Diagnostic system: reading out fault memory and activating systems

Installing oil-pressure sender

533

17 15 19 Removing and installing oil filler neck - as
of MY 2005

- Preliminary work
- Removing oil filler neck
- Installing oil filler neck
- Subsequent work

Preliminary work

Preliminary work

1. Disconnect battery → 2706IN IN -Work instructions after disconnecting the

battery.

Oil filler neck on air cleaner housing

2. Remove air cleaner housing → 242419 Removing and installing air cleaner element - chapter on

"Removing". To do this, unclip the oil filler neck upwards out of the air cleaner housing -arrow- .

3. Release drive belt → 137819 Removing and installing drive belt - chapter on "removing".

Three-phase generator

4. Detach fastening screws for generator -arrows- . Unscrew the longer screw -1- by approx. three turns,

then undo the front pilot bushing by tapping lightly on the screw head (use a plastic hammer). Unscrew
screw and remove with deflection roller.

534

Fastening screws for securing vacuum modulator to intake system

5. Unscrew the fastening screws -3- for the vacuum modulator on the intake

distributor.

Lifting generator out of mount

6. Remove generator→ 272219 Removing and installing three-phase generator - chapter on

"Removing". Turn generator in a clockwise direction, tilt it in direction of travel and lift it out of
the engine over the coolant cap.

Electrical connections on generator

7. Remove electrical connections.

Removing oil filler neck

Diagnostic system: reading out fault memory and activating systems

Preliminary work

535

Removing oil filler neck

Oil filler neck

1. Unscrew two M6 x 16 Torx screws (micro-self-locking) -arrows- , remove oil filler neck -1-

from crankcase.

2. Remove "old" O-ring on support.

3. Clean crankcase bore.

Installing oil filler neck

Installing oil filler neck

Note

Replace the micro-self-locking screws and the O-ring for the filler neck.

Inserting oil filler neck

1.

Diagnostic system: reading out fault memory and activating systems

Removing oil filler neck

536
