CONTROLS

Switching off and brief wipe

Activating/deactivating

Press the lever down.

Press the button on the wiper lever.

▷ To switch off from fast wiper speed: press

Wiping is started.

down twice.

If the vehicle is equipped with a rain sensor: the

▷ To switch off from normal wiper speed:

LED in the wiper lever is illuminated.

press down once.

If wipers are frozen to windshield, wiper opera-

▷ Brief wipe: press down once.

tion is deactivated.

The lever automatically returns to its initial po-

During trip interruption with the rain sensor

sition when released.

switched on: if the trip is resumed within ap-

prox. 15 minutes, the rain sensor is automati-

Interval mode or rain sensor

cally activated again.

Concept

Setting the frequency or sensitivity of

The rain sensor automatically controls the time

the rain sensor

between wipes depending on the intensity of

the rainfall.

General information

The sensor is located on the windshield, directly

in front of the interior mirror. Without the rain

sensor, the frequency of the wiper operation is

preset.

Safety information

Turn the thumbwheel to adjust the frequency

NOTE

or sensitivity of the rain sensor.

If the rain sensor is activated, the wipers

Up: short interval or high sensitivity of the rain

can accidentally start moving in vehicle washes.

sensor.

There is a risk of damage to property. Deacti-

Down: long interval or low sensitivity of the rain

vate the rain sensor in vehicle washes.◀

sensor.

79

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Driving

Windshield washer system

Rear window wiper

Safety information

Overview

WARNING

The washer fluid can freeze onto the win-

dow at low temperatures and obstruct the

view. There is a risk of an accident. Only use the

washer systems, if the washer fluid cannot

freeze. Use antifreeze, if needed.◀

NOTE

When the washer fluid reservoir is empty,

the wash pump cannot work as intended.

There is a risk of damage to property. Do not

Switching on the rear window wiper

use the washer system when the washer fluid

Turn the outer switch upward.

reservoir is empty.◀

▷ Resting position of the wiper, position 0.

▷ Intermittent mode, arrow 1. When reverse

Cleaning the windshield

gear is engaged, the system switches to

continuous operation.

Clean the rear window

Turn the outer switch in the desired direction.

▷ In resting position: turn the switch down-

ward, arrow 3. The switch automatically re-

turns to its resting position when released.

▷ In intermittent mode: turn the switch fur-

ther, arrow 2. The switch automatically re-

Pull the lever.

turns to its intermittent position when re-

The system sprays washer fluid on the wind-

leased.

shield and activates the wipers briefly.

Fold-away position of the wipers

Windshield washer nozzles

Concept

The washer jets are automatically heated

The fold-out position enables the wipers to be

whenever the ignition is switched on.

folded away from the windshield.

General information

Helpful when changing the wiper blades or un-

der frosty conditions, for instance.

80

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving

CONTROLS

Safety information

Folding down the wipers

WARNING

After the wipers are folded back down, the

wiper system must be reactivated.

If the wipers start moving in the folded

away state, body parts can be jammed or dam-

1. Fold the wipers back down onto the wind-

age may occur to parts of the vehicle. There is a

shield.

risk of injury or risk of damage to property.

2. Switch on the ignition.

Make sure that the vehicle is switched off when

3. Push wiper lever down. Wipers return to

the wipers are in the folded away state and the

their resting position and are ready again

wipers are folded in when switching on.◀

for operation.

NOTE

If the wipers are frozen to the windshield,

the wiper blades can be torn off and the wiper

Washer fluid

motor can overheat when switching on. There

is a risk of damage to property. Defrost the

General information

windshield prior to switching the wipers on.◀

All washer nozzles are supplied from one reser-

voir.

Folding away the wipers

Use a mixture of tap water and windshield

1.

Switch the ignition on and off again.

washer concentrate. If desired, a windshield

washer concentrate containing antifreeze can

2.

Press the wiper lever up beyond the point

be used.

of resistance and hold it for approx. 3 sec-

onds, until the wipers remain in a nearly

Recommended minimum fill quantity:

vertical position

0.2 US gal/1 liter.

Safety information

WARNING

Some antifreeze agents can contain

harmful substances and are flammable. There

is a risk of fire and a risk of injury. Follow the in-

structions on the containers. Keep antifreeze

away from ignition sources. Do not refill oper-

ating materials into different bottles. Store op-

3.

Fold the wipers all the way away from the

erating materials out of reach of children.

windshield.

United States: the washer fluid mixture ratio is

regulated by the U.S. EPA and many individual

states; do not exceed the allowable washer

fluid dilution ratio limits that apply. Follow the

usage instructions on the washer fluid con-

tainer.

Use of BMW’s Windshield Washer Concentrate

or the equivalent is recommended.◀

81

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Driving

WARNING

Manual transmission

Washer fluid can ignite and catch fire on

contact with hot engine parts. There is a risk of

Safety information

injury or risk of damage to property. Only add

WARNING

washer fluid when the engine is cooled down.

Next, fully close the lid of the washer fluid res-

An unsecured vehicle can begin to move

ervoir.◀

and possibly roll away. There is a risk of an acci-

dent. Before exiting, secure the vehicle against

NOTE

rolling.

Silicon-containing additives in the washer

In order to ensure that the vehicle is secured

fluid for the water-repelling effect on the win-

against rolling away, follow the following:

dows can lead to damage to the washing sys-

▷

Set the parking brake.

tem. There is a risk of damage to property. Do

▷

On uphill grades or on a downhill slope,

not add silicon-containing additives to the

turn the front wheels in the direction of the

washer fluid.◀

curb.

NOTE

▷

On uphill grades or on a downhill slope,

Mixing different windshield washer con-

also secure the vehicle, for instance with a

centrates or antifreeze can damage the wash-

wheel chock.◀

ing system. There is a risk of damage to prop-

NOTE

erty. Do not mix different windshield washer

When shifting to a lower gear, excessive

concentrates or antifreeze. Follow the informa-

speeds can damage the engine. There is a risk

tion and mixing ratios provided on the contain-

of damage to property. When shifting into 5th

ers.◀

or 6th gear, press the gearshift lever to the

right.◀

Overview

Schematic diagram

The washer fluid reservoir is located in the en-

gine compartment.

▷

1 - 6: forward gears

Malfunction

▷ R: reverse

The use of undiluted windshield washer con-

centrate or alcohol-based antifreeze can lead

to incorrect readings at temperatures below

+5 ℉/-15 ℃.

82

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving

CONTROLS

Shifting

▷ On uphill grades or on a downhill slope,

turn the front wheels in the direction of the

General information

curb.

Depending on the engine installation, the en-

▷ On uphill grades or on a downhill slope,

gine speed during a shifting operation is ad-

also secure the vehicle, for instance with a

justed automatically as required for harmo-

wheel chock.◀

nious and dynamic gear shifting.

Selector lever version

Reverse gear

Select only when the vehicle is stationary.

General information

Depending on the vehicle equipment, a trans-

To overcome the resistance push the gearshift

mission with either a latching selector lever or a

lever dynamically to the left and engage re-

tap-operated selector lever is installed.

verse gear with a forward shifting movement.

Transmission with a latching selector

Rolling or pushing the vehicle

lever

In some situations, the vehicle is to roll without

its own power, for instance in a vehicle wash, or

be pushed.

1. Switch on the ignition.

2. Press on the clutch pedal and shift out of a

forward gear or reverse.

3. Release the parking brake.

Steptronic transmission

The selector lever positions P, R, N, and D are

selected by moving the selector lever into the

Concept

respective selector lever position. The selector

lever engages in the selector lever positions.

The Steptronic transmission combines the func-

tions of an automatic transmission with the

possibility of manual shifting, if needed.

Transmission with a tap-operated

selector lever

Safety information

WARNING

An unsecured vehicle can begin to move

and possibly roll away. There is a risk of an acci-

dent. Before exiting, secure the vehicle against

rolling.

In order to ensure that the vehicle is secured

against rolling away, follow the following:

▷ Set the parking brake.

The selector lever positions P, R, N, and D are

selected by tapping the selector lever forward

83

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving

CONTROLS

▷ Unintentional shifting from selector lever

Engaging selector lever position D, N, R

position P into another selector lever posi-

A selector lever lock prevents the following

tion.

faulty operation:

1. To release the selector lever lock: with the

▷ Unintentional shifting into selector lever

brake pedal depressed, press the button on

position R.

the front of the selector lever.

▷ Unintentional shifting from selector lever

position P into another selector lever posi-

tion.

1. Press and hold the button to release the se-

lector lever lock.

2. Move the selector lever into the desired po-

sition.

2. With the driver's safety belt fastened, briefly

push the selector lever in the desired direc-

tion, past a resistance point, if needed. The

selector lever automatically returns to the

center position when released.

Engaging selector lever positions: with

a tap-operated selector lever

General information

To prevent the vehicle from creeping after you

select a drive mode, maintain pressure on the

brake pedal until you are ready to start.

Functional requirements

Only when the brake pedal is depressed is it

possible to change from selector lever posi-

tion P to another selector lever position.

Depending on the transmission version, the en-

gine may have to be running too.

85

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Driving

Engaging selector lever position P

4. Touch the selector lever lock and engage

selector lever position N.

5. Switch the engine off.

In this way, the ignition remains switched

on, and a Check-Control message is dis-

played.

The vehicle may roll.

NOTE

Selector lever position P is automatically

engaged when the ignition is switched off.

Press button P.

There is a risk of damage to property. Do not

switch drive-ready state off in vehicle washes.◀

Rolling or pushing the vehicle

Irrespective of the ignition, the selector lever

position P is automatically engaged after ap-

General information

prox. 15 minutes.

In some situations, the vehicle is to roll without

its own power for a short distance, for instance

If there is a malfunction, you may not be able

in a vehicle wash, or be pushed.

to change the selector lever position.

Electronically unlock the transmission lock, if

Engaging selector lever position N: with

needed, refer to page 89.

a latching selector lever

1. Switch on the ignition.

Kickdown

2. If necessary, release the parking brake.

Kickdown is used to achieve maximum driving

performance. Step on the accelerator pedal be-

3. Depress the brake pedal.

yond the resistance point at the full throttle po-

4. Touch the selector lever lock and engage

sition.

selector lever position N.

5. Release brake.

Sport program M/S

The vehicle may roll.

Concept

If there is a malfunction, you may not be able

The shifting points and shifting times in the

to change the selector lever position.

Sport program are designed for a sportier driv-

Manually unlock the transmission lock, if

ing style. The transmission, for instance shifts

needed, refer to page 88.

up later and the shifting times are shorter.

Engaging selector lever position N: with

a tap-operated selector lever

1. Start the engine while pressing on the

brake pedal.

2. If necessary, release the parking brake.

3. Depress the brake pedal.

86

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving

CONTROLS

Activating the sport program

Manual mode M/S becomes active and the gear

is changed.

The engaged gear is displayed in the instru-

ment cluster, for instance M1.

Shifting

▷ To shift down: press the selector lever for-

ward.

▷ To shift up: pull the selector lever rear-

wards.

Press the selector lever to the left out of selec-

The Steptronic transmission continues shifting

tor lever position D.

automatically in certain situations, for instance

The engaged gear is displayed in the instru-

when certain engine speed limits are reached.

ment cluster, for instance S1.

With a tap-operated selector lever: when M2 is

The sport program of the transmission is acti-

set manually while the vehicle is stationary, the

vated.

transmission will no longer shift back to M1.

This shifting behavior is retained until you en-

gage M1 manually or exit M.

Ending the Sport program

Push the selector lever to the right.

Avoiding automatic upshifting

D is displayed in the instrument cluster.

Once a particular engine speed is attained, M/S

manual mode is automatically upshifted as

Manual mode M/S

needed.

MINI John Cooper Works: once particular en-

Concept

gine speeds are attained, upshifting is not auto-

Manual gear-shifting is possible in manual

matically performed in M/S manual mode.

mode.

For vehicles with Steptronic Sport transmission,

automatic shift operations are not performed if

Activating manual mode

one of the following conditions is met:

1. Press the selector lever to the left out of se-

▷ DSC is deactivated.

lector lever position D, arrow 1.

▷ TRACTION is activated.

In addition, there is no downshifting for kick-

down.

With the appropriate transmission version, the

lowest possible gear can be selected by simul-

taneously activating kickdown and operating

the left shift paddles. This is not possible by

switching briefly via the shift paddles from se-

lector lever position D to manual mode M/S.

2. Push the selector lever forward or pull it

Ending the manual mode

backward, arrows 2.

Push the selector lever to the right.

87

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Driving

D is displayed in the instrument cluster.

Shifting

Shift paddles for Steptronic Sport

transmission

Concept

The shift paddles on the steering wheel allow

you to shift gears quickly while keeping both

hands on the steering wheel.

General information

▷ To shift up: briefly pull right shift paddle.

Shifting

▷ To shift down: briefly pull left shift paddle.

Gears will only be shifted at appropriate engine

▷ The lowest possible gear can be selected by

and road speeds, for instance downshifting is

pulling and holding the left shift paddle.

not possible if the engine speed is too high.

The selected gear is briefly displayed in the in-

strument cluster, followed by the current gear.

Short-term manual mode

In selector lever position D, actuating a shift

Displays in the instrument cluster

paddle switches into manual mode temporarily.

The selector lever position is dis-

After conservative driving in manual mode

played, for example P.

without acceleration or shifting via the shift

paddles for a certain amount of time, the trans-

mission switches back to automatic mode.

It is possible to switch into automatic mode as

Releasing the transmission lock

follows:

manually: with a latching selector lever

▷ Pull and hold right shift paddle.

If the selector lever is locked in selector lever

▷ In addition to the briefly pulled right shift

position P despite the ignition being switched

paddle, briefly pull the left shift paddle.

on, the brake pedal being depressed and the

button on the selector lever being pressed, the

Continuous manual mode

transmission lock can be unlocked manually:

In selector lever position S, actuating a shift

Before unlocking the transmission lock man-

paddle switches into manual mode perma-

ually, engage the parking brake forcefully to

nently.

prevent the vehicle from rolling away.

1. Loosen the selector lever sleeve, together

with the lower retaining ring, from the cen-

88

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving

CONTROLS

ter console. To do so, pull the retaining ring

Before unlocking the transmission lock, set the

upward at the rear edge.

parking brake to prevent the vehicle from roll-

ing away.

Engaging selector lever position N

Unlocking is possible, if the starter can spin the

engine.

1. Press and hold down brake pedal.

2. Press the Start/Stop button. The starter

must audibly start.

3. Press the button on the selector lever, ar-

2. Lift the sleeve. Unplug the cable connector,

row 1, and press and hold the selector lever

if needed.

into selector lever position N, arrow N, until

3. Using the screwdriver from the onboard ve-

selector lever position N is displayed in the

hicle tool kit, refer to page 233, press the

instrument cluster.

yellow release lever downward, see arrow.

A Check Control message is displayed.

4. Press the button on the front of the selector

4. Release the selector lever.

lever and move the selector lever back

5. Release brake, as soon as the starter stops.

slightly.

6. Maneuver the vehicle from the danger area

Release the release lever.

and secure it against moving on its own.

5. Bring the selector lever into the desired po-

For additional information, see the chapter on

sition.

tow-starting and towing.

For additional information, see the chapter on

tow-starting and towing.

Steptronic Sport transmission: Launch

Control

Releasing the transmission lock

electronically: with a tap-operated

Concept

selector lever

Launch Control enables optimum acceleration

on surfaces with good traction under dry sur-

General information

rounding conditions.

Electronically unlock the transmission lock to

maneuver vehicle from a danger area.

89

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Driving

General information

Repeated use during a trip

The use of Launch Control causes premature

After Launch Control has been used, the trans-

component wear since this function represents

mission must cool down for approx. 5 minutes

a very heavy load for the vehicle.

before Launch Control can be used again.

Do not use Launch Control during the break-in,

refer to page 184, period.

After using Launch Control

To increase vehicle stability, activate DSC Dy-

To start with Launch Control do not steer the

namic Stability Control again.

steering wheel.

System limits

Functional requirements

An experienced driver may be able to achieve

Launch Control is available as soon as the en-

better acceleration values in DSC OFF mode.

gine and transmission are at operating temper-

ature.

The engine is at operating temperature after an

uninterrupted trip of at least 6 miles/10 km.

Depending on the external temperature and

driving style, the transmission requires an unin-

terrupted trip of up to 30 miles/50 km in order

to reach the operating temperature required

for Launch Control.

Start with launch control

While the engine is running:

1.

Press button and select SPORT with

the MINI Driving Modes switch.

The instrument cluster displays TRACTION

in combination with SPORT. The DSC OFF

indicator light lights up.

2. Engage selector lever position S.

3. With the left foot, forcefully press down on

the brake.

4. Step on the accelerator pedal beyond the

resistance point at the full throttle position,

kickdown.

A flag symbol is displayed in the instrument

cluster.

5. The starting engine speed adjusts. Within

3 seconds, release the brake.

90

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Displays

CONTROLS

Displays

necessarily available in your vehicle, e. g., due

Vehicle features and op-

to the selected options or country versions. This

tions

also applies to safety-related functions and sys-

tems. When using these functions and systems,

This chapter describes all standard, country-

the applicable laws and regulations must be

specific and optional features offered with the

observed.

series. It also describes features that are not

Instrument cluster

Overview

1

Tachometer

96

4

Fuel gauge

96

2

Indicator/warning lights

5

Display/reset miles

96

3

Speedometer

6

Electronic displays

92

91

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Displays

Electronic displays

1

Driver assistance systems

Total miles/trip odometer

96

Messages, for instance Check Control

Onboard Computer

100

Time

96

2

Selector lever position

83

External temperature

96

Gear shift indicator

98

Selection lists

100

3

MINI Driving Modes switch status

136

Indicator/warning lights

Check Control

General information

Concept

The indicator/warning lights can light up in a

The Check Control system monitors functions in

variety of combinations and colors.

the vehicle and notifies you of malfunctions in

the monitored systems.

Several of the lights are checked for proper

functioning and light up temporarily when the

General information

engine is started or the ignition is switched on.

A Check Control message is displayed as a com-

Red lights

bination of indicator or warning lights and SMS

text messages in the instrument cluster and in

Safety belt reminder

the Head-up Display.

In addition, an acoustic signal may be output

Indicator light flashes or is illuminated:

and a SMS text message may appear on the

safety belt on the driver or passenger

Control Display.

side is not buckled. The safety belt re-

minder can also be activated if objects are

placed on the front passenger seat.

92

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Displays

CONTROLS

Make sure that the safety belts are positioned

Orange lights

correctly.

Active Cruise Control

Airbag system

The number bars shows the selected

distance from the vehicle driving ahead.

Airbag system and belt tensioner are

not working.

Camera-based cruise control, refer to

page 139.

Have the vehicle checked immediately

by a dealer’s service center or another qualified

service center or repair shop.

Vehicle detection, Active Cruise Control

Indicator light illuminates: a vehicle has

Parking brake

been detected ahead of you.

The parking brake is set.

Indicator light flashes: the conditions

are not adequate for the system to work.

Release the parking brake, refer to

page 74.

The system was deactivated but applies the

brakes until you actively resume control by

pressing on the brake pedal or accelerator

pedal.

Approach control warning

Indicator light illuminates: advance

Yellow lights

warning is issued, for example when

there is the impending danger of a colli-

Anti-lock Braking System ABS

sion or the distance to the vehicle ahead is too

Braking force boost may not be work-

small.

ing. Avoid abrupt braking. Take the lon-

Increase distance.

ger braking distance into account.

Indicator light flashes: acute warning of the im-

Have the system immediately checked

minent danger of a collision when the vehicle

by a dealer’s service center or another

approaches another vehicle at a relatively high

qualified service center or repair shop.

differential speed.

Intervention by braking or make an evasive

DSC Dynamic Stability Control

maneuver.

The indicator light flashes: DSC controls

the drive and braking forces. The vehi-

Person warning

cle is stabilized. Reduce speed and

If a collision with a person detected in

modify your driving style to the driving circum-

this way is imminent, the symbol lights

stances.

up and a signal sounds.

The indicator light lights up: DSC has malfunc-

tioned.

Have the system checked by a dealer’s service

center or another qualified service center or re-

pair shop.

DSC, refer to page 134.

93

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Displays

DSC Dynamic Stability Control is deactivated

Have the system checked by a dealer’s service

or DTC Dynamic Traction Control is activated

center or another qualified service center or re-

pair shop.

DSC is deactivated or DTC is activated.

DSC, refer to page 134, and DTC, refer

Emissions

to page 135.

▷ The warning light lights up:

Flat Tire Monitor FTM

Emissions are deteriorating. Have

the vehicle checked as soon as pos-

The Flat Tire Monitor signals a loss of

sible.

tire inflation pressure in a tire.

▷ The warning light flashes under certain cir-

Reduce your speed and stop cautiously.

cumstances:

Avoid sudden braking and steering maneuvers.

This indicates that there is excessive misfir-

Flat Tire Monitor, refer to page 123.

ing in the engine.

Reduce the vehicle speed and have the sys-

Tire Pressure Monitor TPM

tem checked immediately; otherwise, seri-

The indicator light lights up: the Tire

ous engine misfiring within a brief period

Pressure Monitor reports a low tire in-

can seriously damage emission control

flation pressure or a flat tire. Follow the

components, in particular the catalytic con-

information in the Check Control message.

verter.

The indicator light flashes and then continu-

Socket for Onboard Diagnosis, refer to

ously lights up: no flat tire or loss of tire infla-

page 232.

tion pressure can be detected.

▷ Interference caused by systems or devices

Rear fog light

with the same radio frequency: after leav-

Rear fog light is switched on.

ing the area of the interference, the system

automatically becomes active again.

Rear fog light, refer to page 112.

▷ TPM was unable to complete the reset. Re-

set the system again.

Green lights

▷ A wheel without TPM electronics is

Turn signal

mounted: have it checked by a dealer’s

service center or another qualified service

Turn signal switched on.

center or repair shop as needed.

Unusually rapid flashing of the indicator

▷ Malfunction: have the system checked by a

light indicates that a turn signal bulb

dealer’s service center or another qualified

has failed.

service center or repair shop.

Turn signal, refer to page 74.

Tire Pressure Monitor, refer to page 118.

Parking lights, headlight

Steering system

Parking lights or headlights are

Steering system in some cases not

switched on.

working.

Parking lights/low beams, headlight

control, refer to page 109.

94

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Displays

CONTROLS

Front fog lights

The messages can be hidden for approx. 8 sec-

onds. After this time, they are displayed again

Front fog lights are switched on.

automatically.

Front fog lights, refer to page 112.

Temporary display

High-beam Assistant

Some Check Control messages are hidden auto-

matically after approx. 20 seconds. The Check

High-beam Assistant is switched on.

Control messages are stored and can be dis-

High beams are switched on and off au-

played again later.

tomatically depending on the traffic sit-

uation.

Displaying stored Check Control

High-beam Assistant, refer to page 111.

messages

Via the Central Information Display (CID):

Cruise control

1.

"Vehicle info"

The system is switched on. It maintains

2. "Vehicle status"

the speed that was set using the control

3.

"Check Control"

elements on the steering wheel.

4. Select the SMS text message.

Blue lights

Display

High beams

Check Control

High beams are switched on.

At least one Check Control message is

High beams, refer to page 75.

displayed or is stored.

Hiding Check Control messages

SMS text messages

SMS text messages in combination with a sym-

bol in the instrument cluster explain a Check

Control message and the meaning of the indi-

cator/warning lights.

Supplementary SMS text messages

Additional information, such as on the cause of

an error or the required action, can be called up

via Check Control.

Press and hold button on signal lever.

With urgent messages the added text will be

automatically displayed on the Control Display.

Continuous display

Symbols

Some Check Control messages are displayed

Within the supplementary text, the following

continuously and are not cleared until the mal-

functions can be selected independent of the

function is eliminated. If several malfunctions

check control message.

occur at once, the messages are displayed con-

secutively.

95

Content      ..     3      4      5      6     ..
