Seat Exeo. Service Manual

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit

• Journey duration

Menu display

• Distance covered

• Average fuel consumption

Introduction

• Average speed

The on-board computer can only be operated when the ignition is switched

on. When the ignition is switched on, the display shows the function that was

last selected.

As well as the figures from the on-board computer (computer 1 or 2), the

display can also show information from the navigation system*. Press the

Reset button

briefly to switch back and forward between these displays.

Note

• If you keep the Reset button pressed for longer than two seconds, it will

reset the currently displayed figure to zero (for instance average fuel

Fig. 60 Windscreen wiper

consumption).

lever: Menu selection

• Faults detected by the auto-check control will be displayed even if the

button

display is off.

• The information in the memory is lost if the battery is disconnected.

Fig. 61 Display: Main

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit

Some of the functions in your vehicle can be adjusted, activated and

Controlling the menu

controlled via menus (e.g. tyre pressure*). With the aid of the menus you can

then also select the information you wish to see displayed on the DIS display.

The menu display is called up via the

Reset

button and the

This is only possible when the ignition is on. The menu is enabled using the

rocker switch on the windscreen wiper lever. Use these

Reset

button on the windscreen wiper lever ⇒ page 86, fig. 60.

controls to make checks and adjust the settings.

The main menu lists the different display types (or basic commands):

Programming

Check

Menu off

Help

The main menu options have the following submenus:

Programming

Clock

⇒ page 87

Computer

⇒ page 87

Fig. 62 Windscreen wiper

Speed warning

⇒ page 81

lever: Reset button and

rocker switch

Radio info (on/off)

Units: for measuring dis-

⇒ page 87

Functions of the

⇒ fig. 62 and the rocker switch

tance, fuel consumption and

temperature

Enabling the menu

Language: you can select

⇒ page 87

- Press the

Reset

button until the menu display ⇒ page 86,

one of 6 languages.

fig. 61 appears.

Check

Service

⇒ page 74

Menu off

When the menu is switched off, the display shows the

Selecting and setting

same information as on vehicles without the menu func-

- Press the rocker switch to select one of the menus. Press "up" or

tion.

"down" on the switch to select the options accordingly.

Help

This function helps you select the options you require.

Entering and confirming

- Press the

Reset

button.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit

Use the rocker switch to select the menus and adjust various values. The

driven and the tyre pressure will rise accordingly. Therefore, you should only

selected values are highlighted on a red background.

adjust the tyre pressures when they are cold (i.e. approximately at ambient

temperature).

By pressing the

Reset

button, you can confirm the option you have selected

or the value you have set. Selected functions are marked with a tick.

To ensure that the tyre pressure monitoring system works reliably, you should

check and, if necessary, adjust the tyre pressures at regular intervals and

The following symbols are used:

store the correct pressures (reference values) in the system.

Cursor

Function selected

Red background (active

A tyre pressure information label is attached to the inside of the fuel tank flap.

function)

Tick

Selected

WARNING



• Never adjust tyre pressure when the tyres are hot. This may damage or

Box

Not selected



even burst the tyres. Risk of accident!

• An insufficiently inflated tyre flexes a lot more at high speeds and

Triangle pointing upwards



causes significant heating of the tyre. Under these conditions, the tyre

bead may be released or the tyre may burst. Risk of accident!

Triangle pointing down-



wards

For the sake of the environment

Under-inflated tyres lead to increased fuel consumption and tyre wear.

Tyre pressure monitoring

Note

• Responsibility for ensuring that the tyres are correctly inflated remains

Introduction

with the driver; the system can only provide assistance.

• Pressure can only be adjusted when the tyres are at ambient

The tyre pressure monitoring system constantly checks the

temperature.

pressure of the tyres.

The system warns the driver in the event of a loss of pressure by means of

symbols and messages in the instrument panel display. The system works

with the help of the ABS sensors in the wheels.

Please bear in mind that the tyre inflation pressure is also influenced by the

temperature of the tyre. Tyre pressure increases about 0.1 bar for each 10°C

in tyre temperature increase. The tyre heats up while the vehicle is being

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit

Tyre pressure monitoring display 

The tyre pressure should be corrected as soon as possible if

it is too low.

If the  symbol appears, the tyre pressure on at least one of the

wheels is too low.

- Stop the vehicle.

- Check the tyre(s).

- Correct the tyre pressure ⇒ page 228.

For more detailed information on the tyre pressure monitoring system, please

refer to ⇒ page 227.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Steering wheel controls

The multi-function steering wheel

Introduction

You can use the multi-function steering wheel to quickly and

easily operate selected functions of the radio, CD, TV* and

telephone*.

Fig. 64 Driver informa-

tion system

The functions are operated by pressing or scrolling the controls

the multi-function steering wheel ⇒ fig. 63:

• Press the

MODE

button

repeatedly to switch between modes, which

are then displayed in the driver information system ⇒ fig. 64.

• Scroll and press the left thumbwheel

to select a function from one of

Fig. 63 Controls on the

multi-function steering

the menus.

wheel

• The speech control system* for the on-board phone system is enabled by

pressing the talk button . Pressing the talk button again disables speedC

control*.

• Scroll the right thumbwheel

up/down to raise/lower the volume as

desired.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Steering wheel controls

Steering wheel audio version controls

Press

(Mode)

(PTT)

Press

1st press: starts

Station search.

the search.

No function

Radio mode

Increase fre-

Decrease fre-

Volume up

Volume down

2nd press: cancels

specified

quency

the search

CD mode: next

CD mode: previ-

CD mode: fast for-

No specified

No function

CD/

track.

ous track.

ward.

function

specified

No function

Volume up

Volume down

iPod-USB Mode

iPod/USB Mode:

specified

next track

previous track

fast forward

No specified

MP3 mode

Following track

Previous track

Fast forward

Volume up

Volume down

function

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Steering wheel controls

Steering wheel Audio + Telephone version controls

Press

(Mode)

(PTT)

Press

1st press: starts

Station search.

the search.

No function

Radio mode

Increase fre-

Decrease fre-

Volume up

Volume down

2nd press: cancels

specified

quency

the search

CD mode: next

CD mode: previ-

CD mode: fast for-

Change to

CD/

track.

ous track.

ward.

phone

No function

Volume up

Volume down

iPod-USB Mode

iPod/USB Mode:

Enable voice

specified

next track

previous track

fast forward

recognition

No function

MP3 mode

Next track

Previous track

Fast forward

Volume up

Volume down

specified

Change to

Next name in

Previous name in

radio / CD /

No function

Phone mode

Volume up

Volume down

phone book

iPod-USB /

specified

MP3

One press: accept

Incoming call

No function spec-

No function

call.

No function

Volume up

Volume down

mode

ified

specified

Held down: reject

specified

call

Active call

No function spec-

No function

End call

Volume up

Volume down

mode

ified

specified

Voice activa-

No function spec-

No function

No function speci-

No function

Cancel

Volume up

Volume down

tion mode

ified

specified

fied

specified

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

Remote control keys

Set of keys

Fig. 66 Remote control

key: Release button

The set of keys belonging to your vehicle consists of the following items:

one remote control key.

Fig. 65 Set of keys

one key without remote control.

supplied with the vehicle

one plastic key tab containing the key number.

Remote control key

The remote control key will lock and unlock the car and start the engine. Press

the release button ⇒ fig. 66 -arrow- to make the key spring out of the handle

and to fold it back in.

Spare key

The spare key is not designed for continuous use. It should only be used in

the event of an emergency. Keep it in a safe place and do not carry it on the

key tab.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

Plastic key tab

Indicator light on the remote control key

Spare keys cannot be issued without the key number on the plastic key tab.

Therefore:

The condition of the battery in the remote control key is moni-

tored by the indicator light.

• Always keep the key tab in a safe place.

• Never leave the key tab in the vehicle.

• If you sell the vehicle, please give the plastic key tab to the new owner.

Replacing a key

If you lose a key, please contact the Technical Service. Have the remote

control coding for that key disabled. You should therefore bring the plastic

key tab and all available keys with you. It is also important to notify your

insurance company if a key or the plastic key tab has been lost.

WARNING

• Always take the key with you when leaving the vehicle, even if you only

Fig. 67 LED on the remote

intend to be gone for a short time. This is particularly important if there are

control key

children in the car, as they might otherwise be able to start the engine or

use power-operated equipment (e.g. the electric windows), which could

lead to injuries.

Condition of the key battery

• Wait for the vehicle to come to a standstill before removing the ignition

The indicator light ⇒ fig. 67 (arrow) flashes when one of the buttons is

key from the lock! Otherwise, the steering lock could engage suddenly,

pressed. If the indicator light does not light up or flash, this means that the

causing an accident.

battery is exhausted and must be replaced.

Replacing the batteries ⇒ page 95.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

Replacing the key battery

For the sake of the environment

Used batteries must be disposed of appropriately and must not be discarded

with ordinary household waste.

Note

• The system must be re-synchronised after each battery replacement to be

able to lock and unlock the car using the remote control ⇒ page 103.

• The new battery must be of the same type as the original.

Electronic immobiliser

Fig. 68 Master key:

Opening the cover

The electronic immobiliser is designed to prevent unauthor-

ised persons from starting up the vehicle.

We recommend you have the batteries changed in a specialist

There is an electronic chip inside the key which automatically deactivates the

garage. If you decide to change the used battery yourself, follow the

immobiliser when the key is inserted into the ignition lock. The electronic

steps below:

immobiliser is enabled automatically when the ignition key is removed from

the ignition lock after coming to a stop.

- Carefully prise apart the key ⇒ fig. 68

and the cover

using a coin.

If an uncoded key is used, the message SAFE will appear in the trip recorder

display.

- Remove cover in the direction of the arrow.

- Remove the used battery from the cover.

Note

• The engine can only be started using an original SEAT key with the correct

- Insert the new battery. Make sure that the “+” symbol on the

code.

battery is facing downwards. The correct polarity is indicated on

• It may not be possible to start the engine with the key if there is another

the cover.

ignition key from a different make of vehicle on the same key tab.

- After inserting the battery, align the cover and key and press the

two parts together.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

Central locking

WARNING

Do not leave anyone (especially children) inside the car if it is locked from

Description

the outside and the anti-theft security system is enabled, as the doors and

windows cannot then be opened from the inside. Locked doors could delay

The central locking system enables you to lock and unlock all

assistance in an emergency, potentially putting lives at risk.

the doors, the boot lid and the tank flap together.

The central locking system on your vehicle locks and unlocks all the doors

Note

and the tank flap simultaneously. The tailgate is unlocked when the vehicle

• Should the central locking system fail to work, you can still lock and

is opened. However, the handle must be used to open it. The vehicle can be

unlock the driver's door and the tailgate using the key. For manual release of

locked and unlocked using the remote control ⇒ page 102 or by turning the

the tank flap ⇒ page 209. Locking the doors manually if central locking fails

key in the lock in the driver's door.

to work ⇒ page 99.

The windows can also be centrally opened or closed using the central locking

• The anti-theft mechanism and the anti-theft alarm* cannot be enabled if

system ⇒ page 107. The sun roof* can be closed but not opened using the

the central locking is not working.

central locking system.

• Never leave any valuable items in the vehicle unattended. Even a locked

vehicle is not a safe.

The central locking system is combined with an anti-theft security system. If

the vehicle is locked with the key from the outside, the interior opening levers

stop working, which make it difficult for unauthorised people to get into the

vehicle.

Should the central locking system fail to work, you can still normally enable

all the locks individually. The fuel tank flap can be released manually if neces-

sary. For manual release of the tank flap ⇒ page 209.

Automatic locking function (Auto Lock)*

The Auto Lock* function locks the doors and the boot lid when the vehicle

exceeds a speed of about 15 km/h.

The vehicle is unlocked again automatically when the ignition key is

removed. Alternatively, the driver can also unlock the vehicle using the

central locking switch  or by opening one of the doors.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

Unlocking the vehicle with the key

• The interior lights are switched off, provided the light switch is in the cour-

tesy light position.

• The windows and the sun roof* will close as the key is held in the locking

position.

• The anti-theft security system will be enabled immediately.

Locking the vehicle without enabling the anti-theft security system

With the anti-theft security system enabled, it is more difficult to break into

the vehicle. If the anti-theft security system has been enabled, the inside

door handles and the central locking switch will not work ⇒

If you are leaving passengers in the vehicle while it is parked, it is possible to

lock the vehicle without enabling the anti-theft security system.

Fig. 69 Turning the key to

To do so, turn the key in the driver's door twice in quick succession to position

enable the open and close

⇒ fig. 69.

functions

WARNING

- To unlock the vehicle, turn the key in the driver's door to position

⇒ fig. 69.

Do not leave anyone (especially children) in the car if it is locked from the

outside and the anti-theft security system is enabled, as the doors and

- Pull the handle to open the door.

windows cannot then be opened from the inside. Locked doors could delay

assistance in an emergency, potentially putting lives at risk.

• This will unlock all the doors, the tailgate and the tank flap simultane-

ously.

Caution

• The anti-theft security system will be disabled.

If the driver's door is locked using the key while open, the car will be automat-

ically immobilised and the alarm triggered.

Locking the vehicle with the key

Note

• Please note that when the vehicle is locked without enabling the anti-

- To lock the vehicle, turn the key in the driver's door to position

theft mechanism, the anti-theft alarm* remains operative. You should there-

⇒ fig. 69 ⇒

fore switch off the interior monitor before locking the vehicle, as otherwise

the alarm could be triggered unintentionally.

• This will lock all the doors and the tailgate.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

• The driver's door cannot be locked using the central locking system when

• The doors and the tailgate cannot be opened from the outside (for secu-

it is still open. The door must be locked separately after it has been closed.

rity reasons, e.g. when stopped at traffic lights).

This helps to prevent you from being locked out of the vehicle.

• You can open the doors individually from the inside by pulling the inside

door handle.

• When the driver's door is open, it cannot be locked by pressing the central

locking switch and then closing the door. This helps to prevent you from

Central locking switch

being locked out of the vehicle. The door has to be locked separately after it

The central locking system can be enabled from inside the

has been closed.

vehicle using the central locking switch on the driver's door.

• In the event of an accident in which the airbags inflate, doors locked from

the inside will be automatically unlocked to facilitate access and assistance.

WARNING

The central locking switch is still operative when the ignition is switched

off. This switch can be used to automatically lock all the doors and the boot

lid. However, since this makes it difficult to enter the car from the outside,

you should never leave children unattended in the vehicle. Locked doors

could delay assistance in an emergency, potentially putting lives at risk.

Note

Fig. 70 Detail of driver

The central locking switch inside the vehicle will not be operative if the anti-

door: Central locking

theft mechanism has been enabled.

switch

Locking the vehicle

- Press the



⇒ fig. 70 ⇒ button.

Unlocking the vehicle

- Press the



button.

Please note the following when using the central locking switch to lock your

vehicle:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

Security central locking

Locking the doors manually if the central locking fails to

work

The security central locking feature allows you to only unlock

the driver's door and the tank flap. All other doors and the

Should the central locking system fail to work at any time (for

boot lid remain locked.

instance if there is no electrical power supply), each door will

have to be locked separately.

Unlocking the driver's door and tank flap

- Turn the key once to the unlock position, or press the unlock

button on the remote control once.

Unlocking all the doors, the boot lid and the tank flap

simultaneously.

- Turn the key twice within five seconds, or press the unlock button

on the remote control twice within five seconds.

The security system and the anti-theft alarm* are immediately disabled even

if you only unlock the driver's door, without unlocking the other doors.

Fig. 71 Manual locking

device

Fig. 72 Enabling manual

locking

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

100

Unlocking and locking

A manual locking device (only visible when the door is open) is

Boot lid

provided on the front passenger's door and the rear doors.

- Open the door.

Tailgate: opening and closing

- Use the key ⇒ page 99, fig. 71 to turn the cap slightly and then

fold it downwards.

- Insert the key into the slot inside ⇒ page 99, fig. 72 and turn it

as far as the stop, i.e. about 90 degrees to the right (doors on

right side) or to the left (door on the left side).

Once the door has been closed it can no longer be opened from the outside.

The door can be opened from the inside by pulling the door handle. If the

child-proof catch is engaged on one of the rear doors, the door can be opened

by pulling the inside door handle once and then opening the door from the

outside.

Fig. 73 Driver's door:

Unlocking the tailgate

Fig. 74 Boot: opening

from the outside

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking and locking

101

Opening the tailgate

Childproof locks

- Press the centre button



on the remote control key or press

the switch*



on the driver's door ⇒ page 100, fig. 73. The

Childproof locks on rear doors

tailgate will spring open.

The childproof lock prevents the rear doors from being

- Then lift up the tailgate. If your vehicle is equipped accordingly,

opened from the inside.

the boot lid will open automatically*.

Closing the tailgate

- Pull down the tailgate and let it drop into the latch ⇒

Use the recessed handle in the interior trim to make it easier to pull down the

tailgate.

WARNING

• After closing the boot lid, always check that the catch has engaged

properly. If not, the boot could open while driving, even if it has been

locked. Risk of accident!

Fig. 75 Childproof lock

• The tailgate must always be completely closed when the vehicle is

on the rear doors

moving, otherwise toxic exhaust fumes may be drawn into the vehicle.

Danger of poisoning!

The rear doors are equipped with childproof locks. These can be

operated using the ignition key. The childproof locks are only visible

Note

with the doors open.

• The door catch/boot lid warning symbol lights up in the instrument

cluster if the boot lid is not properly closed when the ignition is switched on

Enabling the childproof lock

⇒ page 73.

- Turn the key in the direction of the arrow ⇒ fig. 75.

Disabling the childproof lock

- Turn the key in the opposite direction of the arrow.

Safety First

Operating instructions

Practical tips

Technical Data

Seat Exeo. Service Manual - part 6
