Resetting a driver profile

The driver profile marked with this sym-

bol can be overwritten.

The settings of the driver profile currently in use

are reset to their factory settings.

4. "Import driver profile (USB)"

Via the Central Information Display (CID):

Select USB storage device as needed.

5. Select the driver profile to be imported.

"My MINI"

2. "Driver profiles"

Displaying driver profiles during start

3. Select driver profile.

The driver profiles can be displayed during each

The driver profile marked with this sym-

start to select the desired profile.

bol can be reset.

Via the Central Information Display (CID):

4. "Reset driver profile"

"My MINI"

5. "OK"

2. "Driver profiles"

Exporting driver profiles

3. "Show driver profiles at startup"

Most settings of the active driver profile can be

exported.

System limits

A clear assignment between the remote control

Exporting is helpful when storing and retrieving

and driver may not be possible in the following

personal settings, for instance before delivering

cases, for example.

the vehicle to a workshop. The stored driver

profiles can be taken into another vehicle.

▷ The passenger unlocks the vehicle with his

or her own remote control, but another

Via the Central Information Display (CID):

person is driving.

"My MINI"

▷ The driver unlocks the vehicle via Comfort

2. "Driver profiles"

Access and has multiple remote controls

3. Select driver profile.

with him or her.

The driver profile marked with this sym-

▷ The driver changes, but the vehicle is not

bol can be exported.

locked and unlocked.

4. "Export driver profile (USB)"

▷ Multiple remote controls are located out-

side of the vehicle.

Select USB storage device as needed.

Importing driver profiles

Settings

Profiles stored on a USB storage device can be

imported via the USB interface.

General information

The existing settings of the active driver profile

Depending on your vehicle's equipment and

are overwritten with the settings of the im-

the country version, various settings for open-

ported driver profile.

ing and closing are possible.

Via the Central Information Display (CID):

These settings are stored for the driver profile,

"My MINI"

refer to page 59, currently used.

2. "Driver profiles"

3. Select the driver profile to overwrite.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Opening and closing

Unlocking

The setting can be made for the driver

profile marked with this symbol.

Doors

4. "Last seat position automatic"

Via the Central Information Display (CID):

When the vehicle is unlocked, the driver's seat

and exterior mirrors resume their last set posi-

"My MINI"

tions.

2. "Vehicle settings"

The most recent position is independent of the

3. "Doors/Key"

positions saved via the seat memory.

4. "Driver's door" or "All doors"

5. Select desired setting:

Automatic locking

▷ "Driver's door only"

Via the Central Information Display (CID):

Only the driver's door and the fuel filler

"My MINI"

flap are unlocked. Pressing again un-

2. "Vehicle settings"

locks the entire vehicle.

3. "Doors/Key"

▷ "All doors"

4. Select desired setting:

The entire vehicle is unlocked.

▷ "Lock automatically"

Split doors

The vehicle locks automatically after a

short period of time if no door is

Via the Central Information Display (CID):

opened after unlocking.

"My MINI"

▷ "Lock after starting to drive"

2. "Vehicle settings"

The vehicle locks automatically after

3. "Doors/Key"

you drive off.

4. Select desired setting:

Automatic unlocking

▷ "Tailgate"

Via the Central Information Display (CID):

Only the split doors are opened.

▷ "Tailgate and door(s)"

"My MINI"

The split doors are opened and the

2. "Vehicle settings"

doors unlocked.

3. "Doors/Key"

Depending on optional features and country

4. "Unlock at end of trip"

version, this setting is not offered in some

After the engine is switched off by pressing

cases.

the Start/Stop button, the locked vehicle is

automatically unlocked.

Adjusting the last seat and mirror

position

Confirmation signals from the vehicle

Via the Central Information Display (CID):

"My MINI"

2. "Driver profiles"

2. "Vehicle settings"

3. Select driver profile.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening and closing

CONTROLS

3. "Doors/Key"

Overview

4. Deactivate or activate the desired confir-

mation signals.

▷ "Flash for lock/unlock"

Unlocking is signaled by two flashes,

locking by one.

▷ With alarm system:

"Acoustic signal for lock/unlock"

Unlocking is signaled by one honk of

the horn.

Indicator light in the roof fin.

Alarm system

General information

When the vehicle is locked, the vehicle alarm

system reacts to the following changes:

▷ Unauthorized opening of a door, the hood

or the split doors.

▷ Movements in the car's interior.

Indicator light on the interior mirror.

▷ Changes in the vehicle tilt, e. g., during at-

tempts at stealing a wheel or when towing

Switching on/off

the vehicle.

When you unlock and lock the vehicle, either

▷ Disconnected battery voltage.

with the remote control or with Comfort Access,

▷ Improper use of the socket for Onboard Di-

the alarm system is switched off and on at the

agnosis.

same time.

The alarm system signals these changes visually

and acoustically:

Opening the doors with the alarm

system switched on

▷ Acoustic alarm.

The alarm system is triggered when a door is

Depending on local regulations, the acous-

opened if the door was unlocked using the

tic alarm may be suppressed.

integrated key in the door lock.

▷ By switching on the hazard warning system.

Switching off the alarm, refer to page 64.

▷ By flashing the daytime running lights.

Opening the split doors with the alarm

system switched on

The split doors can be opened even when the

alarm system is switched on.

After the split doors are closed, they are locked

and monitored again when the doors are

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Opening and closing

locked. The hazard warning system flashes

Interior motion sensor

once.

The windows and the glass sunroof must be

closed for the system to function properly.

Panic mode

You can trigger the alarm system if you find

Avoiding unintentional alarms

yourself in a dangerous situation.

General information

▷ Press button on the remote control

and hold for at least 3 seconds.

The tilt alarm sensor and interior motion sensor

can trigger an alarm, although no unauthorized

▷ Briefly press the button on the remote con-

action occurred.

trol three times in succession.

Possible situations for an unwanted alarm:

To switch off the alarm: press any button.

▷ In automatic vehicle washes.

▷ In duplex garages.

Signals of the indicator lights

▷ During transport on trains carrying vehicles,

▷

The indicator light flashes briefly every

at sea or on a trailer.

2 seconds:

▷ With animals in the vehicle.

The alarm system is switched on.

▷ At the gas station: if the vehicle is locked af-

▷

Indicator light flashes for approx. 10 sec-

ter refueling starts.

onds, then it flashes briefly every 2 sec-

onds:

The tilt alarm sensor and the interior motion

sensor can be switched off in such situations.

Interior motion sensor and tilt alarm sensor

are not active, as doors, hood, or split doors

Switching off the tilt alarm sensor and

are not correctly closed. Correctly closed

interior motion sensor

access points are secured.

When the still open access points are

Press the remote control button again

closed, interior motion sensor and tilt alarm

within 10 seconds as soon as the vehi-

sensor will be switched on.

cle is locked.

▷

The indicator light goes out after unlocking:

The indicator light lights up for approx. 2 sec-

onds and then continues to flash.

The vehicle has not been tampered with.

The tilt alarm sensor and interior motion sensor

▷

The indicator light flashes after unlocking

are switched off until the vehicle is locked

until the engine ignition is switched on, but

again.

no longer than approx. 5 minutes:

An alarm has been triggered.

Switching off the alarm

Tilt alarm sensor

▷ Unlock the vehicle with the remote control

or switch on the ignition, if needed through

The tilt of the vehicle is monitored.

emergency detection of remote control, re-

The alarm system responds in situations such as

fer to page 53.

attempts to steal a wheel or when the vehicle is

▷ With Comfort Access: If you have the re-

towed.

mote control with you, unlock the vehicle

using the button on the driver's side or pas-

senger side door.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening and closing

CONTROLS

Convenient opening via the remote control, re-

Power windows
