OFFSET] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
READ/PUNCH (OFFSET)
O1234 N12345
I/O CHANNEL
3
TV CHECK
OFF
DEVICE NUM.
0
PUNCH CODE
ISO
BAUDRATE
4800
INPUT CODE
ASCII
STOP BIT
2
FEED OUTPUT
FEED
NULL INPUT (EIA)
NO
EOB OUTPUT (ISO) CR
TV CHECK (NOTES)
ON
BAUDRATE CLK. INNER
CD CHECK (232C)
OFF
RESET/ALARM
ON
PARITY BIT
OFF
COM CODE
ASCII
END CODE
EXT
COM PROTCOL
A
INTERFACE
RS422
SAT COMMAND HOST
(0:EIA 1:ISO)>1_
MDI
* * * *
* * *
* * *
* * *
12:34:56
READ
PUNCH
4
Press soft key [READ], then [EXEC].
CAN
EXEC
The offset data is read, and the “INPUT” indicator blinks at the
lower-right corner of the screen.
Upon the completion of input, the “INPUT” indicator is cleared from
the screen.
To cancel input, press soft key [CAN].
622
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Outputting offset data
Procedure
1
Press soft key [OFFSET] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
READ/PUNCH (OFFSET)
O1234 N12345
I/O CHANNEL
3
TV CHECK
OFF
DEVICE NUM.
0
PUNCH CODE
ISO
BAUDRATE
4800
INPUT CODE
ASCII
STOP BIT
2
FEED OUTPUT
FEED
NULL INPUT (EIA)
NO
EOB OUTPUT (ISO) CR
TV CHECK (NOTES)
ON
BAUDRATE CLK. INNER
CD CHECK (232C)
OFF
RESET/ALARM
ON
PARITY BIT
OFF
COM CODE
ASCII
END CODE
EXT
COM PROTCOL
A
INTERFACE
RS422
SAT COMMAND HOST
(0:EIA 1:ISO)>1_
MDI
* * * *
* * *
* * *
* * *
12:34:56
READ
PUNCH
4
Press soft key [PUNCH], then [EXEC].
CAN
EXEC
The offset data is output, and the “OUTPUT” indicator blinks at the
lower-right corner of the screen. Upon the completion of output, the
“OUTPUT” indicator is cleared from the screen.
To cancel output, press soft key [CAN].
623
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
8.10.5
Custom macro common variables can be output using the ALL IO screen.
Outputting Custom
Macro Common
Variables
Outputting custom macro common variables
Procedure
1
Press soft key [MACRO] on the ALL IO screen, described in Section
8.10.1.
2
Select EDIT mode.
3
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
READ/PUNCH (MACRO)
O1234 N12345
I/O CHANNEL
3
TV CHECK
OFF
DEVICE NUM.
0
PUNCH CODE
ISO
BAUDRATE
4800
INPUT CODE
ASCII
STOP BIT
2
FEED OUTPUT
FEED
NULL INPUT (EIA)
NO
EOB OUTPUT (ISO) CR
TV CHECK (NOTES)
ON
BAUDRATE CLK. INNER
CD CHECK (232C)
OFF
RESET/ALARM
ON
PARITY BIT
OFF
COM CODE
ASCII
END CODE
EXT
COM PROTCOL
A
INTERFACE
RS422
SAT COMMAND HOST
(0:EIA 1:ISO)>1_
MDI
* * * *
* * *
* * *
* * *
12:34:56
READ
PUNCH
4
Press soft key [PUNCH], then [EXEC].
CAN
EXEC
The custom macro common variables are output, and the “OUTPUT”
indicator blinks at the lower-right corner of the screen. Upon the
completion of output, the “OUTPUT” indicator is cleared from the
screen.
To cancel output, press soft key [CAN].
NOTE
To input a macro variable, read the desired custom macro
statement as a program, then execute the program.
624
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
8.10.6
The ALL IO screen supports the display of a directory of floppy files, as
well as the input and output of floppy files.
Inputting and
Outputting Floppy
Files
Displaying a file directory
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [FLOPPY].
3
Select EDIT mode. The floppy screen is displayed.
4
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
The floppy screen is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
READ/PUNCH (FLOPPY)
O1234 N12345
>
MDI
* * * *
* * *
* * *
* * *
12:34:56
F SRH
READ
PUNCH
DELETE
5
Press soft key [F SRH].
6
Enter the number of the desired file, then press soft key [F SET].
F SET
CAN
EXEC
625
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
7
Press soft key [EXEC]. A directory is displayed, with the specified
file uppermost. Subsequent files in the directory can be displayed by
pressing the page key.
READ/PUNCH (FLOPPY)
O1234 N12345
No. FILE NAME
(Meter) VOL
0001
PARAMETER
46.1
0002
ALL.PROGRAM
12.3
0003
O0001
11.9
0004
O0002
11.9
0005
O0003
11.9
0006
O0004
11.9
0007
O0005
11.9
0008
O0010
0009
O0020
11.9
11.9
F SRH
File No.=2
>2_
EDIT
* * * *
* * *
* * *
* * *
12:34:56
F SRH
CAN
EXEC
A directory in which the first file is uppermost can be displayed
simply by pressing the page key.
(Soft key [F SRH] need not be
pressed.)
626
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Inputting a file
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [FLOPPY].
3
Select EDIT mode. The floppy screen is displayed.
4
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
The floppy screen is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
READ/PUNCH (FLOPPY)
O1234 N12345
>
MDI
* * * *
* * *
* * *
* * *
12:34:56
F SRH
READ
PUNCH
DELETE
5
Press soft key [READ].
6
Enter the number of a file or program to be input.
F SET
O SET STOP
CAN
EXEC
D Setting a file number: Enter the number of the desired file, then
press soft key [F SET].
D Setting a program number: Enter the number of the desired
program, then press soft key [O SET].
7
Press soft key [EXEC].
The specified file or program is read, and the “INPUT” indicator
blinks at the lower-right corner of the screen. Upon the completion of
input, the “INPUT” indicator is cleared from the screen.
627
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
Outputting a file
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [FLOPPY].
3
Select EDIT mode. The floppy screen is displayed.
4
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
The floppy screen is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
READ/PUNCH (FLOPPY)
O1234 N12345
>
MDI
* * * *
* * *
* * *
* * *
12:34:56
F SRH
READ
PUNCH
DELETE
5
Press soft key [PUNCH].
6
Enter the number of the program to be output, together with a desired
F SET
O SET STOP
CAN
EXEC
output file number.
D Setting a file number: Enter the number of the desired file, then
press soft key [F SET].
D Setting a program number: Enter the number of the desired
program, then press soft key [O SET].
7
Press soft key [EXEC].
The specified program is output, and the “OUTPUT” indicator blinks
at the lower-right corner of the screen. Upon the completion of
output, the “OUTPUT” indicator is cleared from the screen.
If no file number is specified, the program is written at the end of the
currently registered files.
628
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Deleting a file
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [FLOPPY].
3
Select EDIT mode. The floppy screen is displayed.
4
Press soft key [(OPRT)]. The screen and soft keys change as shown
below.
The floppy screen is displayed only in EDIT mode. In all other
modes, the ALL IO screen is displayed.
READ/PUNCH (FLOPPY)
O1234 N12345
>
MDI
* * * *
* * *
* * *
* * *
12:34:56
F SRH
READ
PUNCH
DELETE
5
Press soft key [DELETE].
6
Enter the number of the desired file, then press soft key [F SET].
F SET
CAN
EXEC
7
Press soft key [EXEC]. The specified file is deleted. After the file has
been deleted, the subsequent files are shifted up.
629
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
8.10.7
Data held in CNC memory can be saved to a memory card in MS-DOS
format. Data held on a memory card can be loaded into CNC memory.
Memory Card
A save or load operation can be performed using soft keys while the CNC
Input/Output
is operating.
Loading can be performed in either of two ways. In the first method, all
saved memory data is loaded. In the second method, only selected data
is loaded.
READ/PUNCH(M-CARD)
O1234 N12345
*1: CNC memory
CNC RAM
Memory card
512K byte
2. 000M byte S- RAM
*2: Memory card size and type
(
1/
1)
File
SRAM0_5A. FDB
524288 byte 97/ 01/ 23
*3: Names, sizes, dates, and number of files
recorded on the memory card
Message
COMPLETED.
*4: Operation message
TURN OFF POWER.
Select : All data
*5: Select a desired type of load data only
S
0 T0000
when [LOAD] is selected.
EDIT **** - - EMG- -
12: 15: 00
[FORMAT] [ SAVE ]
[ LOAD ]
[ DELETE]
[
]
[
CAN
]
[
]
[
]
[
CAN
]
[ EXEC ]
When [FORMAT], [SAVE], or
[DELETE] is selected
[ SELECT]
[
]
[
]
[
CAN
]
[ EXEC ]
When [LOAD] is selected
D The CNC memory size (*1) is displayed at all times.
D When no memory card is inserted, the message field (*4) displays a
message prompting the user to insert a memory card, but does not
display the memory card states (*2 and *3).
D If an inserted memory card is invalid (if there is no attribute memory,
or if the attribute memory does not contain any device information),
the message field (*4) displays an error message, but does not display
the memory card states (*2 and *3).
630
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Saving memory data
Data held in CNC memory can be saved to a memory card in MS-DOS
format.
Saving memory data
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [M-CARD].
3
Place the CNC in the emergency stop state.
4
When a memory card is inserted, the state of the memory card is
displayed as shown below.
READ/PUNCH(M-CARD)
O1234 N12345
CNC RAM
Memory card
512K byte
2. 000M byte S- RAM
File
(
1/
1)
SRAM0_5A. FDB
524288 byte 97/ 01/ 23
Message
Select : All data
S
0 T0000
EDIT **** - - EMG- -
12: 15: 00
[FORMAT] [ SAVE ]
[ LOAD ]
[ DELETE]
[
]
5
Press soft key [SAVE].
6
A message prompting the user to confirm the operation is displayed.
CAN
EXEC
Press soft key [EXEC] to execute the save operation.
7
As the data is being saved to the card, the message “RUNNING”
blinks, and the number of bytes saved is displayed in the message
field.
8
Once all data has been saved to the card, the message
“COMPLETED” is displayed in the message field, with the message
“PRESS RESET KEY.” displayed on the second line.
9
Press the RESET key. The displayed messages are cleared from the
screen, and the display of the memory card state is replaced with that
of the saved file.
NOTE
All CNC memory data is saved to a memory card. CNC
memory data cannot be saved selectively.
631
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
Explanations
D File name
The file name used for save operation is determined by the amount of
SRAM mounted in the CNC. A file holding saved data is divided into
blocks of 512KB.
HEAD1 SRAM file
Amount of SRAM
256 KB
0.5 MB
1.0 MB
2.5 MB
Number of files
1
SRAM256A. FDB
SRAM0_5A. FDB
SRAM1_0A. FDB
SRAM2_5A. FDB
2
SRAM1_0B. FDB
SRAM2_5B. FDB
3
SRAM2_5C. FDB
4
SRAM2_5D. FDB
5
SRAM2_5E. FDB
HEAD2 SRAM file
Amount of SRAM
256 KB
0.5 MB
1.0 MB
2.5 MB
Number of files
1
SRAM256A. OP2
SRAM0_5A. OP2
SRAM1_0A. OP2
SRAM2_5A. OP2
2
SRAM1_0B. OP2
SRAM2_5B. OP2
3
SRAM2_5C. OP2
4
SRAM2_5D. OP2
5
SRAM2_5E. OP2
D Canceling saving
To cancel file save prior to its completion, press the
RESET
key on the MDI
panel.
D Memory card
When the memory card has less than 512K bytes of free space, a memory
replacement request
card replacement request is displayed. Insert a new memory card.
632
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Loading data into
CNC memory data that has been saved to a memory card can be loaded
memory (restoration)
(restored) back into CNC memory.
CNC memory data can be loaded in either of two ways. In the first
method, all saved memory data is loaded. In the second method, only
selected data is loaded.
Loading memory data
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [M-CARD].
3
Place the CNC in the emergency stop state.
4
When a memory card is inserted, the state of the memory card is
displayed as shown below.
READ/PUNCH(M-CARD)
O1234 N12345
CNC RAM
Memory card
512K byte
2. 000M byte S- RAM
File
(
1/
1)
SRAM0_5A. FDB
524288 byte 97/ 01/ 23
Message
Select : All data
S
0 T0000
EDIT **** - - EMG- -
12: 15: 00
[FORMAT] [ SAVE ]
[ LOAD ]
[ DELETE]
[
]
5
Press soft key [LOAD].
6
With cursor keys
and
, select the file to be loaded from the
memory card.
A system having 1.0MB or 2.5MB of CNC RAM may require the
loading of multiple files. All or selective data load can be specified
for each file.
7
To perform selective data loading, press soft key [SELECT], then
SELECT
CAN
EXEC
select the data to be loaded. Each time the soft key is pressed, the
information displayed changes cyclically, as shown below.
All data
Program
Parameter
Offset
PMC data
C
Macro data
8
After checking the file selection, press soft key [EXEC].
633
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
9
During loading, the message “RUNNING” blinks, and the number of
bytes loaded is displayed in the message field.
10
Upon the completion of loading, the message “COMPLETED” is
displayed in the message field, with the message “PRESS RESET
KEY.” displayed on the second line.
11
Press the RESET key. The messages are cleared from the screen.
Explanations
D Canceling loading
To cancel file load prior to its completion, press the
RESET
key on the MDI
panel.
D Turning off the power
Depending on the type of data, the system power may have to be turned
after loading
off, then back on, for the load to become effective. When necessary, the
message “TURN OFF POWER.” is displayed in the message field.
D Parameter/PMC data
Before performing parameter/PMC data load, enable parameter write.
D Program/offset data
Before performing program/offset data load, set the data protection key,
on the machine operator’s panel, to the ON position.
D Loading files from
When multiple files are to be loaded from multiple memory cards, a
multiple memory cards
message requesting memory card replacement is displayed.
NOTE
If the saved data and CNC system onto which the saved
data is to be loaded do not satisfy the conditions described
below, an error message is displayed in the message field,
and loading is disabled. Note, however, that in selective
loading, even if the CNC system structure differs from that
of a saved file, the file is never the less loaded.
⋅
The size of a saved file does not match the size of CNC
RAM.
⋅
The saved file has a different extension.
634
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Memory card formatting
Before a file can be saved to a memory card, the memory card must be
formatted.
Formatting a memory card
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [M-CARD].
3
Place the CNC in the emergency stop state.
4
When a memory card is inserted, the state of the memory card is
displayed as shown below.
READ/PUNCH(M-CARD)
O1234 N12345
CNC RAM
Memory card
512K byte
2. 000M byte S- RAM
File
(
1/
1)
SRAM0_5A. FDB
524288 byte 97/ 01/ 23
Message
Select : All data
S
0 T0000
EDIT **** - - EMG- -
12: 15: 00
[FORMAT] [ SAVE ]
[ LOAD ]
[ DELETE]
[
]
5
Press soft key [FORMAT].
6
A message prompting the user to confirm the operation is displayed.
CAN
EXEC
Press soft key [EXEC] to execute the formatting operation.
7
As formatting is being performed, the message “FORMATTING”
blinks.
8
Upon the completion of formatting, the message “COMPLETED” is
displayed in the message field.
635
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
Deleting files
Unnecessary saved files can be deleted from a memory card.
Deleting files
Procedure
1
Press the rightmost soft key
(next-menu key) on the ALL IO
screen, described in Section 8.10.1.
2
Press soft key [M-CARD].
3
Place the CNC in the emergency stop state.
4
When a memory card is inserted, the state of the memory card is
displayed as shown below.
READ/PUNCH(M-CARD)
O1234 N12345
CNC RAM
Memory card
512K byte
2. 000M byte S- RAM
File
(
1/
1)
SRAM0_5A. FDB
524288 byte 97/ 01/ 23
Message
Select : All data
S
0 T0000
EDIT **** - - EMG- -
12: 15: 00
[FORMAT] [ SAVE ]
[ LOAD ]
[ DELETE]
[
]
5
Press soft key [DELETE].
6
With cursor keys
and
, select the file to be deleted from the
memory card.
7
After checking the file selection, press soft key [EXEC].
CAN
EXEC
8
As detection is being performed, the message “DELETING” blinks in
the message field.
9
Upon the completion of deletion, the message “COMPLETED” is
displayed in the message field.
NOTE
An SRAM of 1M bytes or more will contain multiple files. To
delete the contents of such an SRAM, delete all the
contained files.
636
B-63524EN/01
OPERATION
8. DATA INPUT/OUTPUT
Message and restrictions
Messages
Message
Description
INSERT MEMORY CARD.
No memory card is inserted.
UNUSABLE MEMORY CARD
The memory card does not contain device information.
FORMAT MEMORY CARD.
The memory card is not formatted. Format the memory card before
use.
THE FILE IS UNUSABLE.
The format or extension of the file to be loaded is invalid. Alternative-
ly, the data stored on the memory card does not match the CNC
memory size.
REPLACE MEMORY CARD.
Replace the memory card.
FILE SYSTEM ERROR jjj
An error occurred during file system processing. jjj represents a
file system error code.
SET EMERGENCY STOP STATE.
Save/load operation is enabled in the emergency stop state only.
WRITE-PROTECTED
Save operation: The protect switch of the memory card is set to the
disabled position.
Load operation: Parameter write is disabled.
VOLTAGE DECREASED.
The battery voltage of the memory card has dropped.
(The battery requires replacement.)
DEVICE IS BUSY.
Another user is using the memory card. Alternatively, the device can-
not be accessed because automatic operation is in progress.
SRAM ³ MEMORY CARD?
This message prompts the user to confirm the start of data saving.
MEMORY CARD ³ SRAM?
This message prompts the user to confirm the start of data loading.
DO YOU WANT TO DELETE FILE(S)?
This message prompts the user to confirm the start of deletion.
DO YOU WANT TO PERFORM FORMATTING?
This message prompts the user to confirm the start of formatting.
SAVING
Saving is currently being performed.
LOADING
Loading is currently being performed.
DELETING
File deletion is currently being performed.
FORMATTING
Memory card formatting is currently being performed.
COMPLETED
Save or load processing has been completed.
PRESS RESET KEY.
Press the RESET key.
TURN OFF POWER.
Turn the power off, then back on again.
637
8. DATA INPUT/OUTPUT
OPERATION
B-63524EN/01
File system error codes
Code
Meaning
102
The memory card does not have sufficient free space.
105
No memory card is mounted.
106
A memory card is already mounted.
110
The specified directory cannot be found.
111
There are too many files under the root directory to allow a di-
rectory to be added.
114
The specified file cannot be found.
115
The specified file is protected.
117
The file has not yet been opened.
118
The file is already open.
119
The file is locked.
122
The specified file name is invalid.
124
The extension of the specified file is invalid.
129
A non-corresponding function was specified.
130
The specification of a device is invalid.
131
The specification of a pathname is invalid.
133
Multiple files are open at the same time.
135
The device is not formatted.
140
The file has the read/write disabled attribute.
Restrictions
D Memory card size
The size of the memory card to be used must be larger than that of the
RAM module mounted in the CNC. The size of the RAM module can be
determined from the system configuration screen.
D Memory card
Use a memory card that conforms to PCMCIA Ver. 2.0, or JEIDA Ver. 4.1.
specifications
D Attribute memory
A memory card which has no attribute memory, or no device information
in its attribute memory, cannot be used.
D Compatibility of saved
Data saved to a memory card is compatible only with CNCs that have the
data
same hardware configuration and the same option configuration.
D Flash ROM card
A flash ROM card can be used only for data loading.
D Operation during
During automatic operation, the contents of a memory card cannot be
automatic operation
displayed, formatted, or deleted. To enable these operations, therefore,
stop or suspend automatic operation.
638
