Section 09 REAR SUSPENSION Subsection 03 (SC 4 SUSPENSION) AXLE SELF-LOCKING SCREW CAUTION: These self-locking screws must al- NOTE: To prevent an axle from turning when un- – Remove one self-locking screw then install a 10 mm shorter non-self-locking one in place. – Remove the opposite self-locking screw. ing screw. – If it doesn’t work, heat bolt head to melt thread- locker. REAR AXLE REMOVAL Lift rear of vehicle and support it off the ground. Remove screws on rear axle. Completely loosen track tension. A33F5HA 1 1. Completely loosen track tension Remove the following: – rear idler wheels A33F5IA 1 ON BOTH SIDES A33F5JA PULL OUT REAR AXLE REAR AXLE INSTALLATION Installation is reverse of removal procedure. REAR SHOCK ABSORBER Lift rear of vehicle and support it off the ground. NOTE: If necessary, to ease shock removal, un- Remove bolts and nuts from shock. NOTE: If necessary, remove idler wheel(s) to ease mmr2005-096 413 |
