161

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

CAUTION

■

When braking

●

When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and may cause one
side of the vehicle to brake differently than the other side. Also the parking
brake may not securely hold the vehicle.

●

If the power brake assist function does not operate, do not follow other
vehicles closely and avoid hills or sharp turns that require braking.
In this case, braking is still possible, but the brake pedal should be
depressed more firmly than usual. Also, the braking distance will increase.
Have your brakes fixed immediately.

●

Do not pump the brake pedal if the engine stalls.
Each push on the brake pedal uses up the reserve for the power-assisted
brakes.

●

The brake system consists of 2 individual hydraulic systems; if one of the
systems fails, the other will still operate. In this case, the brake pedal
should be depressed more firmly than usual and the braking distance will
increase.
Have your brakes fixed immediately.

162

2-1. Driving procedures

tC_OM_OM21056U_(U)

NOTICE

■

When driving the vehicle (vehicles with an automatic transmission)

●

Do not depress the accelerator and brake pedals at the same time during
driving, as this may restrain driving torque.

●

Do not use the accelerator pedal or depress the accelerator and brake
pedals at the same time to hold the vehicle on a hill.

■

When driving the vehicle (vehicles with a manual transmission)

●

Do not depress the accelerator and brake pedals at the same time during
driving, as this may restrain driving torque.

●

Do not shift gears unless the clutch pedal is fully depressed. After shifting,
do not release the clutch pedal abruptly. Doing so may damage the clutch,
transmission and gears.

●

Observe the following to prevent the clutch from being damaged.

• Do not rest your foot on the clutch pedal while driving.

Doing so may cause clutch trouble.

• Do not use any gear other than the 1st gear when starting off and mov-

ing forward.
Doing so may damage the clutch.

• Do not use the clutch to hold the vehicle when stopping on an uphill

grade.
Doing so may damage the clutch.

●

Do not shift the shift lever to R when the vehicle is still moving. Doing so
may damage the clutch, transmission and gears.

163

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

NOTICE

■

When parking the vehicle (vehicles with an automatic transmission)

Always shift the shift lever to P. Failure to do so may cause the vehicle to
move or the vehicle may accelerate suddenly if the accelerator pedal is acci-
dentally depressed.

■

Avoiding damage to vehicle parts

●

Do not turn the steering wheel fully in either direction and hold it there for
an extended period of time.
Doing so may damage the power steering motor.

●

When driving over bumps in the road, drive as slowly as possible to avoid
damaging the wheels, underside of the vehicle, etc.

■

If you get a flat tire while driving

A flat or damaged tire may cause the following situations. Hold the steering
wheel firmly and gradually depress the brake pedal to slow down the vehicle.

●

It may be difficult to control your vehicle.

●

The vehicle will make abnormal sounds or vibrations.

●

The vehicle will lean abnormally.

Information on what to do in case of a flat tire. (

P. 394)

164

2-1. Driving procedures

tC_OM_OM21056U_(U)

NOTICE

■

When encountering flooded roads

Do not drive on a road that has flooded after heavy rain etc. Doing so may
cause the following serious damage to the vehicle:

●

Engine stalling

●

Short in electrical components

●

Engine damage caused by water immersion

In the event that you drive on a flooded road and the vehicle is flooded, be
sure to have your Scion dealer check the following:

●

Brake function

●

Changes in quantity and quality of engine oil, transaxle fluid, etc.

●

Lubricant condition for the bearings and suspension joints (where possi-
ble) and the function of all joints, bearings, etc.

165

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

Engine (ignition) switch (vehicles without a smart key system)

■

Starting the engine

Automatic transmission

Check that the parking brake is set.

Check that the shift lever is set in P.

Firmly depress the brake pedal.

Turn the engine switch to the “START” position to start the
engine.

Manual transmission

Check that the parking brake is set.

Check that the shift lever is set in N.

Firmly depress the clutch pedal.

Turn the engine switch to the “START” position to start the
engine.

STEP

1

STEP

2

STEP

3

STEP

4

STEP

1

STEP

2

STEP

3

STEP

4

166

2-1. Driving procedures

tC_OM_OM21056U_(U)

■

Changing engine switch positions

“LOCK”

The steering wheel is locked
and the key can be removed.
(Vehicles with an automatic
transmission: The key can be
removed only when the shift
lever is in P.)

“ACC”

Some electrical components
such as the power outlet can
be used.

“ON”

All electrical components can
be used.

“START”

For starting the engine.

167

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

■

Turning the key from “ACC” to “LOCK”

Shift the shift lever to P (automatic transmission) or N (manual
transmission). (

P. 178, 185)

■

If the engine does not start

The engine immobilizer system may not have been deactivated. (

P. 102)

■

When the steering lock cannot be released

■

Key reminder buzzer

A buzzer sounds if the driver’s door is opened while the engine switch is in
the “LOCK” or “ACC” position to remind you to remove the key.

STEP

1

Push in the key and turn it to the “LOCK”
position.

STEP

2

When starting the engine, the engine
switch may seem stuck in the “LOCK”
position. To free it, turn the key while turn-
ing the steering wheel slightly left and
right.

168

2-1. Driving procedures

tC_OM_OM21056U_(U)

CAUTION

■

When starting the engine

Always start the engine while sitting in the driver’s seat. Do not depress the
accelerator pedal while starting the engine under any circumstances.
Doing so may cause an accident resulting in death or serious injury.

■

Caution when driving

Do not turn the engine switch to the “LOCK” position while driving. If, in an
emergency, you must turn the engine off while the vehicle is moving, turn the
engine switch only to the “ACC” position to stop the engine. An accident may
result if the engine is stopped while driving.

NOTICE

■

To prevent battery discharge

Do not leave the engine switch in the “ACC” or “ON” position for long periods
of time without the engine running.

■

When starting the engine

●

Do not crank the engine for more than 30 seconds at a time. This may
overheat the starter and wiring system.

●

Do not race a cold engine.

●

If the engine becomes difficult to start or stalls frequently, have the engine
checked immediately.

169

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

Engine (ignition) switch (vehicles with a smart key system)

Performing the following operations when carrying the electronic

key on your person starts the engine or changes “ENGINE START

STOP” switch modes.

■

Starting the engine

Automatic transmission

Check that the parking brake is set.

Check that the shift lever is set in P.

Firmly depress the brake pedal.

The “ENGINE START STOP” switch indicator will turn green.
If the indicator does not turn green, the engine cannot be started.

Press the “ENGINE START
STOP” switch.

The engine will crank until it
starts or for up to 30 seconds,
whichever is less.

Continue depressing the brake
pedal until the engine is com-
pletely started.

The engine can be started
from any “ENGINE START
STOP” switch mode.

STEP

1

STEP

2

STEP

3

STEP

4

170

2-1. Driving procedures

tC_OM_OM21056U_(U)

Manual transmission

Check that the parking brake is set.

Check that the shift lever is set in N.

Firmly depress the clutch pedal.

The “ENGINE START STOP” switch indicator will turn green.
If the indicator does not turn green, the engine cannot be started.

Press the “ENGINE START
STOP” switch.

The engine will crank until it
starts or for up to 30 seconds,
whichever is less.

Continue depressing the clutch
pedal until the engine is com-
pletely started.

The engine can be started
from any “ENGINE START
STOP” switch mode.

STEP

1

STEP

2

STEP

3

STEP

4

171

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

■

Stopping the engine

Automatic transmission

Stop the vehicle.

Shift the shift lever to P.

Set the parking brake. (

P. 188)

Press the “ENGINE START STOP” switch.

Release the brake pedal and check that the indicator on the
“ENGINE START STOP” switch is off.

Manual transmission

Stop the vehicle.

Shift the shift lever to N.

Set the parking brake. (

P. 188)

Press the “ENGINE START STOP” switch.

Release the brake pedal and check that the indicator on the
“ENGINE START STOP” switch is off.

STEP

1

STEP

2

STEP

3

STEP

4

STEP

5

STEP

1

STEP

2

STEP

3

STEP

4

STEP

5

172

2-1. Driving procedures

tC_OM_OM21056U_(U)

■

Changing “ENGINE START STOP” switch modes

Modes can be changed by pressing the “ENGINE START STOP”
switch with brake pedal (vehicles with an automatic transmission)
or clutch pedal (vehicles with a manual transmission) released.
(The mode changes each time the switch is pressed.)

Off

*

The emergency flashers can
be used.

ACCESSORY mode

Some electrical components
such as the power outlet can
be used.

The “ENGINE START STOP”
switch indicator turns amber.

IGNITION ON mode

All electrical components can
be used.

The “ENGINE START STOP”
switch indicator turns amber.

*

: If the shift lever is in a position

other than P when turning off
the engine, the “ENGINE
START STOP” switch will be
turned to ACCESSORY mode,
not to off (vehicles with an
automatic transmission only).

173

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

When stopping the engine with the shift lever in a position other
than P (vehicles with an automatic transmission)

If the engine is stopped with the shift lever in a position other than P,
the “ENGINE START STOP” switch will not be turned off but instead
be turned to ACCESSORY mode. Perform the following procedure to
turn the switch off:

Check that the parking brake is set.

Shift the shift lever to P.

Check that the indicator on the “ENGINE START STOP”
switch is illuminated in amber and then press the “ENGINE
START STOP” switch once.

Check that the indicator on the “ENGINE START STOP”
switch is off.

STEP

1

STEP

2

STEP

3

STEP

4

174

2-1. Driving procedures

tC_OM_OM21056U_(U)

■

Auto power off function

Vehicles with an automatic transmission
If the vehicle is left in ACCESSORY mode for more than 20 minutes or IGNI-
TION ON mode (the engine is not running) for more than an hour with the
shift lever in P, the “ENGINE START STOP” switch will automatically turn off.
However, this function cannot entirely prevent battery discharge. Do not
leave the vehicle with the “ENGINE START STOP” switch in ACCESSORY
or IGNITION ON mode for long periods of time when the engine is not run-
ning.

Vehicles with a manual transmission
If the vehicle is left in ACCESSORY mode for more than 20 minutes or IGNI-
TION ON mode (the engine is not running) for more than an hour, the
“ENGINE START STOP” switch will automatically turn off. However, this
function cannot entirely prevent battery discharge. Do not leave the vehicle
with the “ENGINE START STOP” switch in ACCESSORY or IGNITION ON
mode for long periods of time when the engine is not running.

■

Operation of the “ENGINE START STOP” switch

When operating the “ENGINE START STOP” switch, one short, firm press is
enough. If the switch is pressed improperly, the engine may not start or the
“ENGINE START STOP” switch mode may not change. It is not necessary to
press and hold the switch.

■

Electronic key battery depletion

P. 45

■

Conditions affecting operation

P. 41

■

Note for the entry function

P. 42

175

2-1. Driving procedures

2

When

 d

riving

tC_OM_OM21056U_(U)

■

If the engine does not start

The engine immobilizer system may not have been deactivated. (

P. 102)

Contact your Scion dealer.

■

Steering lock

After turning the “ENGINE START STOP” switch off and opening and closing
the doors, the steering wheel will be locked due to the steering lock function.
Operating the “ENGINE START STOP” switch again automatically cancels
the steering lock.

■

When the steering lock cannot be released

■

Steering lock motor overheating prevention

To prevent the steering lock motor from overheating, the motor may be sus-
pended if the engine is turned on and off repeatedly in a short period of time.
In this case, refrain from operating the engine. After about 10 seconds, the
steering lock motor will resume functioning.

■

When the “ENGINE START STOP” switch indicator flashes in amber

The system may be malfunctioning. Have the vehicle inspected by your
Scion dealer immediately.

■

If the electronic key battery is depleted

P. 335

The green indicator light on the “ENGINE
START STOP” switch will flash. Press the
“ENGINE START STOP” switch again
while turning the steering wheel left and
right.

176

2-1. Driving procedures

tC_OM_OM21056U_(U)

CAUTION

■

When starting the engine

Always start the engine while sitting in the driver’s seat. Do not depress the
accelerator pedal while starting the engine under any circumstances.
Doing so may cause an accident resulting in death or serious injury.

■

Caution while driving

If the vehicle begins to slide due to engine failure or other circumstances, do
not lock or open the doors until the vehicle reaches a safe and complete
stop. Activation of the steering lock in this circumstance may lead to an acci-
dent, resulting in death or serious injury.

■

Stopping the engine in an emergency

If you want to stop the engine in an emergency while driving the vehicle,
press and hold the “ENGINE START STOP” switch for more than 2 seconds,
or press it briefly 3 times or more in succession.
However, do not touch the “ENGINE START STOP” switch while driving
except in an emergency. Turning the engine off while driving will not cause
loss of steering or braking control, but the power assist to these systems will
be lost. This will make it more difficult to steer and brake, so you should pull
over and stop the vehicle as soon as it is safe to do so.
