MINI 3 door (2016 year). Manual - part 12





-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Engine oil
NOTE
3.
"Measure engine oil level"
An engine oil level that is too low causes
4. "Start measurement"
engine damage. There is a risk of property
The engine oil level is checked and displayed
damage. Immediately add engine oil.
via a scale.
Take care not to add too much engine oil.
Time: approx. 1 minute.
NOTE
Too much engine oil can damage the en-
Adding engine oil
gine or the catalytic converter. There is a risk of
property damage. Do not add too much engine
General information
oil. When too much engine oil is added, have oil
level corrected by a dealer’s service center or
Only add engine oil when the message is dis-
another qualified service center or repair
played in the instrument cluster. The quantity
shop.
to be added is indicated in the message dis-
played in the instrument cluster.
Detailed measurement
Switch off the ignition and safely park the vehi-
cle before engine oil is added.
The concept
Safety information
In the detailed measurement the engine oil
level is checked when the vehicle is stationary,
WARNING
and displayed via a scale.
Operating materials, e.g., oils, greases,
If the engine oil level reaches the minimum
coolants, fuels, can contain harmful ingredi-
level, a check control message is displayed.
ents. There is a risk of injuries or danger to life.
During the measurement, the idle speed is in-
Observe the instructions on the containers.
creased somewhat.
Avoid the contact of articles of clothing, skin or
eyes with operating materials. Do not refill op-
erating materials into different bottles. Store
Requirements
operating materials out of reach of children.
Vehicle is parked in a horizontal position.
Manual transmission: shift lever in neutral
NOTE
position, clutch and accelerator pedals not
An engine oil level that is too low causes
depressed.
engine damage. There is a risk of property
Steptronic transmission: selector lever in se-
damage.
lector lever position N or P and accelerator
Add engine oil within the next
pedal not depressed.
125 miles/200 km.
Engine is running and is at operating tem-
NOTE
perature.
Too much engine oil can damage the en-
Performing a detailed measurement
gine or the catalytic converter. There is a risk of
property damage. Do not add too much engine
On the Control Display:
oil. When too much engine oil is added, have oil
1.
"Vehicle info"
level corrected by a dealer’s service center or
2. "Vehicle status"
another qualified service center or repair
shop.
208

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Engine oil
MOBILITY
Overview
Suitable engine oil types
The oil filler neck is located in the engine com-
Add engine oils that meet the following oil rat-
partment, refer to page 205.
ing standards:
Gasoline engine
Opening the oil filler neck
BMW Longlife-01 FE.
1. Open the hood, refer to page 205.
2. Turn the oil filler neck counter-clockwise,
More information about suitable engine oil rat-
arrow.
ings and viscosities of engine oils can be re-
quested from a dealer’s service center or an-
other qualified service center or repair shop.
Alternative engine oil types
If an engine oil suitable for continuous use is
not available, up to 1 US quart/liter of an en-
gine oil with the following oil rating can be
added:
Gasoline engine
3. Add engine oil.
BMW Longlife-01.
After refilling, perform a detailed measure-
ment, refer to page 208.
API SL or superior oil rating.
Viscosity grades
Engine oil types to add
Gasoline engine:
When selecting an engine oil, make sure that
General information
the engine oil has the viscosity grade SAE
The engine oil quality is critical for the life of the
0W-20. Alternatively, also engine oils with vis-
engine.
cosity grades SAE 0W-30, SAE 5W-20, SAE
5W-30, SAE 0W-40 or SAE 5W-40 can be used.
Safety information
More information about suitable engine oil rat-
NOTE
ings and viscosities of engine oils can be re-
Oil additives can damage the engine.
quested from a dealer’s service center or an-
There is a risk of property damage. Do not use
other qualified service center or repair shop.
oil additives.
NOTE
Engine oil change
Incorrect engine oil can cause malfunc-
tions in the engine or damage it. There is a risk
NOTE
of property damage. When selecting an engine
Engine oil that is not changed in timely
oil, make sure that the engine oil has the cor-
fashion can cause increased engine wear and
rect oil rating.
thus engine damage. There is a risk of property
damage. Do not exceed the service data indi-
cated in the vehicle.
209

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Engine oil
The vehicle manufacturer recommends that
you have a dealer’s service center or another
qualified service center or repair shop change
the engine oil.
210

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Coolant
MOBILITY
Coolant
Vehicle features and op-
Coolant level
tions
Overview
This chapter describes all standard, country-
Open the hood, refer to page 205.
specific and optional features offered with the
The coolant reservoir is in the engine compart-
series. It also describes features that are not
ment, refer to page 205.
necessarily available in your vehicle, e. g., due
to the selected options or country versions. This
Checking
also applies to safety-related functions and sys-
tems. When using these functions and systems,
There are yellow Min and Max marks in the
the applicable country provisions must be ob-
coolant reservoir.
served.
1. Let the engine cool.
2. Turn the lid of the coolant reservoir slightly
counterclockwise to allow any excess pres-
General information
sure to dissipate, then open it.
Coolant consists of water and additives.
Not all commercially available additives are
suitable for the vehicle. Information about suit-
able additives is available from a dealer’s serv-
ice center or another qualified service center or
repair shop.
Safety information
3. The coolant level is correct if it lies between
WARNING
the minimum and maximum marks in the
With the engine hot and the cooling sys-
filler neck.
tem open, coolant can escape and lead to
scalding. There is a risk of injury. Only open the
cooling system with the engine cooled down.
WARNING
Additives are harmful and incorrect addi-
tives can damage the engine. There is a risk of
injury and risk of property damage. Do not al-
low additives to come into contact with skin,
eyes or articles of clothing. Use suitable addi-
tives only.
211

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Coolant
Adding
1. Let the engine cool.
2. Turn the lid of the coolant reservoir slightly
counterclockwise to allow any excess pres-
sure to dissipate, then open it.
3. If the coolant is low, slowly add coolant up
to the specified level; do not overfill.
4. Close cap.
5. Have the cause of the coolant loss elimi-
nated as soon as possible.
Disposal
Comply with the relevant environmen-
tal protection regulations when dispos-
ing of coolant and coolant additives.
212

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
MOBILITY
Maintenance
Information on service requirements, refer to
Vehicle features and op-
page 85, can be displayed on the Control Dis-
tions
play.
This chapter describes all standard, country-
Service data in the remote control
specific and optional features offered with the
series. It also describes features that are not
Information on the required maintenance is
necessarily available in your vehicle, e. g., due
continuously stored in the remote control. The
to the selected options or country versions. This
dealer’s service center can read this data out
also applies to safety-related functions and sys-
and suggest an optimized maintenance scope
tems. When using these functions and systems,
for the vehicle.
the applicable country provisions must be ob-
Therefore, hand the service advisor the remote
served.
control with which the vehicle was driven most
recently.
MINI maintenance system
Storage periods
Storage periods during which the vehicle bat-
The maintenance system indicates required
tery was disconnected are not taken into ac-
maintenance measures, and thereby provides
count.
support in maintaining road safety and the op-
erational reliability of the vehicle.
If this occurs, have a dealer's service center or
another qualified service center or repair shop
In some cases scopes and intervals may vary
update the time-dependent maintenance pro-
according to the country-specific version. Re-
cedures, such as checking brake fluid and, if
placement work, spare parts, fuels and lubri-
necessary, changing the engine oil and the mi-
cants and wear materials are calculated sepa-
crofilter/activated-charcoal filter.
rately. Further information is available from a
dealer’s service center or another qualified
service center or repair shop.
Service and Warranty In-
formation Booklet for
Condition Based Service
US models and Warranty
CBS
and Service Guide Book-
Sensors and special algorithms take into ac-
let for Canadian models
count the driving conditions of the vehicle.
Based on this, Condition Based Service recog-
Please consult your Service and Warranty Infor-
nizes the maintenance requirements.
mation Booklet for US models and Warranty
and Service Guide Booklet for Canadian models
The system makes it possible to adapt the
for additional information on service require-
amount of maintenance corresponding to your
ments.
user profile.
The manufacturer of your vehicle recommends
that maintenance and repair be performed by a
dealer’s service center or another qualified
213

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Maintenance
service center or repair shop. Records of regu-
Emissions
lar maintenance and repair work should be re-
The warning lamp lights up:
tained.
Emissions are deteriorating. Have
the vehicle checked as soon as pos-
sible.
Socket for OBD Onboard
The warning lamp flashes under certain cir-
Diagnosis
cumstances:
This indicates that there is excessive misfir-
Safety information
ing in the engine.
NOTE
Reduce the vehicle speed and have the sys-
The socket for Onboard Diagnosis is an
tem checked immediately; otherwise, seri-
intricate component intended to be used in
ous engine misfiring within a brief period
conjunction with specialized equipment to
can seriously damage emission control
check the vehicle’s primary emissions system.
components, in particular the catalytic con-
Improper use of the socket for Onboard Diag-
verter.
nosis, or contact with the socket for Onboard
Diagnosis for other than its intended purpose,
can cause vehicle malfunctions and creates
risks of personal and property damage. Given
the foregoing, the manufacture of your vehicle
strongly recommends that access to the socket
for Onboard Diagnosis be limited to a dealer's
service center or another qualified service cen-
ter or repair shop or other persons that have
the specialized training and equipment for pur-
poses of properly utilizing the socket for On-
board Diagnosis.
Position
There is an OBD socket on the driver's side for
checking the primary components in the vehi-
cle's emissions.
214

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
Replacing components
NOTE
Vehicle features and op-
Folded-away wipers can be jammed
tions
when the hood is opened. There is a risk of
This chapter describes all standard, country-
property damage. Make sure that the wipers
specific and optional features offered with the
with the wiper blades mounted are folded
series. It also describes features that are not
down onto the windshield before opening the
necessarily available in your vehicle, e. g., due
hood.
to the selected options or country versions. This
also applies to safety-related functions and sys-
Replacing the front wiper blades
tems. When using these functions and systems,
1. To change the wiper blades, fold up, refer
the applicable country provisions must be ob-
to page 72, the wiper arms.
served.
2. Fold up and hold the wiper arm firmly.
3. Open the wiper blade lock, arrow.
Onboard vehicle tool kit
4. Pull the wiper blade down first out of the
holder on the wiper arm, arrow 1.
The onboard vehicle tool kit is located in the
trough under the trunk floor.
Then pull the wiper blade free from the
holder of the wiper arm, arrow 2.
Wiper blade replacement
Safety information
NOTE
If the wiper arm falls onto the windshield
without the wiper blades installed, the wind-
shield can be damaged. There is a risk of prop-
erty damage. Secure the wiper arm when re-
5. Insert and latch a new wiper blade in re-
placing the wiper blades and do not fold down
verse order.
the wipers without the wiper blades installed.
6. Fold down the wipers.
215

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
Replace rear wiper blade
ventional lasers and are officially designated as
Class 1 light-emitting diodes.
1. Fold up and hold the wiper arm firmly.
Observe the safety information, refer to
2. Turn the wiper blade all the way back.
page 216.
Headlight glass
Condensation can form on the inside of the ex-
ternal lights in cool or humid weather. When
driving with the lights switched on, the conden-
sation evaporates after a short time. The head-
light glass does not need to be changed.
If despite driving with the lights switched on,
increasing humidity forms, e. g. water droplets
3. Continue turning the wiper blade all the
in the lamp, the manufacturer of your vehicle
way so that it pops out of the holder.
recommends having it checked by a dealer’s
4. Press the new wiper blade into the holder
service center or another qualified service cen-
until you hear it snap into place.
ter or repair shop.
5. Fold the wipers in.
Headlight setting
The headlight adjustments can be affected by
Lamp and bulb replace-
changing lights and bulbs. After the headlight
adjustment was changed, have it checked and,
ment
if necessary, corrected by a dealer’s service
center or another qualified service center or re-
General information
pair shop.
Lights and bulbs
Safety information
Lights and bulbs make an essential contribution
to vehicle safety.
Lights and bulbs
The manufacturer of the vehicle recommends
WARNING
that you have appropriate work performed by a
Bulbs can get hot during operation. Con-
dealer’s service center or another qualified
tact with the bulbs can cause burns. There is a
service center or repair shop if you are unfami-
risk of injury. Only change bulbs after they have
liar with it or if it has not been described here.
cooled off.
A spare lamp box is available from a dealer’s
service center or another qualified service cen-
WARNING
ter or repair shop.
Work on switched-on lighting systems
Observe the safety information, refer to
can cause short circuits. There is a risk of injury
page 216.
or risk of property damage. When working on
the lighting system, switch off the lamps in
Light-emitting diodes (LEDs)
question. If necessary, heed the bulb manufac-
Some items of equipment use light-emitting di-
turer's instructions.
odes installed behind a cover as a light source.
These light-emitting diodes are related to con-
216

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
NOTE
LED headlights
Dirty bulbs have a reduced service life.
There is a risk of property damage. Do not hold
new bulbs with your bare hands. Use a clean
cloth or something similar, or hold the bulb by
its base.
Light-emitting diodes (LEDs)
WARNING
Too intensive brightness can irritate or
1
Daytime running lights
damage the retina of the eye. There is a risk of
injury. Do not look directly into the headlights
2
Low beams/high beams
or other light sources. Do not remove the LED
3
Turn signal
covers.
Bug light
Front lights, bulb replacement
Overview
Halogen headlights
1
Parking lights
2
Daytime running lights
3
Fog lights
1
Low beams/high beams
LED bug light
2
Turn signal
1
Parking lights
2
Fog lights
217

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
LED low beams/LED high beams
Turn signal
Follow the general instructions on lights and
Follow the general instructions on lights and
bulbs, refer to page 216.
bulbs, refer to page 216.
The lights feature LED technology. In the case
Bulbs: PW24W
of a malfunction, contact a dealer’s service cen-
With white turn signal lights: PWY24W
ter or another qualified service center or repair
shop.
1. Turn the steering wheel.
2. Turn the lid counterclockwise, arrow 1, and
Halogen low beams/halogen high
remove.
beams
Follow the general instructions on lights and
bulbs, refer to page 216.
Bulbs: H4
1. Open the hood, refer to page 206.
2. Turn the lid counterclockwise, arrow, and
remove.
3. Unscrew the inner lid counterclockwise,
and remove it.
3. Pull off the connector.
4. Unclip spring clip, arrow, and fold down.
4. Pull bulb holder out of the bulb housing; if
needed, loosen it with small tilting move-
ments if possible.
5. Remove the bulb from the headlight hous-
ing.
6. Insert the new bulb and install the cover in
the reverse order.
218

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
5. Pull the bulb out of the fixture.
Daytime running lights: press together
the upper and lower locking of the bulb
6. Insert the new bulb and install the cover in
holder, arrow 2, and remove the bulb
the reverse order.
holder.
LED parking lights/LED fog lights
For better accessibility, remove the bulb
of the fog lamp as needed.
Follow the general instructions on lights and
bulbs, refer to page 216.
Fog lamps: turn the bulb holder, ar-
row 3, counter-clockwise and remove.
The lights feature LED technology. In the case
of a malfunction, contact a dealer’s service cen-
ter or another qualified service center or repair
shop.
Parking lights/fog lights/daytime
running lights
Follow the general instructions on lights and
bulbs, refer to page 216.
Bulbs:
5.
Pull the bulb out of the fixture.
Parking lights for halogen headlights: W5W
6.
Insert the new bulb and install the cover in
Parking lights for LED headlights:
the reverse order.
W5W NBV.
The daytime running lights bulb holder en-
Daytime running light: PSX24W.
gages audibly, first below, then above.
Fog lamp: H8.
Tail lamps, bulb replacement
Replacing the bulbs
1. Turn the steering wheel.
Overview
2. Turn the lid counterclockwise, arrow 2, and
remove.
Vehicles with a rear fog lamp
3. Pull off the connector.
1
Side tail lamps
4. Remove the bulb holder.
2
Rear fog lamp
Parking lights: turn the bulb holder, ar-
3
License plate lamp
row 1, counter-clockwise and remove.
4
Center brake lamp
219

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
Vehicle with two rear fog lights
3
Brake light
4
Reversing lights
Side tail lamps
Follow the general instructions on lights and
bulbs, refer to page 216.
Bulbs: P21W
1. Open tailgate, refer to page 40.
2. Remove left or right cover.
1
Side tail lamps
2
Rear fog lights
3
License plate lamp
4
Center brake lamp
Side tail lamps
3. Through the opening, loosen the plug con-
nector, arrow 2 on the bulb holder.
Press the latches together, arrows 1, and
remove the bulb holder.
1
Brake lights/tail lamps
2
Turn signal
3
Reversing lights
Side LED tail lights
4. Remove the bulb holder from the opening.
5. Press the nonworking bulb gently into the
socket, turn counterclockwise and remove.
Arrow 1: brake lights/tail lamps.
Arrow 2: turn signal.
1
Tail lamps
2
Turn signal
220

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
Arrow 3: reversing light.
3. Turn the bulb socket counterclockwise and
remove.
The wire is long enough to guide the socket
down and through between any heat shield
that may be installed and the bumper.
6. Proceed in the reverse order to insert the
new bulb and attach the bulb holder. Make
sure that the bulb holder engages in all fas-
teners.
4. Replace nonworking bulb.
Central brake lamp and license plate
5. To install the new bulb, proceed in reverse
lamp
order of removal.
Follow the general instructions on lights and
bulbs, refer to page 216.
Vehicle with two rear fog lights
The lights feature LED technology. In the case
Follow the general instructions on lights and
of a malfunction, contact a dealer’s service cen-
bulbs, refer to page 216.
ter or another qualified service center or repair
Bulbs: W16W
shop.
Left rear fog lamp:
Vehicles with a rear fog lamp
1. On vehicles with heat shield:
Follow the general instructions on lights and
Loosen 3 screws, arrow.
bulbs, refer to page 216.
Bulbs: W16W
1. On vehicles with heat shield:
Loosen 3 screws, arrow.
2. Push the heat shield forward and the
bumper back in order to be able to reach
the fog lamp.
3. Turn the bulb socket counterclockwise and
remove.
2. Push the heat shield forward and the
bumper back in order to be able to reach
the fog lamp.
221

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
The wire is long enough to guide the socket
With white lens: WY5W.
down and through between any heat shield
1. Open the hood. The covers of the side turn
that may be installed and the bumper.
signal lights are on the left and right next to
the hinges of the hood.
4. Replace nonworking bulb.
5. To install the new bulb, proceed in reverse
2. Loosen nuts of the cover by hand and re-
order of removal.
move the cover.
Right fog lamp:
1. Turn the bulb socket counterclockwise and
remove.
The wire is long enough to guide the socket
down and through between any heat shield
that may be installed and the bumper.
3. Turn the bulb holder counterclockwise and
remove.
2. Replace nonworking bulb.
3. To install the new bulb, proceed in reverse
order of removal.
Side turn signal, bulb replacement
4. Replace the bulb.
Follow the general instructions on lights and
5. To insert the new bulb, proceed in reverse
bulbs, refer to page 216.
order of removal. Insert the nuts of the
Bulbs:
cover and press down.
With orange lens: W5W.
222

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
If the vehicle is not used for more than a
Vehicle battery
month.
Maintenance
Steptronic transmission: when parked for
long periods of time in selector lever posi-
The battery is maintenance-free.
tion D, R or N.
The added amount of acid is sufficient for the
service life of the battery.
Safety information
More information about the battery can be re-
NOTE
quested from a dealer’s service center or an-
Battery chargers for the vehicle battery
other qualified service center or repair shop.
can work with high voltages and currents,
which means that the 12 volt on-board net-
Battery replacement
work can be overloaded or damaged. There is a
NOTE
risk of property damage. Only connect battery
Vehicle batteries that are not compatible
chargers for the vehicle battery to the starting
can damage vehicle systems and impair vehicle
aid terminals in the engine compartment.
functions. There is a risk of personal and prop-
erty damage. Only vehicle batteries that are
Starting aid terminals
compatible with your vehicle type should be in-
In the vehicle, only charge the battery via the
stalled in your vehicle. Information on compati-
starting aid terminals, refer to page 226, in the
ble vehicle batteries is available at your dealer’s
engine compartment with the engine off.
service center.
After a battery replacement, the manufacturer
Power failure
of your vehicle recommends that the vehicle
After a power loss, some equipment needs to
battery be registered on the vehicle by a deal-
be newly initialized or individual settings up-
er’s service center or another qualified service
dated, for example:
center or repair shop to ensure that all comfort
Time: update.
features are fully available and that any Check
Control messages of these comfort features are
Date: update.
no longer displayed.
Glass sunroof: initialize the system.
Charging the battery
Disposing of old batteries
Have old batteries disposed of by a
General information
dealer’s service center or another quali-
Make sure that the battery is always sufficiently
fied service center or repair shop or
charged to guarantee that the battery remains
take them to a collection point.
usable for its full service life.
Maintain the battery in an upright position for
A red indicator lamp is displayed when
transport and storage. Secure the battery so
the battery is discharged.
that it does not tip over during transport.
The battery may need to be charged in the fol-
lowing cases:
When making frequent short-distance
drives.
223

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
Fuses
Safety information
WARNING
Incorrect and repaired fuses can overload
electrical lines and components. There is a risk
of fire. Never attempt to repair a blown fuse.
Do not replace a nonworking fuse with a sub-
stitute of another color or amperage rating.
Replacing a fuse
The fuses are located in the passenger floor
area under the dashboard.
Plastic tweezers and information on the fuse
types and locations are stored in the fuse box.
1. To open, loosen screws, arrow 1.
2. Fold down the fuse holder, arrow 2.
3. Replace the fuse in question.
4. The installation is done in reverse order
from the removal.
224















Content      ..     10      11      12      13     ..
