Garage door opener/HomeLink with fixed code system

Overview of button assignment for garage door opener

Note

This operation erases the standard codes set in the factory. Do not repeat this operation if additional
buttons are to be programmed.

•

Hold the two outer buttons -1 and 3- down for around 20 seconds until the LED -A- starts to flash
quickly. All programmed signals for the buttons -1 to 3- are erased.

•

Overview of button assignment for garage door opener

1. Press the required button until the LED flashes slowly. You then have around 5 minutes to complete steps

2 and 3.

Diagnostic system: reading out fault memory and activating systems

Garage door opener/HomeLink with fixed code system

4233

Teaching position for remote control

2. Hold the original remote control approx. 0 - 30 cm in front of the marked position on the vehicle.

3. Press the Send button on the original remote control until the fog lights flash three times (up to

approx. 45 seconds).

4. Repeat steps 1 to 3 to assign further

buttons.

Note

A number of attempts may be necessary at different distances between the vehicle and original remote control.
The fog lights flash once after 5 minutes. The programming operation must then be started from scratch.

Garage door opener/HomeLink with variable code system

Check operating instructions for the garage door drive (or other system) for specification of a variable code.
If the garage door opener control unit has been programmed to a variable code system, it will still have to be
synchronised with this system on completion of programming before it will work correctly.

Button assignment for garage door opener

1. Press the required button until the LED flashes slowly. You then have around 5 minutes to complete steps

2 and 3.

Teaching position for remote control

2. Hold the original remote control approx. 0 - 30 cm in front of the marked position on the vehicle.

3. Press the Send button on the original remote control until the fog lights flash three times (up to

approx. 45 seconds).

4. To synchronise the system: press the programming button on the garage door drive receiver. You then

have 30 seconds to initiate step 5.

5.

Diagnostic system: reading out fault memory and activating systems

Garage door opener/HomeLink with variable code system

4234

Press assigned button on the HomeLink twice. (You may have to press the button to be assigned a
third time on some equipment in order to complete the setting.)

6. Repeat the programming steps to assign further buttons.

Re-programming an individual button

Button assignment for garage door opener

1. Press the required button until the LED flashes slowly (approx. 20 seconds). You then have around 5

minutes to complete steps 2 and 3.

Teaching position for remote control

2. Hold the original remote control approx. 0 - 30 cm in front of the marked position on the vehicle.

3. Press the Send button on the original remote control until the fog lights flash three times (up to

approx. 45 seconds).

4. Repeat steps 1 to 3 to assign further

buttons.

Note

A number of attempts may be necessary at different distances between the vehicle and original remote control.
The fog lights flash once after 5 minutes. The programming operation must then be started from scratch.

Diagnostic system: reading out fault memory and activating systems

Re-programming an individual button

4235

Erasing programmed signals on the HomeLink

Button assignment for garage door opener

Note

This operation erases the standard codes set in the factory. Do not repeat this operation if additional buttons
are to be programmed.
Hold the two outer buttons -1 and 3- down for around 20 seconds until the LED -A- starts to flash quickly.
All programmed signals for the buttons -1 to 3- are erased.

Do this before selling the vehicle, for example.

997110, 997111, 997120, 997121, 997310, 997311, 997320, 997321, 997410, 997411, 997430, 997431,
997610, 997611, 997620, 997621

WARNUNG

Gefahr des Verlusts der Text-Bild-Zuordnung beim Ausdruck.

Aus technischen Gründen kann derzeit nicht ausgeschlossen werden, dass trotz
einwandfreier Darstellung auf dem Bildschirm beim Ausdruck der
Zusammenhang von Text und zugehörigem Bild verloren geht.

•

Wird der Fehler nicht bemerkt, besteht die Gefahr, daß Arbeiten nicht korrekt
durchgeführt werden und es dadurch zu Personen- und Sachschäden kommt.

•

→ Vergleichen Sie deshalb nach dem Druckvorgang unbedingt die Ausdrucke mit der
Bildschirmdarstellung. Korrigieren Sie die Ausdrucke im Fehlerfall so, daß der Inhalt der
Bildschirmdarstellung zutreffend wiedergegeben wird.

WARNING

Danger of losing text-figure correspondence when printing out.

Diagnostic system: reading out fault memory and activating systems

Erasing programmed signals on the HomeLink
