Model MA TOW Tractor. Manual - part 24
Chapter 4: Illustrated Parts List
Jan. 1997
Section 4-1
p. 1
I.
Description
A.
INTRODUCTION
The Illustrated Parts List contained herein furnishes spare parts and replacement parts
information and provides general part and assembly information necessary for maintenance of
the Tug Manufacturing Corporation Model MA Tow Tractor.
B.
USING THE ILLUSTRATED PARTS LIST (IPL)
The Illustrated Parts List provides an illustrated break-down of components and systems which
comprise the tractor. It consists of numerous figures with corresponding parts lists. The IPL is
arranged in such a manner that each list is on a right hand page, with the corresponding
illustration on the facing left hand page.
1.
Figure and Index Number
The figure and index number indicates the figure number (found on the facing page) and
the item number which identifies each line item shown on that figure. (See illustration
below).
2.
Part Numbers and Vendor Codes
Parts are identified by part numbers assigned by Tug Manufacturing Corporation or, in the
case of fasteners etc., by industry standard identification. When applicable, vendors’ part
numbers are also included and the individual vendor for each item is identified.
Vendor codes are provided for quick, easy reference to an individual vendor. The vendor
can be identified by referring to the Vendor Codes Reference List in this section.
