Snowmobile Arctic Cat (2004 year). Manual - part 66

5-31

Peak Voltage Tests

(600/700/900 cc Carb Models)

NOTE: The following tests should be made using

the Fluke Model 73 Multimeter (p/n 0644-191) with
Peak Voltage Reading Adapter (p/n 0644-307).

NOTE: Peak voltage test specifications are on

the Electrical Specifications (Individual) pages in
this section.

The Fluke Multimeter w/Adapter can perform the fol-
lowing tests.

A. DC Power Coil Output

B. Voltage Regulator Output

C. Primary Coil Output

D. Ignition Timing Sensor

E. Lighting Coil Output

NOTE: Peak Voltage Tests were made with con-

nectors plugged in, spark plugs removed and
grounded, and by pulling the recoil starter rope
briskly.

DC POWER COIL OUTPUT

1. Connect the red meter lead to the red/yellow wire

from the stator; then connect the black meter lead
to the yellow/red wire from the stator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

VOLTAGE REGULATOR OUTPUT

NOTE: To conduct this test, use the multimeter

set on the A.C. Volt scale.

1. Connect the red meter lead to the red wire from the

regulator; then connect the black meter lead to the
brown wire from the regulator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

PRIMARY COIL OUTPUT

1. Connect the red meter lead to the orange wire;

then connect the black meter lead to the black
wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

IGNITION TIMING SENSOR

1. Connect the red meter lead to the green/white

wire; then connect the black meter lead to the
brown/green wire (600/700 cc) or brown wire (900
cc).

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

LIGHTING COIL OUTPUT

1. Connect the red meter lead to one yellow wire;

then connect the black meter lead to the other
yellow wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

Peak Voltage Tests

550 cc Model)

NOTE: The following tests should be made using

the Fluke Model 73 Multimeter (p/n 0644-191) with
Peak Voltage Reading Adapter (p/n 0644-307).

NOTE: Peak voltage test specifications are on

the Electrical Specifications (Individual) pages in
this section.

The Fluke Multimeter w/Adapter can perform the fol-
lowing tests.

A. Charge Coil (1) Output

B. Charge Coil (2) Output

C. Lighting Coil Output

D. Primary Coil Output

E. Voltage Regulator Output

NOTE: Peak Voltage Tests were made with con-

nectors plugged in, spark plugs removed and
grounded, and by pulling the recoil starter rope
briskly.

CHARGE COIL (1) OUTPUT

1. Connect the red meter lead to the red/white wire;

then connect the black meter lead to the black/
white wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

! WARNING

Most voltages generated by the ignition system
are sufficient to interrupt pacemakers! All techni-
cians, especially those using pacemakers, must
avoid contact with all electrical connections after
the engine has been started.

! WARNING

5-32

CHARGE COIL (2) OUTPUT

1. Connect the red meter lead to the black/red wire;

then connect the black meter lead to the red/white
wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

LIGHTING COIL OUTPUT

1. Connect the red meter lead to one yellow wire;

then connect the black meter lead to the other
yellow wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

PRIMARY COIL OUTPUT

1. Connect the red meter lead to the orange wire;

then connect the black meter lead to the black
wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

VOLTAGE REGULATOR OUTPUT

NOTE: To conduct this test, use the multimeter

set on the A.C. Volt scale.

1. Connect the red meter lead to the yellow wire from

the regulator; then connect the black meter lead to
the brown wire from the regulator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

Peak Voltage Tests

(500 cc w/APV Models)

NOTE: The following tests should be made using

the Fluke Model 73 Multimeter (p/n 0644-191) with
Peak Voltage Reading Adapter (p/n 0644-307).

NOTE: Peak voltage test specifications are on

the Electrical Specifications (Individual) pages in
this section.

The Fluke Multimeter w/Adapter can perform the fol-
lowing tests.

A. DC Power Coil Output

B. Voltage Regulator Output

C. Primary Coil Output

D. Ignition Timing Sensor

E. Lighting Coil Output

NOTE: Peak Voltage Tests were made with con-

nectors plugged in, spark plugs removed and
grounded, and by pulling the recoil starter rope
briskly.

DC POWER COIL OUTPUT

1. Connect the red meter lead to the red/yellow wire

from the stator; then connect the black meter lead
to the yellow/red wire from the stator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

VOLTAGE REGULATOR OUTPUT

NOTE: To conduct this test, use the multimeter

set on the A.C. Volt scale.

1. Connect the red meter lead to the blue wire from

the regulator; then connect the black meter lead to
the brown wire from the regulator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

PRIMARY COIL OUTPUT

1. Connect the red meter lead to the orange wire;

then connect the black meter lead to the black
wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

IGNITION TIMING SENSOR

1. Connect the red meter lead to the green/white

wire; then connect the black meter lead to the
brown/green wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

LIGHTING COIL OUTPUT

1. Connect the red meter lead to one yellow wire;

then connect the black meter lead to the other
yellow wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

! WARNING

5-33

Peak Voltage Tests

(500 cc w/o APV Models)

NOTE: The following tests should be made using

the Fluke Model 73 Multimeter (p/n 0644-191) with
Peak Voltage Reading Adapter (p/n 0644-307).

NOTE: Peak voltage test specifications are on

the Electrical Specifications (Individual) pages in
this section.

The Fluke Multimeter w/Adapter can perform the fol-
lowing tests.

A. Charge Coil (1) Output

B. Charge Coil (2) Output

C. Lighting Coil Output

D. Primary Coil Output

E. Ignition Timing Sensor

F. Voltage Regulator Output

NOTE: Peak Voltage Tests were made with con-

nectors plugged in, spark plugs removed and
grounded, and by pulling the recoil starter rope
briskly.

CHARGE COIL (1) OUTPUT

1. Connect the red meter lead to the black/red wire;

then connect the black meter lead to the green/red
wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

CHARGE COIL (2) OUTPUT

1. Connect the red meter lead to the brown/white

wire; then connect the black meter lead to the
green/red wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

LIGHTING COIL OUTPUT

1. Connect the red meter lead to one yellow wire;

then connect the black meter lead to the other
yellow wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

PRIMARY COIL OUTPUT

1. Connect the red meter lead to the orange wire;

then connect the black meter lead to the black
wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

IGNITION TIMING SENSOR

1. Connect the red meter lead to the green/white

wire; then connect the black meter lead to the
brown wire.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

VOLTAGE REGULATOR OUTPUT

NOTE: To conduct this test, use the multimeter

set on the A.C. Volt scale.

1. Connect the red meter lead to the yellow wire from

the regulator; then connect the black meter lead to
the brown wire from the regulator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

Peak Voltage Tests

(EFI Models)

NOTE: The following tests should be made using

the Fluke Model 73 Multimeter (p/n 0644-191) with
Peak Voltage Reading Adapter (p/n 0644-307).

NOTE: Peak voltage test specifications are on

the Electrical Specifications (Individual) pages in
this section.

The Fluke Multimeter w/Adapter can perform the
following output tests.

A. Fuel Pump Coil

B. Injector Coil

C. Charge Coil (1)

D. Charge Coil (2)

E. Ignition Timing Sensor

F. Voltage Regulator

! WARNING

5-34

FUEL PUMP COIL

1. Test between the two orange wires in the four-

prong connector from the stator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

INJECTOR COIL

1. Test between the two blue/white leads in the

connector harness from the stator plate.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

CHARGE COIL (1)

1. Test between the green/red and black/red wires in

the triple-plug connector from the stator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

CHARGE COIL (2)

1. Test between the green/red and brown/white wires

in the triple-plug connector from the stator.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

IGNITION TIMING SENSOR

1. Test between the green/white and brown wires in

the connector from the sensor.

2. Pull the recoil starter rope briskly. Meter reading

must be within specification.

Testing Low-Oil

Light Sensor

The low-oil light sensor is a magnetic switch. Its oper-
ation is based on a magnet located around the inside
diameter of a 1/2 in. hole in a plastic float. The switch
located in the stem of the sending unit is positioned
through the hole in the float. When the float drops to
the lower part of the stem, the magnet closes the elec-
trical contacts (located in the stem) allowing the cur-
rent to pass on to the warning light.

If the sensor should fail, it must be replaced. To test
the sensor, use the following procedure.

1. Remove the sensor from the oil reservoir by

twisting and pulling upwards. Wipe excess oil
from the sensor.

2. Unplug the sensor from the wiring harness.

3. Using an ohmmeter, set the selector on the X1K

position.

4. Touch each of the meter leads to one of the two

wires coming from the sensor. With the sensor in
its normal position (float end down), the meter
should read resistance.

5. If the meter reads no resistance, check to make

sure good contact has been made with each of the
wires coming from the sensor. If the meter still
reads no resistance, replace the sensor.

6. While maintaining contact between the meter

leads and the sensor, raise the float. The meter
must read no resistance. If the meter reads
resistance, replace the sensor.

7. If the sensor tested out satisfactory but the light

doesn’t illuminate with only a small amount of oil
in the reservoir, check the bulb.

8. If the bulb is in good condition, check for voltage

at the connection where the sensor plugs into the
accessory wiring harness. Using a multimeter set
on the 50 ACV scale, start the engine and allow it
to idle. Touch the red lead of the voltmeter to the
red wire in the two-prong connector. Touch the
black lead to the black wire in the wiring harness.
At idle, the meter should read 5 to 6 volts (AC). If
no voltage is present but the lights on the
snowmobile operate normally, either check the
wiring harness for a broken wire or replace the
harness.

Content .. 64 65 66 67 ..
