Section 08 DRIVE SYSTEM Subsection 02 (DRIVE PULLEY) 1 A03D3EA 1. Support guide Install sliding half no. 8 then a second support A03D3FA 1 1. Support guide Remove 3 Allen screws no. 11 retaining spring Remove spring cover, spring no. 12 and spring CLEANING Fixed and Sliding Halves Parts must be at room temperature before clean- Clean pulley halves and shaft with fine steel wool Using a paper towel with pulley flange cleaner CAUTION: Avoid contact between cleaner and Remove all hardened oil deposits that have baked CAUTION: Do not use any other type of abra- Reclean mounting surfaces with paper towel and Wipe off the mounting surfaces with a clean, dry CAUTION: Mounting surfaces must be free of Bushings Clean sliding half bushing no. 14 and spring cover CAUTION: Do not use acetone to clean bush- INSPECTION Drive pulley should be inspected annually. Thrust Washer and Roller Check rollers no. 16 for roundness of external di- CAUTION: Ensure rollers are in good condition. Lever Bolt and Flanged Bushing Check the flanged bushings no. 18 for wear. Re- mmr2005-087 331 |
