Porshe 911 (997). Manual - part 324

- Preliminary work
- Removing front wheel housing liner
- Installing front wheel housing liner
- Subsequent work

Preliminary work

Preliminary work

Remove front wheel. → 440519 Removing and installing wheel - chapter on "removing"

Removing front wheel housing liner

Remove front wheel housing liner - front section

Installation Location:

Installation position of front wheel housing liner

1453

Note

The front part of the wheel housing liner can also be removed without disassembling the front wheels.

Removing wheel housing liner part B

1. Unscrew fastening screws -2, 3- and remove wheel housing liner

-B-

 .

Installing front wheel housing liner

Install front wheel housing liner - front section

Installation Location:

Installation position of front wheel housing liner

Diagnostic system: reading out fault memory and activating systems

Remove front wheel housing liner - front section

1454

Note

Push in wheel housing liner toward the outside up to contact in wing stop position.

•

Ensure that the right wheel housing liner is guided through the opening on the wheel well.

•

Fasten wheel housing liner part B

1. Insert wheel housing liner -B- .

2. Screw in fastening screws -2- and tighten → Final tightening: 2 (1.5) Nm (ftlb.) .

3. Screw in fastening screws -3- and tighten → Final tightening: 2.8 (1.8) Nm (ftlb.) .

Installing front wheel housing liner - rear section

Installation Location:

Installation position of front wheel housing liner

Note

Diagnostic system: reading out fault memory and activating systems

Install front wheel housing liner - front section

1455

Push in wheel housing liner toward the outside up to contact in wing stop position.

•

Ensure that the right wheel housing liner is guided through the opening on the wheel well.

•

Removing front wheel housing liner - rear section

1. Insert wheel housing liner -A- .

2. Screw on fastening nuts -1- and tighten to the specified tightening torque → Final tightening: 1.5 (1.0

ftlb.) Nm

 .

3. Screw in fastening screws -2- and tighten to the specified tightening torque → Final tightening: 2 (1.5

ftlb.) Nm

 .

Subsequent work

Reworking

Fit front wheel. → 440519 Removing and installing wheel - chapter on "installing"

997621

WARNUNG

Gefahr des Verlusts der Text-Bild-Zuordnung beim Ausdruck.

Aus technischen Gründen kann derzeit nicht ausgeschlossen werden, dass trotz
einwandfreier Darstellung auf dem Bildschirm beim Ausdruck der
Zusammenhang von Text und zugehörigem Bild verloren geht.

•

Diagnostic system: reading out fault memory and activating systems

Installing front wheel housing liner - rear section

1456
