Page 9
Lotus Service Notes
Section OI
9
Complete Warranty Literature
Check presence of vehicle handbook, audio booklet & other documentation.
Complete pages 2, 3, 4a & 4c in "Maintenance Record" booklet.
Cut out pages 4a & 4c for return to Lotus Cars Warranty Department.
Copy alarm installation certificate, PIN & key details (inc. locking wheel bolts). Originals to customer.
MODEL
OPERATION DESCRIPTION
Fit number plates and tax disc holder.
Fit protective covers to seats, footwells & steering wheel.
Engine Bay
Check engine, transmission & PAS oil levels.
Check coolant fill level.
VIN
SCC _ _ _ _ _ _ _ _ _ _ _ _ _ _
PRE-DELIVERY INSPECTION
LSL345E
COLOUR
Start Engine
Inspect engine & transmission for oil leaks.
Inspect cooling system for leaks.
Wheels & Tyres
Fill fuel tank and inspect entire fuel system for leaks.
Use Lotus TechCentre to check for stored codes.
Check cold tyre pressures.
Check torque of wheel bolts.
Electrical
Check tyreweld canister is fitted in rear luggage compartment.
Check security of battery terminals and voltage. Below 12.4V recharge. Below 11.7V replace*.
Inspect operation of all exterior & interior lamps.
Inspect operation of horn & hazard switch.
Inspect operation of alarm system, CDL & fuel flap release.
Inspect wiper operation at all speeds & park position.
Inspect screen washer & powerwash operation, jet alignment & reservoir level.
Inspect operation of all instrumentsl, mirror adjustment & fold.
Inspect operation of heater / air conditioning & blower fan.
Inspect operation of audio equipment & set time clock (if applicable).
Check brake / clutch fluid level.
Body
Inspect operation of doors, door locks & tailgate release (incl. Evora cable).
Inspect all paint work for damage (Elise LSL407a; Exige LSL409a; Europa LSL514; Evora LSL544).
Check presence of toolkit & literature pack.
Inspect operation of electric window lift mechanism.
Inspect fit of hard & soft top roofs.
Inspect seat adjustment latching & operation of front & rear seatbelts.
Inspect interior trim for damage & cleanliness.
U.K.:
Complete Lotus Roadside Assistance card (expiry date 2 years from reg. date).
* Battery claims will not be accepted unless correct trickle charging has been maintained.
