Vauxhall ADAM (2012 year). Manual

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

141

Automatic deactivation:

Switching off

Activation

●

Vehicle speed is below approx.

Press m; control indicator m in

20 mph.

instrument cluster extinguishes. The

●

Vehicle speed drops more than

stored speed is deleted.

15 mph below the set speed.

Pressing L to activate the speed

●

The brake pedal is depressed.

limiter or switching off the ignition also

●

The clutch pedal is depressed for

switches off cruise control and

a few seconds.

deletes the stored speed.

●

The selector lever is in N.

Speed limiter

●

Engine speed is in a very low

range.

The speed limiter prevents the

●

The Traction Control system or

vehicle exceeding a preset maximum

Electronic Stability Control is

speed.

Press L. If cruise control has been

operating.

The maximum speed can be set at

activated before, it is switched off

●

Simultaneous pressing RES/+

speeds above 15 mph up to

when speed limiter is activated and

and brake pedal deactivates

125 mph.

the control indicator m extinguishes.

cruise control and will delete

The driver can only accelerate up to

stored speed.

the preset speed. Deviations from the

Set speed limit

limited speed may occur when driving

Accelerate to the desired speed and

Resume stored speed

downhill.

briefly turn thumb wheel to SET/-: the

Turn thumb wheel to RES/+ at a

The preset speed limit is displayed in

current speed is stored as maximum

speed above 20 mph. The stored

the Driver Information Centre when

speed. Speed limit is displayed in the

speed will be obtained.

the system is active.

Driver Information Centre.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

142

Driving and operating

In the event of an emergency, it is

By pressing m to activate cruise

possible to exceed the speed limit by

control, speed limiter is also

depressing the accelerator pedal

deactivated and the stored speed is

firmly nearly to the final point. In this

deleted.

case no chime appears.

By switching off the ignition, speed

Release the accelerator pedal and

limiter is also deactivated, but the

the speed limiter function is

speed limit will be stored for next

reactivated once a speed lower than

speed limiter activation.

the limit speed is obtained.

Parking assist

Deactivation

Press y: speed limiter is deactivated

Rear parking assist

Change speed limit

and the vehicle can be driven without

speed limit.

9 Warning

With speed limiter active, turn thumb

The limited speed is stored.

wheel to RES/+ to increase or SET/-

It is the driver who bears full

to decrease the desired maximum

Additionally, a corresponding

responsibility for the parking

speed.

message appears on the Uplevel-

manoeuvre.

Display.

Exceeding the speed limit

Always check the surrounding

Resume limit speed

area while reversing and using the

When exceeding the limited speed

rear parking assist system.

without driver input, the speed will

Turn thumb wheel to RES/+. The

flash in the Driver Information Centre

stored speed limit will be obtained.

The rear parking assist makes

and a chime sounds during this

parking easier by measuring the

period.

Switching off

distance between the vehicle and

Press L, the speed limit indication in

rear obstacles. It informs and warns

the Driver Information Centre

the driver by giving acoustic and

extinguishes. The stored speed is

visual signals.

deleted.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

143

sounds becomes shorter as the

Manual deactivation is also possible

vehicle gets closer to that obstacle.

by pressing the parking assist button

When the distance is less than

approximately 30 cm, the sound is

In both cases the LED in the button

continuous.

extinguishes.

Additionally, the distance to rear

obstacles is displayed by changing

Fault

distance lines in the Driver

In the event of a fault or if the system

Information Centre 3 88 or,

does not work temporarily, e.g.

depending on the version, on the

because of high external noise level

Colour-Info-Display 3 93.

or other interference factors, the LED

in the button flashes for three

Deactivation

seconds and then extinguishes.

The system has four ultrasonic

Control indicator

illuminates in

parking sensors in the rear bumper.

the instrument cluster 3 86 and a

Activation

message pops-up in the Driver

When reverse gear is engaged, the

Information Centre.

system is ready to operate

Front-rear parking assist

automatically.

An illuminated LED in the parking

9 Warning

assist button

indicates that the

system is ready to operate.

The driver bears full responsibility

for the parking manoeuvre.

Indication

The system warns the driver with

Always check the surrounding

acoustic signals against potentially

area when driving backwards or

The system automatically switches

hazardous obstacles behind the

forwards while using parking

off when reverse gear is disengaged.

vehicle in a distance range up to

assist system.

1.5 metres. The interval between the

-------------------------------------------------------------------------------------------------------------------------------------------------------------

144

Driving and operating

The front-rear parking assist

Front-rear parking assist is always

A long press of

(approx.

measures the distance between the

combined with advanced parking

one second) activates or deactivates

vehicle and obstacles in front and

assist, see "Advanced parking assist"

the advanced parking assist, see

behind the vehicle. It informs and

section below.

separate description.

warns the driver by giving acoustic

Button logic operates the systems by

signals and display indication.

Parking assist button

and

pressing

as follows:

operation logic

●

If only front-rear parking assist is

active, a brief press deactivates

front-rear parking assist.

●

If only front-rear parking assist is

active, a long press activates

advanced parking assist.

●

If only advanced parking assist is

active and the system is in

parking slot searching mode, a

brief press activates front-rear

parking assist.

●

If only advanced parking assist is

The system has six ultrasonic parking

active and the system is in park

sensors in both the rear and front

Front-rear parking assist and

guiding mode, a brief press

bumper.

advanced parking assist both use the

deactivates advanced parking

same button for activation and

It uses two different acoustic warning

assist.

deactivation:

signals for the front and rear

●

If advanced parking assist is

monitoring areas, each with a

A brief press of

activates or

active, a long press deactivates

different tone frequency.

deactivates the parking assist.

advanced parking assist and

front-rear parking assist.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

145

● If a forward gear or neutral is

vehicle in a distance range up to 80

selected, a brief press activates

cm and against potentially hazardous

or deactivates only front parking

obstacles behind the vehicle in a

assist.

distance range up to 1.5 metres.

● If reverse gear is selected, a brief

Depending on which side of the

press activates or deactivates

vehicle is closer to an obstacle, you

front and rear parking assist.

will hear acoustic warning signals in

the vehicle on the respective side.

Activation

The interval between the sounds

The system is activated automatically

becomes shorter as the vehicle gets

at a speed up to 7 mph.

closer to that obstacle. When the

An illuminated LED in the parking

distance is less than approx. 30 cm,

assist button

indicates that the

the sound is continuous.

The distance to a front and rear

system is ready to operate.

Additionally, the distance to obstacles

obstacle is displayed by changing

is switched off within an ignition

is shown in the Driver Information

distance lines in the Driver

Centre 3 88 or, depending on the

Information Centre.

cycle, the front parking assist is

version, on the Colour-Info-Display

deactivated. If vehicle speed has

The distance indication can be

3 93.

exceeded 15 mph beforehand,

inhibited by vehicle messages with a

parking assist will be reactivated

higher priority. After dismissing the

when speed drops below 7 mph.

message distance indication appears

again.

When the system is deactivated, the

LED in the button extinguishes and

Park Assist Off pops-up in the Driver

Information Centre.

Indication

The system warns the driver with

acoustic signals against potentially

hazardous obstacles in front of the

-------------------------------------------------------------------------------------------------------------------------------------------------------------

146

Driving and operating

After a manual deactivation, the front-

Always check the surrounding

rear parking assist is activated again

area in all directions when using

if D

is pressed.

the advanced parking assist.

The complete system can be

manually deactivated in the vehicle

The advanced parking assist

personalisation menu in the

measures a suitable parking slot

Info-Display. It remains deactivated

while passing, calculates the

during the ignition cycle or until

trajectory and automatically steers

activation in personalisation menu

the vehicle into a parallel or

again. Vehicle personalisation 3 98.

perpendicular parking slot.

Instructions are given in the Driver

Fault

Information Centre 3 88 or,

In the event of a fault or if the system

The distance to obstacles is shown on

depending on the version, on the

does not work temporarily, e.g.

the Colour-Info-Display by coloured

Colour-Info-Display 3 93, supported

because of high external noise level

zones in front of or behind the vehicle

by acoustic signals.

or other interference factors, a

3 93.

message pops-up in the Driver

The driver must control acceleration,

Deactivation

Information Centre.

braking and gearshifting, while

steering is done automatically.

The system is deactivated

Vehicle messages 3 95.

automatically when vehicle speed

Advanced parking assist can only be

exceeds 7 mph.

Advanced parking assist

activated when driving forwards.

Manual deactivation is also possible

by pressing the parking assist button

9 Warning

The driver bears full responsibility

When the system is deactivated, the

for accepting the parking slot

LED in the button extinguishes and

suggested by the system and the

and, if manual deactivated,Park

parking manoeuvre.

Assist Off pops-up in the Driver

Information Centre.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

147

Button logic operates the systems by

● If forward gear or neutral is

pressing

as follows:

selected, a brief press activates

or deactivates front parking

●

If only front-rear parking assist is

assist.

active, a brief press deactivates

front-rear parking assist.

● If reverse gear is selected, a brief

press activates or deactivates

●

If only front-rear parking assist is

front and rear parking assist.

active, a long press activates

advanced parking assist.

Activation

●

If only advanced parking assist is

active and the system is in

parking slot searching mode, a

brief press activates front-rear

Advanced parking assist is always

parking assist.

combined with front-rear parking

●

If only advanced parking assist is

assist, see previous section. Both

active and the system is in park

systems use the same sensors in the

guiding mode, a brief press

front and rear bumper.

deactivates advanced parking

Button

and operation logic

assist.

Advanced parking assist and front-

●

If advanced parking assist is

rear parking assist both use the same

active, a long press deactivates

button for activation and deactivation:

advanced parking assist and

When searching for a parking slot, the

front-rear parking assist.

A brief press of

activates or

system is ready to operate with a long

deactivates the parking assist.

press of

A long press of

(approx.

The system recognises and

one second) activates or deactivates

memorises ten metres for parallel

the advanced parking assist, see

parking slots or six metres for

separate description below.

perpendicular parking slots in the

parking assist mode.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

148

Driving and operating

The system can only be activated at

a speed up to 18 mph and the system

searches for a parking slot at a speed

up to 18 mph.

The maximum allowed parallel

distance between the vehicle and a

row of parked cars is 1.8 metres for

parallel parking and 2.5 metres for

perpendicular parking.

Functionality

Parking slot searching mode

Indication in the Driver Information

Select parallel or perpendicular

When a slot is detected, visual

Centre

parking slot in Driver Information

feedback in the Driver Information

Centre by pressing SET/CLR.

Centre and an acoustic signal are

given.

The system is configured to detect

parking slots by default on the

Indication in the Colour-Info-Display

passenger side. To detect parking

slots on the driver side, switch on turn

signal indicator on the driver side.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

149

Select parallel or perpendicular

metres for parallel parking slots or six

Display indication

parking slot by tapping the respective

metres for perpendicular parking slots

The instructions in the display show:

icon on the display.

after the Stop message is given. The

●

general hints and warning

system calculates the optimal path

Select parking side by tapping the

messages

into the parking slot.

respective icon on the display.

●

a hint when driving faster than

A brief vibration in the steering wheel

18 mph during parking slot

after engaging reverse gear indicates

searching mode, or 5 mph in

that the steering is controlled by the

guiding mode

system. Then the vehicle is steered

●

the demand to stop the vehicle,

into the slot automatically by giving

when a parking slot is detected

the driver detailed instructions for

braking, accelerating and

●

the direction of driving during the

gearshifting. The driver must keep

parking manoeuvre

hands away from the steering wheel.

●

the demand to gearshift

Always pay attention to the sound of

rearwards or forwards

the front-rear parking assist.

●

the demand to accelerate or

Continuous sound indicates that the

brake

distance to an obstacle is less than

●

for some of the instructions a

When a slot is detected, visual

approx. 30 cm.

progress bar is shown in the

feedback on the Colour-Info-Display

If, for any reason, the driver must take

Driver Information Centre

and an acoustic signal are given.

over control of the steering, hold the

●

successful parking manoeuvre

If the driver does not stop the vehicle

steering wheel only at the outer edge.

indicated by a pop-up symbol

after a parking slot is proposed, the

Automatic steering is cancelled in this

and a chime,

system starts to search for another

event.

suitable parking slot.

●

the cancelling of a parking

manoeuvre

Park guiding mode

The parking slot suggestion of the

system is accepted when the vehicle

is stopped by the driver within ten

-------------------------------------------------------------------------------------------------------------------------------------------------------------

150

Driving and operating

Display priorities

Deactivation by the driver or by the

Basic notes on parking assist

Advanced parking assist indication on

system during manoeuvring will be

systems

the Driver Information Centre can be

indicated by Parking Deactivated on

inhibited by vehicle messages with a

the display. Additionally, an acoustic

9 Warning

higher priority. After approving the

signal sounds.

message by pressing SET/CLR on

Under certain circumstances,

Fault

the turn signal lever, advanced

various reflective surfaces on

parking assist instructions appear

A message appears when:

objects or clothing as well as

again and the parking manoeuvre can

● there is a fault in the system

external noise sources may cause

be continued.

● the driver did not successfully

the system to fail to detect

complete the parking manoeuvre

obstacles.

Deactivation

● the system is not operational

Special attention must be paid to

The system is deactivated by:

low obstacles which can damage

●

a long press of

● any of the deactivation reasons

the lower part of the bumper.

described above apply

●

parking manoeuvre successfully

ended

If an object is detected during parking

instructions, Stop is indicated on the

Caution

●

driving faster than 18 mph during

display. Removing the object will

parking slot search

resume the parking manoeuvre. If the

Performance of the system can be

●

driving faster than 5 mph during

object is not removed, the system will

reduced when sensors are

parking guidance

be deactivated. A long press of

covered, e.g. by ice or snow.

●

driver interference on steering

will activate the system and search for

Performance of the parking assist

wheel detected

a new parking slot.

system can be reduced due to

●

exceeding the maximum number

heavy loading.

of gear changes: eight parking

Special conditions apply if there

cycles when parallel parking or

are taller vehicles in the vicinity

five cycles when perpendicular

(e.g. off-road vehicles, mini vans,

parking

vans). Object identification and

●

switching off the ignition

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

151

gateway, a courtyard or even a

correct distance indication in the

Side blind spot alert

crossing as a parking slot. After

upper part of these vehicles

The Side blind spot alert system

selecting reverse gear the system

cannot be guaranteed.

detects and reports objects on either

will start a parking manoeuvre. Take

Objects with a very small reflection

side of the vehicle, within a specified

care regarding the availability of the

cross-section, e.g. objects of

"blind spot" zone. The system alerts

suggested parking slot.

narrow size or soft materials, may

visually in each exterior mirror, when

Surface irregularities, e.g. on

not be detected by the system.

detecting objects that may not be

construction zones, are not detected

visible in the interior and exterior

Parking assist systems do not

by the system. The driver accepts

mirrors.

detect objects outside the

responsibility.

detection range.

Side blind spot alert uses some of the

Notice

advanced parking assist sensors

Notice

If engaging a forward gear and

which are located in the front and rear

It is possible that the sensor detects

exceeding a certain speed, the rear

bumper on both sides of the vehicle.

parking assist will be deactivated

a non-existing object caused by

when the rear carrier system is

echo disturbance from external

9 Warning

extended.

acoustic noise or mechanical

misalignments (sporadic false

If engaging reverse at first, the

Side blind spot alert does not

warnings may occur).

parking assist will detect the rear

replace driver vision.

carrier system and provide a buzzing

Make sure that the front number

The system does not detect:

plate is properly mounted (not bent

sound. Press

briefly to

● Vehicles outside the side blind

and no gaps to the bumper on the left

deactivate the parking assist.

zones which may be rapidly

or right side) and the sensors are

Notice

approaching.

firmly in place.

After production, the system

● Pedestrians, cyclists or

Advanced parking assist system

requires a calibration. For optimal

animals.

may not respond to changes in the

parking guidance, a driving distance

Before changing a lane, always

available parking space after

of at least 6 miles, including a

check all mirrors, look over the

initiating a parking manoeuvre. The

number of bends, is required.

shoulder and use the turn signal.

system may recognize an entry, a

-------------------------------------------------------------------------------------------------------------------------------------------------------------

152

Driving and operating

When the system detects a vehicle in

Side blind spot alert is active from

Side blind spot alert is designed to

the side blind zone while driving

speeds of 6 mph up to 87 mph.

ignore stationary objects, e.g.

forwards, either while passing a

Driving faster than 87 mph

guardrails, posts, curbs, walls and

vehicle or being passed, a yellow

deactivates the system, indicated by

beams. Parked vehicles or oncoming

warning symbol B will illuminate in

low lighting warning symbols B in

vehicles are not detected.

the relevant exterior mirror. If the

both exterior mirrors. Reducing the

driver then activates the turn signal,

speed again will extinguish the

Fault

the warning symbol B starts flashing

warning symbols. If a vehicle is then

Occasional missed alerts can occur

yellow as a warning not to change

detected in the blind zone, the

under normal circumstances and will

lanes.

warning symbols B will illuminate as

increase in wet conditions.

normal on the relevant side.

Notice

Side blind spot alert does not operate

If the passing vehicle is at least

When the vehicle is started, both

when the left or right corners of the

6 mph faster than the passed

exterior mirror displays will briefly

rear bumper are covered with mud,

vehicle, the warning symbol B in the

come on to indicate that the system is

dirt, snow, ice, slush, or in heavy

relevant exterior mirror may not

operating.

rainstorms. Cleaning instructions

illuminate.

The system can be activated or

3 205.

deactivated in the Info-Display,

In the event of a fault in the system or

vehicle personalisation 3 98.

if the system does not work due to

Deactivation is indicated by a

temporary conditions, a message is

message in the Driver Information

displayed in the Driver Information

Centre.

Centre. Seek the assistance of a

workshop.

Detection zones

The detection zones start at the rear

bumper and extend approx. three

metres rearwards and to the sides.

The height of the zone is between

approx. 0.5 metres and two metres off

the ground.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

153

The boiling point depends on the

Fuel

Caution

pressure and mixing ratio. At ambient

pressure, it is between -42 °C (pure

Fuel for petrol engines

Use of fuel that does not comply to

propane) and -0.5 °C (pure butane).

Only use unleaded fuel that complies

EN 228 or E DIN 51626-1 or

with European standard EN 228 or

equivalent can lead to deposits or

Caution

E DIN 51626-1 or equivalent.

engine damage.

The engine is capable of running with

The system works at an ambient

fuel that contains up to 10% ethanol

Caution

temperature of approx. -8 °C to

(e.g. named E10).

100 °C.

Use fuel with the recommended

Use of fuel with too low an octane

octane rating. The engine specific

rating could lead to uncontrolled

Full function of the LPG system can

requirements are given in the engine

combustion and engine damage.

only be guaranteed with liquid gas

which complies with the minimum

data overview 3 217. A country

requirements of DIN EN 589.

specific label at the fuel filler flap can

Fuel for liquid gas operation

supersede the requirement.

Liquid gas is known as LPG

Fuel selector

(Liquefied Petroleum Gas) or under

Caution

its French name GPL (Gaz de Pétrole

Liquéfié). LPG is also known as

Do not use fuel or fuel additives

Autogas.

that contain metallic compounds

LPG consists mainly of propane and

such as manganese-based

butane. The octane rating is between

additives. This may cause engine

105 and 115, depending on the

damage.

butane proportion. LPG is stored

liquid at around five to ten bar

pressure.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

154

Driving and operating

Pressing LPG switches between

The selected fuel mode is stored and

Due to extreme temperatures in

petrol and liquid gas operation as

reactivated at the next ignition cycle if

combination with the gas

soon as the required parameters

conditions allow.

composition, it may take slightly

(coolant temperature, gas

longer before the system switches

As soon as the liquid gas tanks are

temperature and minimum engine

from petrol to gas mode.

empty, petrol operation is

speed) have been reached. The

automatically engaged until the

In extreme situations, the system may

requirements are usually fulfilled after

ignition is switched off.

also switch back to petrol mode if the

approx. 60 seconds (depending on

minimum requirements are not

When switching automatically

exterior temperature) and the first firm

fulfilled. If conditions allow, it might be

between petrol or gas operation, a

press on the accelerator. The LED

possible to manually switch back to

brief delay of engine tractive power

status shows the current operating

liquid gas operation.

may be noticeable.

mode.

Seek the assistance of a workshop in

Every six months, run the petrol tank

LED off

: petrol operation

the event of all other faults.

down until control indicator Y

LED

: checking conditions for

illuminates, then refuel. This helps

flashes

fuel transition to liquid

maintain fuel quality and system

Caution

gas operation.

function for petrol operation.

Illuminates if conditions

Repairs and adjustments may only

are fulfilled.

Fill the tank completely at regular

be made by trained specialists in

LED illu-

: liquid gas operation

intervals to prevent corrosion in the

order to maintain the safety and

minates

tank.

warranty on the LPG system.

LED

: liquid gas tank is empty

Faults and remedies

flashes

or failure in liquid gas

Liquid gas is given a particular odour

five

system. A message is

If gas mode is not possible, check the

(odorised) so that any leaks can be

times

displayed in the Driver

following:

detected easily.

and

Information Centre.

● Is there enough liquid gas

extin-

present?

guishes

● Is there enough petrol present for

If the fuel tank is empty, the engine

starting?

will not start.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

155

9 Warning

9 Danger

If you smell gas in the vehicle or in

Fuel is flammable and explosive.

the immediate vicinity, switch to

No smoking. No naked flames or

petrol mode immediately. No

sparks.

smoking. No naked flames or

If you can smell fuel in your

ignition sources.

vehicle, have the cause of this

remedied immediately by a

If the gas odour persists, do not start

workshop.

the engine. Have the cause of the

fault remedied by a workshop.

Caution

When using underground car parks,

The fuel filler flap can only be opened

follow the instructions of the operator

In case of misfuelling, do not

when the vehicle is unlocked.

and local laws.

switch on ignition.

Push the flap to engage. Then open

Notice

the flap.

In the event of an accident, switch off

Fuel filler flap is located at right rear

the ignition and lights.

Turn the fuel filler cap slowly

side of the vehicle.

anticlockwise to open.

Refuelling

9 Danger

Before refuelling, switch off the

ignition.

Follow the operating and safety

instructions of the filling station

when refuelling.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

156

Driving and operating

Liquid gas refuelling

Follow the operating and safety

instructions of the filling station when

refuelling.

The filling valve for the liquid gas is

behind the fuel filler cap.

The fuel filler cap can be retained in

Screw the required adapter hand-

the bracket on the fuel filler flap.

tight onto the filler neck.

To refuel, fully insert the pump nozzle

and switch it on.

After the automatic cut-off, the tank

can be topped up by operating the

pump nozzle a maximum of two more

times.

Unscrew protective cap from the filler

neck.

Caution

Wipe off any overflowing fuel

immediately.

To close, turn the fuel filler cap

clockwise until it clicks.

Close the flap and allow it to engage.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

157

Driving and operating

ACME Adapter: Screw the nut of the

Fit protective cap to prevent the

Filling adapter

filling nozzle onto the adapter. Press

penetration of foreign bodies into the

As filling systems are not

locking lever on filler nozzle down.

filler opening and the system.

standardised, different adapters are

DISH filler neck: Place the filler nozzle

required which are available from

into the adapter. Press locking lever

9 Warning

Vauxhall Distributors and from

on filler nozzle down.

Vauxhall Authorised Repairers.

Due to the system design, an

Bayonet filler neck: Place filler nozzle

escape of liquid gas after

on the adapter and turn clockwise or

releasing the locking lever is

anticlockwise through one quarter

unavoidable. Avoid inhaling.

turn. Pull locking lever of filler nozzle

fully.

EURO filler neck: Press the filler

9 Warning

nozzle onto the adapter until it

engages.

The liquid gas tank should only be

filled to 80% capacity, for safety

Press the button at the liquid gas

reasons.

supply point. The filling system stops

or begins to run slowly when 80% of

The multivalve on the liquid gas tank

the tank volume is reached

automatically limits the fill quantity. If

(maximum fill level).

ACME adapter: Belgium, Germany,

a larger quantity is added, we

Ireland, Luxembourg, Switzerland

Release button on filling system and

recommend not exposing the vehicle

the filling process stops. Release the

to the sun until the excess amount

locking lever and remove the filler

has been used up.

nozzle. A small quantity of liquid gas

may escape.

Remove adapter and stow securely in

vehicle.

Vauxhall ADAM (2012 year). Manual - part 9
