7-8. Declaration of Conformity

7

Customer In

fo

rma

tio

n and Re

porting Safety

D

e

fects

■

Type B



For vehicles sold in the U.S.A. and Canada

563

iA_OM_OM99M17z_(U)

8

Specifications

8-1. Identification Numbers

Vehicle Information

Labels ............................. 564

8-2. Specifications

Specifications.................... 566

8-3. Customizable Features

Customizable

Features.......................... 572

564

iA_OM_OM99M17z_(U)

8-1. Identification Numbers

Vehicle Information Labels

The vehicle identification number
legally identifies your vehicle. The
number is on a plate attached to
the cowl panel located on the left
corner of the dashboard. This
plate can easily be seen through
the windshield.

Open the cover shown in the fig-
ure to check the chassis number.

Vehicle Identification Number

Motor Vehicle Safety Standard Label

Chassis Number

565

8-1. Identification Numbers

iA_OM_OM99M17z_(U)

8

Specifica

tio

ns

Vehicle Emission Control Information Label

Tire Pressure Label

Engine Number

Forward

566

iA_OM_OM99M17z_(U)

8-2. Specifications

Specifications

*

The spark plugs provide the engine its optimum performance. Consult your
Scion dealer for details.

Engine

Item

Specification

Type

DOHC-16V in-line, 4-cylinder

Bore

 Stroke

2.93

 3.38 in. (74.5  85.8 mm)

Displacement

1,496.1 ml (1,496.1 cc)

Compression ratio

12.0

Electrical System

Item

Classification

Battery

12V-60Ah/20HR

Spark-plug number

spark plug required

*

P51R-18-110

NOTICE

When cleaning the iridium plugs, do not use a wire brush. The fine particu-
late coating on the iridium alloy and platinum tips could be damaged.

567

8-2. Specifications

iA_OM_OM99M17z_(U)

8

Specifica

tio

ns

Refer to Introduction on (

P. 418) for owner’s responsibility in protecting your

investment.

Approximate Quantities:

Check oil and fluid levels with dipsticks or reservoir gauges.

Lubricant Quality

Item

Classification

Engine oil

Refer to Recommended Oil on P. 429.

Manual transaxle oil

API Service

GL-4

SAE

75W-80

Automatic transaxle fluid

ATF required

Brake/Clutch fluid

SAE J1703 or FMVSS116 DOT-3

Capacities

Item

Capacity

Engine oil

With oil filter replacement

4.4 qt. (4.2 L, 3.7 Imp.qt.)

Without oil filter replace-
ment

4.1 qt. (3.9 L, 3.4 Imp.qt.)

Coolant

Manual transaxle

5.7 qt. (5.4 L, 4.8 Imp.qt.)

Automatic transaxle

5.9 qt. (5.6 L, 4.9 Imp.qt.)

Manual transaxle oil

1.68 qt. (1.59 L, 1.40 Imp.qt.)

Automatic transaxle fluid

7.6 qt. (7.2 L, 6.3 Imp.qt.)

Fuel tank

11.6 gal. (44.0 L, 9.68 Imp.gal.)

568

8-2. Specifications

iA_OM_OM99M17z_(U)

Dimensions

Item

Vehicle specification

Overall length

171.7 in. (4,360 mm)

Overall width

66.7 in. (1,695 mm)

Overall height

58.3 in. (1,480 mm)

Front track

58.9 in. (1,495 mm)

Rear track

58.5 in. (1,485 mm)

Wheelbase

101.2 in. (2,570 mm)

Weights

Item

Weight

Manual transaxle

Automatic transaxle

GVWR
(Gross Vehicle Weight Rating)

3,344 lb. (1,517 kg)

3,393 lb. (1,539 kg)

GAWR (Gross Axle
Weight Rating)

Front

1,753 lb. (795 kg)

1,795 lb. (814 kg)

Rear

1,638 lb. (743 kg)

1,627 lb. (738 kg)

569

8-2. Specifications

iA_OM_OM99M17z_(U)

8

Specifica

tio

ns

The type of refrigerant used is indicated on a label attached to the
inside of the engine compartment. Check the label before recharging
the refrigerant. Refer to Climate Control System on P. 234.



For Exterior light

*

1

 UNECE stands for United Nations Economic Commission for Europe.

*

2

LED is the abbreviation for Light Emitting Diode.

*

3

Double-filament light bulb, however, only 60 W filament bulb is used in the
daytime running lights.

Air Conditioner

Item

Classification

Refrigerant Type

HFC134a (R-134a)

Light Bulbs

Light bulb

Category

Wattage

UNECE

*

1



(SAE)

Headlights

60/55

H4 (H4)

Daytime running lights (if equipped)

60/55

*

3

H4 (H4)

Front side- marker lights

5

WY5W (

)

Parking lights

21

WY21W

(7443NA)

Front turn signal lights

28/8



(7444NA)

Fog lights (if equipped)

55

H11 (H11)

Side turn signal lights (if equipped)

LED

*

2

 ()

High-mount brake light

LED

*

2

 ()

Rear turn signal lights

21

WY21W

(7443NA)

Brake lights/Taillights

21/5

W21/5W

(7443)

Rear side-marker lights

5

W5W (

)

Reverse lights

18

W16W

(921)

License plate lights

5

W5W (

)

570

8-2. Specifications

iA_OM_OM99M17z_(U)



For Interior light

*

1

 UNECE stands for United Nations Economic Commission for Europe.

Check the tire pressure label for tire size and inflation pressure.

Refer to Tire Inflation Pressure on P. 446.

After adjusting the tire pressure, initialization of the tire pressure mon-
itoring system is necessary to make the system operates normally.

Refer to Tire Pressure Monitoring System Initialization on P. 221.

■

Standard tire

1 person’s weight: About 75 kg

■

Temporary spare tire

Light bulb

Category

Wattage

UNECE

*

1

Trunk light

3



Overhead lights

8



Tires

Tire size

Inflation pressure

P185/65R15 86H

Front:
255 kPa (37 psi)
Rear:
230 kPa (33 psi)

P185/60R16 86H

Front:
250 kPa (36 psi)
Rear:
230 kPa (33 psi)

Tire size

Inflation pressure

T125/70D15 95M

420 kPa (60 psi)

571

8-2. Specifications

iA_OM_OM99M17z_(U)

8

Specifica

tio

ns

■

Lug nut tightening torque

When installing a tire, tighten the lug nut to the following torque.
80-108 ft

•

lbf (108-147 N

•

m, 12-14 kgf

•

m)

The tires have been optimally matched with the chassis of your vehicle.

When replacing tires, Scion recommends that you replace tires of the
same type originally fitted to your vehicle. For details, contact your Scion
dealer.

Refer to Fuses on P. 460.

Fuses

572

iA_OM_OM99M17z_(U)

8-3. Customizable Features

Customizable Features

The following customizable features can be set or changed by your
Scion dealer. Consult your Scion dealer for details.

Additionally, some of the customizable features can be changed by
the customer depending on the feature.

Customizable features which can be changed differ depending on the
market and specification.

Settings can be changed by operating the center display screen.

Settings can be changed by operating the vehicle switches.

Settings can be changed by your Scion dealer.

1
2
3

573

8-3. Customizable Features

iA_OM_OM99M17z_(U)

8

Specifica

tio

ns

Item

Feature

Factory

Setting

Avail-

able

Settings

Settings change

method

Safety

Smart
City
Brake
Support
(SCBS)
Refer to
Smart
City
Brake
Support
(SCBS)
on
P. 205.

The sys-
tem can
be
changed
so that
Smart
City
Brake
Support
(SCBS)
does not
oper-
ate.

*

1

On

On/Off



Refer to

Set-

tings on

P. 295.



Refer to

Stop-

ping

The

Smart

City

Brake

Sup-

port

(SCBS)

System

Opera-

tion on
P. 210.





Vehicle

Power
door lock
Refer to
Auto
Lock/
Unlock
Function
on P. 98.

Changes
the auto
lock/
unlock
function
setting for
all the
doors
accord-
ing to the
vehicle
speed,
the vehi-
cle power
supply
condi-
tion, and
the selec-
tor lever
position.

Lock:

When

Driving

Unlock:
IGN Off

Lock:

When

Driving

Unlock:

In Park/

Lock:

Out of

Park

Unlock:

In Park/

Lock:

Shifting

Out of

Park/
Lock:

When

Driving

Unlock:

IGN Off/

Lock:

When

Driving/

Off



Refer to

Set-

tings on

P. 295.



Refer to

Auto

Lock/

Unlock

Func-

tion on

P. 98.



1

2

3

574

8-3. Customizable Features

iA_OM_OM99M17z_(U)

Vehicle

Keyless
entry sys-
tem
Refer to
Keyless
Entry
System
on P. 88.

The
method
for
unlock-
ing the
doors
using the
smart
Key can
be
changed.

Driver’s:

Once,

All

Doors:

Twice

All

Doors:

Once/

Driver’s:

Once,

All

Doors:

Twice



Refer to

Set-

tings on

P. 295.



Refer to

Smart

Key on

P. 89.



The time
required
for the
doors to
relock
automati-
cally after
unlock-
ing with
the smart
Key can
be
changed.

60 sec-

onds

90 sec-

onds/

60 sec-

onds/

30 sec-

onds



Refer to

Set-

tings on

P. 295.





Item

Feature

Factory

Setting

Avail-

able

Settings

Settings change

method

1

2

3

575

8-3. Customizable Features

iA_OM_OM99M17z_(U)

8

Specifica

tio

ns

Vehicle

Illumina-
tion entry
Refer to
Illumi-
nated
Entry
System
on P. 408.

The time
required
for the
interior
lamp to
turn off
automati-
cally can
be
changed
(pre-
vents bat-
tery
depletion
when a
door is
open/
ajar).

30 min-

utes

60 min-

utes/

30 min-

utes/

10 min-

utes



Refer to

Set-

tings on

P. 295.





The time
required
for the
interior
lamp to
turn off
automati-
cally after
all doors
are
closed
can be
changed.

15 sec-

onds

60 sec-

onds/

30 sec-

onds/

15 sec-

onds/

7.5 sec-

onds



Refer to

Set-

tings on

P. 295.





Item

Feature

Factory

Setting

Avail-

able

Settings

Settings change

method

1

2

3

576

8-3. Customizable Features

iA_OM_OM99M17z_(U)

Vehicle

Daytime
running
lights
Refer to
Daytime
Running
Lights on
P. 178.

The func-
tion of the
daytime
running
lights can
be
changed.

On

On/Off



Refer to

Set-

tings on

P. 295.





Auto
headlight
off
Refer to
Head-
lights on
P. 175.

The time
required
for head-
lights to
turn off
after igni-
tion is
switched
off can be
changed.

30 sec-

onds

120

sec-

onds/

90 sec-

onds/

60 sec-

onds/

30 sec-

onds/

Off

*

2



Refer to

Set-

tings on

P. 295.





Lights-on
reminder

*

3

 Refer

to Lights-
On
Reminder
on P. 522.

The vol-
ume of
the lights-
on
reminder
warning
alarm can
be
changed.

Off

High/

Low/

Off



Refer to

Set-

tings on

P. 295.





Item

Feature

Factory

Setting

Avail-

able

Settings

Settings change

method

1

2

3

577

8-3. Customizable Features

iA_OM_OM99M17z_(U)

8

Specifica

tio

ns

Vehicle

Coming
home
light sys-
tem Refer
to Com-
ing Home
Light
System
on
P. 177.

The time
required
for the
head-
lights to
turn off
after clos-
ing all of
the doors
can be
changed.

30 sec-

onds

120

sec-

onds/

90 sec-

onds/

60 sec-

onds/

30 sec-

onds/

Off



Refer to

Set-

tings on

P. 295.





Leaving
home
light sys-
tem Refer
to Leav-
ing Home
Light
System
on
P. 177.

The leav-
ing home
light sys-
tem func-
tion can
be
changed.

On

On/Off



Refer to

Set-

tings on

P. 295.





Vehicle

Turn indi-
cator
Refer to
Turn and
Lane-
Change
Signals
on
P. 180.

The turn
indicator
beep vol-
ume level
can be
changed.

High

High/

Low



Refer to

Set-

tings on

P. 295.





Three-
flash turn
signal
Refer to
Three-
Flash
Turn Sig-
nal on
P. 181.

The
three-
flash turn
function
can be
changed.

On

On/Off



Refer to

Set-

tings on

P. 295.





Item

Feature

Factory

Setting

Avail-

able

Settings

Settings change

method

1

2

3
