Snowmobile Arctic Cat Panther 570 (2006 year). Manual - part 12

2006 Panther 570

43

Ref. Part No. Qty. Description

Ref. Part No.

Qty. Description

MAGNETO



0739-387

1 3005-636

1

Stator Assembly

2 3006-467

1

Rotor/Flywheel

3 3006-022

1

Base, Stator - Plate

4 3004-378

4

Bolt

5 3005-433

3

Bolt

6 3006-476

1

Bolt

7 3005-987

1

Washer

8 3004-362

1

Washer, Lock

9 3004-706

2

Screw

10 3005-926

1

Sensor, Ignition Timing

11 3006-531

1

Grommet, Magneto Lead Wire
